KE74V-EXMDS (1983)
Toyota Corolla
(8308- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55301 - PANEL SUB-ASSY, INSTRUMENT | ||||
| 55311-1215001 |
AE70,CE7#,KE7#,TE7#..SED,V,WG BLACK,BLACK,TRIM2# |
1 | ||
| 55311-1215025 |
CE7#,KE7#..DX,GL BEIGE,BEIGE,TRIM3#,4# |
1 | ||
| 55301G - REINFORCEMENT SUB-ASSY, INSTRUMENT PANEL | ||||
| 55305-12050 |
AE70,KE7#,TE7#..SED,V |
1 | ||
| 55308 - TRAY SUB-ASSY, INSTRUMENT PANEL UNDER | ||||
| 55601-1208002 |
CE7#,KE74 MAROON,RED/MAROON,TRIM3# |
1 | ||
| 55333 - REINFORCEMENT, INSTRUMENT PANEL, NO.3 | ||||
| 55334-12020 |
KE7#..(SED,V)..(CTD,DX,STD) LH |
1 | ||
| 55333-12060 |
KE7#..(SED,V)..(CTD,DX,STD) RH |
1 | ||
| 55333 - REINFORCEMENT, INSTRUMENT PANEL, NO.3 | ||||
| 55334-12020 |
KE7#..(SED,V)..(CTD,DX,STD) LH |
1 | ||
| 55333-12060 |
KE7#..(SED,V)..(CTD,DX,STD) RH |
1 | ||
| 55342 - BRACE, INSTRUMENT PANEL, NO.2 | ||||
| 55307-12030 |
AE70,CE7#,KE7#,TE7#..SED,V,WG |
1 | ||
| 55343 - BRACE, INSTRUMENT PANEL, NO.3 | ||||
| 55308-12100 |
AE70,CE7#,KE7#,TE7#..SED,V,WG |
1 | ||
| 55401 - PANEL SUB-ASSY, INSTRUMENT CLUSTER FINISH | ||||
| 55410-1A07002 |
CE7#,KE72,74..DX,GL W/RADIO,MAROON,MAROON,TRIM3# |
1 | ||
| 55404 - SAFETY PAD SUB-ASSY, INSTRUMENT PANEL, UPPER | ||||
| 55401-1209001 |
AE70,CE7#,KE7#,TE7#..SED,V,WG BLACK,BLACK,TRIM2# |
1 | ||
| 55401-1218002 |
CE7#,KE7#..DX,GL MAROON,RED/MAROON,TRIM3# |
1 | ||
| 55414 - BEZEL, CIGAR LIGHTER HOLE | ||||
| 55477-12050 |
AE70,KE7#,TE7#..(SED,V)..(CTD,DX,GL,GT,SE) |
1 | ||
| 55415 - PANEL, INSTRUMENT CLUSTER FINISH, CENTER | ||||
| 55412-1235002 |
CE7#,KE72,74..DX,GL MAROON,RED/MAROON,TRIM3# |
1 | ||
| 55432B - PANEL, INSTRUMENT PANEL FINISH, LOWER | ||||
| 55432-1206025 |
CE7#,KE72,74..DX,GL BEIGE,BEIGE,TRIM3#,4# |
1 | ||
| 55505B - BRACKET, GLOVE COMPARTMENT DOOR LOCK MOUNTING | ||||
| 55378-12060 |
AE70,KE7#,TE7#..SED,V |
1 | ||
| 55510 - DOOR ASSY, GLOVE COMPARTMENT | ||||
| 55550-1216001 |
KE7#..(SED,V)..(CTD,DX,STD) BLACK,BLACK,TRIM2# |
1 | ||
| 55550-1219025 |
CE7#,KE7#..DX,GL BEIGE,BEIGE,TRIM3# |
1 | ||
| 55510 - DOOR ASSY, GLOVE COMPARTMENT | ||||
| 55550-1216001 |
KE7#..(SED,V)..(CTD,DX,STD) BLACK,BLACK,TRIM2# |
1 | ||
| 55550-1219025 |
CE7#,KE7#..DX,GL BEIGE,BEIGE,TRIM3# |
1 | ||
| 55510A - CUSHION(FOR GLOVE COMPARTMENT DOOR) | ||||
| 55557-16010 |
CE7#,KE7#..DX,GL |
84 | ||
| 55545 - COVER, FUSE BOX OPENING | ||||
| 55540-1201001 |
AE70,KE7#,TE7#..SED,V BLACK,BLACK,TRIM2# |
1 | ||
| 55545-1201025 |
CE7#,KE7#..DX,GL BEIGE,BEIGE,TRIM3# |
1 | ||
| 55578 - COVER, SIDE DEFROSTER OPENING, RH | ||||
| 55578-1203002 |
CE7#,KE7#..DX MAROON,RED/MAROON,TRIM3# |
1 | ||
| 55579 - COVER, SIDE DEFROSTER OPENING, LH | ||||
| 55578-1203002 |
CE7#,KE7#..DX MAROON,RED/MAROON,TRIM3# |
1 | ||
| 55584 - HOLDER, MAP | ||||
| 55584-12020 |
KE7#..CTD,DX,STD |
1 | ||
| 55650 - REGISTER ASSY, INSTRUMENT PANEL, NO.1 | ||||
| 55650-1213002 |
CE7#,KE7#..DX,GL MAROON,RED/MAROON,TRIM3# |
1 | ||
| 55650-1204001 |
AE70,CE7#,KE7#,TE7#..SED,V,WG BLACK,BLACK,TRIM2# |
1 | ||
| 55651 - REGISTER, INSTRUMENT PANEL, NO.1 | ||||
| 55670-12020 |
AE70,KE7#,TE7#..SED,V |
1 | ||
| 55660 - REGISTER ASSY, INSTRUMENT PANEL, NO.2 | ||||
| 55660-1207003 |
AE70,KE7#,TE7#..SED,V GRAY,GRAY,TRIM1# |
1 | ||
| 55660-1221002 |
CE7#,KE7#..DX,GL MAROON,RED/MAROON,TRIM3# |
1 | ||
| 55691 - BASE, INSTRUMENT PANEL NAME | ||||
| 55512-12080 |
AE70,CE7#,KE7#,TE7#..SED,V,WG |
2 | ||
| Common parts | ||||
| 90119-06022 | ||||
| 90119-06104 | ||||
| 90159-50082 | ||||
| 90159-60025 | ||||
| 90179-06019 | ||||
| 90179-06097 | ||||
| 90183-05009 | ||||
| 90183-05094 | ||||
| 90183-05103 | ||||
| 90463-05001 | ||||
| 90468-08025 | ||||
| 90541-03015 | ||||
| 91666-40616 | ||||
| 93229-54010 | ||||
| 93249-55008 | ||||
| 93385-15016 | ||||
| 93540-15016 | ||||
| 93540-55014 | ||||
| 93540-55016 | ||||
| 93560-55016 | ||||
| 93566-14512 | ||||
| 93567-55016 | ||||
