EE101-AEKDK (1991)
Toyota Corolla
(9106- )
ｱﾘ(ﾁﾙﾄｽﾃｱﾘﾝｸﾞ)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-12180 |
AE109,CE106,109,EE103,107..DX,GL;AE100,101,104,CE100,104,108,EE101,104,108..BZT,G,GT,L,LT,LX,SEG,SEL,SJ,XE |
1 | ||
| 45026 - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.2 | ||||
| 45026-12020 |
EE103..GL;EE102..4F..02S;EE102,103..(3FC,4F)..(DX,DXJ)..05S;AE10#,CE100,104,106,108,109,EE101,104,106,107,108 ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
AE104,CE100..DX,G,LX,SEL,XE;AE100,101,CE104,106,108,109,EE101,106,107,108 厚さ=1.20 |
2 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
AE104,CE100..DX,G,LX,SEL,XE;AE100,101,CE104,106,108,109,EE101,106,107,108 厚さ=1.20 |
2 | ||
| 45209 - YOKE SUB-ASSY, STEERING SLIDING | ||||
| 45209-12080 |
EE103..GL;EE102..4F..02S;AE10#,CE10#,EE101,104,106,107,108;EE102,103..(3FC,4F)..(DX,DXJ)..05S ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-12430 |
EE103..GL;EE102..4F..02S;AE10#,CE10#,EE101,104,106,107,108;EE102,103..(3FC,4F)..(DX,DXJ)..05S ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45271 - CLAMP, STEERING COLUMN, UPPER | ||||
| 45271-12070 |
AE100,104,109,CE10#,EE10#..CTD,DX,DXJ,GL,L,LT,LX,XE |
1 | ||
| 45271-12080 |
EE103..GL;EE102..4F..02S;EE102,103..(3FC,4F)..(DX,DXJ)..05S;AE10#,CE100,104,106,108,109,EE101,104,106,107,108 ｱﾘ(ﾁﾙﾄ ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45273 - BUSH, STEERING MAIN SHAFT | ||||
| 45273-16010 |
AE100,104,CE10#,EE10#..CTD,DX,GL,L,LT,LX,XE |
1 | ||
| 45280A - BRACKET ASSY, STEERING COLUMN, UPPER | ||||
| 45280-12240 |
AE100,104,CE10#,EE10#..MTM..(CTD,DX,DXJ,GL,L,LT,LX,XE) |
1 | ||
| 45280-12241 |
AE100,104,109,CE10#,EE10#..MTM..(CTD,DX,DXJ,GL,L,LT,LX,XE) |
1 | ||
| 45286 - COVER, STEERING COLUMN | ||||
| 45286-12946K0 |
AE104..4FC..SEL;AE100..5F..(LX,XE);AE100..ATM..(LX,SEL,XE);AE104,CE100,104,EE101..LX,XE TAUPE,TRIM9# |
1 | ||
| 45286-12946W3 |
AE104..4FC..SEL;AE100..5F..(LX,XE);AE100..ATM..(LX,SEL,XE);AE104,CE100,104,EE101..LX,XE DARK BLUE,TRIM8# |
1 | ||
| 45286-12946P0 |
AE104..4FC..SEL;AE100..5F..(DX,LT,LX,XE);AE100..ATM..(DX,LT,LX,SEL,XE);AE104,109,CE10#,EE10#..CTD,DX,DXJ,GL,L,LT,LX,XE SHADOW GRAY,TRIM1# |
1 | ||
| 45802 - PROTECTOR SUB-ASSY, STEERING COLUMN, NO.1 | ||||
| 45874-12060 |
AE10#,CE10#,EE10# |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AE10#,CE10#,EE10# |
2 | ||
| Common parts | ||||
| 90119-06378 | ||||
| 90119-06569 | ||||
| 90119-08560 | ||||
| 90119-10478 | ||||
| 90168-55002 | ||||
| 90179-06009 | ||||
| 90179-10016 | ||||
| 90179-10065 | ||||
| 90201-10283 | ||||
| 90206-10011 | ||||
| 91611-60820 | ||||
| 91651-60618 | ||||
| 91651-60625 | ||||
| 93315-14012 | ||||
| 93566-15514 | ||||
| 94614-10600 | ||||
(9106- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-12180 |
AE109,CE106,109,EE103,107..DX,GL;AE100,101,104,CE100,104,108,EE101,104,108..BZT,G,GT,L,LT,LX,SEG,SEL,SJ,XE |
1 | ||
| 45026 - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.2 | ||||
| 45026-12020 |
EE103..GL;EE102..4F..02S;EE102,103..(3FC,4F)..(DX,DXJ)..05S;AE10#,CE100,104,106,108,109,EE101,104,106,107,108 ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
AE104,CE100..DX,G,LX,SEL,XE;AE100,101,CE104,106,108,109,EE101,106,107,108 厚さ=1.20 |
2 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
AE104,CE100..DX,G,LX,SEL,XE;AE100,101,CE104,106,108,109,EE101,106,107,108 厚さ=1.20 |
2 | ||
| 45209 - YOKE SUB-ASSY, STEERING SLIDING | ||||
| 45209-12080 |
EE103..GL;EE102..4F..02S;AE10#,CE10#,EE101,104,106,107,108;EE102,103..(3FC,4F)..(DX,DXJ)..05S ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-12430 |
EE103..GL;EE102..4F..02S;AE10#,CE10#,EE101,104,106,107,108;EE102,103..(3FC,4F)..(DX,DXJ)..05S ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45271 - CLAMP, STEERING COLUMN, UPPER | ||||
| 45271-12070 |
AE100,104,109,CE10#,EE10#..CTD,DX,DXJ,GL,L,LT,LX,XE |
1 | ||
| 45271-12080 |
EE103..GL;EE102..4F..02S;EE102,103..(3FC,4F)..(DX,DXJ)..05S;AE10#,CE100,104,106,108,109,EE101,104,106,107,108 ｱﾘ(ﾁﾙﾄ ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45273 - BUSH, STEERING MAIN SHAFT | ||||
| 45273-16010 |
AE100,104,CE10#,EE10#..CTD,DX,GL,L,LT,LX,XE |
1 | ||
| 45280A - BRACKET ASSY, STEERING COLUMN, UPPER | ||||
| 45280-12240 |
AE100,104,CE10#,EE10#..MTM..(CTD,DX,DXJ,GL,L,LT,LX,XE) |
1 | ||
| 45280-12241 |
AE100,104,109,CE10#,EE10#..MTM..(CTD,DX,DXJ,GL,L,LT,LX,XE) |
1 | ||
| 45286 - COVER, STEERING COLUMN | ||||
| 45286-12946K0 |
AE104..4FC..SEL;AE100..5F..(LX,XE);AE100..ATM..(LX,SEL,XE);AE104,CE100,104,EE101..LX,XE TAUPE,TRIM9# |
1 | ||
| 45286-12946W3 |
AE104..4FC..SEL;AE100..5F..(LX,XE);AE100..ATM..(LX,SEL,XE);AE104,CE100,104,EE101..LX,XE DARK BLUE,TRIM8# |
1 | ||
| 45286-12946P0 |
AE104..4FC..SEL;AE100..5F..(DX,LT,LX,XE);AE100..ATM..(DX,LT,LX,SEL,XE);AE104,109,CE10#,EE10#..CTD,DX,DXJ,GL,L,LT,LX,XE SHADOW GRAY,TRIM1# |
1 | ||
| 45802 - PROTECTOR SUB-ASSY, STEERING COLUMN, NO.1 | ||||
| 45874-12060 |
AE10#,CE10#,EE10# |
1 | ||
| 45870 - TUBE ASSY, STEERING COLUMN | ||||
| 45870-12270 |
AE104..4FC..SEL;AE100..5F..(DX,LT,LX,XE);AE100..ATM..(DX,LT,LX,SEL,XE);AE104,CE10#,EE10#..CTD,DX,DXJ,GL,L,LX,XE |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AE10#,CE10#,EE10# |
2 | ||
| Common parts | ||||
| 90119-08560 | ||||
| 90119-10478 | ||||
| 90179-10016 | ||||
| 91651-60618 | ||||
| 91651-60625 | ||||
| 93315-14012 | ||||
| 93566-15514 | ||||
