AE91-AGMGH (1989)
Toyota Corolla
(8905- )5AFHE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17111 - MANIFOLD, INTAKE | ||||
| 17101-15020 |
4AF,5AF..AE91,95 |
1 | ||
| 17101-15050 |
5AFHE..AE91 |
1 | ||
| 17111A - PLUG, NO.1 | ||||
| 90345-51006 |
4AFE,5AFHE,5AFE..AE91,95 |
1 | ||
| 90344-53011 |
4AF,5AF..AE91,95 |
1 | ||
| 17118 - STAY, MANIFOLD | ||||
| 17118-15070 |
4AF#,5AF,5AFE..AE91,95 |
1 | ||
| 17118-16040 |
5AFHE..AE91 |
1 | ||
| 17119 - STAY, MANIFOLD, NO.2 | ||||
| 17139-16040 |
5AFHE..AE91 NO.2 |
1 | ||
| 17139-15020 |
5AF..AE91 |
1 | ||
| 17139-16030 |
5AFHE..AE91 NO.1 |
1 | ||
| 17119 - STAY, MANIFOLD, NO.2 | ||||
| 17139-16040 |
5AFHE..AE91 NO.2 |
1 | ||
| 17139-15020 |
5AF..AE91 |
1 | ||
| 17139-16030 |
5AFHE..AE91 NO.1 |
1 | ||
| 17129A - UNION, NO.1 | ||||
| 90345-51006 |
5AFE,5AFHE..AE91 |
1 | ||
| 17141 - MANIFOLD, EXHAUST | ||||
| 17141-15120 |
4AF#,5AF,5AFE..AE91,95 |
1 | ||
| 17141-15130 |
5AFHE..AE91 |
1 | ||
| 17141D - BOLT, STUD(FOR OXYGEN SENSOR) | ||||
| 90116-08168 |
4AGE,5AFHE..AE91,92 |
2 | ||
| 17152 - BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||||
| 90116-10146 |
5AFHE..AE91 |
3 | ||
| 90116-10058 |
4AF,5AF#..AE91,95 |
2 | ||
| 90116-10146 |
5AFHE..AE91 |
3 | ||
| 90116-10146 |
4AGE,5AFHE..AE91,92 |
3 | ||
| 90116-10146 |
4AGE,5AFHE..AE91,92 |
3 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 92112-61032 |
4AF#,5AF#..AE91,95 EXHAUST MANIFOLD |
2 | ||
| 92112-60825 |
4AFE..AE95..4FC;4AF,5AF#..AE91,95 INTAKE MANIFOLD |
2 | ||
| 92112-61028 |
4AFE,5AF#..AE91,95 EXHAUST MANIFOLD |
3 | ||
| 92112-61028 |
4AFE,5AF#..AE91,95 EXHAUST MANIFOLD |
3 | ||
| 92112-60825 |
4AFE,5AF#..AE91,95 INTAKE MANIFOLD |
2 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 92112-61032 |
4AF#,5AF#..AE91,95 EXHAUST MANIFOLD |
2 | ||
| 92112-60825 |
4AFE..AE95..4FC;4AF,5AF#..AE91,95 INTAKE MANIFOLD |
2 | ||
| 92112-61028 |
4AFE,5AF#..AE91,95 EXHAUST MANIFOLD |
3 | ||
| 92112-61028 |
4AFE,5AF#..AE91,95 EXHAUST MANIFOLD |
3 | ||
| 92112-60825 |
4AFE,5AF#..AE91,95 INTAKE MANIFOLD |
2 | ||
| 17167 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.1 | ||||
| 17167-16050 |
4AGE,5AFHE..AE91,92 |
1 | ||
| 17107-15010 |
4AF,5AF..AE91,95 |
1 | ||
| 17168 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.2 | ||||
| 17168-15010 |
4AF#,5AF,5AFE..AE91,95 |
1 | ||
| 17168-15020 |
5AFHE..AE91 |
1 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-15010 |
4AF#,5AF#..AE91,95 |
1 | ||
| 17173-15011 |
4AFE,5AF#..AE91,95 |
1 | ||
| 17173-15040 |
5AF#..AE91 |
1 | ||
| 17177 - GASKET, INTAKE MANIFOLD TO HEAD, NO.1 | ||||
| 17171-16030 |
5AFHE..AE91;4AFE..AE95..5F |
1 | ||
| 17171-15020 |
4AF,5AF..AE91,95 |
1 | ||
| 17171-15020 |
5AF,5AFE..AE91;4AFE..AE95..4FC |
1 | ||
| 17171-16031 |
5AFHE..AE91;4AFE..AE95..5F |
1 | ||
| 35138B - ADAPTER, STIFFENER PLATE | ||||
| 35138-12020 |
AE92;AE91..EFIS |
1 | ||
| Common parts | ||||
| 90116-10025 | ||||
| 90119-06380 | ||||
| 90119-08959 | ||||
| 90119-10062 | ||||
| 90119-10673 | ||||
| 90179-08153 | ||||
| 90179-10070 | ||||
| 90179-10077 | ||||
| 90339-03002 | ||||
| 91511-B0814 | ||||
| 91611-61030 | ||||
| 91621-60816 | ||||
| 91621-61020 | ||||
| 92122-40612 | ||||
| 92122-B0610 | ||||
| 92122-B0840 | ||||
(8705-8908)4AF,5AF
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16265 - HOSE, INTAKE MANIFOLD WATER | ||||
| 16265-15020 |
4AF,5AF..AE91,95 |
1 | ||
| 16265A - CLAMP OR CLIP, HOSE(FOR INTAKE MANIFOLD WATER) | ||||
| 90467-21001 |
4AF,5AF..AE91,95 |
2 | ||
| 16265A - CLAMP OR CLIP, HOSE(FOR INTAKE MANIFOLD WATER) | ||||
| 90467-21001 |
4AF,5AF..AE91,95 |
2 | ||
| 17111 - MANIFOLD, INTAKE | ||||
| 17101-15020 |
4AF,5AF..AE91,95 |
1 | ||
| 17101-15050 |
5AFHE..AE91 |
1 | ||
| 17111A - PLUG, NO.1 | ||||
| 90345-51006 |
4AFE,5AFHE,5AFE..AE91,95 |
1 | ||
| 90344-53011 |
4AF,5AF..AE91,95 |
1 | ||
| 17111B - PLUG, NO.2 | ||||
| 90344-54003 |
4AF,5AF..AE91,95 |
1 | ||
| 17118 - STAY, MANIFOLD | ||||
| 17118-15070 |
4AF#,5AF,5AFE..AE91,95 |
1 | ||
| 17118-16040 |
5AFHE..AE91 |
1 | ||
| 17119 - STAY, MANIFOLD, NO.2 | ||||
| 17139-16040 |
5AFHE..AE91 NO.2 |
1 | ||
| 17139-15020 |
5AF..AE91 |
1 | ||
| 17139-16030 |
5AFHE..AE91 NO.1 |
1 | ||
| 17141 - MANIFOLD, EXHAUST | ||||
| 17141-15120 |
4AF#,5AF,5AFE..AE91,95 |
1 | ||
| 17141-15130 |
5AFHE..AE91 |
1 | ||
| 17151 - BOLT, STUD(FOR MANIFOLD TO CARBURETOR) | ||||
| 92112-40832 |
4AF,5AF..AE91,95 |
4 | ||
| 17152 - BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||||
| 90116-10146 |
5AFHE..AE91 |
3 | ||
| 90116-10058 |
4AF,5AF#..AE91,95 |
2 | ||
| 90116-10146 |
5AFHE..AE91 |
3 | ||
| 90116-10146 |
4AGE,5AFHE..AE91,92 |
3 | ||
| 90116-10146 |
4AGE,5AFHE..AE91,92 |
3 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 92112-61032 |
4AF#,5AF#..AE91,95 EXHAUST MANIFOLD |
2 | ||
| 92112-60825 |
4AFE..AE95..4FC;4AF,5AF#..AE91,95 INTAKE MANIFOLD |
2 | ||
| 92112-61028 |
4AFE,5AF#..AE91,95 EXHAUST MANIFOLD |
3 | ||
| 92112-61028 |
4AFE,5AF#..AE91,95 EXHAUST MANIFOLD |
3 | ||
| 92112-60825 |
4AFE,5AF#..AE91,95 INTAKE MANIFOLD |
2 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 92112-61032 |
4AF#,5AF#..AE91,95 EXHAUST MANIFOLD |
2 | ||
| 92112-60825 |
4AFE..AE95..4FC;4AF,5AF#..AE91,95 INTAKE MANIFOLD |
2 | ||
| 92112-61028 |
4AFE,5AF#..AE91,95 EXHAUST MANIFOLD |
3 | ||
| 92112-61028 |
4AFE,5AF#..AE91,95 EXHAUST MANIFOLD |
3 | ||
| 92112-60825 |
4AFE,5AF#..AE91,95 INTAKE MANIFOLD |
2 | ||
| 17167 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.1 | ||||
| 17167-16050 |
4AGE,5AFHE..AE91,92 |
1 | ||
| 17107-15010 |
4AF,5AF..AE91,95 |
1 | ||
| 17168 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.2 | ||||
| 17168-15010 |
4AF#,5AF,5AFE..AE91,95 |
1 | ||
| 17168-15020 |
5AFHE..AE91 |
1 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-15010 |
4AF#,5AF#..AE91,95 |
1 | ||
| 17173-15011 |
4AFE,5AF#..AE91,95 |
1 | ||
| 17173-15040 |
5AF#..AE91 |
1 | ||
| 17177 - GASKET, INTAKE MANIFOLD TO HEAD, NO.1 | ||||
| 17171-16030 |
5AFHE..AE91;4AFE..AE95..5F |
1 | ||
| 17171-15020 |
4AF,5AF..AE91,95 |
1 | ||
| 17171-15020 |
5AF,5AFE..AE91;4AFE..AE95..4FC |
1 | ||
| 17171-16031 |
5AFHE..AE91;4AFE..AE95..5F |
1 | ||
| 25508 - CONVERTER SUB-ASSY, MANIFOLD | ||||
| 25508-15020 |
4AF,5AFE,5AF..AE91,95 |
1 | ||
| 25508A - BOLT, STUD(FOR MANIFOLD CONVERTER) | ||||
| 90116-10017 |
4AF,5AF#..AE91,95 |
2 | ||
| 25509 - INSULATOR SUB-ASSY, MANIFOLD CONVERTOR | ||||
| 25509-15020 |
4AF,5AF#..AE91,95 |
1 | ||
| 25576 - GASKET, MANIFOLD CONVERTER | ||||
| 25576-15010 |
4AF#,5AF,5AFE..AE91,95 |
1 | ||
| Common parts | ||||
| 90116-08039 | ||||
| 90116-08263 | ||||
| 90119-06380 | ||||
| 90119-10269 | ||||
| 90119-10329 | ||||
| 90119-10485 | ||||
| 90119-10673 | ||||
| 90179-08025 | ||||
| 90179-08175 | ||||
| 90179-10025 | ||||
| 90179-10070 | ||||
| 90344-53011 | ||||
| 91615-60830 | ||||
| 91621-60816 | ||||
| 91621-60818 | ||||
| 91651-60816 | ||||
| 91655-60616 | ||||
| 92112-40616 | ||||
| 92112-40820 | ||||
