AE91-AEHDU (1987)
Toyota Corolla
(8705- )DX,FXD,FXG,FXL,FXZI,G,GL,STD,TX,XE ;(8905- )CTD,FXGTV,FXV,FXVS,L,LT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-12180 |
EE90..FXD,FXL,TX,XE;CE96,97,EE97,98..DX,GL;AE9#,CE90..FXG,FXGTV,FXL,FXV,G,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45025-12170 |
EE90;AE91..(DX,FXG,FXL,G,TX)..CBR;AE91..(DX,FXG,FXL,FXV,LT,TX)..EFI;AE92,95,CE90,96,97,EE96,97,98..CTD,DX,FXGTV,GL,L,STD,TX |
1 | ||
| 45026 - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.2 | ||||
| 45026-12010 |
EE90;AE91..(DX,FXG,FXL,G,TX)..CBR;AE91..(DX,FXG,FXL,FXV,LT,TX)..EFI;AE92,95,CE90,96,97,EE96,97,98..CTD,DX,FXGTV,GL,L,STD,TX |
1 | ||
| 45026-12020 |
EE90..FXD,FXL,TX,XE;CE96,97,EE97,98..DX,GL;AE9#,CE90..FXG,FXGTV,FXL,FXV,G,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
AE9#,CE9#,EE9# 厚さ=1.20 |
2 | ||
| 90520-17196 |
AE9#,CE9#,EE9#..CTD,DX,FXD,FXG,FXGTV,FXL,FXV,FXVS,FXZI,G,GL,L,LT,STD,TX,XE 厚さ=1.35−1.45 |
2 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
AE9#,CE9#,EE9# 厚さ=1.20 |
2 | ||
| 90520-17196 |
AE9#,CE9#,EE9#..CTD,DX,FXD,FXG,FXGTV,FXL,FXV,FXVS,FXZI,G,GL,L,LT,STD,TX,XE 厚さ=1.35−1.45 |
2 | ||
| 45209 - YOKE SUB-ASSY, STEERING SLIDING | ||||
| 45209-12050 |
EE90..FXD,FXL,TX,XE;CE96,97,EE97,98..DX,GL;AE9#,CE90..FXG,FXGTV,FXL,FXV,G,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45209-32010 |
EE90;AE91..(DX,FXG,FXL,G,TX)..CBR;AE91..(DX,FXG,FXL,FXV,LT,TX)..EFI;AE92,95,CE90,96,97,EE96,97,98..CTD,DX,FXGTV,GL,L,STD,TX |
1 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-12320 |
EE90..FXD,FXL,TX,XE;CE96,97,EE97,98..DX,GL;AE9#,CE90..FXG,FXGTV,FXL,FXV,G,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45210-12400 |
AE91,EE90..TX ﾗｲﾑ & ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45210-12300 |
EE90;AE91..(DX,FXG,FXL,G,TX)..CBR;AE91..(DX,FXG,FXL,FXV,LT,TX)..EFI;AE92,95,CE90,96,97,EE96,97,98..CTD,DX,FXGTV,GL,L,STD,TX |
1 | ||
| 45271 - CLAMP, STEERING COLUMN, UPPER | ||||
| 45271-12060 |
AE91,EE90..TX ﾗｲﾑ & ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45271-12050 |
AE9#,CE9#,EE9#..CTD,DX,FXD,FXG,FXGTV,FXL,FXV,FXVS,FXZI,G,GL,L,LT,STD,TX,XE |
1 | ||
| 45273 - BUSH, STEERING MAIN SHAFT | ||||
| 45273-16010 |
AE91,95,CE9#,EE9#..DX,FXD,FXG,FXL,FXZI,G,GL,STD,TX,XE |
1 | ||
| 45273-16010 |
AE9#,CE9#,EE9# |
1 | ||
| 45273-16010 |
AE9#,CE9#,EE9# |
1 | ||
| 45280A - BRACKET ASSY, STEERING COLUMN, UPPER | ||||
| 45280-12100 |
AE91,95,CE9#,EE9#..DX,FXD,FXG,FXL,FXZI,G,GL,STD,TX,XE |
1 | ||
| 45280-12120 |
AE91,EE90..TX ﾗｲﾑ & ｱﾘ( ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45283A - PLATE, BEAM CHANGE & TURN SIGNAL CAUTION | ||||
| 45283-22010 |
AE9#,CE9#,EE9# |
1 | ||
| 45286 - COVER, STEERING COLUMN | ||||
| 45286-1294005 |
CE96,97,EE96,97,98..DX,GL;AE91,95,CE90,EE90..FXD,FXG,FXL,FXZI,TX,XE BEIGE,TRIM4# |
1 | ||
| 45286-1294205 |
AE91,EE90..TX ﾗｲﾑ,BEIGE,TRIM4# |
1 | ||
| 45286-1294003 |
AE9#,CE9#,EE9#..CTD,DX,FXD,FXG,FXGTV,FXL,FXV,FXVS,FXZI,G,GL,L,LT,STD,TX,XE SHADOW GRAY,TRIM1# |
1 | ||
| 45286-1294203 |
AE91,EE90..TX ﾗｲﾑ,SHADOW GRAY,TRIM1# |
1 | ||
| 45870 - TUBE ASSY, STEERING COLUMN | ||||
| 45870-12241 |
AE91,95,CE9#,EE9#..DX,FXD,FXG,FXL,FXZI,G,GL,STD,TX,XE |
1 | ||
| 45870-12240 |
AE91,95,CE9#,EE9#..DX,FXD,FXG,FXL,FXZI,G,GL,STD,TX,XE |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AE91,95..CBR;AE91..(FXG,FXZI,SE)..EFI;AE92,CE9#,EE9#..DX,FXD,FXGT,FXL,GL,GT,SE,STD,TX,XE |
2 | ||
| Common parts | ||||
| 90119-08560 | ||||
| 90119-10478 | ||||
| 90164-50048 | ||||
| 90179-10016 | ||||
| 91655-40625 | ||||
| 93315-14012 | ||||
(8705-9005)AE91,EE90..TX ; (8705- )FXGT,G,GT,SE ; (8905- )FXGT,FXZS ; (9101-
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-12180 |
EE90..FXD,FXL,TX,XE;CE96,97,EE97,98..DX,GL;AE9#,CE90..FXG,FXGTV,FXL,FXV,G,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45025-12170 |
EE90;AE91..(DX,FXG,FXL,G,TX)..CBR;AE91..(DX,FXG,FXL,FXV,LT,TX)..EFI;AE92,95,CE90,96,97,EE96,97,98..CTD,DX,FXGTV,GL,L,STD,TX |
1 | ||
| 45026 - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.2 | ||||
| 45026-12010 |
EE90;AE91..(DX,FXG,FXL,G,TX)..CBR;AE91..(DX,FXG,FXL,FXV,LT,TX)..EFI;AE92,95,CE90,96,97,EE96,97,98..CTD,DX,FXGTV,GL,L,STD,TX |
1 | ||
| 45026-12020 |
EE90..FXD,FXL,TX,XE;CE96,97,EE97,98..DX,GL;AE9#,CE90..FXG,FXGTV,FXL,FXV,G,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45201A - BEARING(FOR STEERING MAIN SHAFT) | ||||
| 90363-18004 |
AE9#,CE9#,EE9# |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
AE9#,CE9#,EE9# 厚さ=1.20 |
2 | ||
| 90520-17196 |
AE9#,CE9#,EE9#..CTD,DX,FXD,FXG,FXGTV,FXL,FXV,FXVS,FXZI,G,GL,L,LT,STD,TX,XE 厚さ=1.35−1.45 |
2 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
AE9#,CE9#,EE9# 厚さ=1.20 |
2 | ||
| 90520-17196 |
AE9#,CE9#,EE9#..CTD,DX,FXD,FXG,FXGTV,FXL,FXV,FXVS,FXZI,G,GL,L,LT,STD,TX,XE 厚さ=1.35−1.45 |
2 | ||
| 45201G - SPRING, COMPRESSION(FOR STEERING MAIN SHAFT) | ||||
| 90501-40017 |
AE91,EE90..TX |
1 | ||
| 45204 - TUBE ASSY, STEERING COLUMN, LOWER | ||||
| 45204-12090 |
AE91,EE90..TX |
1 | ||
| 45205J - TUBE SUB-ASSY, STEERING COLUMN, UPPER | ||||
| 45205-12251 |
AE91,EE90..TX |
1 | ||
| 45205-12250 |
AE91,EE90..TX |
1 | ||
| 45209 - YOKE SUB-ASSY, STEERING SLIDING | ||||
| 45209-12050 |
EE90..FXD,FXL,TX,XE;CE96,97,EE97,98..DX,GL;AE9#,CE90..FXG,FXGTV,FXL,FXV,G,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45209-32010 |
EE90;AE91..(DX,FXG,FXL,G,TX)..CBR;AE91..(DX,FXG,FXL,FXV,LT,TX)..EFI;AE92,95,CE90,96,97,EE96,97,98..CTD,DX,FXGTV,GL,L,STD,TX |
1 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-12320 |
EE90..FXD,FXL,TX,XE;CE96,97,EE97,98..DX,GL;AE9#,CE90..FXG,FXGTV,FXL,FXV,G,TX ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45210-12400 |
AE91,EE90..TX ﾗｲﾑ & ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45210-12300 |
EE90;AE91..(DX,FXG,FXL,G,TX)..CBR;AE91..(DX,FXG,FXL,FXV,LT,TX)..EFI;AE92,95,CE90,96,97,EE96,97,98..CTD,DX,FXGTV,GL,L,STD,TX |
1 | ||
| 45215 - COLLAR, MAIN SHAFT BEARING THRUST | ||||
| 45215-12010 |
AE91,EE90..TX |
1 | ||
| 45260 - SHAFT ASSY, STEERING INTERMEDIATE, NO.2 | ||||
| 45260-12170 |
AE91,EE90..TX ﾗｲﾑ & ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45271 - CLAMP, STEERING COLUMN, UPPER | ||||
| 45271-12060 |
AE91,EE90..TX ﾗｲﾑ & ｱﾘ(ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45271-12050 |
AE9#,CE9#,EE9#..CTD,DX,FXD,FXG,FXGTV,FXL,FXV,FXVS,FXZI,G,GL,L,LT,STD,TX,XE |
1 | ||
| 45273 - BUSH, STEERING MAIN SHAFT | ||||
| 45273-16010 |
AE9#,CE9#,EE9# |
1 | ||
| 45273-16010 |
AE9#,CE9#,EE9# |
1 | ||
| 45273-16010 |
AE91,95,CE9#,EE9#..DX,FXD,FXG,FXL,FXZI,G,GL,STD,TX,XE |
1 | ||
| 45280A - BRACKET ASSY, STEERING COLUMN, UPPER | ||||
| 45280-12100 |
AE91,95,CE9#,EE9#..DX,FXD,FXG,FXL,FXZI,G,GL,STD,TX,XE |
1 | ||
| 45280-12120 |
AE91,EE90..TX ﾗｲﾑ & ｱﾘ( ﾊﾟﾜ- ｽﾃｱﾘﾝｸﾞ) |
1 | ||
| 45283A - PLATE, BEAM CHANGE & TURN SIGNAL CAUTION | ||||
| 45283-22010 |
AE9#,CE9#,EE9# |
1 | ||
| 45286 - COVER, STEERING COLUMN | ||||
| 45286-1294005 |
CE96,97,EE96,97,98..DX,GL;AE91,95,CE90,EE90..FXD,FXG,FXL,FXZI,TX,XE BEIGE,TRIM4# |
1 | ||
| 45286-1294205 |
AE91,EE90..TX ﾗｲﾑ,BEIGE,TRIM4# |
1 | ||
| 45286-1294003 |
AE9#,CE9#,EE9#..CTD,DX,FXD,FXG,FXGTV,FXL,FXV,FXVS,FXZI,G,GL,L,LT,STD,TX,XE SHADOW GRAY,TRIM1# |
1 | ||
| 45286-1294203 |
AE91,EE90..TX ﾗｲﾑ,SHADOW GRAY,TRIM1# |
1 | ||
| 45804C - WASHER, PLATE(FOR STEERING TILT LEVER) | ||||
| 90201-10283 |
AE91,EE90..TX |
2 | ||
| 45804C - WASHER, PLATE(FOR STEERING TILT LEVER) | ||||
| 90201-10283 |
AE91,EE90..TX |
2 | ||
| 45805A - SUPPORT SUB-ASSY, TILT STEERING | ||||
| 45805-12010 |
AE91,EE90..TX |
1 | ||
| 45805B - BUSH(FOR TILT STEERING SUPPORT) | ||||
| 90386-06031 |
AE91,EE90..TX..CBR |
4 | ||
| 45805C - SPRING, COMPRESSION(FOR TILT STEERING SUPPORT) | ||||
| 90501-20072 |
AE91,EE90..TX..CBR |
2 | ||
| 45826 - LEVER, STEERING TILT | ||||
| 45826-12020 |
AE91,EE90..TX |
1 | ||
| 45826A - SPRING, TENSION(FOR STEERING TILT LEVER) | ||||
| 90507-12029 |
AE91,EE90..TX |
2 | ||
| 45826A - SPRING, TENSION(FOR STEERING TILT LEVER) | ||||
| 90507-12029 |
AE91,EE90..TX |
2 | ||
| 45827A - LEVER, STEERING TILT SUB | ||||
| 45827-12010 |
AE91,EE90..TX |
1 | ||
| 45831 - BOLT, TILT LEVER LOCK, NO.1 | ||||
| 45831-12010 |
AE91,EE90..TX |
1 | ||
| 45890A - PAWL ASSY, TILT STEERING | ||||
| 45890-12020 |
AE91,EE90..TX 左側 |
1 | ||
| 45890-12030 |
AE91,EE90..TX 右側 |
1 | ||
| 45890A - PAWL ASSY, TILT STEERING | ||||
| 45890-12020 |
AE91,EE90..TX 左側 |
1 | ||
| 45890-12030 |
AE91,EE90..TX 右側 |
1 | ||
| 45890C - COLLAR(FOR TILT STEERING PAWL) | ||||
| 90389-07008 |
AE91,EE90..TX ﾏｰｸ A |
1 | ||
| 90389-07005 |
AE91,EE90..TX ﾏｰｸ 2 |
1 | ||
| 90389-07007 |
AE91,EE90..TX ﾏｰｸ 4 |
1 | ||
| 90389-07004 |
AE91,EE90..TX ﾏｰｸ 0 |
1 | ||
| 90389-07006 |
AE91,EE90..TX ﾏｰｸ 3 |
1 | ||
| 90389-07010 |
AE91,EE90..TX ﾏｰｸ 7 |
1 | ||
| 90389-07009 |
AE91,EE90..TX ﾏｰｸ 6 |
1 | ||
| 90389-07011 |
AE91,EE90..TX ﾏｰｸ 8 |
1 | ||
| 45890C - COLLAR(FOR TILT STEERING PAWL) | ||||
| 90389-07008 |
AE91,EE90..TX ﾏｰｸ A |
1 | ||
| 90389-07005 |
AE91,EE90..TX ﾏｰｸ 2 |
1 | ||
| 90389-07007 |
AE91,EE90..TX ﾏｰｸ 4 |
1 | ||
| 90389-07004 |
AE91,EE90..TX ﾏｰｸ 0 |
1 | ||
| 90389-07006 |
AE91,EE90..TX ﾏｰｸ 3 |
1 | ||
| 90389-07010 |
AE91,EE90..TX ﾏｰｸ 7 |
1 | ||
| 90389-07009 |
AE91,EE90..TX ﾏｰｸ 6 |
1 | ||
| 90389-07011 |
AE91,EE90..TX ﾏｰｸ 8 |
1 | ||
| 45893A - STOPPER, TILT STEERING PAWL | ||||
| 45893-12020 |
AE91,EE90..TX 左側 |
1 | ||
| 45893-12070 |
AE91,EE90..TX 右側 |
1 | ||
| 45893A - STOPPER, TILT STEERING PAWL | ||||
| 45893-12020 |
AE91,EE90..TX 左側 |
1 | ||
| 45893-12070 |
AE91,EE90..TX 右側 |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AE91,95..CBR;AE91..(FXG,FXZI,SE)..EFI;AE92,CE9#,EE9#..DX,FXD,FXGT,FXL,GL,GT,SE,STD,TX,XE |
2 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AE91,95..CBR;AE91..(FXG,FXZI,SE)..EFI;AE92,CE9#,EE9#..DX,FXD,FXGT,FXL,GL,GT,SE,STD,TX,XE |
2 | ||
| Common parts | ||||
| 90119-06378 | ||||
| 90119-06569 | ||||
| 90119-08560 | ||||
| 90119-10277 | ||||
| 90164-50048 | ||||
| 90179-06045 | ||||
| 90179-10016 | ||||
| 90179-10065 | ||||
| 90206-10009 | ||||
| 91611-60820 | ||||
| 91655-40620 | ||||
| 93315-14012 | ||||
| 94614-10600 | ||||
