AE81-ELHSS (1983)
Toyota Corolla
(8305- )4D,5D2,5D3
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69207 - HANDLE SUB-ASSY, FRONT DOOR INSIDE, RH | ||||
| 69205-1207002 |
AE81..4F..DX;AE81..GL,SX,ZX;AE80,82,CE80..CTD,DX,GL,SR,SX,ZX MAROON,RED/MAROON,TRIM3# |
1 | ||
| 69205-1207002 |
AE8#,CE80..GL,SE,SR,SX,ZX MAROON,RED/MAROON,TRIM3# |
1 | ||
| 69205-1207004 |
AE8#,CE80..GL,SE,SR,SX,ZX BLUE,BLUE,TRIM8# |
1 | ||
| 69205-1207003 |
AE8#,CE80..GL,SE,SR,SX,ZX GRAY,GRAY,TRIM1# |
1 | ||
| 69208 - HANDLE SUB-ASSY, FRONT DOOR INSIDE, LH | ||||
| 69206-1207004 |
AE8#,CE80..GL,SE,SR,SX,ZX BLUE,BLUE,TRIM8# |
1 | ||
| 69206-1207002 |
AE8#,CE80..GL,SE,SR,SX,ZX MAROON,RED/MAROON,TRIM3# |
1 | ||
| 69206-1207003 |
AE8#,CE80..GL,SE,SR,SX,ZX GRAY,GRAY,TRIM1# |
1 | ||
| 69206-1207002 |
AE81..4F..DX;AE81..GL,SX,ZX;AE80,82,CE80..CTD,DX,GL,SR,SX,ZX MAROON,RED/MAROON,TRIM3# |
1 | ||
| 69210 - HANDLE ASSY, FRONT DOOR, OUTSIDE RH | ||||
| 69240-12070 |
AE8#,CE80,EE80..CTD,DX,FXD,FXL,FXR,FXT,GL,SR,SX,ZX |
1 | ||
| 69210B - CUSHION(FOR FRONT DOOR OUTSIDE HANDLE) | ||||
| 90541-03021 |
AE8#,CE80,EE80 |
4 | ||
| 69220 - HANDLE ASSY, FRONT DOOR OUTSIDE, LH | ||||
| 69230-12070 |
AE8#,CE80,EE80..CTD,DX,FXD,FXL,FXR,FXT,GL,SR,SX,ZX |
1 | ||
| 69273 - SNAP, DOOR INSIDE HANDLE ROD | ||||
| 69759-20070 |
AE80,82,CE80;AE81..4F..DX;AE81..GL,SE,SX,ZX LH |
1 | ||
| 69759-20060 |
AE80,82,CE80;AE81..4F..DX;AE81..GL,SE,SX,ZX RH |
1 | ||
| 69276 - BEZEL, FRONT DOOR INSIDE HANDLE | ||||
| 69277-3202004 |
AE8#,CE80..GL,SE,SR,SX,ZX BLUE,BLUE,TRIM8# |
2 | ||
| 69277-3202026 |
AE8#,CE80..(4D,5D2,5D3)..(CTD,DX,FXG,FXL,FXR,GL,SE,SR,SX,ZX) BROWN,BROWN,TRIM4# |
1 | ||
| 69277-3202012 |
AE8#,CE80..GL,SE,SR,SX,ZX MAROON,RED/MAROON,TRIM3# |
2 | ||
| 69277-3202033 |
AE8#,CE80..GL,SE,SR,SX,ZX GRAY,GRAY,TRIM1# |
2 | ||
| 69277-3202012 |
AE80,82,CE80;AE81..4F..DX;AE81..GL,SE,SX,ZX MAROON,RED/MAROON,TRIM3# |
2 | ||
| 69293A - SNAP, FRONT DOOR OUTSIDE HANDLE | ||||
| 69293-12040 |
AE8#,CE80,EE80 LH |
1 | ||
| 69293-12030 |
AE8#,CE80,EE80 RH |
1 | ||
| 69310 - LOCK ASSY, FRONT DOOR, RH | ||||
| 69310-12140 |
AE8#,CE80..(4D,5D2,5D3)..(CTD,DX,FXG,FXL,FXR,GL,GT,SE,SR,SX) |
1 | ||
| 69310 - LOCK ASSY, FRONT DOOR, RH | ||||
| 69310-12140 |
AE8#,CE80..(4D,5D2,5D3)..(CTD,DX,FXG,FXL,FXR,GL,GT,SE,SR,SX) |
1 | ||
| 69320 - LOCK ASSY, FRONT DOOR, LH | ||||
| 69320-12160 |
AE8#,CE80..(4D,5D2,5D3)..(CTD,DX,FXG,FXL,FXR,GL,GT,SE,SR,SX) |
1 | ||
| 69320 - LOCK ASSY, FRONT DOOR, LH | ||||
| 69320-12160 |
AE8#,CE80..(4D,5D2,5D3)..(CTD,DX,FXG,FXL,FXR,GL,GT,SE,SR,SX) |
1 | ||
| 69377 - SNAP, FRONT DOOR LOCK CONTROL ROD | ||||
| 69759-20050 |
AE8#,CE80,EE80..4D,5D2,5D3 RH |
1 | ||
| 69759-20040 |
AE8#,CE80,EE80..4D,5D2,5D3 LH |
1 | ||
| 69377 - SNAP, FRONT DOOR LOCK CONTROL ROD | ||||
| 69759-20050 |
AE8#,CE80,EE80..4D,5D2,5D3 RH |
1 | ||
| 69759-20040 |
AE8#,CE80,EE80..4D,5D2,5D3 LH |
1 | ||
| 69410 - PLATE ASSY, FRONT DOOR LOCK STRIKER | ||||
| 69410-87001 |
AE8#,CE80,EE80 |
2 | ||
| 69710 - LINK ASSY, FRONT DOOR OPEN CONTROL, RH | ||||
| 69711-12070 |
AE8#,CE80,EE80..4D,5D2,5D3 |
1 | ||
| 69720 - LINK ASSY, FRONT DOOR OPEN CONTROL, LH | ||||
| 69712-12080 |
AE8#,CE80,EE80..4D,5D2,5D3 |
1 | ||
| 69736A - GUIDE, FRONT DOOR LOCK LINK | ||||
| 69736-22021 |
AE8#,CE80..GL,SE,SR,SX,ZX |
2 | ||
| 69747A - BUTTON, DOOR LOCKING(FOR FRONT DOOR) | ||||
| 69741-3201001 |
AE8#,CE80..4D,5D2,5D3 BLACK,BLACK,TRIM1# |
2 | ||
| 69749 - CLAMP, FRONT DOOR LOCK LINK | ||||
| 69749-20010 |
AE8#,CE80,EE80..4D,5D2,5D3 |
2 | ||
| Common parts | ||||
| 90159-60268 | ||||
| 90159-60329 | ||||
| 90159-80014 | ||||
| 90168-60014 | ||||
| 90189-06043 | ||||
| 91651-40610 | ||||
| 91651-40612 | ||||
| 93530-54010 | ||||
| Linked diagrams | ||||
| 8511 | ||||
