XZB50-ZRPNH (2004)
Toyota Coaster
(0408- )DX,EX,GX,LX,SULNG
ｳﾝﾃﾝｾｷ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55560D - LOCK ASSY, SEAT UNDER TRAY | ||||
| 55560-95J00E0 |
BB4#,HDB5#,HZB4#,5# GREIGE,TRIM4# |
1 | ||
| 71071S - COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71071-36020E0 |
BB4#,HDB50,HZB40,5#..GX,LX GREIGE,TRIM4# |
1 | ||
| 71071-36012B0 |
BZB40,50..STD;XZB40,50..(26S,29S,39S,49S)..(DX,LX,STD)..CBU ｼ-ﾄ = TYPE A-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71071-36072B2 |
BZB40,50,XZB4#,50,56..(08S,09S,26S,29S)..(DX,LX) ｼ-ﾄ = TYPE B-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71071-36082B2 |
BZB40,50,XZB4#,50,56..(09S,20S,26S,29S)..LX ｼ-ﾄ = TYPE C-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71073S - COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71073-36020E0 |
BB4#,HDB50,HZB40,5#..GX,LX GREIGE,TRIM4# |
1 | ||
| 71073-36112B2 |
BZB40,50,XZB4#,50,56..(08S,09S,26S,29S)..(DX,LX) ｼ-ﾄ = TYPE B-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71073-36011B0 |
BZB40,50..STD;XZB40,50..(26S,29S,39S,49S)..(DX,LX,STD)..CBU ｼ-ﾄ = TYPE A-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71073-36122B1 |
BZB40,50,XZB4#,50,56..(09S,20S,26S,29S)..LX ｼ-ﾄ = TYPE C-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71073S - COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71073-36020E0 |
BB4#,HDB50,HZB40,5#..GX,LX GREIGE,TRIM4# |
1 | ||
| 71073-36112B2 |
BZB40,50,XZB4#,50,56..(08S,09S,26S,29S)..(DX,LX) ｼ-ﾄ = TYPE B-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71073-36011B0 |
BZB40,50..STD;XZB40,50..(26S,29S,39S,49S)..(DX,LX,STD)..CBU ｼ-ﾄ = TYPE A-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71073-36122B1 |
BZB40,50,XZB4#,50,56..(09S,20S,26S,29S)..LX ｼ-ﾄ = TYPE C-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71073S - COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71073-36020E0 |
BB4#,HDB50,HZB40,5#..GX,LX GREIGE,TRIM4# |
1 | ||
| 71073-36112B2 |
BZB40,50,XZB4#,50,56..(08S,09S,26S,29S)..(DX,LX) ｼ-ﾄ = TYPE B-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71073-36011B0 |
BZB40,50..STD;XZB40,50..(26S,29S,39S,49S)..(DX,LX,STD)..CBU ｼ-ﾄ = TYPE A-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71073-36122B1 |
BZB40,50,XZB4#,50,56..(09S,20S,26S,29S)..LX ｼ-ﾄ = TYPE C-*104,MEDIUM CHARCOAL,TRIM1# |
1 | ||
| 71108B - LEG SUB-ASSY, FRONT SEAT, RH | ||||
| 71108-36010E0 |
BB4#,HDB5#,HZB4#,5# GREIGE,TRIM4# |
1 | ||
| 71108-36011B0 |
XZB40,50..(26S,29S)..LX..(4FC,6F) ｼ-ﾄ = TYPE C OR TYPE D OR TYPE E-*104,MD.CHARCOAL,TRIM10 |
1 | ||
| 71108-36011C0 |
XZB40,50..(26S,29S)..LX..(4FC,6F) ｼ-ﾄ = TYPE A OR TYPE B-*104,BLACK,TRIM10 |
1 | ||
| 71149 - WIRE, FRONT SEAT CUSHION CONNECTING | ||||
| 71149-36010 |
BB4#,5#,HDB5#,HZB4#,5#..CBU,IV5 |
1 | ||
| 71511S - PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71501-36010 |
BB4#,55,HDB5#,HZB4#,5# |
1 | ||
| 71501-36011 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) |
1 | ||
| 71524 - PAD, FRONT SEAT CUSHION SILENCER, D | ||||
| 71524-36010 |
BB4#,5#,HDB5#,HZB4#,5#..CBU,IV5 |
2 | ||
| 71524-36010 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) |
2 | ||
| 71524 - PAD, FRONT SEAT CUSHION SILENCER, D | ||||
| 71524-36010 |
BB4#,5#,HDB5#,HZB4#,5#..CBU,IV5 |
2 | ||
| 71524-36010 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) |
2 | ||
| 71551S - PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71551-36010 |
BB4#,HDB5#,HZB4#,5# |
1 | ||
| 71551-36010 |
XZB4#,50,56..(LX,STD)..(4FC,6F) |
1 | ||
| 71610S - SPRING ASSY, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71610-36010 |
BB4#,55,HDB5#,HZB4#,5# |
1 | ||
| 71610-36020 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) |
1 | ||
| 71630S - SPRING ASSY, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71630-36030 |
BB4#,HDB50,HZB40,5# |
1 | ||
| 71630-36051 |
XZB4#,50,56..(LX,STD)..(4FC,6F) |
1 | ||
| 71750A - TRAY ASSY, FRONT SEAT UNDER | ||||
| 71750-36010E0 |
BB4#,5#,HDB5#,HZB4#,5#..CBU,IV5 GREIGE,TRIM4# |
1 | ||
| 71811D - SHIELD, FRONT SEAT CUSHION, RH | ||||
| 71811-20160B0 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) MD.CHARCOAL,TRIM1# |
1 | ||
| 71811-20160E0 |
BB4#,5#,HDB5#,HZB4#,5#..CBU,IV5 GREIGE,TRIM4# |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-60040E2 |
BB4#,5#,HDB50,HZB40,5# GREIGE,TRIM4# |
1 | ||
| 71910-60040B1 |
XZB4#,50,56..(LX,STD)..(4FC,6F) MD.CHARCOAL,TRIM1# |
1 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71931-10020E4 |
BB4#,HDB5#,HZB4#,5# ﾛｯｸ無,GREIGE,TRIM4# |
1 | ||
| 71931-12040P9 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) ﾛｯｸ無,MD.CHARCOAL,TRIM1# |
1 | ||
| 71930-10070E4 |
BB4#,HDB5#,HZB4#,5# ﾛｯｸ付,GREIGE,TRIM4# |
1 | ||
| 71930-44010B3 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) ﾛｯｸ付,MD.CHARCOAL,TRIM1# |
1 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71931-10020E4 |
BB4#,HDB5#,HZB4#,5# ﾛｯｸ無,GREIGE,TRIM4# |
1 | ||
| 71931-12040P9 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) ﾛｯｸ無,MD.CHARCOAL,TRIM1# |
1 | ||
| 71930-10070E4 |
BB4#,HDB5#,HZB4#,5# ﾛｯｸ付,GREIGE,TRIM4# |
1 | ||
| 71930-44010B3 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) ﾛｯｸ付,MD.CHARCOAL,TRIM1# |
1 | ||
| 72110A - TRACK ASSY, FRONT SEAT, OUTER RH | ||||
| 72110-36010 |
BB4#,55,HDB5#,HZB4#,5# |
1 | ||
| 72110-36010 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) |
1 | ||
| 72130A - TRACK ASSY, FRONT SEAT, INNER RH | ||||
| 72130-36010 |
BB4#,55,HDB5#,HZB4#,5# |
1 | ||
| 72130-36011 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) |
1 | ||
| 72301 - WIRE SUB-ASSY, SEAT TRACK EQUALIZING | ||||
| 72301-60020 |
BB4#,HDB5#,HZB4#,5# |
1 | ||
| 72301-60020 |
XZB4#,5#..(EX,GX,LX,STD)..(4FC,6F) |
1 | ||
| 72510 - ADJUSTER ASSY, RECLINING SEAT BACK, RH | ||||
| 72510-36010 |
BB4#,55,HDB5#,HZB4#,5# |
1 | ||
| 72510-36020 |
XZB4#,5#..(EX,GX,LX)..(4FC,6F) |
1 | ||
| Common parts | ||||
| 90119-05008 | ||||
| 90119-08079 | ||||
| 90119-08080 | ||||
| 90119-08873 | ||||
| 90119-10037 | ||||
| 90119-10428 | ||||
| 90167-40044 | ||||
| 90176-08039 | ||||
| 90179-05004 | ||||
| 90179-06208 | ||||
| 90202-14007 | ||||
| 90386-12051 | ||||
| 90389-10008 | ||||
| 91651-61040 | ||||
| 93240-56014 | ||||
| 93249-55016 | ||||
| 93530-14025 | ||||
| 93560-54012 | ||||
| 94542-01400 | ||||
| Linked diagrams | ||||
| 7152 | ||||
