RB11-JDER (1977)

Toyota Coaster

Production Aug 1977 - Nov 1979
Engine 20R
Transmission
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 2 OF 2(7708- )20R,22R

Click highlighted areas on diagram

diagram 1709 1709 1709 17700 17700 17700A 17700A 17700B 17700B 17701 17701 17801 17801 17807 17807 17841 17841 17841 17841 17845 17845
Part # Description Qty Price
17700 - CLEANER ASSY, AIR
17700-38070

20R..RB11

 1
17700-38070

20R..RB11

 1
17700 - CLEANER ASSY, AIR
17700-38070

20R..RB11

 1
17700-38070

20R..RB11

 1
17700A - NUT, WING(FOR AIR CLEANER)
94271-00800

20R,22R..RB1#

 1
94271-00800

20R,22R..RB1#

 1
17700A - NUT, WING(FOR AIR CLEANER)
94271-00800

20R,22R..RB1#

 1
94271-00800

20R,22R..RB1#

 1
17700B - WASHER, SEAL(FOR AIR CLEANER)
90210-08004

20R,22R..RB1#

 1
90210-08004

20R,22R..RB1#

 1
17700B - WASHER, SEAL(FOR AIR CLEANER)
90210-08004

20R,22R..RB1#

 1
90210-08004

20R,22R..RB1#

 1
17701 - CASE SUB-ASSY, AIR CLEANER
17701-38070

20R..RB11

 1
17701-38070

20R..RB11

 1
17701 - CASE SUB-ASSY, AIR CLEANER
17701-38070

20R..RB11

 1
17701-38070

20R..RB11

 1
17801 - ELEMENT SUB-ASSY, AIR CLEANER FILTER
17801-48011

20R,22R..RB1#

 1
17801-48011

20R,22R..RB1#

 1
17801 - ELEMENT SUB-ASSY, AIR CLEANER FILTER
17801-48011

20R,22R..RB1#

 1
17801-48011

20R,22R..RB1#

 1
17807 - PLATE SUB-ASSY, AIR CLEANER FILTER SET
17807-56010

20R,22R..RB1#

 1
17807-56010

20R,22R..RB1#

 1
17807 - PLATE SUB-ASSY, AIR CLEANER FILTER SET
17807-56010

20R,22R..RB1#

 1
17807-56010

20R,22R..RB1#

 1
17841 - GASKET, FILTER ELEMENT
17841-56010

20R..RB1#

 2
17841-56010

20R..RB1#

 2
17841 - GASKET, FILTER ELEMENT
17841-56010

20R..RB1#

 2
17841-56010

20R..RB1#

 2
17841 - GASKET, FILTER ELEMENT
17841-56010

20R..RB1#

 2
17841-56010

20R..RB1#

 2
17841 - GASKET, FILTER ELEMENT
17841-56010

20R..RB1#

 2
17841-56010

20R..RB1#

 2
17845 - GASKET, AIR CLEANER CAP
17845-56020

20R,22R..RB1#

 1
17845-56020

20R,22R..RB1#

 1
17845 - GASKET, AIR CLEANER CAP
17845-56020

20R,22R..RB1#

 1
17845-56020

20R,22R..RB1#

 1
Linked diagrams
1709

ILLUST NO. 1 OF 2(7708- )20R,22R

Click highlighted areas on diagram

diagram 17700F 17764 17764A 17764B 17805 17848 17853 17871 17881 17881A 17881A 17882 17882 17882A 17882A 17882A 17882A 17883 17883A 17883A 17901 9017906020 9017906027 9017908146 9021009026 9046123023 9046320303 9048075154 9161140830 9165140814 9165140825 9165160820 9166160816 9338315016 9461310800
Part # Description Qty Price
17700F - BOLT, STUD(FOR AIR CLEANER SETTING)
90116-06143

20R..RB1#

 1
17764 - DUCT, AIR CLEANER
58609-90500

20R,22R..RB1#

 1
17764A - SEAL, AIR CLEANER DUCT
58395-90740

20R,22R..RB1#

 1
17764B - PLATE, AIR CLEANER SEALD
58396-90740

20R..RB11

 1
17805 - CONNECTOR SUB-ASSY, INTAKE AIR
17861-38010

20R..RB11

 1
17861-38011

20R..RB11

 1
17848 - GASKET, AIR CLEANER TO CARBURETOR
17849-38010

20R..RB1#

 1
17871 - STAY, AIR CONNECTOR
17871-38010

20R..RB11

 1
17881 - HOSE, AIR CLEANER, NO.1
17881-38020

20R,22R..RB1#

 1
17881A - CLAMP(FOR AIR CLEANER HOSE, NO.1)
96111-10750

20R,22R..RB1#

ID=75

 2
17881A - CLAMP(FOR AIR CLEANER HOSE, NO.1)
96111-10750

20R,22R..RB1#

ID=75

 2
17882 - HOSE, AIR CLEANER, NO.2
17882-38040

20R,22R..RB1#

 1
17882 - HOSE, AIR CLEANER, NO.2
17882-38040

20R,22R..RB1#

 1
17882A - CLAMP(FOR AIR CLEANER HOSE, NO.2)
96111-10750

20R,22R..RB1#

ID=75

 2
17882A - CLAMP(FOR AIR CLEANER HOSE, NO.2)
96111-10750

20R,22R..RB1#

ID=75

 2
17882A - CLAMP(FOR AIR CLEANER HOSE, NO.2)
96111-10750

20R,22R..RB1#

ID=75

 2
17882A - CLAMP(FOR AIR CLEANER HOSE, NO.2)
96111-10750

20R,22R..RB1#

ID=75

 2
Common parts
90179-06020
90179-06027
90179-08146
90210-09026
90461-23023
90463-20303
90480-75154
91611-40830
91651-40814
91651-40825
91651-60820
91661-60816
93383-15016
94613-10800
