BB30-MDY (1982)
Toyota Coaster
(8205- )3B
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16261 - HOSE, WATER BY-PASS | ||||
| 16261-56012 |
14B,3B..BB2#,3# |
1 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 90044-60053 |
3B..BB2#,3# |
2 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 90044-60053 |
3B..BB2#,3# |
2 | ||
| 16331 - OUTLET, WATER | ||||
| 16331-56020 |
14B,3B..BB2#,3# |
1 | ||
| 16331A - THERMOSTAT | ||||
| 90916-03059 |
3B..BB2#,3# *WAX 88−100 |
1 | ||
| 16333 - HOUSING, WATER OUTLET | ||||
| 16333-56060 |
3B..BB2#,3# |
1 | ||
| 16341 - GASKET, WATER OUTLET | ||||
| 16341-56020 |
3B..BB2#,3# |
1 | ||
| 16343 - GASKET, WATER OUTLET HOUSING | ||||
| 16343-56020 |
3B..BB2#,3# |
1 | ||
| 16361 - FAN | ||||
| 16361-41070 |
14B,3B..BB2#,3# |
1 | ||
| 16381 - BAR, FAN BELT ADJUSTING | ||||
| 16381-58010 |
3B..BB2#,3#..WOC COLD SPEC |
1 | ||
| 16381-56030 |
3B..BB2#,3#..WOC |
1 | ||
| 16381 - BAR, FAN BELT ADJUSTING | ||||
| 16381-58010 |
3B..BB2#,3#..WOC COLD SPEC |
1 | ||
| 16381-56030 |
3B..BB2#,3#..WOC |
1 | ||
| 16400 - RADIATOR ASSY | ||||
| 16400-58050 |
3B..BB2#,3# |
1 | ||
| 16400B - PLUG, RADIATOR DRAIN COCK | ||||
| 16417-24200 |
14B,3B..BB2#,3# |
1 | ||
| 16400F - PACKING(FOR RADIATOR DRAIN COCK) | ||||
| 16418-24200 |
14B,3B..BB2#,3# |
1 | ||
| 16401 - CAP SUB-ASSY, RADIATOR | ||||
| 16401-41021 |
3B..BB2#,3# |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-90B01 |
14B,3B..BB20,21,23,26,3# |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90447-12035 |
3B..BB2#,3# |
1 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
14B,3B..BB2#,3# |
2 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
14B,3B..BB2#,3# |
2 | ||
| 16470C - BRACKET(FOR RADIATOR RESERVE TANK) | ||||
| 16611-90B00 |
14B,3B..BB2#,3# |
1 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16405-90B00 |
3B..BB2#,3# |
1 | ||
| 16472 - HOSE, BREATHER | ||||
| 85338-22020 |
3B..BB2#,3# |
1 | ||
| 16571 - HOSE, RADIATOR, INLET | ||||
| 16571-58020 |
14B,3B..BB2#,3# |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90460-50016 |
3B..BB2#,3# |
2 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90460-50016 |
3B..BB2#,3# |
2 | ||
| 16572 - HOSE, RADIATOR, OUTLET | ||||
| 16572-58020 |
3B..BB2#,3# |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 90460-50016 |
3B..BB2#,3# RADIATOR SIDE |
1 | ||
| 96111-10560 |
3B..BB2#,3# WATER PUMP SIDE |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 90460-50016 |
3B..BB2#,3# RADIATOR SIDE |
1 | ||
| 96111-10560 |
3B..BB2#,3# WATER PUMP SIDE |
1 | ||
| 16593 - GUIDE, RADIATOR AIR, NO.1 | ||||
| 16593-58010 |
14B,3B..BB2#,3# RH |
1 | ||
| 16595-58010 |
14B,3B..BB2#,3# LH |
1 | ||
| 16593 - GUIDE, RADIATOR AIR, NO.1 | ||||
| 16593-58010 |
14B,3B..BB2#,3# RH |
1 | ||
| 16595-58010 |
14B,3B..BB2#,3# LH |
1 | ||
| 16594 - GUIDE, RADIATOR AIR, NO.2 | ||||
| 16594-58010 |
14B,3B..BB2#,3# |
1 | ||
| 16701 - SHROUD SUB-ASSY, FAN | ||||
| 16701-56220 |
3B..BB2#,3# |
1 | ||
| Common parts | ||||
| 90179-06293 | ||||
| 90179-08088 | ||||
| 90341-12006 | ||||
| 90345-54005 | ||||
| 90430-12221 | ||||
| 90651-40818 | ||||
| 91611-60822 | ||||
| 91611-60825 | ||||
| 91611-61020 | ||||
| 91611-61028 | ||||
| 91651-40616 | ||||
| 91651-40620 | ||||
| 91651-40814 | ||||
| 91651-40816 | ||||
| 94110-40600 | ||||
| Linked diagrams | ||||
| 1605 | ||||
| 8401 | ||||
