YX80Y-BTHRP (1988)
Toyota Chaser
(8808-9210)
ｱﾘ(ﾜｲﾔﾚｽ ﾄﾞｱﾛﾂｸ)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Linked diagrams | ||||
| 8420 | ||||
(8808-9210)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69051 - CYLINDER & KEY SET, DOOR LOCK, RH | ||||
| 69051-91609 |
GX81,LX80,SX80,YX80..KYO,SXL,XG,XL |
1 | ||
| 69052 - CYLINDER & KEY SET, DOOR LOCK, LH | ||||
| 69052-91609 |
GX81,JZX81,LX80,MX83,SX80,YX80 |
1 | ||
| 69055A - CYLINDER & KEY SET, LUGGAGE COMPARTMENT LOCK | ||||
| 69055-91614 |
GX81,LX80,SX80,YX80..KYO,SXL,XG,XL |
1 | ||
| 69057A - CYLINDER & KEY SET, IGNITION SWITCH LOCK | ||||
| 69057-91605 |
GX81,JZX81,LX80,MX83,SX80,YX80 |
1 | ||
| 69062 - CYLINDER & KEY SET, GLOVE COMPARTMENT LOCK | ||||
| 69056-91606 |
GX81,JZX81,LX80,MX83,SX80,YX80 |
1 | ||
| 69503 - CYLINDER SET, LOCK | ||||
| 69005-91622 |
GX81,LX80,SX80,YX80..KYO,SXL,XG,XL |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00146 |
GX81,JZX81,LX80,SX80,YX80 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00147 |
GX81,JZX81,LX80,MX83,SX80,YX80 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00148 |
GX81,JZX81,LX80,MX83,SX80,YX80 ｻﾌﾞｷｰ |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00146 |
GX81,JZX81,LX80,SX80,YX80 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00147 |
GX81,JZX81,LX80,MX83,SX80,YX80 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00148 |
GX81,JZX81,LX80,MX83,SX80,YX80 ｻﾌﾞｷｰ |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00146 |
GX81,JZX81,LX80,SX80,YX80 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00147 |
GX81,JZX81,LX80,MX83,SX80,YX80 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00148 |
GX81,JZX81,LX80,MX83,SX80,YX80 ｻﾌﾞｷｰ |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00146 |
GX81,JZX81,LX80,SX80,YX80 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00147 |
GX81,JZX81,LX80,MX83,SX80,YX80 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00148 |
GX81,JZX81,LX80,MX83,SX80,YX80 ｻﾌﾞｷｰ |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00146 |
GX81,JZX81,LX80,SX80,YX80 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00147 |
GX81,JZX81,LX80,MX83,SX80,YX80 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00148 |
GX81,JZX81,LX80,MX83,SX80,YX80 ｻﾌﾞｷｰ |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00146 |
GX81,JZX81,LX80,SX80,YX80 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00147 |
GX81,JZX81,LX80,MX83,SX80,YX80 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00148 |
GX81,JZX81,LX80,MX83,SX80,YX80 ｻﾌﾞｷｰ |
1 | ||
| 69555 - COVER, KEY | ||||
| 69555-20010 |
GX81,JZX81,LX80,MX83,SX80,YX80 |
1 | ||
| 69561A - RETAINER, LUGGAGE COMPARTMENT LOCK CYLINDER | ||||
| 69561-91603 |
GX81,JZX81,LX80,MX83,SX80,YX80 |
1 | ||
| 69562 - LEVER, LUGGAGE COMPARTMENT DOOR LOCK | ||||
| 69562-23010 |
GX81,JZX81,LX80,MX83,SX80,YX80 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-22080 |
GX81,JZX81,LX80,MX83,SX80,YX80 右側 |
1 | ||
| 69759-22090 |
GX81,JZX81,LX80,MX83,SX80,YX80 左側 |
1 | ||
| 69759-24090 |
GX81,LX80,SX80,YX80..KYO,SXL,XG,XL BROWN,左側 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-22080 |
GX81,JZX81,LX80,MX83,SX80,YX80 右側 |
1 | ||
| 69759-22090 |
GX81,JZX81,LX80,MX83,SX80,YX80 左側 |
1 | ||
| 69759-24090 |
GX81,LX80,SX80,YX80..KYO,SXL,XG,XL BROWN,左側 |
1 | ||
| Common parts | ||||
| 90151-40011 | ||||
| 90523-05005 | ||||
| 91611-60610 | ||||
| Linked diagrams | ||||
| 5501 | ||||
