RX63-DTMZF (1980)
Toyota Chaser
(8009-8208)18RGEU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11011 - WASHER SET, CRANKSHAFT THRUST | ||||
| 11011-38010 |
21RU,18RGEU..RX6# STD,STD |
1 | ||
| 11012-38010 |
18RGEU..RX63 O/S 0.125,O/S 0.125 |
1 | ||
| 11011-38010 |
18RGEU..RX63 STD,STD |
1 | ||
| 11013-38010 |
18RGEU..RX63 O/S 0.250,O/S 0.250 |
1 | ||
| 11012-38010 |
21RU,18RGEU..RX6# O/S 0.125,O/S 0.125 |
1 | ||
| 11013-38010 |
21RU,18RGEU..RX6# O/S 0.250,O/S 0.250 |
1 | ||
| 11702 - BEARING SET, CRANKSHAFT | ||||
| 11703-88270 |
18RGEU..RX63 U/S 0.05 |
1 | ||
| 11702-88270 |
18RGEU..RX63 STD |
1 | ||
| 11704-88270 |
18RGEU..RX63 U/S 0.25 |
1 | ||
| 13011 - RING SET, PISTON | ||||
| 13011-88270 |
18RGEU..RX63 STD |
1 | ||
| 13013-88270 |
18RGEU..RX63 O/S 0.50 |
1 | ||
| 13015-88270 |
18RGEU..RX63 O/S 1.00 |
1 | ||
| 13101 - PISTON SUB-ASSY, W/PIN | ||||
| 13101-88270 |
18RGEU..RX63 STD |
4 | ||
| 13105-88270 |
18RGEU..RX63 O/S 1.00 |
4 | ||
| 13103-88270 |
18RGEU..RX63 O/S 0.50 |
4 | ||
| 13101A - RING, HOLE SNAP(FOR PISTON PIN) | ||||
| 90072-52104 |
18RGEU..RX63 |
8 | ||
| 13201 - ROD SUB-ASSY, CONNECTING | ||||
| 13201-37011 |
18RGEU..RX63 |
4 | ||
| 13201A - BUSH(FOR CONNECTING ROD SMALL END) | ||||
| 90999-73072 |
21RU,18RGEU..RX6# |
4 | ||
| 13202 - BEARING SET, CONNECTING ROD | ||||
| 13204-33011 |
18RGEU..RX63 U/S 0.25 |
1 | ||
| 13202-33011 |
18RGEU..RX63 STD |
1 | ||
| 13265 - BOLT, CONNECTING ROD | ||||
| 13265-37011 |
18RGEU..RX63 |
8 | ||
| 13265A - NUT, HEXAGON(FOR CONNECTING ROD BOLT) | ||||
| 90170-10198 |
21RU,18RGEU..RX6# |
8 | ||
| 13405 - FLYWHEEL SUB-ASSY | ||||
| 13405-39037 |
18RGEU..RX63 N=115 |
1 | ||
| 13405A - PIN, STRAIGHT(FOR FLYWHEEL) | ||||
| 90250-08054 |
21RU,18RGEU..RX6#..MTM 長さ=23,外径=8 |
3 | ||
| 13405B - BOLT, FLYWHEEL SETTING | ||||
| 90105-10030 |
18RGEU..RX63 |
6 | ||
| 13411 - CRANKSHAFT | ||||
| 13411-34906 |
18RGEU..RX63 |
1 | ||
| 13453 - GEAR, FLYWHEEL RING | ||||
| 13453-20010 |
21RU,18RGEU..RX6#..MTM |
1 | ||
| 13471 - PULLEY, CRANKSHAFT | ||||
| 13407-37014 |
18RGEU..RX63 |
1 | ||
| 13407-37013 |
18RGEU..RX63 |
1 | ||
| 13471A - KEY, CRANKSHAFT(FOR CRANKSHAFT PULLEY SET) | ||||
| 90280-05010 |
21RU,18RGEU..RX6# |
1 | ||
| 13471C - BOLT(FOR CRANKSHAFT PULLEY SET) | ||||
| 90105-14048 |
18RGEU..RX63 *14-1.5PX26-21 |
1 | ||
| 13521 - GEAR OR SPROCKET, CRANKSHAFT TIMING | ||||
| 13521-33010 |
18RGEU..RX63 |
1 | ||
| 13521A - KEY(FOR CRANKSHAFT TIMING GEAR) | ||||
| 90280-05010 |
21RU,18RGEU..RX6# |
1 | ||
| Linked diagrams | ||||
| 3101 | ||||
