GX81-BTPQF (1988)
Toyota Chaser
(8808-9008)AVT,AVTG,GT
W/O REAR SPEAKER
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88901 - MOTOR SUB-ASSY, AIR PURIFIER | ||||
| 88901-22140 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88904A - ACCESSORY SUB-ASSY, AIR PURIFIRE | ||||
| 88904-22150 |
GX81,JZX81,MX83..SPC,TWC,TWT |
1 | ||
| 88904-2214006 |
GX81,MX83..SPC,TWC ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),SABLE,TRIM3# |
1 | ||
| 88904-2214006 |
GX81..SPC,TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),SABLE,TRIM3#,4# |
1 | ||
| 88904-2214004 |
GX81,MX83..SPC,TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),BLUE,TRIM8# |
1 | ||
| 88904-22290 |
GX81,JZX81,MX83..TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88905 - WIRE SUB-ASSY, AIR PURIFIER, NO.1 | ||||
| 88905-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88905-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88905-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88912 - FAN, AIR PURIFIER | ||||
| 88912-22140 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88912-22140 |
GX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88915 - RESISTOR, AIR PURIFIER | ||||
| 88915-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88920A - PURIFIER ASSY, AIR | ||||
| 88920-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88920-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88920-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88926 - FILTER, AIR PURIFIER | ||||
| 88926-24010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88927 - FILTER, AIR PURIFIER, NO.2 | ||||
| 88927-24010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88928A - CASE, AIR PURIFIER FILTER | ||||
| 88928-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88929A - PIN, AIR PURIFIER DUCT | ||||
| 88929-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
4 | ||
| 88930A - SWITCH ASSY, AIR PURIFIER | ||||
| 88930-22140 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88930-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88931 - SENSOR, SMOKE | ||||
| 88931-22021 |
GX81,MX83..AVT,AVTG,GT |
1 | ||
| 88931-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88932 - COVER, SMOKE SENSOR | ||||
| 88932-2214004 |
GX81,MX83..AVT,AVTG,GT DRAK BLUE,TRIM8# |
1 | ||
| 88932-2214006 |
GX81..AVT,AVTG,GT SABLE,TRIM3#,4# |
1 | ||
| 88932-2214006 |
GX81,MX83..SPC,TWC SABLE,TRIM3# |
1 | ||
| 88950 - AMPLIFIER ASSY, AIR PURIFIER | ||||
| 88950-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88950-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88950-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| Common parts | ||||
| 90119-06055 | ||||
| 90159-45004 | ||||
| 90159-50033 | ||||
| 91661-40630 | ||||
| 94525-00600 | ||||
(8808-9008)AVT,SXL,XG,XL
W/ REAR SPEAKER
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88901 - MOTOR SUB-ASSY, AIR PURIFIER | ||||
| 88901-22140 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88904A - ACCESSORY SUB-ASSY, AIR PURIFIRE | ||||
| 88904-22150 |
GX81,JZX81,MX83..SPC,TWC,TWT |
1 | ||
| 88904-2214006 |
GX81,MX83..SPC,TWC ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),SABLE,TRIM3# |
1 | ||
| 88904-2214006 |
GX81..SPC,TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),SABLE,TRIM3#,4# |
1 | ||
| 88904-2214004 |
GX81,MX83..SPC,TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),BLUE,TRIM8# |
1 | ||
| 88904-22290 |
GX81,JZX81,MX83..TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88905 - WIRE SUB-ASSY, AIR PURIFIER, NO.1 | ||||
| 88905-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88905-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88905-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88912 - FAN, AIR PURIFIER | ||||
| 88912-22140 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88912-22140 |
GX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88915 - RESISTOR, AIR PURIFIER | ||||
| 88915-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88920A - PURIFIER ASSY, AIR | ||||
| 88920-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88920-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88920-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88926 - FILTER, AIR PURIFIER | ||||
| 88926-24010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88927 - FILTER, AIR PURIFIER, NO.2 | ||||
| 88927-24010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88928A - CASE, AIR PURIFIER FILTER | ||||
| 88928-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88929A - PIN, AIR PURIFIER DUCT | ||||
| 88929-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
4 | ||
| 88930A - SWITCH ASSY, AIR PURIFIER | ||||
| 88930-22140 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88930-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88931 - SENSOR, SMOKE | ||||
| 88931-22021 |
GX81,MX83..AVT,AVTG,GT |
1 | ||
| 88931-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88932 - COVER, SMOKE SENSOR | ||||
| 88932-2214004 |
GX81,MX83..AVT,AVTG,GT DRAK BLUE,TRIM8# |
1 | ||
| 88932-2214006 |
GX81..AVT,AVTG,GT SABLE,TRIM3#,4# |
1 | ||
| 88932-2214006 |
GX81,MX83..SPC,TWC SABLE,TRIM3# |
1 | ||
| 88950 - AMPLIFIER ASSY, AIR PURIFIER | ||||
| 88950-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88950-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88950-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| Common parts | ||||
| 90119-06055 | ||||
| 90159-45004 | ||||
| 91661-40630 | ||||
| 94525-00600 | ||||
(9008- )AVT,AVTG,GT
W/O REAR SPEAKER
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88901 - MOTOR SUB-ASSY, AIR PURIFIER | ||||
| 88901-22140 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88904A - ACCESSORY SUB-ASSY, AIR PURIFIRE | ||||
| 88904-22150 |
GX81,JZX81,MX83..SPC,TWC,TWT |
1 | ||
| 88904-2214006 |
GX81,MX83..SPC,TWC ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),SABLE,TRIM3# |
1 | ||
| 88904-2214006 |
GX81..SPC,TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),SABLE,TRIM3#,4# |
1 | ||
| 88904-2214004 |
GX81,MX83..SPC,TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),BLUE,TRIM8# |
1 | ||
| 88904-22290 |
GX81,JZX81,MX83..TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88905 - WIRE SUB-ASSY, AIR PURIFIER, NO.1 | ||||
| 88905-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88905-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88905-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88912 - FAN, AIR PURIFIER | ||||
| 88912-22140 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88912-22140 |
GX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88915 - RESISTOR, AIR PURIFIER | ||||
| 88915-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88920A - PURIFIER ASSY, AIR | ||||
| 88920-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88920-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88920-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88926 - FILTER, AIR PURIFIER | ||||
| 88926-24010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88927 - FILTER, AIR PURIFIER, NO.2 | ||||
| 88927-24010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88928A - CASE, AIR PURIFIER FILTER | ||||
| 88928-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88929A - PIN, AIR PURIFIER DUCT | ||||
| 88929-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
4 | ||
| 88930A - SWITCH ASSY, AIR PURIFIER | ||||
| 88930-22140 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88930-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88931 - SENSOR, SMOKE | ||||
| 88931-22021 |
GX81,MX83..AVT,AVTG,GT |
1 | ||
| 88931-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88950 - AMPLIFIER ASSY, AIR PURIFIER | ||||
| 88950-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88950-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88950-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| Common parts | ||||
| 90119-06055 | ||||
| 90159-50033 | ||||
| 91661-40630 | ||||
| 94525-00600 | ||||
(9008- )GX81,LX80,SX80..AVT,SXL,XG,XL
W/ REAR SPEAKER
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88901 - MOTOR SUB-ASSY, AIR PURIFIER | ||||
| 88901-22140 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88904A - ACCESSORY SUB-ASSY, AIR PURIFIRE | ||||
| 88904-22150 |
GX81,JZX81,MX83..SPC,TWC,TWT |
1 | ||
| 88904-2214006 |
GX81,MX83..SPC,TWC ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),SABLE,TRIM3# |
1 | ||
| 88904-2214006 |
GX81..SPC,TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),SABLE,TRIM3#,4# |
1 | ||
| 88904-2214004 |
GX81,MX83..SPC,TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ),BLUE,TRIM8# |
1 | ||
| 88904-22290 |
GX81,JZX81,MX83..TWC,TWT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88905 - WIRE SUB-ASSY, AIR PURIFIER, NO.1 | ||||
| 88905-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88905-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88905-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88912 - FAN, AIR PURIFIER | ||||
| 88912-22140 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88912-22140 |
GX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88915 - RESISTOR, AIR PURIFIER | ||||
| 88915-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88920A - PURIFIER ASSY, AIR | ||||
| 88920-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88920-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88920-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88926 - FILTER, AIR PURIFIER | ||||
| 88926-24010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88927 - FILTER, AIR PURIFIER, NO.2 | ||||
| 88927-24010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88928A - CASE, AIR PURIFIER FILTER | ||||
| 88928-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
1 | ||
| 88929A - PIN, AIR PURIFIER DUCT | ||||
| 88929-22010 |
GX81,JZX81,LX80,MX83,SX80..AVT,AVTG,GT,SXL,XG,XL |
4 | ||
| 88930A - SWITCH ASSY, AIR PURIFIER | ||||
| 88930-22140 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88930-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88931 - SENSOR, SMOKE | ||||
| 88931-22021 |
GX81,MX83..AVT,AVTG,GT |
1 | ||
| 88931-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88950 - AMPLIFIER ASSY, AIR PURIFIER | ||||
| 88950-22140 |
GX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| 88950-22150 |
GX81,JZX81,MX83..AVT,AVTG,GT |
1 | ||
| 88950-22290 |
GX81,JZX81,MX83..AVT,AVTG,GT ｱﾘ(ｽﾓ-ｸ ｾﾝｻ) |
1 | ||
| Common parts | ||||
| 90119-06055 | ||||
| 91661-40630 | ||||
| 94525-00600 | ||||
