RA63-BCMQF (1981)
Toyota Celica
(8107-8308)TA61,63..5F..GT,GTR,ST,SX
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 31111 - HOUSING, CLUTCH | ||||
| 31111-14070 |
TA61,63..5F..(GT,GTR,ST,SX) |
1 | ||
| 31111-14060 |
RA63 |
1 | ||
| 33104 - PLUG SUB-ASSY, DRAIN(MTM) | ||||
| 90341-18057 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| 90341-18081 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33104A - GASKET, DRAIN PLUG(MTM) | ||||
| 90430-18007 |
AA63,GA61,MA61,RA63,SA60,TA6#..MTM |
1 | ||
| 33111 - CASE, MANUAL TRANSMISSION | ||||
| 33101-14040 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33101-22021 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| 33111A - PLUG, MANUAL TRANSMISSION CASE | ||||
| 90341-18002 |
GA61,MA61,RA63,SA60,TA6#..MTM |
1 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12002 |
GA61,MA61,RA63..5F 長さ=16,外径=12,L=16 |
4 | ||
| 90250-08030 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) 長さ=16,外径=8 |
2 | ||
| 90250-12146 |
GA61,MA61,RA63..5F 長さ=17,外径=12,L=17 |
2 | ||
| 33111X - GASKET, TRANSMISSION CASE PLUG | ||||
| 90430-18007 |
AA63,GA61,MA61,RA63,SA60,TA6#..MTM |
1 | ||
| 33116 - GASKET, MANUAL TRANSMISSION CASE | ||||
| 33116-14020 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33118 - PLATE, STIFFENER, RH(MTM) | ||||
| 33118-22030 |
RA63 |
1 | ||
| 33119 - PLATE, STIFFENER, LH(MTM) | ||||
| 33119-22021 |
RA63 |
1 | ||
| 33121G - COVER, MANUAL TRANSMISSION CASE | ||||
| 33121-14010 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33122A - GASKET, MANUAL TRANSMISSION CASE COVER | ||||
| 33122-14010 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33131 - RETAINER, BEARING, FRONT(MTM) | ||||
| 33131-22020 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| 33131-14020 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33131A - SEAL, OIL(FOR TRANSMISSION FRONT BEARING RETAINER) | ||||
| 90311-30115 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| 90311-25003 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33132 - GASKET, FRONT BEARING RETAINER(MTM) | ||||
| 33132-14020 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33132-22010 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| 33283C - BALL, REVERSE RESTRICT | ||||
| 90360-10003 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| Common parts | ||||
| 90119-08068 | ||||
| 90119-08069 | ||||
| 90119-08261 | ||||
| 90119-08285 | ||||
| 90119-08286 | ||||
| 90119-08318 | ||||
| 90119-10052 | ||||
| 90119-12010 | ||||
| 90119-12168 | ||||
| 90341-18049 | ||||
| 90430-18007 | ||||
| 91611-61028 | ||||
| 91611-61040 | ||||
| 91651-61040 | ||||
(8107-8208)RA63
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 31111 - HOUSING, CLUTCH | ||||
| 31111-14070 |
TA61,63..5F..(GT,GTR,ST,SX) |
1 | ||
| 31111-14060 |
RA63 |
1 | ||
| 33104 - PLUG SUB-ASSY, DRAIN(MTM) | ||||
| 90341-18057 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| 90341-18081 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33104A - GASKET, DRAIN PLUG(MTM) | ||||
| 90430-18007 |
AA63,GA61,MA61,RA63,SA60,TA6#..MTM |
1 | ||
| 33111 - CASE, MANUAL TRANSMISSION | ||||
| 33101-14040 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33101-22021 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| 33111A - PLUG, MANUAL TRANSMISSION CASE | ||||
| 90341-18002 |
GA61,MA61,RA63,SA60,TA6#..MTM |
1 | ||
| 33111C - PLUG(FOR TRANSMISSION CASE) | ||||
| 90331-14004 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) 外径=14 |
3 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12002 |
GA61,MA61,RA63..5F 長さ=16,外径=12,L=16 |
4 | ||
| 90250-08030 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) 長さ=16,外径=8 |
2 | ||
| 90250-12146 |
GA61,MA61,RA63..5F 長さ=17,外径=12,L=17 |
2 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12002 |
GA61,MA61,RA63..5F 長さ=16,外径=12,L=16 |
4 | ||
| 90250-08030 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) 長さ=16,外径=8 |
2 | ||
| 90250-12146 |
GA61,MA61,RA63..5F 長さ=17,外径=12,L=17 |
2 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12002 |
GA61,MA61,RA63..5F 長さ=16,外径=12,L=16 |
4 | ||
| 90250-08030 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) 長さ=16,外径=8 |
2 | ||
| 90250-12146 |
GA61,MA61,RA63..5F 長さ=17,外径=12,L=17 |
2 | ||
| 33111X - GASKET, TRANSMISSION CASE PLUG | ||||
| 90430-18007 |
AA63,GA61,MA61,RA63,SA60,TA6#..MTM |
1 | ||
| 33118 - PLATE, STIFFENER, RH(MTM) | ||||
| 33118-22030 |
RA63 |
1 | ||
| 33119 - PLATE, STIFFENER, LH(MTM) | ||||
| 33119-22021 |
RA63 |
1 | ||
| 33131 - RETAINER, BEARING, FRONT(MTM) | ||||
| 33131-22020 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| 33131-14020 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33131A - SEAL, OIL(FOR TRANSMISSION FRONT BEARING RETAINER) | ||||
| 90311-30115 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| 90311-25003 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33132 - GASKET, FRONT BEARING RETAINER(MTM) | ||||
| 33132-14020 |
AA63,SA60,TA61,63..MTM..(GT,GTR,ST,SV,SX) |
1 | ||
| 33132-22010 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| 33138 - GASKET, INTERMEDIATE PLATE | ||||
| 33142-22010 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
2 | ||
| 33151 - RETAINER, OUTPUT SHAFT REAR BEARING(MTM) | ||||
| 33107-22010 |
GA61,MA61,RA63,TA63,64..5F..(G,GT,GTS,GTT,L,S) |
1 | ||
| Common parts | ||||
| 90119-08213 | ||||
| 90149-80002 | ||||
| 91611-61028 | ||||
| 91611-61040 | ||||
| 91611-61045 | ||||
| 91619-61250 | ||||
