TA63-ACMSE (1981)
Toyota Carina Fr
(8109-8305)18RGEU,2TGEU,3TEU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04181 - PELLET KIT | ||||
| 04181-41030 |
18RGEU,3AU,1SU,2TGEU,3TEU..AA60,RA63,SA60,TA61,63 |
1 | ||
| 17400 - CONVERTER ASSY, W/CATALYST | ||||
| 17040-26070 |
2TGEU,3TEU..TA61,63 |
1 | ||
| 17400A - FLANGE, THERMOSENSER INLET | ||||
| 18491-38040 |
2TGEU,3TEU..TA61,63 |
1 | ||
| 17400F - PLATE, CATALYZER INLET PLUG LOCK | ||||
| 18493-38011 |
18RGEU,3AU,1SU,2TGEU,3TEU..AA60,RA63,SA60,TA61,63 |
1 | ||
| 17400G - GASKET, CATALYZER INLET | ||||
| 18494-38010 |
18RGEU,3AU,1SU,2TGEU,3TEU..AA60,RA63,SA60,TA61,63 |
1 | ||
| 17400H - PLUG, W/HEAD STRAIGHT SCREW(FOR CATALYZER INLET) | ||||
| 90341-24093 |
18RGEU,3AU,1SU,2TGEU,3TEU..AA60,RA63,SA60,TA61,63 |
1 | ||
| 17400J - GUIDE, CATALYTIC CONVERTER SENSOR | ||||
| 18492-45010 |
18RGEU,3AU,1SU,2TGEU,3TEU..AA60,RA63,SA60,TA61,63 |
1 | ||
| 17400P - GASKET(FOR CATALYTIC CONVERTER SENSOR GUIDE) | ||||
| 90430-08252 |
18RGEU,3AU,1SU,2TGEU,3TEU..AA60,RA63,SA60,TA61,63 |
1 | ||
| 17410 - PIPE ASSY, EXHAUST, FRONT | ||||
| 17410-26310 |
2TGEU,3TEU..TA61,63 |
1 | ||
| 17410 - PIPE ASSY, EXHAUST, FRONT | ||||
| 17410-26310 |
2TGEU,3TEU..TA61,63 |
1 | ||
| 17410A - NUT, EXHAUST PIPE SET STUD BOLT | ||||
| 90179-10028 |
12TJ,18RGEU,3AU,4AGEU,1C,5KJ,1SU,2TGEU,3T#..AA6#,CA6#,KA67,RA63,SA60,TA6# |
3 | ||
| 17410A - NUT, EXHAUST PIPE SET STUD BOLT | ||||
| 90179-10028 |
12TJ,18RGEU,3AU,4AGEU,1C,5KJ,1SU,2TGEU,3T#..AA6#,CA6#,KA67,RA63,SA60,TA6# |
3 | ||
| 17410B - GASKET, EXHAUST PIPE | ||||
| 90917-06001 |
12TJ,3AU,1SU,3TEU..AA60,SA60,TA63,67 |
2 | ||
| 17410B - GASKET, EXHAUST PIPE | ||||
| 90917-06001 |
12TJ,3AU,1SU,3TEU..AA60,SA60,TA63,67 |
2 | ||
| 17410B - GASKET, EXHAUST PIPE | ||||
| 90917-06001 |
12TJ,3AU,1SU,3TEU..AA60,SA60,TA63,67 |
2 | ||
| 17410B - GASKET, EXHAUST PIPE | ||||
| 90917-06001 |
12TJ,3AU,1SU,3TEU..AA60,SA60,TA63,67 |
2 | ||
| 17410C - BRACKET, EXHAUST PIPE FRONT (FOR FRONT) | ||||
| 17571-26180 |
12TJ,2TGEU,3TEU..TA6# |
1 | ||
| 17410C - BRACKET, EXHAUST PIPE FRONT (FOR FRONT) | ||||
| 17571-26180 |
12TJ,2TGEU,3TEU..TA6# |
1 | ||
| 17410E - CLAMP NO.1, EXHAUST PIPE FRONT (FOR FRONT) | ||||
| 90917-04030 |
12TJ,18RGEU,3AU,4AGEU,1SU,2TGEU,3TEU..AA6#,RA63,SA60,TA6# |
1 | ||
| 17410E - CLAMP NO.1, EXHAUST PIPE FRONT (FOR FRONT) | ||||
| 90917-04030 |
12TJ,18RGEU,3AU,4AGEU,1SU,2TGEU,3TEU..AA6#,RA63,SA60,TA6# |
1 | ||
| 17410V - BRACKET, EXHAUST PIPE FRONT (FOR REAR) | ||||
| 17505-28050 |
18RGEU,4AGEU,2TGEU,3T#..AA63,RA63,TA61,63 SIDE MEMBER |
1 | ||
| 17503-26060 |
2TGEU,3TEU..TA61,63..5F CCO SUPPORT |
1 | ||
| 17410V - BRACKET, EXHAUST PIPE FRONT (FOR REAR) | ||||
| 17505-28050 |
18RGEU,4AGEU,2TGEU,3T#..AA63,RA63,TA61,63 SIDE MEMBER |
1 | ||
| 17503-26060 |
2TGEU,3TEU..TA61,63..5F CCO SUPPORT |
1 | ||
| 17410Y - BOLT OR RING, EXHAUST PIPE FRONT (FOR REAR) | ||||
| 90301-36001 |
18RGEU,3AU,4AGEU,1SU,2TGEU,3T#..AA6#,RA63,SA60,TA61,63 |
2 | ||
| 17410Y - BOLT OR RING, EXHAUST PIPE FRONT (FOR REAR) | ||||
| 90301-36001 |
18RGEU,3AU,4AGEU,1SU,2TGEU,3T#..AA6#,RA63,SA60,TA61,63 |
2 | ||
| 17430 - PIPE ASSY, EXHAUST, TAIL | ||||
| 17430-28150 |
2TGEU,3TEU..TA61,63 |
1 | ||
| 17430A - BRACKET, EXHAUST TAIL PIPE(FOR FRONT) | ||||
| 17506-28010 |
18RGEU,4AGEU,2TGEU,3T#..AA63,RA63,TA61,63 UPR |
1 | ||
| 17509-28010 |
18RGEU,4AGEU,2TGEU,3T#..AA63,RA63,TA61,63 LWR |
1 | ||
| 17430A - BRACKET, EXHAUST TAIL PIPE(FOR FRONT) | ||||
| 17506-28010 |
18RGEU,4AGEU,2TGEU,3T#..AA63,RA63,TA61,63 UPR |
1 | ||
| 17509-28010 |
18RGEU,4AGEU,2TGEU,3T#..AA63,RA63,TA61,63 LWR |
1 | ||
| 17430D - BOLT OR RING, EXHAUST TAIL PIPE (FOR FRONT) | ||||
| 17565-15010 |
18RGEU,4AGEU,2TGEU,3T#..AA63,RA63,TA61,63 |
1 | ||
| 17430F - BRACKET, EXHAUST TAIL PIPE(FOR CENTER) | ||||
| 17507-28010 |
18RGEU,4AGEU,2TGEU,3T#..AA63,RA63,TA61,63 |
1 | ||
| 17430J - BOLT OR RING, EXHAUST TAIL PIPE(FOR CENTER) | ||||
| 90301-34207 |
12TJ,18RGEU,3AU,4AGEU,1C,5KJ,1SU,2TGEU,3T#..AA6#,CA6#,KA67,RA63,SA60,TA6# |
2 | ||
| 17430J - BOLT OR RING, EXHAUST TAIL PIPE(FOR CENTER) | ||||
| 90301-34207 |
12TJ,18RGEU,3AU,4AGEU,1C,5KJ,1SU,2TGEU,3T#..AA6#,CA6#,KA67,RA63,SA60,TA6# |
2 | ||
| 17430S - BRACKET, EXHAUST TAIL PIPE (FOR REAR) | ||||
| 17508-26100 |
18RGEU,3AU,4AGEU,1C,1SU,2TGEU,3T#..AA6#,CA60,RA63,SA60,TA61,63..CP,SED |
1 | ||
| 17430V - BOLT OR RING, EXHAUST TAIL PIPE (FOR REAR) | ||||
| 90301-34207 |
12TJ,18RGEU,3AU,4AGEU,1C,5KJ,1SU,2TGEU,3T#..AA6#,CA6#,KA67,RA63,SA60,TA6# |
2 | ||
| 17430V - BOLT OR RING, EXHAUST TAIL PIPE (FOR REAR) | ||||
| 90301-34207 |
12TJ,18RGEU,3AU,4AGEU,1C,5KJ,1SU,2TGEU,3T#..AA6#,CA6#,KA67,RA63,SA60,TA6# |
2 | ||
| 17448 - BAFFLE, TAIL PIPE | ||||
| 17448-70020 |
18RGEU,4AGEU,2TGEU,3T#..AA63,RA63,TA61,63 |
1 | ||
| 17451 - GASKET, EXHAUST PIPE | ||||
| 90917-06004 |
3AU,1SU,2TGEU,3TEU..AA60,SA60,TA61,63 CTR OR RR |
2 | ||
| 90917-06018 |
3AU,1SU,2TGEU,3TEU..AA60,SA60,TA61,63 FR |
1 | ||
| 17451 - GASKET, EXHAUST PIPE | ||||
| 90917-06004 |
3AU,1SU,2TGEU,3TEU..AA60,SA60,TA61,63 CTR OR RR |
2 | ||
| 90917-06018 |
3AU,1SU,2TGEU,3TEU..AA60,SA60,TA61,63 FR |
1 | ||
| 18435 - PROTECTOR, CATALYTIC CONVERTER | ||||
| 18407-26011 |
2TGEU,3TEU..TA61,63 |
1 | ||
| 18448 - BRACKET, CONVERTER PROTECTOR, CENTER | ||||
| 18448-26020 |
18RGEU,3AU,1SU,2TGEU,3TEU..AA60,RA63,SA60,TA61,63 |
2 | ||
| Common parts | ||||
| 90105-10023 | ||||
| 90119-06059 | ||||
| 90119-08281 | ||||
| 90179-06007 | ||||
| 91511-61070 | ||||
| 91611-60816 | ||||
| 91655-40820 | ||||
| 91656-40818 | ||||
| 94180-41000 | ||||
