RA63-ACMQF (1981)
Toyota Carina Fr
(8109-8507)CP
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 67001 - PANEL SUB-ASSY, FRONT DOOR, RH | ||||
| 67001-14280 |
AA6#,RA63,SA60,TA61,63..CP |
1 | ||
| 67002 - PANEL SUB-ASSY, FRONT DOOR, LH | ||||
| 67002-14310 |
AA6#,RA63,SA60,TA61,63..CP |
1 | ||
| 67111 - PANEL, FRONT DOOR, OUTER RH | ||||
| 67111-14210 |
AA6#,RA63,SA60,TA61,63..CP |
1 | ||
| 67112 - PANEL, FRONT DOOR, OUTER LH | ||||
| 67112-14220 |
AA6#,RA63,SA60,TA61,63..CP |
1 | ||
| 67139 - LINING, DOOR OUTSIDE PANEL REINFORCEMENT | ||||
| 67812-20050 |
AA60,CA6#,RA63,SA60,TA6# |
2 | ||
| 67401F - FRAME SUB-ASSY, FRONT DOOR, FRONT LOWER RH | ||||
| 67401-14140 |
AA60,RA63,SA60,TA61,63..CP |
1 | ||
| 67401F - FRAME SUB-ASSY, FRONT DOOR, FRONT LOWER RH | ||||
| 67401-14140 |
AA60,RA63,SA60,TA61,63..CP |
1 | ||
| 67402F - FRAME SUB-ASSY, FRONT DOOR, FRONT LOWER LH | ||||
| 67402-14140 |
AA60,RA63,SA60,TA61,63..CP |
1 | ||
| 67402F - FRAME SUB-ASSY, FRONT DOOR, FRONT LOWER LH | ||||
| 67402-14140 |
AA60,RA63,SA60,TA61,63..CP |
1 | ||
| 67433 - FRAME, FRONT DOOR WINDOW, REAR LOWER RH | ||||
| 67403-14040 |
AA6#,RA63,SA60,TA61,63..CP |
1 | ||
| 67434 - FRAME, FRONT DOOR WINDOW, REAR LOWER LH | ||||
| 67404-14040 |
AA6#,RA63,SA60,TA61,63..CP |
1 | ||
| 67491A - GARNISH, FRONT DOOR LOWER FRAME BRACKET, RH | ||||
| 67491-14080 |
AA60,RA63,SA60,TA61,63..CP W/FENDER MIRROR |
1 | ||
| 67491A - GARNISH, FRONT DOOR LOWER FRAME BRACKET, RH | ||||
| 67491-14080 |
AA60,RA63,SA60,TA61,63..CP W/FENDER MIRROR |
1 | ||
| 67492A - GARNISH, FRONT DOOR LOWER FRAME BRACKET, LH | ||||
| 67492-14080 |
AA60,RA63,SA60,TA61,63..CP W/FENDER MIRROR |
1 | ||
| 67492A - GARNISH, FRONT DOOR LOWER FRAME BRACKET, LH | ||||
| 67492-14080 |
AA60,RA63,SA60,TA61,63..CP W/FENDER MIRROR |
1 | ||
| 67601 - BOARD SUB-ASSY, FRONT DOOR TRIM, RH | ||||
| 67610-1B85006 |
RA63,TA61..CP W/*PW,DARK BROWN,BROWN,TRIM4# |
1 | ||
| 67610-1B82006 |
RA63,TA61..CP DARK BROWN,BROWN,TRIM4# |
1 | ||
| 67610-1B82004 |
RA63,TA61..CP BLUE,BLUE,TRIM8# |
1 | ||
| 67610-1B82001 |
RA63,TA61..CP BLACK,BLACK,TRIM2# |
1 | ||
| 67610-1B85001 |
RA63,TA61..CP W/*PW,BLACK,BLACK,TRIM2# |
1 | ||
| 67610-1B85004 |
RA63,TA61..CP W/*PW,BLUE,BLUE,TRIM8# |
1 | ||
| 67610-1D12004 |
RA63,TA61..CP COLD SPEC,BLUE,BLUE,TRIM8# |
1 | ||
| 67610-1D12006 |
RA63,TA61..CP COLD SPEC,DARK BROWN,BROWN,TRIM4# |
1 | ||
| 67610-1D14006 |
RA63,TA61..CP W/*PW & COLD SPEC,DARK BROWN,BROWN,TRIM4# |
1 | ||
| 67610-1D14001 |
RA63,TA61..CP W/*PW & COLD SPEC,BLACK,BLACK,TRIM2# |
1 | ||
| 67610-1D14004 |
RA63,TA61..CP W/*PW & COLD SPEC,BLUE,BLUE,TRIM8# |
1 | ||
| 67610-1D12001 |
RA63,TA61..CP COLD SPEC,BLACK,BLACK,TRIM2# |
1 | ||
| 67601A - RETAINER(FOR FRONT DOOR TRIM BOARD) | ||||
| 67771-14010 |
AA6#,CA6#,KA67,RA63,SA60,TA6# |
2 | ||
| 67601B - CLIP(FOR FRONT DOOR TRIM BOARD) | ||||
| 67771-12010 |
AA6#,CA6#,KA67,RA63,SA60,TA6# |
22 | ||
| 67602 - BOARD SUB-ASSY, FRONT DOOR TRIM, LH | ||||
| 67620-1B51004 |
RA63,TA61..CP BLUE,BLUE,TRIM8# |
1 | ||
| 67620-1B51001 |
RA63,TA61..CP BLACK,BLACK,TRIM2# |
1 | ||
| 67620-1B51006 |
RA63,TA61..CP DARK BROWN,BROWN,TRIM4# |
1 | ||
| 67620-1B52004 |
RA63,TA61..CP W/*PW,BLUE,BLUE,TRIM8# |
1 | ||
| 67620-1B52006 |
RA63,TA61..CP W/*PW,DARK BROWN,BROWN,TRIM4# |
1 | ||
| 67620-1B52001 |
RA63,TA61..CP W/*PW,BLACK,BLACK,TRIM2# |
1 | ||
| 67620-1B63004 |
RA63,TA61..CP COLD SPEC,BLUE,BLUE,TRIM8# |
1 | ||
| 67620-1B63001 |
RA63,TA61..CP COLD SPEC,BLACK,BLACK,TRIM2# |
1 | ||
| 67620-1B65001 |
RA63,TA61..CP W/*PW & COLD SPEC,BLACK,BLACK,TRIM2# |
1 | ||
| 67620-1B63006 |
RA63,TA61..CP COLD SPEC,DARK BROWN,BROWN,TRIM4# |
1 | ||
| 67620-1B65004 |
RA63,TA61..CP W/*PW & COLD SPEC,BLUE,BLUE,TRIM8# |
1 | ||
| 67620-1B65006 |
RA63,TA61..CP W/*PW & COLD SPEC,DARK BROWN,BROWN,TRIM4# |
1 | ||
| 67777 - POCKET, FRONT DOOR TRIM, RH | ||||
| 67770-1401004 |
RA63,TA61,63..GT,SE BLUE,BLUE,TRIM8# |
1 | ||
| 67770-1401005 |
RA63,TA61,63..GT,SE BEIGE,BEIGE,TRIM4# |
1 | ||
| 67770-1401003 |
RA63,TA61,63..GT,GTT,SE GRAY,GRAY,TRIM2# |
1 | ||
| 67831 - COVER, FRONT DOOR SERVICE HOLE, RH | ||||
| 67831-14160 |
AA60,RA63,TA61,63..CP..(GT,GTT,SE) |
1 | ||
| 67832 - COVER, FRONT DOOR SERVICE HOLE, LH | ||||
| 67832-14080 |
AA60,RA63,TA61,63..CP..(GT,GTT,SE) |
1 | ||
| 67861 - WEATHERSTRIP, FRONT DOOR, RH | ||||
| 67861-14270 |
AA6#,RA63,SA60,TA61,63..CP |
1 | ||
| 67862 - WEATHERSTRIP, FRONT DOOR, LH | ||||
| 67862-14270 |
AA6#,RA63,SA60,TA61,63..CP |
1 | ||
| 68101 - GLASS SUB-ASSY, FRONT DOOR, RH | ||||
| 68111-14280 |
AA60,RA63,SA60,TA61,63..CP T=4.0,*TT |
1 | ||
| 68102 - GLASS SUB-ASSY, FRONT DOOR, LH | ||||
| 68112-14290 |
AA60,RA63,SA60,TA61,63..CP T=4.0,*TT |
1 | ||
| 68141 - RUN, FRONT DOOR GLASS | ||||
| 68141-14070 |
AA60,RA63,SA60,TA61,63..CP RH |
1 | ||
| 68151-14010 |
AA60,RA63,SA60,TA61,63..CP LH |
1 | ||
| 68143 - RUN, FRONT DOOR GLASS, LOWER | ||||
| 68143-22020 |
AA6#,RA63,SA60,TA61,63..CP |
2 | ||
| 68170 - WEATHERSTRIP ASSY, FRONT DOOR GLASS, INNER | ||||
| 68170-14170 |
AA60,RA63,SA60,TA61,63..CP RH |
1 | ||
| 68220-14150 |
AA60,RA63,SA60,TA61,63..CP LH |
1 | ||
| 68194 - SEAL, FRONT DOOR BELT, RH | ||||
| 68194-14010 |
AA6#,RA63,SA60,TA61,63..CP |
1 | ||
| 68195 - SEAL, FRONT DOOR BELT, LH | ||||
| 68195-14010 |
AA6#,RA63,SA60,TA61,63..CP |
1 | ||
| 68610 - CHECK ASSY, FRONT DOOR | ||||
| 68610-14050 |
AA6#,RA63,SA60,TA61,63..CP |
2 | ||
| 68610A - PIN(FOR FRONT DOOR CHECK) | ||||
| 68617-30010 |
AA6#,RA63,SA60,TA61,63..CP |
2 | ||
| Common parts | ||||
| 67772-22010 | ||||
| 90159-40074 | ||||
| 90168-40025 | ||||
| 90179-06070 | ||||
| 90183-04057 | ||||
| 91651-40612 | ||||
| 93319-15012 | ||||
| 93530-54014 | ||||
| Linked diagrams | ||||
| 7404 | ||||
| 8121 | ||||
| 8202 | ||||
