RA63-ACMQF (1981)
Toyota Carina Fr
(8109-8210)18RGEU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 13506 - CHAIN SUB-ASSY | ||||
| 13506-33010 |
18RGEU..RA63 |
1 | ||
| 13507 - CHAIN SUB-ASSY, NO.2 | ||||
| 13507-88210 |
18RGEU..RA63 |
1 | ||
| 13511 - CAMSHAFT | ||||
| 13501-88270 |
18RGEU..RA63 |
1 | ||
| 13511A - PIN, STRAIGHT(FOR CAMSHAFT KNOCK) | ||||
| 90072-25005 |
18RGEU..RA63 |
2 | ||
| 13511A - PIN, STRAIGHT(FOR CAMSHAFT KNOCK) | ||||
| 90072-25005 |
18RGEU..RA63 |
2 | ||
| 13512 - CAMSHAFT, NO.2 | ||||
| 13502-88270 |
18RGEU..RA63 |
1 | ||
| 13515 - GEAR, DISTRIBUTOR DRIVE | ||||
| 13515-88211 |
18RGEU..RA63 |
1 | ||
| 13515B - KEY, WOODRUFF(FOR DISTRIBUTOR DRIVE GEAR) | ||||
| 90280-05010 |
18RGEU..RA63 |
1 | ||
| 13522 - GEAR, PUMP DRIVE SHAFT | ||||
| 13522-33010 |
18RGEU..RA63 |
1 | ||
| 13522A - KEY, WOODRUFF(FOR PUMP DRIVE SHAFT GEAR) | ||||
| 90280-05001 |
18RGEU..RA63 |
1 | ||
| 13523 - GEAR OR SPROCKET, CAMSHAFT TIMING | ||||
| 13523-88220 |
18RGEU..RA63 |
2 | ||
| 13523 - GEAR OR SPROCKET, CAMSHAFT TIMING | ||||
| 13523-88220 |
18RGEU..RA63 |
2 | ||
| 13528 - GEAR, CAMSHAFT DRIVE | ||||
| 13528-33010 |
18RGEU..RA63 |
1 | ||
| 13540 - TENSIONER ASSY, CHAIN, NO.1 | ||||
| 13540-33014 |
18RGEU..RA63 |
1 | ||
| 13547 - PLATE, TENSIONER BOLT LOCK, NO.1 | ||||
| 13547-33010 |
18RGEU..RA63 |
1 | ||
| 13547A - BOLT(FOR TENSIONER LOCK PLATE SET) | ||||
| 90119-08013 |
18RGEU..RA63 |
1 | ||
| 13547B - BOLT, UNION(FOR TENSIONER LOCK PLATE) | ||||
| 90401-10049 |
18RGEU..RA63 |
1 | ||
| 13550 - TENSIONER ASSY, CHAIN, NO.2 | ||||
| 13550-88270 |
18RGEU..RA63 |
1 | ||
| 13550B - GASKET, CHAIN TENSIONER, NO.2 | ||||
| 90430-22135 |
18RGEU..RA63 |
1 | ||
| 13553 - COVER, CHAIN TENSIONER DUST | ||||
| 13553-88210 |
18RGEU..RA63 |
1 | ||
| 13559 - SLIPPER, CHAIN TENSIONER | ||||
| 13559-88270 |
18RGEU..RA63 |
1 | ||
| 13559A - RING, E(FOR CHAIN TENSIONER SLIPPER) | ||||
| 96160-00700 |
18RGEU..RA63 |
1 | ||
| 13561 - DAMPER, CHAIN VIBRATION, NO.1 | ||||
| 13561-34010 |
18RGEU..RA63 |
1 | ||
| 13562 - DAMPER, CHAIN VIBRATION, NO.2 | ||||
| 13562-88210 |
18RGEU..RA63 |
1 | ||
| 13563 - DAMPER, CHAIN VIBRATION, NO.3 | ||||
| 13563-88250 |
18RGEU..RA63 |
1 | ||
| 13574 - PLATE, PUMP DRIVE SHAFT | ||||
| 13574-33010 |
18RGEU..RA63 |
1 | ||
| 13612 - SHAFT, PUMP DRIVE | ||||
| 13612-88270 |
18RGEU..RA63 |
1 | ||
| 13711 - VALVE, INTAKE | ||||
| 13711-88212 |
18RGEU..RA63 |
4 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90072-72206 |
18RGEU..RA63 |
8 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90072-72206 |
18RGEU..RA63 |
8 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90072-50137 |
18RGEU..RA63 |
8 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90072-50137 |
18RGEU..RA63 |
8 | ||
| 13711C - SPRING, COMPRESSION(FOR OUTER) | ||||
| 90072-50136 |
18RGEU..RA63 |
8 | ||
| 13711C - SPRING, COMPRESSION(FOR OUTER) | ||||
| 90072-50136 |
18RGEU..RA63 |
8 | ||
| 13715 - VALVE, EXHAUST | ||||
| 13715-88222 |
18RGEU..RA63 |
4 | ||
| 13734 - SEAT, VALVE SPRING | ||||
| 13734-88211 |
18RGEU..RA63 |
8 | ||
| 13734 - SEAT, VALVE SPRING | ||||
| 13734-88211 |
18RGEU..RA63 |
8 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-88211 |
18RGEU..RA63 |
8 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-88211 |
18RGEU..RA63 |
8 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03010 |
18RGEU..RA63 |
16 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03010 |
18RGEU..RA63 |
16 | ||
| 13751 - LIFTER, VALVE | ||||
| 13751-8821003 |
18RGEU..RA63 OD=37.937-37.943,YELLOW,GRAY |
8 | ||
| 13751-8821004 |
18RGEU..RA63 OD=37.943-37.949,RED,BLUE |
8 | ||
| 13751-8821001 |
18RGEU..RA63 OD=37.925-37.931,BLACK,BLACK |
8 | ||
| 13751-8821002 |
18RGEU..RA63 OD=37.931-37.937,BLUE,RED/MAROON |
8 | ||
| 13751 - LIFTER, VALVE | ||||
| 13751-8821003 |
18RGEU..RA63 OD=37.937-37.943,YELLOW,GRAY |
8 | ||
| 13751-8821004 |
18RGEU..RA63 OD=37.943-37.949,RED,BLUE |
8 | ||
| 13751-8821001 |
18RGEU..RA63 OD=37.925-37.931,BLACK,BLACK |
8 | ||
| 13751-8821002 |
18RGEU..RA63 OD=37.931-37.937,BLUE,RED/MAROON |
8 | ||
| 13751D - PAD, VALVE ADJUSTING | ||||
| 90072-72601 |
18RGEU..RA63 T=1.00 |
8 | ||
| 90072-72603 |
18RGEU..RA63 T=1.05 |
8 | ||
| 90072-72607 |
18RGEU..RA63 T=1.15 |
8 | ||
| 90072-72609 |
18RGEU..RA63 T=1.20 |
8 | ||
| 90072-72605 |
18RGEU..RA63 T=1.10 |
8 | ||
| 90072-72617 |
18RGEU..RA63 T=1.40 |
8 | ||
| 90072-72615 |
18RGEU..RA63 T=1.35 |
8 | ||
| 90072-72619 |
18RGEU..RA63 T=1.45 |
8 | ||
| 90072-72611 |
18RGEU..RA63 T=1.25 |
8 | ||
| 90072-72613 |
18RGEU..RA63 T=1.30 |
8 | ||
| 90072-72625 |
18RGEU..RA63 T=1.60 |
8 | ||
| 90072-72621 |
18RGEU..RA63 T=1.50 |
8 | ||
| 90072-72631 |
18RGEU..RA63 T=1.75 |
8 | ||
| 90072-72627 |
18RGEU..RA63 T=1.65 |
8 | ||
| 90072-72633 |
18RGEU..RA63 T=1.80 |
8 | ||
| 90072-72623 |
18RGEU..RA63 T=1.55 |
8 | ||
| 90072-72629 |
18RGEU..RA63 T=1.70 |
8 | ||
| 90072-72639 |
18RGEU..RA63 T=1.95 |
8 | ||
| 90072-72635 |
18RGEU..RA63 T=1.85 |
8 | ||
| 90072-72641 |
18RGEU..RA63 T=2.00 |
8 | ||
| 90072-72649 |
18RGEU..RA63 T=2.20 |
8 | ||
| 90072-72647 |
18RGEU..RA63 T=2.15 |
8 | ||
| 90072-72643 |
18RGEU..RA63 T=2.05 |
8 | ||
| 90072-72637 |
18RGEU..RA63 T=1.90 |
8 | ||
| 90072-72645 |
18RGEU..RA63 T=2.10 |
8 | ||
| 90072-72651 |
18RGEU..RA63 T=2.25 |
8 | ||
| 90072-72653 |
18RGEU..RA63 T=2.30 |
8 | ||
| 90072-72659 |
18RGEU..RA63 T=2.45 |
8 | ||
| 90072-72655 |
18RGEU..RA63 T=2.35 |
8 | ||
| 90072-72657 |
18RGEU..RA63 T=2.40 |
8 | ||
| 90072-72661 |
18RGEU..RA63 T=2.50 |
8 | ||
| 90072-72665 |
18RGEU..RA63 T=2.60 |
8 | ||
| 90072-72667 |
18RGEU..RA63 T=2.65 |
8 | ||
| 90072-72673 |
18RGEU..RA63 T=2.80 |
8 | ||
| 90072-72663 |
18RGEU..RA63 T=2.55 |
8 | ||
| 90072-72677 |
18RGEU..RA63 T=2.90 |
8 | ||
| 90072-72675 |
18RGEU..RA63 T=2.85 |
8 | ||
| 90072-72669 |
18RGEU..RA63 T=2.70 |
8 | ||
| 90072-72679 |
18RGEU..RA63 T=2.95 |
8 | ||
| 90072-72681 |
18RGEU..RA63 T=3.00 |
8 | ||
| 90072-72671 |
18RGEU..RA63 T=2.75 |
8 | ||
| 13751D - PAD, VALVE ADJUSTING | ||||
| 90072-72601 |
18RGEU..RA63 T=1.00 |
8 | ||
| 90072-72603 |
18RGEU..RA63 T=1.05 |
8 | ||
| 90072-72607 |
18RGEU..RA63 T=1.15 |
8 | ||
| 90072-72609 |
18RGEU..RA63 T=1.20 |
8 | ||
| 90072-72605 |
18RGEU..RA63 T=1.10 |
8 | ||
| 90072-72617 |
18RGEU..RA63 T=1.40 |
8 | ||
| 90072-72615 |
18RGEU..RA63 T=1.35 |
8 | ||
| 90072-72619 |
18RGEU..RA63 T=1.45 |
8 | ||
| 90072-72611 |
18RGEU..RA63 T=1.25 |
8 | ||
| 90072-72613 |
18RGEU..RA63 T=1.30 |
8 | ||
| 90072-72625 |
18RGEU..RA63 T=1.60 |
8 | ||
| 90072-72621 |
18RGEU..RA63 T=1.50 |
8 | ||
| 90072-72631 |
18RGEU..RA63 T=1.75 |
8 | ||
| 90072-72627 |
18RGEU..RA63 T=1.65 |
8 | ||
| 90072-72633 |
18RGEU..RA63 T=1.80 |
8 | ||
| 90072-72623 |
18RGEU..RA63 T=1.55 |
8 | ||
| 90072-72629 |
18RGEU..RA63 T=1.70 |
8 | ||
| 90072-72639 |
18RGEU..RA63 T=1.95 |
8 | ||
| 90072-72635 |
18RGEU..RA63 T=1.85 |
8 | ||
| 90072-72641 |
18RGEU..RA63 T=2.00 |
8 | ||
| 90072-72649 |
18RGEU..RA63 T=2.20 |
8 | ||
| 90072-72647 |
18RGEU..RA63 T=2.15 |
8 | ||
| 90072-72643 |
18RGEU..RA63 T=2.05 |
8 | ||
| 90072-72637 |
18RGEU..RA63 T=1.90 |
8 | ||
| 90072-72645 |
18RGEU..RA63 T=2.10 |
8 | ||
| 90072-72651 |
18RGEU..RA63 T=2.25 |
8 | ||
| 90072-72653 |
18RGEU..RA63 T=2.30 |
8 | ||
| 90072-72659 |
18RGEU..RA63 T=2.45 |
8 | ||
| 90072-72655 |
18RGEU..RA63 T=2.35 |
8 | ||
| 90072-72657 |
18RGEU..RA63 T=2.40 |
8 | ||
| 90072-72661 |
18RGEU..RA63 T=2.50 |
8 | ||
| 90072-72665 |
18RGEU..RA63 T=2.60 |
8 | ||
| 90072-72667 |
18RGEU..RA63 T=2.65 |
8 | ||
| 90072-72673 |
18RGEU..RA63 T=2.80 |
8 | ||
| 90072-72663 |
18RGEU..RA63 T=2.55 |
8 | ||
| 90072-72677 |
18RGEU..RA63 T=2.90 |
8 | ||
| 90072-72675 |
18RGEU..RA63 T=2.85 |
8 | ||
| 90072-72669 |
18RGEU..RA63 T=2.70 |
8 | ||
| 90072-72679 |
18RGEU..RA63 T=2.95 |
8 | ||
| 90072-72681 |
18RGEU..RA63 T=3.00 |
8 | ||
| 90072-72671 |
18RGEU..RA63 T=2.75 |
8 | ||
| Common parts | ||||
| 90072-20110 | ||||
| 90072-20111 | ||||
| 90072-20914 | ||||
| 90101-14010 | ||||
| 90119-08028 | ||||
| 90202-08039 | ||||
| 91162-51228 | ||||
| 91611-60814 | ||||
| 91611-60816 | ||||
