ST215-CEPEK (1996)
Toyota Carina Ff
(9608-9808)ST215..4FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 36148 - SHIM, PINION BEARING CAGE | ||||
| 36148-32030 |
CT215,ST215 厚さ=0.36,ﾏｰｸ C |
1 | ||
| 36148-32010 |
CT215,ST215 厚さ=0.30,ﾏｰｸ A |
1 | ||
| 36148-32070 |
CT215,ST215 厚さ=0.48,ﾏｰｸ G |
1 | ||
| 36148-32040 |
CT215,ST215 厚さ=0.39,ﾏｰｸ D |
1 | ||
| 36148-32020 |
CT215,ST215 厚さ=0.33,ﾏｰｸ B |
1 | ||
| 36148-32100 |
CT215,ST215 厚さ=0.57,ﾏｰｸ K |
1 | ||
| 36148-32090 |
CT215,ST215 厚さ=0.54,ﾏｰｸ J |
1 | ||
| 36148-32060 |
CT215,ST215 厚さ=0.45,ﾏｰｸ F |
1 | ||
| 36148-32080 |
CT215,ST215 厚さ=0.51,ﾏｰｸ H |
1 | ||
| 36148-32050 |
CT215,ST215 厚さ=0.42,ﾏｰｸ E |
1 | ||
| 41117A - RESERVOIR, CENTER DIFFERENTIAL OIL | ||||
| 41117-12020 |
ST215..4FC |
1 | ||
| 41201K - BEARING (FOR TRANSFER DRIVEN PINION FRONT) | ||||
| 90366-40052 |
ST215..4FC |
1 | ||
| 41201L - BEARING (FOR TRANSFER DRIVEN PINION REAR) | ||||
| 90366-32019 |
CT215,ST215 |
1 | ||
| 41201P - GEAR KIT, TRANSFER | ||||
| 41201-12160 |
ST215..4FC |
1 | ||
| 41201Q - NUT (FOR TRANSFER GEAR) | ||||
| 90179-30004 |
CT215,ST215 |
1 | ||
| 41222C - BOLT (FOR TRANSFER RING GEAR) | ||||
| 90105-11028 |
ST215..4FC |
12 | ||
| 41231B - SPACER, TRANSFER PINION BEARING | ||||
| 41231-12040 |
CT215,ST215 |
1 | ||
| 41301K - CASE SUB-ASSY, CENTER DIFFERENTIAL RING GEAR MOUNTING | ||||
| 41301-12151 |
ST215..4FC |
1 | ||
| 41301-12152 |
ST215..4FC |
1 | ||
| 41311M - CASE, CENTER DIFFERENTIAL | ||||
| 41311-12122 |
ST215..4FC |
1 | ||
| 41311-12121 |
ST215..4FC |
1 | ||
| 41311N - BEARING, TAPERED ROLLER (FOR CENTER DIFFERENTIAL CASE) | ||||
| 90366-62001 |
ST215..4FC 左側 |
1 | ||
| 90366-54011 |
ST215..4FC 右側 |
1 | ||
| 41311N - BEARING, TAPERED ROLLER (FOR CENTER DIFFERENTIAL CASE) | ||||
| 90366-62001 |
ST215..4FC 左側 |
1 | ||
| 90366-54011 |
ST215..4FC 右側 |
1 | ||
| 41311U - SHIM (FOR TRANSFER RING GEAR) | ||||
| 90564-64002 |
ST215..4FC 厚さ=2.16,ﾏｰｸ 72 |
1 | ||
| 90564-64003 |
ST215..4FC 厚さ=2.19,ﾏｰｸ 73 |
1 | ||
| 90564-64005 |
ST215..4FC 厚さ=2.25,ﾏｰｸ 75 |
1 | ||
| 90564-64006 |
ST215..4FC 厚さ=2.28,ﾏｰｸ 76 |
1 | ||
| 90564-64004 |
ST215..4FC 厚さ=2.22,ﾏｰｸ 74 |
1 | ||
| 90564-64009 |
ST215..4FC 厚さ=2.37,ﾏｰｸ 79 |
1 | ||
| 90564-64012 |
ST215..4FC 厚さ=2.46,ﾏｰｸ 82 |
1 | ||
| 90564-64010 |
ST215..4FC 厚さ=2.40,ﾏｰｸ 80 |
1 | ||
| 90564-64008 |
ST215..4FC 厚さ=2.34,ﾏｰｸ 78 |
1 | ||
| 90564-64007 |
ST215..4FC 厚さ=2.31,ﾏｰｸ 77 |
1 | ||
| 90564-64001 |
ST215..4FC 厚さ=2.13,ﾏｰｸ 71 |
1 | ||
| 90564-64015 |
ST215..4FC 厚さ=2.55,ﾏｰｸ 85 |
1 | ||
| 90564-64014 |
ST215..4FC 厚さ=2.52,ﾏｰｸ 84 |
1 | ||
| 90564-64013 |
ST215..4FC 厚さ=2.49,ﾏｰｸ 83 |
1 | ||
| 90564-64028 |
ST215..4FC 厚さ=2.82,ﾏｰｸ 94 |
1 | ||
| 90564-64019 |
ST215..4FC 厚さ=2.64,ﾏｰｸ 88 |
1 | ||
| 90564-64016 |
ST215..4FC 厚さ=2.58,ﾏｰｸ 86 |
1 | ||
| 90564-64020 |
ST215..4FC 厚さ=2.67,ﾏｰｸ 89 |
1 | ||
| 90564-64027 |
ST215..4FC 厚さ=2.79,ﾏｰｸ 93 |
1 | ||
| 90564-64018 |
ST215..4FC 厚さ=2.61,ﾏｰｸ 87 |
1 | ||
| 90564-64021 |
ST215..4FC 厚さ=2.70,ﾏｰｸ 90 |
1 | ||
| 90564-64026 |
ST215..4FC 厚さ=2.76,ﾏｰｸ 92 |
1 | ||
| 90564-64022 |
ST215..4FC 厚さ=2.73,ﾏｰｸ 91 |
1 | ||
| 90564-64011 |
ST215..4FC 厚さ=2.43,ﾏｰｸ 81 |
1 | ||
| 41313A - RING, O (FOR CENTER DIFFERENTIAL RING GEAR MOUNTING CAS | ||||
| 90301-99053 |
ST215..4FC |
1 | ||
| 41315C - NUT, TRANSFER GEAR ADJUST | ||||
| 41315-12040 |
ST215..4FC |
1 | ||
| 41315D - BOLT (FOR TRANSFER GEAR ADJUST NUT) | ||||
| 90109-08162 |
ST215..4FC |
1 | ||
| 41315E - RING, O (FOR TRANSFER GEAR ADJUST NUT BOLT) | ||||
| 90301-06196 |
ST215..4FC |
1 | ||
| 41316B - PLATE, ADJUSTING NUT LOCK | ||||
| 41316-32010 |
ST215..4FC |
1 | ||
| 41331B - GEAR, CENTER DIFFERENTIAL SIDE | ||||
| 41331-32050 |
ST215..4FC 左側 |
1 | ||
| 41331-32040 |
ST215..4FC 右側 |
1 | ||
| 41331B - GEAR, CENTER DIFFERENTIAL SIDE | ||||
| 41331-32050 |
ST215..4FC 左側 |
1 | ||
| 41331-32040 |
ST215..4FC 右側 |
1 | ||
| 41331C - RING, SHAFT SNAP(FOR PINION SHAFT SPACER) | ||||
| 90520-89001 |
ST215..4FC |
1 | ||
| 41335A - HOLDER, DIFFERENTIAL SIDE GEAR SHAFT | ||||
| 41335-32010 |
ST215..4FC |
1 | ||
| 41335B - RING, SHAFT SNAP (FOR SIDE GEAR SHAFT HOLDER) | ||||
| 90520-40001 |
CT215,ST215 |
1 | ||
| 41335C - RING, HOLE SNAP (FOR SIDE GEAR SHAFT HOLDER) | ||||
| 90521-76004 |
ST215..4FC |
1 | ||
| 41335D - BEARING (FOR SIDE GEAR SHAFT HOLDER) | ||||
| 90365-44006 |
CT215,ST215 |
1 | ||
| 41341A - PINION, CENTER DIFFERENTIAL | ||||
| 41341-32030 |
ST215..4FC |
4 | ||
| 41341A - PINION, CENTER DIFFERENTIAL | ||||
| 41341-32030 |
ST215..4FC |
4 | ||
| 41341A - PINION, CENTER DIFFERENTIAL | ||||
| 41341-32030 |
ST215..4FC |
4 | ||
| 41341A - PINION, CENTER DIFFERENTIAL | ||||
| 41341-32030 |
ST215..4FC |
4 | ||
| 41342C - SHAFT, CENTER DIFFERENTIAL PINION | ||||
| 41342-12071 |
ST215..4FC ﾚｯﾄﾞ ﾍﾟｲﾝﾄ |
4 | ||
| 41342-12100 |
ST215..4FC ｸﾞﾘｰﾝ ﾍﾟｲﾝﾄ |
4 | ||
| 41342C - SHAFT, CENTER DIFFERENTIAL PINION | ||||
| 41342-12071 |
ST215..4FC ﾚｯﾄﾞ ﾍﾟｲﾝﾄ |
4 | ||
| 41342-12100 |
ST215..4FC ｸﾞﾘｰﾝ ﾍﾟｲﾝﾄ |
4 | ||
| 41342C - SHAFT, CENTER DIFFERENTIAL PINION | ||||
| 41342-12071 |
ST215..4FC ﾚｯﾄﾞ ﾍﾟｲﾝﾄ |
4 | ||
| 41342-12100 |
ST215..4FC ｸﾞﾘｰﾝ ﾍﾟｲﾝﾄ |
4 | ||
| 41342C - SHAFT, CENTER DIFFERENTIAL PINION | ||||
| 41342-12071 |
ST215..4FC ﾚｯﾄﾞ ﾍﾟｲﾝﾄ |
4 | ||
| 41342-12100 |
ST215..4FC ｸﾞﾘｰﾝ ﾍﾟｲﾝﾄ |
4 | ||
| 41344A - SPACER, CENTER DIFFERENTIAL PINION SHAFT, NO.1 | ||||
| 41344-12011 |
ST215..4FC |
1 | ||
| 41351A - WASHER, CENTER DIFFERENTIAL PINION TRUST | ||||
| 41351-12050 |
ST215..4FC |
4 | ||
| 41351A - WASHER, CENTER DIFFERENTIAL PINION TRUST | ||||
| 41351-12050 |
ST215..4FC |
4 | ||
| 41351A - WASHER, CENTER DIFFERENTIAL PINION TRUST | ||||
| 41351-12050 |
ST215..4FC |
4 | ||
| 41351A - WASHER, CENTER DIFFERENTIAL PINION TRUST | ||||
| 41351-12050 |
ST215..4FC |
4 | ||
| 41361B - WASHER, CENTER DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-12140 |
ST215..4FC 厚さ=1.05,ﾏｰｸ B |
1 | ||
| 41361-12200 |
ST215..4FC 厚さ=1.35,ﾏｰｸ H |
1 | ||
| 41361-12160 |
ST215..4FC 厚さ=1.15,ﾏｰｸ D |
1 | ||
| 41361-12170 |
ST215..4FC 厚さ=1.20,ﾏｰｸ E |
1 | ||
| 41361-12180 |
ST215..4FC 厚さ=1.25,ﾏｰｸ F |
1 | ||
| 41361-12190 |
ST215..4FC 厚さ=1.30,ﾏｰｸ G |
1 | ||
| 41361-12210 |
ST215..4FC 厚さ=1.40,ﾏｰｸ J |
1 | ||
| 41361-12130 |
ST215..4FC 厚さ=1.00,ﾏｰｸ A |
1 | ||
| 41361-12150 |
ST215..4FC 厚さ=1.10,ﾏｰｸ C |
1 | ||
| 41361D - WASHER, CENTER DIFFERENTIAL SIDE GEAR THRUST, NO.2 | ||||
| 41361-12230 |
ST215..4FC 厚さ=1.05,ﾏｰｸ B |
1 | ||
| 41361-12220 |
ST215..4FC 厚さ=1.00,ﾏｰｸ A |
1 | ||
| 41361-12260 |
ST215..4FC 厚さ=1.20,ﾏｰｸ E |
1 | ||
| 41361-12240 |
ST215..4FC 厚さ=1.10,ﾏｰｸ C |
1 | ||
| 41361-12270 |
ST215..4FC 厚さ=1.25,ﾏｰｸ F |
1 | ||
| 41361-12280 |
ST215..4FC 厚さ=1.30,ﾏｰｸ G |
1 | ||
| 41361-12320 |
ST215..4FC 厚さ=1.50,ﾏｰｸ L |
1 | ||
| 41361-12310 |
ST215..4FC 厚さ=1.45,ﾏｰｸ K |
1 | ||
| 41361-12250 |
ST215..4FC 厚さ=1.15,ﾏｰｸ D |
1 | ||
| 41361-12290 |
ST215..4FC 厚さ=1.35,ﾏｰｸ H |
1 | ||
| 41361-12300 |
ST215..4FC 厚さ=1.40,ﾏｰｸ J |
1 | ||
| 41361H - WASHER, CONICAL SPRING(FOR CENTER DIFFERENTIAL SIDE GEA | ||||
| 90208-40001 |
ST215..4FC |
1 | ||
| 41375C - HOLDER, CENTER DIFFERENTIAL PINION SHAFT | ||||
| 41375-12040 |
ST215..4FC |
1 | ||
| Common parts | ||||
| 90364-35007 | ||||
| 90364-55001 | ||||
| 90364-82001 | ||||
