ST162-AEMVF (1985)
Toyota Carina Ff
(8508- )3SGELU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11011 - WASHER SET, CRANKSHAFT THRUST | ||||
| 11011-25010 |
1SILU,3SGELU..ST150,162 STD |
1 | ||
| 11702 - BEARING SET, CRANKSHAFT | ||||
| 11704-88360 |
3SGELU..ST162 U/S 0.25,U/S 0.25,*54 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-8836001 |
3SGELU..ST162 NO.3 MARK"1",MARK 1 |
1 | ||
| 11701-8836002 |
3SGELU..ST162 NO.1,2,4,5 MARK"2",MARK 2 |
4 | ||
| 11701-8836003 |
3SGELU..ST162 NO.1,2,4,5 MARK"3",MARK 3 |
4 | ||
| 11071-8836002 |
3SGELU..ST162 NO.3 MARK"2",MARK 2 |
1 | ||
| 11071-8836003 |
3SGELU..ST162 NO.3 MARK"3",MARK 3 |
1 | ||
| 11701-8836001 |
3SGELU..ST162 NO.1,2,4,5 MARK"1",MARK 1 |
4 | ||
| 11071-8836005 |
3SGELU..ST162 NO.3 MARK"5",MARK 5 |
1 | ||
| 11701-8836004 |
3SGELU..ST162 NO.1,2,4,5 MARK"4",MARK 4 |
4 | ||
| 11071-8836004 |
3SGELU..ST162 NO.3 MARK"4",MARK 4 |
1 | ||
| 11701-8836005 |
3SGELU..ST162 NO.1,2,4,5 MARK"5",MARK 5 |
4 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-8836001 |
3SGELU..ST162 NO.3 MARK"1",MARK 1 |
1 | ||
| 11701-8836002 |
3SGELU..ST162 NO.1,2,4,5 MARK"2",MARK 2 |
4 | ||
| 11701-8836003 |
3SGELU..ST162 NO.1,2,4,5 MARK"3",MARK 3 |
4 | ||
| 11071-8836002 |
3SGELU..ST162 NO.3 MARK"2",MARK 2 |
1 | ||
| 11071-8836003 |
3SGELU..ST162 NO.3 MARK"3",MARK 3 |
1 | ||
| 11701-8836001 |
3SGELU..ST162 NO.1,2,4,5 MARK"1",MARK 1 |
4 | ||
| 11071-8836005 |
3SGELU..ST162 NO.3 MARK"5",MARK 5 |
1 | ||
| 11701-8836004 |
3SGELU..ST162 NO.1,2,4,5 MARK"4",MARK 4 |
4 | ||
| 11071-8836004 |
3SGELU..ST162 NO.3 MARK"4",MARK 4 |
1 | ||
| 11701-8836005 |
3SGELU..ST162 NO.1,2,4,5 MARK"5",MARK 5 |
4 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-8836001 |
3SGELU..ST162 NO.3 MARK"1",MARK 1 |
1 | ||
| 11701-8836002 |
3SGELU..ST162 NO.1,2,4,5 MARK"2",MARK 2 |
4 | ||
| 11701-8836003 |
3SGELU..ST162 NO.1,2,4,5 MARK"3",MARK 3 |
4 | ||
| 11071-8836002 |
3SGELU..ST162 NO.3 MARK"2",MARK 2 |
1 | ||
| 11071-8836003 |
3SGELU..ST162 NO.3 MARK"3",MARK 3 |
1 | ||
| 11701-8836001 |
3SGELU..ST162 NO.1,2,4,5 MARK"1",MARK 1 |
4 | ||
| 11071-8836005 |
3SGELU..ST162 NO.3 MARK"5",MARK 5 |
1 | ||
| 11701-8836004 |
3SGELU..ST162 NO.1,2,4,5 MARK"4",MARK 4 |
4 | ||
| 11071-8836004 |
3SGELU..ST162 NO.3 MARK"4",MARK 4 |
1 | ||
| 11701-8836005 |
3SGELU..ST162 NO.1,2,4,5 MARK"5",MARK 5 |
4 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-8836001 |
3SGELU..ST162 NO.3 MARK"1",MARK 1 |
1 | ||
| 11701-8836002 |
3SGELU..ST162 NO.1,2,4,5 MARK"2",MARK 2 |
4 | ||
| 11701-8836003 |
3SGELU..ST162 NO.1,2,4,5 MARK"3",MARK 3 |
4 | ||
| 11071-8836002 |
3SGELU..ST162 NO.3 MARK"2",MARK 2 |
1 | ||
| 11071-8836003 |
3SGELU..ST162 NO.3 MARK"3",MARK 3 |
1 | ||
| 11701-8836001 |
3SGELU..ST162 NO.1,2,4,5 MARK"1",MARK 1 |
4 | ||
| 11071-8836005 |
3SGELU..ST162 NO.3 MARK"5",MARK 5 |
1 | ||
| 11701-8836004 |
3SGELU..ST162 NO.1,2,4,5 MARK"4",MARK 4 |
4 | ||
| 11071-8836004 |
3SGELU..ST162 NO.3 MARK"4",MARK 4 |
1 | ||
| 11701-8836005 |
3SGELU..ST162 NO.1,2,4,5 MARK"5",MARK 5 |
4 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-8836001 |
3SGELU..ST162 NO.3 MARK"1",MARK 1 |
1 | ||
| 11701-8836002 |
3SGELU..ST162 NO.1,2,4,5 MARK"2",MARK 2 |
4 | ||
| 11701-8836003 |
3SGELU..ST162 NO.1,2,4,5 MARK"3",MARK 3 |
4 | ||
| 11071-8836002 |
3SGELU..ST162 NO.3 MARK"2",MARK 2 |
1 | ||
| 11071-8836003 |
3SGELU..ST162 NO.3 MARK"3",MARK 3 |
1 | ||
| 11701-8836001 |
3SGELU..ST162 NO.1,2,4,5 MARK"1",MARK 1 |
4 | ||
| 11071-8836005 |
3SGELU..ST162 NO.3 MARK"5",MARK 5 |
1 | ||
| 11701-8836004 |
3SGELU..ST162 NO.1,2,4,5 MARK"4",MARK 4 |
4 | ||
| 11071-8836004 |
3SGELU..ST162 NO.3 MARK"4",MARK 4 |
1 | ||
| 11701-8836005 |
3SGELU..ST162 NO.1,2,4,5 MARK"5",MARK 5 |
4 | ||
| 13011 - RING SET, PISTON | ||||
| 13011-88362 |
3SGELU..ST162 STD |
1 | ||
| 13011-74100 |
3SGELU..ST162 STD,STD |
1 | ||
| 13011-88363 |
3SGELU..ST162 STD,STD |
1 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-8836001 |
3SGELU..ST162 MARK"1",MARK 1 |
4 | ||
| 13041-8836002 |
3SGELU..ST162 MARK"2",MARK 2 |
4 | ||
| 13041-8836003 |
3SGELU..ST162 MARK"3",MARK 3 |
4 | ||
| 13101 - PISTON SUB-ASSY, W/PIN | ||||
| 13101-74030 |
3SGELU..ST162 STD,STD |
4 | ||
| 13101-74031 |
3SGELU..ST162 STD,STD |
4 | ||
| 13101-74032 |
3SGELU..ST162 STD,STD |
4 | ||
| 13101-7403203 |
3SGELU..ST162 STD,STD,MARK"3",MARK3 |
4 | ||
| 13101-7403201 |
3SGELU..ST162 STD,STD,MARK"1",MARK1 |
4 | ||
| 13101-7403202 |
3SGELU..ST162 STD,STD,MARK"2",MARK2 |
4 | ||
| 13101A - RING, HOLE SNAP(FOR PISTON PIN) | ||||
| 90521-25004 |
3SGELU..ST162 |
8 | ||
| 90072-52104 |
3SGELU..ST162 |
8 | ||
| 13201 - ROD SUB-ASSY, CONNECTING | ||||
| 13201-79095 |
3SGELU..ST162 |
4 | ||
| 13201-79065 |
3SGELU..ST162 |
4 | ||
| 13201-79096 |
3SGELU..ST162 |
4 | ||
| 13201A - BUSH(FOR CONNECTING ROD SMALL END) | ||||
| 90999-73106 |
3SGELU..ST162 |
4 | ||
| 90999-73112 |
3SGELU..ST162 |
4 | ||
| 13202 - BEARING SET, CONNECTING ROD | ||||
| 13204-88360 |
3SGELU..ST162 U/S 0.25,U/S 0.25,*54 |
1 | ||
| 13265 - BOLT, CONNECTING ROD | ||||
| 13265-39025 |
3SGELU..ST162 |
8 | ||
| 13265-74010 |
3SGELU..ST162 |
8 | ||
| 13265 - BOLT, CONNECTING ROD | ||||
| 13265-39025 |
3SGELU..ST162 |
8 | ||
| 13265-74010 |
3SGELU..ST162 |
8 | ||
| 13265A - NUT, HEXAGON(FOR CONNECTING ROD BOLT) | ||||
| 90179-10042 |
3SGELU..ST162 |
8 | ||
| 90179-10107 |
3SGELU..ST162 |
8 | ||
| 13405 - FLYWHEEL SUB-ASSY | ||||
| 13405-79075 |
3SGELU..ST162..5F |
1 | ||
| 13405-74011 |
3SGELU..ST162..5F |
1 | ||
| 13405 - FLYWHEEL SUB-ASSY | ||||
| 13405-79075 |
3SGELU..ST162..5F |
1 | ||
| 13405-74011 |
3SGELU..ST162..5F |
1 | ||
| 13405A - PIN, STRAIGHT(FOR FLYWHEEL) | ||||
| 90250-08054 |
1SILU,3SGELU..ST150,162..5F 長さ=23,外径=8 |
3 | ||
| 13405B - BOLT, FLYWHEEL SETTING | ||||
| 90105-10071 |
1SILU,3SGELU..ST150,162..5F |
8 | ||
| 13411 - CRANKSHAFT | ||||
| 13411-74900 |
3SGELU..ST162 |
1 | ||
| 13411-74902 |
3SGELU..ST162 |
1 | ||
| 13453 - GEAR, FLYWHEEL RING | ||||
| 13453-20010 |
1SILU,3SGELU..ST150,162..5F |
1 | ||
| 13471 - PULLEY, CRANKSHAFT | ||||
| 13407-88360 |
3SGELU..ST162 |
1 | ||
| 13471A - KEY, CRANKSHAFT(FOR CRANKSHAFT PULLEY SET) | ||||
| 95161-10519 |
1SILU,3SGELU..ST150,162 |
1 | ||
| 13471C - BOLT(FOR CRANKSHAFT PULLEY SET) | ||||
| 90105-14057 |
3SGELU..ST162 *53 |
1 | ||
| 90105-14011 |
3SGELU..ST162 *54 |
1 | ||
| 90105-14011 |
3SGELU..ST162 |
1 | ||
| 13521A - KEY(FOR CRANKSHAFT TIMING GEAR) | ||||
| 95161-10519 |
1SILU,3SGELU..ST150,162 |
1 | ||
| 13521P - PULLEY, CRANKSHAFT TIMING | ||||
| 13521-88360 |
3SGELU..ST162 |
1 | ||
| 13566A - GUIDE, TIMING BELT | ||||
| 13566-88360 |
3SGELU..ST162 |
1 | ||
