CT176V-CXPDS (1989)
Toyota Carina Ff
(9005- )DX,SG,STD,SV ; (9011- )
ｼﾝﾀｲｼﾖｳｶﾞｲｼﾔﾖｳ ｼﾔﾘﾖｳ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45100 - WHEEL ASSY, STEERING | ||||
| 45100-2057003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45100-2057006 |
CT176,ET176..DX,SG;AT170,175,CT170..SG,SV SABLE,TRIM4# |
1 | ||
| 45100-2084003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45130 - BUTTON ASSY, HORN | ||||
| 45130-2060003 |
AT170,CT17#,ET176..DX,SG,STD,SV 2ｽﾎﾟ-ｸ,GRAY,GRAY,TRIM1# |
1 | ||
| 45130-2060006 |
AT170,CT170..SG,SV;CT176,ET176..DX,SG 2ｽﾎﾟ-ｸ,SABLE,SABLE,TRIM4# |
1 | ||
| 45130-2B07003 |
CT176..4FC GRAY,TRIM1# |
1 | ||
| 45180 - COVER SUB-ASSY, STEERING WHEEL | ||||
| 45180-2006006 |
CT176,ET176..DX,SG;AT170,175,CT170..SG,SV SABLE,TRIM4# |
1 | ||
| 45180-2006003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45180-2016003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45201P - NUT, STEERING WHEEL SET | ||||
| 90179-12086 |
AT17#,CT17#,ET176,ST170 |
1 | ||
| Common parts | ||||
| 90159-50310 | ||||
| 93510-14014 | ||||
(9005- )S,SE,SGEXT,SX
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45100 - WHEEL ASSY, STEERING | ||||
| 45100-2057003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45100-2057006 |
CT176,ET176..DX,SG;AT170,175,CT170..SG,SV SABLE,TRIM4# |
1 | ||
| 45100-2084003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45105 - PLATE SUB-ASSY, HORN BUTTON CONTACT, NO.1 | ||||
| 45105-20190 |
AT170,175,CT17#,ET176..DX,SG,STD,SV 右側 |
1 | ||
| 45105-20200 |
AT170,175,CT17#,ET176..DX,SG,STD,SV 左側 |
1 | ||
| 45180 - COVER SUB-ASSY, STEERING WHEEL | ||||
| 45180-2006006 |
CT176,ET176..DX,SG;AT170,175,CT170..SG,SV SABLE,TRIM4# |
1 | ||
| 45180-2006003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45180-2016003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45201P - NUT, STEERING WHEEL SET | ||||
| 90179-12086 |
AT17#,CT17#,ET176,ST170 |
1 | ||
| Common parts | ||||
| 90157-40012 | ||||
| 90159-30016 | ||||
| 90159-50310 | ||||
| 93319-14010 | ||||
| 93510-13010 | ||||
(8805-9005)DX,SG,STD,SV
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45100 - WHEEL ASSY, STEERING | ||||
| 45100-2057003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45100-2057006 |
CT176,ET176..DX,SG;AT170,175,CT170..SG,SV SABLE,TRIM4# |
1 | ||
| 45100-2084003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45105 - PLATE SUB-ASSY, HORN BUTTON CONTACT, NO.1 | ||||
| 45105-20190 |
AT170,175,CT17#,ET176..DX,SG,STD,SV 右側 |
1 | ||
| 45105-20200 |
AT170,175,CT17#,ET176..DX,SG,STD,SV 左側 |
1 | ||
| 45105 - PLATE SUB-ASSY, HORN BUTTON CONTACT, NO.1 | ||||
| 45105-20190 |
AT170,175,CT17#,ET176..DX,SG,STD,SV 右側 |
1 | ||
| 45105-20200 |
AT170,175,CT17#,ET176..DX,SG,STD,SV 左側 |
1 | ||
| 45125 - MARK, STEERING WHEEL PAD | ||||
| 45125-20400 |
AT170,175,CT17#,ET176..DX,SG,STD,SV |
1 | ||
| 45126 - PLATE, STEERING WHEEL PAD SET | ||||
| 45126-20060 |
AT170,175,CT17#,ET176..DX,SG,STD,SV |
1 | ||
| 45130 - BUTTON ASSY, HORN | ||||
| 45130-2060003 |
AT170,CT17#,ET176..DX,SG,STD,SV 2ｽﾎﾟ-ｸ,GRAY,GRAY,TRIM1# |
1 | ||
| 45130-2060006 |
AT170,CT170..SG,SV;CT176,ET176..DX,SG 2ｽﾎﾟ-ｸ,SABLE,SABLE,TRIM4# |
1 | ||
| 45130-2B07003 |
CT176..4FC GRAY,TRIM1# |
1 | ||
| 45180 - COVER SUB-ASSY, STEERING WHEEL | ||||
| 45180-2006006 |
CT176,ET176..DX,SG;AT170,175,CT170..SG,SV SABLE,TRIM4# |
1 | ||
| 45180-2006003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45180-2016003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45201P - NUT, STEERING WHEEL SET | ||||
| 90179-12086 |
AT17#,CT17#,ET176,ST170 |
1 | ||
| 45713A - DAMPER, STEERING SHAKE | ||||
| 45713-20040 |
CT17# |
1 | ||
| Common parts | ||||
| 93319-15012 | ||||
| 93510-14014 | ||||
| 93510-15012 | ||||
(8805-9005) ; (8903-9005)
SG ｴｸｽﾄﾗ;ｼﾞﾕﾝ;ﾏｲﾛ-ﾄﾞ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45100 - WHEEL ASSY, STEERING | ||||
| 45100-2057003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45100-2057006 |
CT176,ET176..DX,SG;AT170,175,CT170..SG,SV SABLE,TRIM4# |
1 | ||
| 45100-2084003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45105 - PLATE SUB-ASSY, HORN BUTTON CONTACT, NO.1 | ||||
| 45105-20190 |
AT170,175,CT17#,ET176..DX,SG,STD,SV 右側 |
1 | ||
| 45105-20200 |
AT170,175,CT17#,ET176..DX,SG,STD,SV 左側 |
1 | ||
| 45125 - MARK, STEERING WHEEL PAD | ||||
| 45125-20400 |
AT170,175,CT17#,ET176..DX,SG,STD,SV |
1 | ||
| 45130 - BUTTON ASSY, HORN | ||||
| 45130-2060003 |
AT170,CT17#,ET176..DX,SG,STD,SV 2ｽﾎﾟ-ｸ,GRAY,GRAY,TRIM1# |
1 | ||
| 45130-2060006 |
AT170,CT170..SG,SV;CT176,ET176..DX,SG 2ｽﾎﾟ-ｸ,SABLE,SABLE,TRIM4# |
1 | ||
| 45130-2B07003 |
CT176..4FC GRAY,TRIM1# |
1 | ||
| 45180 - COVER SUB-ASSY, STEERING WHEEL | ||||
| 45180-2006006 |
CT176,ET176..DX,SG;AT170,175,CT170..SG,SV SABLE,TRIM4# |
1 | ||
| 45180-2006003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45180-2016003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45201P - NUT, STEERING WHEEL SET | ||||
| 90179-12086 |
AT17#,CT17#,ET176,ST170 |
1 | ||
| 45713A - DAMPER, STEERING SHAKE | ||||
| 45713-20040 |
CT17# |
1 | ||
| Common parts | ||||
| 90159-50229 | ||||
(8805-9005)GLIM ; (8805-9006)S ; (8812-9005)
S ﾘﾐﾃﾂﾄﾞ; ｽ-ﾊﾟ- ﾛ-ﾄﾞ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45100 - WHEEL ASSY, STEERING | ||||
| 45100-2057003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45100-2057006 |
CT176,ET176..DX,SG;AT170,175,CT170..SG,SV SABLE,TRIM4# |
1 | ||
| 45100-2084003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45126 - PLATE, STEERING WHEEL PAD SET | ||||
| 45126-20060 |
AT170,175,CT17#,ET176..DX,SG,STD,SV |
1 | ||
| 45126 - PLATE, STEERING WHEEL PAD SET | ||||
| 45126-20060 |
AT170,175,CT17#,ET176..DX,SG,STD,SV |
1 | ||
| 45180 - COVER SUB-ASSY, STEERING WHEEL | ||||
| 45180-2006006 |
CT176,ET176..DX,SG;AT170,175,CT170..SG,SV SABLE,TRIM4# |
1 | ||
| 45180-2006003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45180-2016003 |
AT170,175,CT17#,ET176..DX,SG,STD,SV GRAY,TRIM1# |
1 | ||
| 45201P - NUT, STEERING WHEEL SET | ||||
| 90179-12086 |
AT17#,CT17#,ET176,ST170 |
1 | ||
| Common parts | ||||
| 90159-40157 | ||||
| 90159-50161 | ||||
| 93510-13010 | ||||
| 93510-14012 | ||||
