CT176V-CXMNS (1988)

Toyota Carina Ff

Production May 1988 - Nov 1992
Engine 2C
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8805- )

Click highlighted areas on diagram

diagram 35519A 41992 74529 74541 74541E 74542 74559A 74559B 74562 74563 74571 74579 75341C
Part # Description Qty Price
74541 - PLATE, TIRE PRESSURE CAUTION
42661-20460

CT176,ET176

 1
42661-20740

CT176,ET176

 1
74542 - PLATE, REAR WINDOW MARK
74542-12020

AT170,171,CT17#,ET176,ST170

ﾕｷｸﾞﾆ ｼﾖｳ

 1
74559A - PLATE, FUEL CAUTION
74559-14030

CT17#

 1
74562 - PLATE, EMISSION CONTROL SYSTEM INFORMATION
74562-28110

CT176

 1
74563 - PLATE, EMISSION CONTROL DEVICE IDENTIFICATION
74563-20170

CT176

 1
74571 - PLATE, BRAKE FLUID CAUTION
47288-32010

AT17#,CT17#,ET176,ST170

 1
75341C - PLATE, HOOD NAME
75341-20060

AT17#,CT17#,ET176,ST170

 1
