CT170-CEMNS (1988)

Toyota Carina Ff

Production May 1988 - Aug 1992
Engine 2C
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8805- )

Click highlighted areas on diagram

diagram 11284 11288 11289 11291 11291 11292 11293A 11296A 11297A 1356410010 15369 17700D 17791 17792
Part # Description Qty Price
11297A - PLATE, ENGINE START CAUTION
11297-64010

2C..CT17#

 1
15369 - PLATE, ENGINE OIL CAUTION
15369-54010

2C..CT17#

 1
17700D - PLATE, ENGINE CAUTION
11296-55020

2C..CT17#

 1
17791 - LABEL, MAINTENANCE INFORMATION
17791-55010

2C..CT17#

 1
17791-55010

2C,3E..CT17#,ET176

 1
17791-55010

4AF#,5AFE,2C,3E..AT17#,CT17#,ET176

 1
Common parts
13564-10010
