ST180-CTMGM (1989)
Toyota Carina Ed
(8909- )F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71015 - FRAME SUB-ASSY, REAR SEAT CUSHION | ||||
| 71015-20340 |
ST18# |
1 | ||
| 71017A - FRAME SUB-ASSY, REAR SEAT BACK | ||||
| 71017-20420 |
ST180..F |
1 | ||
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71075-2B10006 |
ST18#..GLIM,S,SLIM SABLE,TRIM4# |
1 | ||
| 71075-2B10003 |
ST18#..GLIM,S,SLIM SHADOW GRAY,TRIM1# |
1 | ||
| 71075-2B66006 |
ST18#..X SABLE,TRIM4# |
1 | ||
| 71075-2B09003 |
ST180..F SHADOW GRAY,TRIM1# |
1 | ||
| 71075-2B09006 |
ST180..F SABLE,TRIM4# |
1 | ||
| 71075-2B66007 |
ST18#..X KHAKI,TRIM6# |
1 | ||
| 71075-2B66003 |
ST18#..X SHADOW GRAY,TRIM1# |
1 | ||
| 71077B - COVER, REAR SEAT BACK (FOR BENCH TYPE) | ||||
| 71077-2D45006 |
ST180..F SABLE,TRIM4# |
1 | ||
| 71077-2D45003 |
ST180..F SHADOW GRAY,TRIM1# |
1 | ||
| 71460B - CUSHION ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71460-2B56006 |
ST180..F ***,SABLE,TRIM4# |
1 | ||
| 71460-2B57006 |
ST18#..X ***,SABLE,TRIM4# |
1 | ||
| 71460-2B57003 |
ST18#..X ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71460-2B57007 |
ST18#..X ***,KHAKI,TRIM6# |
1 | ||
| 71460-2B56003 |
ST180..F ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71460-2B78006 |
ST18#..GLIM,S,SLIM ***,SABLE,TRIM4# |
1 | ||
| 71460-2B78003 |
ST18#..GLIM,S,SLIM ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71480B - BACK ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71480-2D72006 |
ST180..F ***,BROWN,TRIM4# |
1 | ||
| 71480-2D72003 |
ST180..F ***,RED,TRIM1# |
1 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71611-20510 |
ST18#..GLIM,S,SLIM,X |
1 | ||
| 71651B - PAD, REAR SEAT BACK(FOR BENCH TYPE) | ||||
| 71651-20620 |
ST180..F |
1 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-20030 |
ST18# |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-20030 |
ST18# |
2 | ||
| Common parts | ||||
| 90119-08160 | ||||
(8909- )GLIM,S,SLIM,X
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71015 - FRAME SUB-ASSY, REAR SEAT CUSHION | ||||
| 71015-20340 |
ST18# |
1 | ||
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71075-2B10006 |
ST18#..GLIM,S,SLIM SABLE,TRIM4# |
1 | ||
| 71075-2B10003 |
ST18#..GLIM,S,SLIM SHADOW GRAY,TRIM1# |
1 | ||
| 71075-2B66006 |
ST18#..X SABLE,TRIM4# |
1 | ||
| 71075-2B09003 |
ST180..F SHADOW GRAY,TRIM1# |
1 | ||
| 71075-2B09006 |
ST180..F SABLE,TRIM4# |
1 | ||
| 71075-2B66007 |
ST18#..X KHAKI,TRIM6# |
1 | ||
| 71075-2B66003 |
ST18#..X SHADOW GRAY,TRIM1# |
1 | ||
| 71077S - COVER, REAR SEAT BACK, RH (FOR SEPARATE TYPE) | ||||
| 71077-2D47006 |
ST18#..GLIM,S,SLIM SABLE,TRIM4# |
1 | ||
| 71077-2D48003 |
ST18#..X SHADOW GRAY,TRIM1# |
1 | ||
| 71077-2D48006 |
ST18#..X SABLE,TRIM4# |
1 | ||
| 71077-2D48007 |
ST18#..X KHAKI,TRIM6# |
1 | ||
| 71077-2D47003 |
ST18#..GLIM,S,SLIM SHADOW GRAY,TRIM1# |
1 | ||
| 71078S - COVER, REAR SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71078-2052006 |
ST18#..GLIM,S,SLIM SABLE,TRIM4# |
1 | ||
| 71078-2069006 |
ST18#..X SABLE,TRIM4# |
1 | ||
| 71078-2069003 |
ST18#..X SHADOW GRAY,TRIM1# |
1 | ||
| 71078-2052003 |
ST18#..GLIM,S,SLIM SHADOW GRAY,TRIM1# |
1 | ||
| 71078-2069007 |
ST18#..X KHAKI,TRIM6# |
1 | ||
| 71202B - PANEL, REAR SEAT BACK | ||||
| 71203-20030 |
ST18#..GLIM,S,SLIM,X 左側 |
1 | ||
| 71202-20020 |
ST18#..GLIM,S,SLIM,X 右側 |
1 | ||
| 71202B - PANEL, REAR SEAT BACK | ||||
| 71203-20030 |
ST18#..GLIM,S,SLIM,X 左側 |
1 | ||
| 71202-20020 |
ST18#..GLIM,S,SLIM,X 右側 |
1 | ||
| 71303 - HINGE SUB-ASSY, REAR SEAT BACK | ||||
| 71304-20080 |
ST18#..GLIM,S,SLIM,X 左側 |
1 | ||
| 71303-20090 |
ST18#..GLIM,S,SLIM,X 右側 |
1 | ||
| 71303 - HINGE SUB-ASSY, REAR SEAT BACK | ||||
| 71304-20080 |
ST18#..GLIM,S,SLIM,X 左側 |
1 | ||
| 71303-20090 |
ST18#..GLIM,S,SLIM,X 右側 |
1 | ||
| 71305A - HINGE SUB-ASSY, REAR SEAT BACK, CENTER | ||||
| 71305-20130 |
ST18#..GLIM,S,SLIM,X |
1 | ||
| 71349C - COVER, REAR SEAT BACK HINGE | ||||
| 71349-20020E0 |
ST18#..GLIM,S,SLIM,X SABLE,TRIM4# |
1 | ||
| 71349-20020G0 |
ST18#..GLIM,SLIM,X KHAKI,TRIM6# |
1 | ||
| 71349-20020P0 |
ST18#..GLIM,S,SLIM,X SHADOW GRAY,TRIM1# |
1 | ||
| 71460B - CUSHION ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71460-2B56006 |
ST180..F ***,SABLE,TRIM4# |
1 | ||
| 71460-2B57006 |
ST18#..X ***,SABLE,TRIM4# |
1 | ||
| 71460-2B57003 |
ST18#..X ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71460-2B57007 |
ST18#..X ***,KHAKI,TRIM6# |
1 | ||
| 71460-2B56003 |
ST180..F ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71460-2B78006 |
ST18#..GLIM,S,SLIM ***,SABLE,TRIM4# |
1 | ||
| 71460-2B78003 |
ST18#..GLIM,S,SLIM ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71480S - BACK ASSY, REAR SEAT, RH (FOR SEPARATE TYPE) | ||||
| 71480-2G07006 |
ST18#..X ***,SABLE,TRIM4# |
1 | ||
| 71480-2D75006 |
ST18#..GLIM,S,SLIM ***,SABLE,TRIM4# |
1 | ||
| 71480-2D75003 |
ST18#..GLIM,S,SLIM ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71480-2G07003 |
ST18#..X ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71480-2G07007 |
ST18#..X ***,KHAKI,TRIM6# |
1 | ||
| 71490S - BACK ASSY, REAR SEAT, LH (FOR SEPARATE TYPE) | ||||
| 71490-2083007 |
ST18#..X ***,KHAKI,TRIM6# |
1 | ||
| 71490-2084003 |
ST18#..GLIM,S,SLIM ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71490-2083003 |
ST18#..X ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71490-2084006 |
ST18#..GLIM,S,SLIM ***,SABLE,TRIM4# |
1 | ||
| 71490-2083006 |
ST18#..X ***,SABLE,TRIM4# |
1 | ||
| 71540A - BACK ASSY, REAR SIDE SEAT, RH | ||||
| 71540-2006006 |
ST18#..GLIM,S,SLIM ***,SABLE,TRIM4# |
1 | ||
| 71540-2010003 |
ST18#..X ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71540-2010007 |
ST18#..X ***,KHAKI,TRIM6# |
1 | ||
| 71540-2010006 |
ST18#..X ***,SABLE,TRIM4# |
1 | ||
| 71540-2006003 |
ST18#..GLIM,S,SLIM ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71550A - BACK ASSY, REAR SIDE SEAT, LH | ||||
| 71550-2010007 |
ST18#..X ***,KHAKI,TRIM6# |
1 | ||
| 71550-2010006 |
ST18#..X ***,SABLE,TRIM4# |
1 | ||
| 71550-2010003 |
ST18#..X ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71550-2006006 |
ST18#..GLIM,S,SLIM ***,SABLE,TRIM4# |
1 | ||
| 71550-2006003 |
ST18#..GLIM,S,SLIM ***,SHADOW GRAY,TRIM1# |
1 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71611-20510 |
ST18#..GLIM,S,SLIM,X |
1 | ||
| 71651S - PAD, REAR SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71507-20210 |
ST18#..GLIM,S,SLIM,X |
1 | ||
| 71652S - PAD, REAR SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71508-20040 |
ST18#..GLIM,S,SLIM,X |
1 | ||
| 71880A - CARPET ASSY, REAR SEAT BACK BOARD, RH | ||||
| 71880-2016003 |
ST180,181..S GRAY,TRIM1#,4# |
1 | ||
| 71880-2016003 |
ST18#..GLIM,SLIM,X GRAY,TRIM1#,4#,6# |
1 | ||
| 71890A - CARPET ASSY, REAR SEAT BACK BOARD, LH | ||||
| 71890-2010003 |
ST180,181..S GRAY,TRIM1#,4# |
1 | ||
| 71890-2010003 |
ST18#..GLIM,SLIM,X GRAY,TRIM1#,4#,6# |
1 | ||
| 72067 - LEVER SUB-ASSY, REAR BACK LOCK CONTROL, RH | ||||
| 72067-20040 |
ST18#..GLIM,S,SLIM,X |
1 | ||
| 72068 - LEVER SUB-ASSY, REAR BACK LOCK CONTROL, LH | ||||
| 72068-20040 |
ST18#..GLIM,S,SLIM,X |
1 | ||
| 72601 - STRIKER SUB-ASSY, REAR SEAT LOCK | ||||
| 72610-20030 |
ST18#..GLIM,S,SLIM,X |
2 | ||
| 72601 - STRIKER SUB-ASSY, REAR SEAT LOCK | ||||
| 72610-20030 |
ST18#..GLIM,S,SLIM,X |
2 | ||
| 72603 - LOCK SUB-ASSY, REAR SEAT BACK, RH | ||||
| 72603-20060 |
ST18#..GLIM,S,SLIM,X |
1 | ||
| 72604 - LOCK SUB-ASSY, REAR SEAT BACK, LH | ||||
| 72604-20060 |
ST18#..GLIM,S,SLIM,X |
1 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-1403003 |
ST18#..GLIM,S,SLIM,X SHADOW GRAY,TRIM1# |
1 | ||
| 72646-1403026 |
ST18#..GLIM,S,SLIM,X SABLE,TRIM4# |
1 | ||
| 72646-1403007 |
ST18#..GLIM,SLIM,X KHAKI,TRIM6# |
1 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-1403003 |
ST18#..GLIM,S,SLIM,X SHADOW GRAY,TRIM1# |
1 | ||
| 72646-1403026 |
ST18#..GLIM,S,SLIM,X SABLE,TRIM4# |
1 | ||
| 72646-1403007 |
ST18#..GLIM,SLIM,X KHAKI,TRIM6# |
1 | ||
| 72653A - SNAP, REAR SEAT BACK LOCK ROD | ||||
| 69759-24020 |
ST18#..GLIM,S,SLIM,X 左側 |
1 | ||
| 69759-24010 |
ST18#..GLIM,S,SLIM,X 右側 |
1 | ||
| 72653A - SNAP, REAR SEAT BACK LOCK ROD | ||||
| 69759-24020 |
ST18#..GLIM,S,SLIM,X 左側 |
1 | ||
| 69759-24010 |
ST18#..GLIM,S,SLIM,X 右側 |
1 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72658-2301006 |
ST18#..GLIM,S,SLIM,X SABLE,TRIM4# |
2 | ||
| 72658-2301007 |
ST18#..GLIM,SLIM,X KHAKI,TRIM6# |
2 | ||
| 72658-2301023 |
ST18#..GLIM,S,SLIM,X GRAY,TRIM1# |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72658-2301006 |
ST18#..GLIM,S,SLIM,X SABLE,TRIM4# |
2 | ||
| 72658-2301007 |
ST18#..GLIM,SLIM,X KHAKI,TRIM6# |
2 | ||
| 72658-2301023 |
ST18#..GLIM,S,SLIM,X GRAY,TRIM1# |
2 | ||
| 72679 - BEZEL, REAR SEAT BACK LOCK CONTROL | ||||
| 72679-1601033 |
ST180,181..S LIGHT GRAY,TRIM1#,4# |
2 | ||
| 72679-1601033 |
ST18#..GLIM,SLIM,X LIGHT GRAY,TRIM1#,4#,6# |
2 | ||
| 72679 - BEZEL, REAR SEAT BACK LOCK CONTROL | ||||
| 72679-1601033 |
ST180,181..S LIGHT GRAY,TRIM1#,4# |
2 | ||
| 72679-1601033 |
ST18#..GLIM,SLIM,X LIGHT GRAY,TRIM1#,4#,6# |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-20030 |
ST18# |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-20030 |
ST18# |
2 | ||
| 72830 - ARMREST ASSY, REAR SEAT, CENTER | ||||
| 72830-2032003 |
ST18#..X SHADOW GRAY,TRIM1# |
1 | ||
| 72830-2032006 |
ST18#..X SABLE,TRIM4# |
1 | ||
| 72830-2033006 |
ST18#..GLIM,S,SLIM SABLE,TRIM4# |
1 | ||
| 72830-2032007 |
ST18#..X KHAKI,TRIM6# |
1 | ||
| 72830-2033003 |
ST18#..GLIM,S,SLIM SHADOW GRAY,TRIM1# |
1 | ||
| 72887 - STOPPER, REAR SEAT CENTER ARMREST DOOR | ||||
| 72887-20020 |
ST18#..GLIM,S,SLIM,X |
1 | ||
| Common parts | ||||
| 90105-08102 | ||||
| 90109-06169 | ||||
| 90119-06172 | ||||
| 90119-08786 | ||||
| 90159-50268 | ||||
| 90163-50010 | ||||
| 90386-09016 | ||||
| 90467-05083 | ||||
| 90468-18071 | ||||
| 91621-40608 | ||||
| 91651-60616 | ||||
| 91656-60616 | ||||
| 91665-60820 | ||||
| 93530-54010 | ||||
