ST162-ATMVF (1985)
Toyota Carina Ed
(8508- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55441D - BOX, INSTRUMENT PANEL COIN | ||||
| 55441-2015003 |
ST16# GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 55441-2015006 |
ST16# BROWN,BROWN,TRIM1#,4# |
1 | ||
| 55441D - BOX, INSTRUMENT PANEL COIN | ||||
| 55441-2015003 |
ST16# GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 55441-2015006 |
ST16# BROWN,BROWN,TRIM1#,4# |
1 | ||
| 55539A - COVER, SPARE SWITCH HOLE | ||||
| 55539-2002006 |
ST160;ST162..5F BROWN,BROWN,TRIM1#,4# |
1 | ||
| 55539-2002003 |
ST160;ST162..5F GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 55539A - COVER, SPARE SWITCH HOLE | ||||
| 55539-2002006 |
ST160;ST162..5F BROWN,BROWN,TRIM1#,4# |
1 | ||
| 55539-2002003 |
ST160;ST162..5F GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 55547B - COVER, REMOTE CONTROL MIRROR HOLE | ||||
| 55547-2002003 |
ST16# GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 55547-2002006 |
ST16# BROWN,BROWN,TRIM1#,4# |
1 | ||
| 55547B - COVER, REMOTE CONTROL MIRROR HOLE | ||||
| 55547-2002003 |
ST16# GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 55547-2002006 |
ST16# BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58808 - COVER SUB-ASSY, SHIFTING HOLE | ||||
| 58808-2005003 |
ST16#..5F GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 58808-2005006 |
ST16#..5F BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58808 - COVER SUB-ASSY, SHIFTING HOLE | ||||
| 58808-2005003 |
ST16#..5F GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 58808-2005006 |
ST16#..5F BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58810 - CONSOLE ASSY | ||||
| 58801-2010003 |
ST16#..G,L,S GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 58801-2011003 |
ST162 G LIMITED,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 58801-2010006 |
ST16#..G,L,S BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58801-2011006 |
ST162 G LIMITED,BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58810 - CONSOLE ASSY | ||||
| 58801-2010003 |
ST16#..G,L,S GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 58801-2011003 |
ST162 G LIMITED,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 58801-2010006 |
ST16#..G,L,S BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58801-2011006 |
ST162 G LIMITED,BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58839A - COVER, CONSOLE BOX HOLE | ||||
| 58839-2002003 |
ST16# GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 58839-2002006 |
ST16# BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58839A - COVER, CONSOLE BOX HOLE | ||||
| 58839-2002003 |
ST16# GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 58839-2002006 |
ST16# BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58871 - CUSHION, CONSOLE BOX | ||||
| 90541-04079 |
ST162 G LIMITED |
2 | ||
| 58905 - DOOR SUB-ASSY, CONSOLE COMPARTMENT | ||||
| 58951-2007003 |
ST16#..G,L,S GRAY,GRAY,TRIM1# |
1 | ||
| 58905-2006006 |
ST162 G LIMITED,BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58951-2007006 |
ST16#..G,L,S BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58905-2006003 |
ST162 G LIMITED,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 58905 - DOOR SUB-ASSY, CONSOLE COMPARTMENT | ||||
| 58951-2007003 |
ST16#..G,L,S GRAY,GRAY,TRIM1# |
1 | ||
| 58905-2006006 |
ST162 G LIMITED,BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58951-2007006 |
ST16#..G,L,S BROWN,BROWN,TRIM1#,4# |
1 | ||
| 58905-2006003 |
ST162 G LIMITED,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 58959B - CUSHION, CONSOLE COMPARTMENT DOOR | ||||
| 58959-16010 |
ST16# |
2 | ||
| 58959B - CUSHION, CONSOLE COMPARTMENT DOOR | ||||
| 58959-16010 |
ST16# |
2 | ||
| 58964 - STOPPER, CONSOLE COMPARTMENT DOOR, NO.1 | ||||
| 58964-30030 |
ST16# LH |
1 | ||
| 58964-90K00 |
ST16# RH |
1 | ||
| 58964 - STOPPER, CONSOLE COMPARTMENT DOOR, NO.1 | ||||
| 58964-30030 |
ST16# LH |
1 | ||
| 58964-90K00 |
ST16# RH |
1 | ||
| 58964 - STOPPER, CONSOLE COMPARTMENT DOOR, NO.1 | ||||
| 58964-30030 |
ST16# LH |
1 | ||
| 58964-90K00 |
ST16# RH |
1 | ||
| 58964 - STOPPER, CONSOLE COMPARTMENT DOOR, NO.1 | ||||
| 58964-30030 |
ST16# LH |
1 | ||
| 58964-90K00 |
ST16# RH |
1 | ||
| 58965A - STOPPER, CONSOLE COMPARTMENT DOOR, NO.2 | ||||
| 58965-20020 |
ST16#..G,L,S RH |
1 | ||
| 58965-12010 |
ST16#..G,L,S LH |
1 | ||
| 58976 - STRIKER, CONSOLE COMPARTMENT DOOR LOCK | ||||
| 58976-22020 |
ST16# |
1 | ||
| 58976 - STRIKER, CONSOLE COMPARTMENT DOOR LOCK | ||||
| 58976-22020 |
ST16# |
1 | ||
| 58996 - BRACKET, CONSOLE BOX MOUNTING, NO.1 | ||||
| 58995-20030 |
ST16# |
2 | ||
| 58996 - BRACKET, CONSOLE BOX MOUNTING, NO.1 | ||||
| 58995-20030 |
ST16# |
2 | ||
| 58996 - BRACKET, CONSOLE BOX MOUNTING, NO.1 | ||||
| 58995-20030 |
ST16# |
2 | ||
| 58996 - BRACKET, CONSOLE BOX MOUNTING, NO.1 | ||||
| 58995-20030 |
ST16# |
2 | ||
| 58996A - BRACKET, CONSOLE BOX MOUNTING, NO.2 | ||||
| 58996-20030 |
ST16# |
1 | ||
| 58996A - BRACKET, CONSOLE BOX MOUNTING, NO.2 | ||||
| 58996-20030 |
ST16# |
1 | ||
| Common parts | ||||
| 90183-05094 | ||||
| 90523-05004 | ||||
| 93567-54512 | ||||
| 93567-55014 | ||||
| Linked diagrams | ||||
| 7404 | ||||
