VZV31-ATPQK (1990)
Toyota Camry/Vista
(9007- )VZV3#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04446 - GASKET KIT, POWER STEERING PUMP | ||||
| 04446-32020 |
CV30,VZV3# |
1 | ||
| 16929B - VALVE, HYDRAULIC MOTOR CONTROL | ||||
| 16929-62010 |
1VZFE..VZV30,31 |
1 | ||
| 44280 - BUFFER ASSY, POWER STEERING | ||||
| 44280-32050 |
VZV3# |
1 | ||
| 44302 - HOUSING SUB-ASSY, VANE PUMP, FRONT | ||||
| 44302-32070 |
VZV3# |
1 | ||
| 44302G - SEAL, OIL, NO.2(FOR VANE PUMP HOUSING) | ||||
| 90311-17007 |
CV30,VZV3# |
1 | ||
| 44304 - HOUSING SUB-ASSY, VANE PUMP, REAR | ||||
| 44304-32010 |
VZV3# |
1 | ||
| 44305 - CAP SUB-ASSY, VANE PUMP OIL RESERVOIR | ||||
| 44305-32020 |
SV3#,VZV3# |
1 | ||
| 44308 - UNION SUB-ASSY, PRESSURE PORT | ||||
| 44308-32060 |
CV30,VZV3# RR |
1 | ||
| 44308-32100 |
VZV31,33 FR |
1 | ||
| 44308-32110 |
VZV31 FR |
1 | ||
| 44308 - UNION SUB-ASSY, PRESSURE PORT | ||||
| 44308-32060 |
CV30,VZV3# RR |
1 | ||
| 44308-32100 |
VZV31,33 FR |
1 | ||
| 44308-32110 |
VZV31 FR |
1 | ||
| 44311 - PULLEY, VANE PUMP | ||||
| 44311-32060 |
VZV3# |
1 | ||
| 44312 - SHAFT, VANE PUMP | ||||
| 44312-32030 |
CV30,VZV3# OD=17.999-18.004 |
1 | ||
| 44312-32040 |
CV30,VZV3# OD=17.994-17.999 |
1 | ||
| 44312A - BEARING(FOR VANE PUMP SHAFT) | ||||
| 90363-17007 |
CV30,VZV3# |
1 | ||
| 44312B - RING, SNAP, NO.1(FOR VANE PUMP SHAFT) | ||||
| 90520-15001 |
CV30,VZV3# |
1 | ||
| 44312G - RING, SNAP, NO.2(FOR VANE PUMP SHAFT BEARING) | ||||
| 90521-51003 |
CV30,VZV3# |
1 | ||
| 44313 - ROTOR, VANE PUMP | ||||
| 44313-22040 |
CV30,VZV3# ﾏｰｸ無し,ﾘﾔ |
1 | ||
| 44313-22050 |
CV30,VZV3# ﾏｰｸ 1,ﾘﾔ |
1 | ||
| 44313-22070 |
CV30,VZV3# ﾏｰｸ 3,ﾘﾔ |
1 | ||
| 44313-22080 |
CV30,VZV3# ﾏｰｸ 4,ﾘﾔ |
1 | ||
| 44313-22060 |
CV30,VZV3# ﾏｰｸ 2,ﾘﾔ |
1 | ||
| 44313-26060 |
CV30,VZV3# ﾏｰｸ無し,ﾌﾛﾝﾄ |
1 | ||
| 44313-26090 |
CV30,VZV3# ﾏｰｸ 3,ﾌﾛﾝﾄ |
1 | ||
| 44313-26100 |
CV30,VZV3# ﾏｰｸ 4,ﾌﾛﾝﾄ |
1 | ||
| 44313-26070 |
CV30,VZV3# ﾏｰｸ 1,ﾌﾛﾝﾄ |
1 | ||
| 44313-26080 |
CV30,VZV3# ﾏｰｸ 2,ﾌﾛﾝﾄ |
1 | ||
| 44313 - ROTOR, VANE PUMP | ||||
| 44313-22040 |
CV30,VZV3# ﾏｰｸ無し,ﾘﾔ |
1 | ||
| 44313-22050 |
CV30,VZV3# ﾏｰｸ 1,ﾘﾔ |
1 | ||
| 44313-22070 |
CV30,VZV3# ﾏｰｸ 3,ﾘﾔ |
1 | ||
| 44313-22080 |
CV30,VZV3# ﾏｰｸ 4,ﾘﾔ |
1 | ||
| 44313-22060 |
CV30,VZV3# ﾏｰｸ 2,ﾘﾔ |
1 | ||
| 44313-26060 |
CV30,VZV3# ﾏｰｸ無し,ﾌﾛﾝﾄ |
1 | ||
| 44313-26090 |
CV30,VZV3# ﾏｰｸ 3,ﾌﾛﾝﾄ |
1 | ||
| 44313-26100 |
CV30,VZV3# ﾏｰｸ 4,ﾌﾛﾝﾄ |
1 | ||
| 44313-26070 |
CV30,VZV3# ﾏｰｸ 1,ﾌﾛﾝﾄ |
1 | ||
| 44313-26080 |
CV30,VZV3# ﾏｰｸ 2,ﾌﾛﾝﾄ |
1 | ||
| 44320 - PUMP ASSY, VANE | ||||
| 44320-32230 |
VZV31 |
1 | ||
| 44320-32231 |
VZV31 |
1 | ||
| 44322 - SEAL, VANE PUMP SIDE PLATE | ||||
| 44322-32010 |
CV30,VZV3# |
1 | ||
| 44325D - PIN, RING(FOR VANE PUMP CAM RING) | ||||
| 90253-04001 |
CV30,VZV3# |
1 | ||
| 44326 - RING, CAM(FOR VANE PUMP) | ||||
| 44325-32140 |
CV30,VZV31 ﾏｰｸ 3,ﾌﾛﾝﾄ |
1 | ||
| 44325-32130 |
CV30,VZV31 ﾏｰｸ 2,ﾌﾛﾝﾄ |
1 | ||
| 44325-32150 |
CV30,VZV31 ﾏｰｸ 4,ﾌﾛﾝﾄ |
1 | ||
| 44325-32160 |
CV30,VZV31 ﾏｰｸ 5,ﾌﾛﾝﾄ |
1 | ||
| 44325-32170 |
CV30,VZV31 ﾏｰｸ 6,ﾌﾛﾝﾄ |
1 | ||
| 44325-32330 |
CV30,VZV30,31,33 ﾏｰｸ 6,ﾌﾛﾝﾄ |
1 | ||
| 44325-32140 |
CV30,VZV3# ﾏｰｸ 3,ﾘﾔ |
1 | ||
| 44325-32150 |
CV30,VZV3# ﾏｰｸ 4,ﾘﾔ |
1 | ||
| 44325-32130 |
CV30,VZV3# ﾏｰｸ 2,ﾘﾔ |
1 | ||
| 44325-32120 |
CV30,VZV3# ﾏｰｸ 1,ﾘﾔ |
1 | ||
| 44325-32110 |
CV30,VZV3# ﾏｰｸ無し,ﾘﾔ |
1 | ||
| 44326 - RING, CAM(FOR VANE PUMP) | ||||
| 44325-32140 |
CV30,VZV31 ﾏｰｸ 3,ﾌﾛﾝﾄ |
1 | ||
| 44325-32130 |
CV30,VZV31 ﾏｰｸ 2,ﾌﾛﾝﾄ |
1 | ||
| 44325-32150 |
CV30,VZV31 ﾏｰｸ 4,ﾌﾛﾝﾄ |
1 | ||
| 44325-32160 |
CV30,VZV31 ﾏｰｸ 5,ﾌﾛﾝﾄ |
1 | ||
| 44325-32170 |
CV30,VZV31 ﾏｰｸ 6,ﾌﾛﾝﾄ |
1 | ||
| 44325-32330 |
CV30,VZV30,31,33 ﾏｰｸ 6,ﾌﾛﾝﾄ |
1 | ||
| 44325-32140 |
CV30,VZV3# ﾏｰｸ 3,ﾘﾔ |
1 | ||
| 44325-32150 |
CV30,VZV3# ﾏｰｸ 4,ﾘﾔ |
1 | ||
| 44325-32130 |
CV30,VZV3# ﾏｰｸ 2,ﾘﾔ |
1 | ||
| 44325-32120 |
CV30,VZV3# ﾏｰｸ 1,ﾘﾔ |
1 | ||
| 44325-32110 |
CV30,VZV3# ﾏｰｸ無し,ﾘﾔ |
1 | ||
| 44326A - PIN, STRAIGHT(FOR VANE PUMP CAM RING) | ||||
| 90250-04083 |
CV30,VZV3# 長さ=59.5,外径=4 |
1 | ||
| 44327C - GASKET, VANE PUMP HOUSING | ||||
| 44327-32010 |
CV30,VZV3# |
1 | ||
| 44330 - VALVE ASSY, FLOW CONTROL | ||||
| 44330-22101 |
CV30,VZV3# ﾏｰｸ A,MARK A,RR |
1 | ||
| 44330-22111 |
CV30,VZV3# ﾏｰｸ B,MARK B,RR |
1 | ||
| 44330-22141 |
CV30,VZV3# ﾏｰｸ E,MARK E,RR |
1 | ||
| 44330-22121 |
CV30,VZV3# ﾏｰｸ C,MARK C,RR |
1 | ||
| 44330-22151 |
CV30,VZV3# ﾏｰｸ F,MARK F,RR |
1 | ||
| 44330-22131 |
CV30,VZV3# ﾏｰｸ D,MARK D,RR |
1 | ||
| 44330-32440 |
VZV31,33 ﾏｰｸ B,GEAR SIDE |
1 | ||
| 44330-32470 |
VZV31,33 ﾏｰｸ E,GEAR SIDE |
1 | ||
| 44330-32450 |
VZV31,33 ﾏｰｸ C,GEAR SIDE |
1 | ||
| 44330-32480 |
VZV31,33 ﾏｰｸ F,GEAR SIDE |
1 | ||
| 44330-32570 |
CV30,VZV30,31,32 ﾏｰｸ C,MARK C,RR |
1 | ||
| 44330-32590 |
CV30,VZV30,31,32 ﾏｰｸ E,MARK E,RR |
1 | ||
| 44330-32600 |
CV30,VZV30,31,32 ﾏｰｸ F,MARK F,RR |
1 | ||
| 44330-32560 |
CV30,VZV30,31,32 ﾏｰｸ B,MARK B,RR |
1 | ||
| 44330-32580 |
CV30,VZV30,31,32 ﾏｰｸ D,MARK D,RR |
1 | ||
| 44330-32550 |
CV30,VZV30,31,32 ﾏｰｸ A,MARK A,RR |
1 | ||
| 44330-32460 |
VZV31,33 ﾏｰｸ D,GEAR SIDE |
1 | ||
| 44330-32430 |
VZV31 ﾏｰｸ A,MARK A,FR |
1 | ||
| 44330 - VALVE ASSY, FLOW CONTROL | ||||
| 44330-22101 |
CV30,VZV3# ﾏｰｸ A,MARK A,RR |
1 | ||
| 44330-22111 |
CV30,VZV3# ﾏｰｸ B,MARK B,RR |
1 | ||
| 44330-22141 |
CV30,VZV3# ﾏｰｸ E,MARK E,RR |
1 | ||
| 44330-22121 |
CV30,VZV3# ﾏｰｸ C,MARK C,RR |
1 | ||
| 44330-22151 |
CV30,VZV3# ﾏｰｸ F,MARK F,RR |
1 | ||
| 44330-22131 |
CV30,VZV3# ﾏｰｸ D,MARK D,RR |
1 | ||
| 44330-32440 |
VZV31,33 ﾏｰｸ B,GEAR SIDE |
1 | ||
| 44330-32470 |
VZV31,33 ﾏｰｸ E,GEAR SIDE |
1 | ||
| 44330-32450 |
VZV31,33 ﾏｰｸ C,GEAR SIDE |
1 | ||
| 44330-32480 |
VZV31,33 ﾏｰｸ F,GEAR SIDE |
1 | ||
| 44330-32570 |
CV30,VZV30,31,32 ﾏｰｸ C,MARK C,RR |
1 | ||
| 44330-32590 |
CV30,VZV30,31,32 ﾏｰｸ E,MARK E,RR |
1 | ||
| 44330-32600 |
CV30,VZV30,31,32 ﾏｰｸ F,MARK F,RR |
1 | ||
| 44330-32560 |
CV30,VZV30,31,32 ﾏｰｸ B,MARK B,RR |
1 | ||
| 44330-32580 |
CV30,VZV30,31,32 ﾏｰｸ D,MARK D,RR |
1 | ||
| 44330-32550 |
CV30,VZV30,31,32 ﾏｰｸ A,MARK A,RR |
1 | ||
| 44330-32460 |
VZV31,33 ﾏｰｸ D,GEAR SIDE |
1 | ||
| 44330-32430 |
VZV31 ﾏｰｸ A,MARK A,FR |
1 | ||
| 44330A - SPRING, COMPRESSION(FOR FLOW CONTROL VALVE) | ||||
| 90501-11047 |
CV30,SV32,33,35,VZV3# |
1 | ||
| 44330A - SPRING, COMPRESSION(FOR FLOW CONTROL VALVE) | ||||
| 90501-11047 |
CV30,SV32,33,35,VZV3# |
1 | ||
| 44337 - UNION, POWER STEERING SUCTION PORT | ||||
| 44337-32060 |
VZV3# FR |
1 | ||
| 44337-32070 |
VZV3# RR |
1 | ||
| 44337 - UNION, POWER STEERING SUCTION PORT | ||||
| 44337-32060 |
VZV3# FR |
1 | ||
| 44337-32070 |
VZV3# RR |
1 | ||
| 44337A - RING, O(FOR POWER STEERING SUCTION PORT) | ||||
| 90301-11010 |
CV30,VZV3# FR |
1 | ||
| 96711-19016 |
CV30,VZV3# OD=19.6,ID=15.8,RR |
1 | ||
| 90301-11010 |
CV30,VZV31,32 FR |
1 | ||
| 44337A - RING, O(FOR POWER STEERING SUCTION PORT) | ||||
| 90301-11010 |
CV30,VZV3# FR |
1 | ||
| 96711-19016 |
CV30,VZV3# OD=19.6,ID=15.8,RR |
1 | ||
| 90301-11010 |
CV30,VZV31,32 FR |
1 | ||
| 44338A - RING, O(FOR PRESSURE PORT UNION) | ||||
| 90301-19003 |
CV30,VZV3# 内径=19.5,外径=22.5 |
2 | ||
| 44338A - RING, O(FOR PRESSURE PORT UNION) | ||||
| 90301-19003 |
CV30,VZV3# 内径=19.5,外径=22.5 |
2 | ||
| 44341 - PLATE, VANE PUMP SIDE, FRONT | ||||
| 44341-32020 |
CV30,VZV3# |
1 | ||
| 44342E - PLATE, VANE PUMP SIDE, REAR NO.1 | ||||
| 44342-32020 |
CV30,VZV3# |
1 | ||
| 44342F - PLATE, VANE PUMP SIDE, REAR NO.2 | ||||
| 44342-32030 |
CV30,VZV3# |
1 | ||
| 44342G - PLATE, VANE PUMP SIDE, REAR NO.3 | ||||
| 44342-32040 |
CV30,VZV3# |
1 | ||
| 44342H - RING, O(FOR VANE PUMP SIDE PLATE REAR NO.1) | ||||
| 90301-15008 |
CV30,VZV30,31 |
1 | ||
| 44342J - RING, O(FOR VANE PUMP SIDE PLATE REAR NO.2) | ||||
| 90301-36007 |
CV30,VZV3# OD=40.16,ID=36.6,RR |
1 | ||
| 90301-56003 |
CV30,VZV3# OD=60.5,ID=56.5,FR |
1 | ||
| 44342J - RING, O(FOR VANE PUMP SIDE PLATE REAR NO.2) | ||||
| 90301-36007 |
CV30,VZV3# OD=40.16,ID=36.6,RR |
1 | ||
| 90301-56003 |
CV30,VZV3# OD=60.5,ID=56.5,FR |
1 | ||
| 44345B - PLATE, VANE PUMP | ||||
| 44345-12010 |
CV30,VZV3# 長さ=14.997,L=14.007,REAR |
10 | ||
| 44345-12020 |
CV30,VZV3# 長さ=14.995,L=14.005,REAR |
10 | ||
| 44345-12050 |
CV30,VZV3# 長さ=14.989,L=13.001,REAR |
10 | ||
| 44345-26010 |
CV30,VZV3# 長さ=15.000,L=15.000,FRONT |
10 | ||
| 44345-26020 |
CV30,VZV3# 長さ=14.998,L=14.008,FRONT |
10 | ||
| 44345-26030 |
CV30,VZV3# 長さ=14.996,L=14.006,FRONT |
10 | ||
| 44345-32070 |
CV30,VZV3# ﾛｰﾀ ﾏｰｸ 1,L=15.002,FRONT |
10 | ||
| 44345-12030 |
CV30,VZV3# 長さ=14.993,L=14.003,REAR |
10 | ||
| 44345-12040 |
CV30,VZV3# 長さ=14.991,L=14.001,REAR |
10 | ||
| 44345-32060 |
CV30,VZV3# ﾛｰﾀ ﾏｰｸ無し,L=15.004,FRONT |
10 | ||
| 44345B - PLATE, VANE PUMP | ||||
| 44345-12010 |
CV30,VZV3# 長さ=14.997,L=14.007,REAR |
10 | ||
| 44345-12020 |
CV30,VZV3# 長さ=14.995,L=14.005,REAR |
10 | ||
| 44345-12050 |
CV30,VZV3# 長さ=14.989,L=13.001,REAR |
10 | ||
| 44345-26010 |
CV30,VZV3# 長さ=15.000,L=15.000,FRONT |
10 | ||
| 44345-26020 |
CV30,VZV3# 長さ=14.998,L=14.008,FRONT |
10 | ||
| 44345-26030 |
CV30,VZV3# 長さ=14.996,L=14.006,FRONT |
10 | ||
| 44345-32070 |
CV30,VZV3# ﾛｰﾀ ﾏｰｸ 1,L=15.002,FRONT |
10 | ||
| 44345-12030 |
CV30,VZV3# 長さ=14.993,L=14.003,REAR |
10 | ||
| 44345-12040 |
CV30,VZV3# 長さ=14.991,L=14.001,REAR |
10 | ||
| 44345-32060 |
CV30,VZV3# ﾛｰﾀ ﾏｰｸ無し,L=15.004,FRONT |
10 | ||
| 44360 - RESERVOIR ASSY, VANE PUMP OIL | ||||
| 44360-32070 |
VZV3# |
1 | ||
| 44369 - BRACKET, OIL RESERVOIR, NO.1 | ||||
| 44369-32070 |
VZV3# |
1 | ||
| Common parts | ||||
| 90110-10012 | ||||
| 90119-08469 | ||||
| 90179-12022 | ||||
| 90204-10005 | ||||
| 90206-43002 | ||||
| 90301-14002 | ||||
| 90301-25005 | ||||
| 90461-06404 | ||||
| 90467-21005 | ||||
| 90467-28005 | ||||
| 90904-61001 | ||||
| 91652-60612 | ||||
| Linked diagrams | ||||
| 4503 | ||||
