VZV30-ATMQK (1990)
Toyota Camry/Vista
(9007-9206)1VZFE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17111 - MANIFOLD, INTAKE | ||||
| 17111-62010 |
1VZFE..VZV30,31 |
1 | ||
| 17118 - STAY, MANIFOLD | ||||
| 17118-62010 |
1VZFE,4VZFE..VZV3# |
1 | ||
| 17126 - STAY, SURGE TANK, NO.2 | ||||
| 17126-62010 |
1VZFE..VZV30,31 |
1 | ||
| 17127 - GASKET, SURGE TANK COVER | ||||
| 17127-62020 |
1VZFE..VZV30,31 |
1 | ||
| 17129 - TANK, INTAKE AIR SURGE | ||||
| 17109-62021 |
1VZFE..VZV30,31 |
1 | ||
| 17109-62020 |
1VZFE..VZV30,31 |
1 | ||
| 17129H - UNION, NO.4 | ||||
| 90404-51064 |
1VZFE..VZV30,31 |
1 | ||
| 17139 - STAY, MANIFOLD, NO.2 | ||||
| 17139-62010 |
1VZFE,4VZFE..VZV3# |
1 | ||
| 17141 - MANIFOLD, EXHAUST | ||||
| 17141-62030 |
1VZFE..VZV30,31 |
1 | ||
| 17141J - BOLT, STUD(FOR EXHAUST MANIFOLD, RH) | ||||
| 90116-08128 |
1VZFE..VZV3# |
2 | ||
| 90126-08007 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 90116-08359 |
1VZFE..VZV3# |
2 | ||
| 90116-08128 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 90126-08007 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 90126-08006 |
1VZFE..VZV30,31 NO.1 |
1 | ||
| 17141J - BOLT, STUD(FOR EXHAUST MANIFOLD, RH) | ||||
| 90116-08128 |
1VZFE..VZV3# |
2 | ||
| 90126-08007 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 90116-08359 |
1VZFE..VZV3# |
2 | ||
| 90116-08128 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 90126-08007 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 90126-08006 |
1VZFE..VZV30,31 NO.1 |
1 | ||
| 17142B - MANIFOLD, EXHAUST, LH | ||||
| 17142-62020 |
1VZFE..VZV30,31 |
1 | ||
| 17142C - BOLT, STUD(FOR EXHAUST MANIFOLD, LH) | ||||
| 90116-08359 |
1VZFE..VZV3# |
2 | ||
| 90126-08007 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 90126-08006 |
1VZFE..VZV30,31 NO.1 |
1 | ||
| 90126-08007 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 90116-08128 |
1VZFE..VZV3# |
2 | ||
| 90116-08128 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 17142C - BOLT, STUD(FOR EXHAUST MANIFOLD, LH) | ||||
| 90116-08359 |
1VZFE..VZV3# |
2 | ||
| 90126-08007 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 90126-08006 |
1VZFE..VZV30,31 NO.1 |
1 | ||
| 90126-08007 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 90116-08128 |
1VZFE..VZV3# |
2 | ||
| 90116-08128 |
1VZFE..VZV30,31 NO.2 |
1 | ||
| 17152 - BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||||
| 90126-10003 |
1VZFE,4VZFE..VZV3# |
4 | ||
| 17152A - BOLT,STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||||
| 90126-10003 |
1VZFE,4VZFE..VZV3# |
4 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-10150 |
1VZFE,4VZFE..VZV3# EXHAUST MANIFOLD |
12 | ||
| 90116-08251 |
1VZFE,4VZFE..VZV3# INTAKE MANIFOLD |
4 | ||
| 17167 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.1 | ||||
| 17167-62020 |
1VZFE,4VZFE..VZV3# |
1 | ||
| 17168 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.2 | ||||
| 17168-62020 |
1VZFE,4VZFE..VZV3# |
1 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-62030 |
1VZFE..VZV30,31 |
1 | ||
| 17173A - GASKET, EXHAUST MANIFOLD TO HEAD, LH | ||||
| 17173-62030 |
1VZFE..VZV30,31 |
1 | ||
| 17176 - GASKET, AIR SURGE TANK TO INTAKE MANIFOLD | ||||
| 17176-62020 |
1VZFE..VZV30,31 |
1 | ||
| 17177 - GASKET, INTAKE MANIFOLD TO HEAD, NO.1 | ||||
| 17177-62010 |
1VZFE..VZV30,31 |
2 | ||
| 17177 - GASKET, INTAKE MANIFOLD TO HEAD, NO.1 | ||||
| 17177-62010 |
1VZFE..VZV30,31 |
2 | ||
| 17300 - VALVE ASSY, INTAKE AIR CONTROL | ||||
| 17300-62012 |
1VZFE..VZV30,31 |
1 | ||
| 17300B - UNION(FOR INTAKE AIR CONTROL VALVE) | ||||
| 90404-51096 |
1VZFE..VZV30,31 |
1 | ||
| 17315A - GASKET, INTAKE AIR CONTROL VALVE | ||||
| 17315-62010 |
1VZFE..VZV30,31 |
1 | ||
| 23260E - INJECTOR ASSY, COLD START FUEL | ||||
| 23260-69015 |
1VZFE..VZV30,31 |
1 | ||
| 23293A - GASKET, COLD START FUEL INJECTOR | ||||
| 23293-62020 |
1VZFE..VZV30,31 |
1 | ||
| 25052 - CONVERTER SUB-ASSY, EXHAUST MANIFOLD, NO.2 | ||||
| 25052-62010 |
1VZFE..VZV3# |
1 | ||
| 25508 - CONVERTER SUB-ASSY, MANIFOLD | ||||
| 25051-62010 |
1VZFE..VZV3# |
1 | ||
| 25576 - GASKET, MANIFOLD CONVERTER | ||||
| 25576-62010 |
1VZFE..VZV3# |
1 | ||
| 25577 - GASKET, MANIFOLD COVER, LH | ||||
| 25576-62010 |
1VZFE..VZV3# |
1 | ||
| 25586 - INSULATOR, MANIFOLD CONVERTER, NO.1 | ||||
| 25586-62010 |
1VZFE,4VZFE..VZV3# |
1 | ||
| 25587 - INSULATOR, MANIFOLD CONVERTER, NO.2 | ||||
| 25587-62010 |
1VZFE,4VZFE..VZV3# |
1 | ||
| 25588 - INSULATOR, MANIFOLD CONVERTER, NO.3 | ||||
| 25588-62010 |
1VZFE,4VZFE..VZV3# |
1 | ||
| 25589 - INSULATOR, MANIFOLD CONVERTER, NO.4 | ||||
| 25589-62010 |
1VZFE,4VZFE..VZV3# |
1 | ||
| Common parts | ||||
| 78186-32050 | ||||
| 90105-10273 | ||||
| 90116-06028 | ||||
| 90116-06070 | ||||
| 90116-08231 | ||||
| 90116-08252 | ||||
| 90116-08327 | ||||
| 90116-10149 | ||||
| 90116-10162 | ||||
| 90119-06494 | ||||
| 90119-08609 | ||||
| 90119-08809 | ||||
| 90119-10663 | ||||
| 90126-06003 | ||||
| 90126-10002 | ||||
| 90179-06080 | ||||
| 90179-08117 | ||||
| 90179-08183 | ||||
| 90179-10070 | ||||
| 90179-10147 | ||||
| 90901-19005 | ||||
| 91651-60620 | ||||
| 91651-61018 | ||||
| 94623-10800 | ||||
