SV33-AEPMK (1990)
Toyota Camry/Vista
(9007- )4FC
A140E,A140L,A540E,A540H
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 30250 - CONVERTER ASSY, TORQUE, REBUILT | ||||
| 30250-32100 |
VZV32,33 |
1 | ||
| 30250-20190 |
SV32,33..4FC..(ETO,LUM,VE,VX,ZX) |
1 | ||
| 32000 - CONVERTER ASSY, TORQUE | ||||
| 32000-32100 |
VZV32,33 |
1 | ||
| 32000-20190 |
SV32,33..4FC..(ETO,LUM,VE,VX,ZX) |
1 | ||
| 32101 - GEAR SUB-ASSY, DRIVE PLATE & RING | ||||
| 32101-32050 |
SV30,32,33..4FC..(ETO,LUM,VE,VL,VR,VX,XT,ZE,ZV,ZX) |
1 | ||
| 32101-32080 |
VZV32,33 |
1 | ||
| 32101A - BOLT(FOR DRIVE PLATE & TORQUE CONVERTER SETTING) | ||||
| 90119-09009 |
VZV32,33 *9−1.25PX12.8−8.8,ｲｴﾛｰ |
5 | ||
| 90119-08498 |
SV3#,VZV30,31..4FC *8−1.25PX12−8 |
5 | ||
| 90109-08113 |
SV3#,VZV30,31..4FC *8−1.25PX12−8.4 |
1 | ||
| 90119-09019 |
VZV32,33 *9−1.25PX12.4−8.3,OLIVE GREEN |
1 | ||
| 90119-09018 |
VZV32,33 *9−1.25PX12.4−8.4,ｲｴﾛｰ |
5 | ||
| 90119-09010 |
VZV32,33 *9−1.25PX12.8−9,OLIVE GREEN |
1 | ||
| 32101C - BOLT, HEXAGON(FOR DRIVE PLATE SETTING) | ||||
| 90105-10048 |
VZV32,33 *10−1.25PX18−13 |
8 | ||
| 90109-10054 |
SV3#..4FC..(ETO,LUM,VE,VL,VR,VX,XT,ZE,ZV,ZX) *10−1.25PX22−16 |
8 | ||
| 32116 - SPACER, DRIVE PLATE, FRONT | ||||
| 32116-32011 |
SV3#..4FC..(ETO,LUM,VE,VL,VR,VX,XT,ZE,ZV,ZX) |
1 | ||
| 32117 - SPACER, DRIVE PLATE, REAR | ||||
| 32117-32010 |
SV3#..4FC..(ETO,LUM,VE,VL,VR,VX,XT,ZE,ZV,ZX) |
1 | ||
| 35301 - BODY SUB-ASSY, FRONT OIL PUMP | ||||
| 35035-32020 |
CV30,SV30,32,33..4FC TOYOTA |
1 | ||
| 35035-32010 |
CV30,SV30,32,33..4FC AISIN AW |
1 | ||
| 35301 - BODY SUB-ASSY, FRONT OIL PUMP | ||||
| 35035-32020 |
CV30,SV30,32,33..4FC TOYOTA |
1 | ||
| 35035-32010 |
CV30,SV30,32,33..4FC AISIN AW |
1 | ||
| 35301A - SEAL, OIL (FOR FRONT OIL PUMP) | ||||
| 90311-38020 |
CV30,SV3#,VZV3#..4FC |
1 | ||
| 90311-38020 |
CV30,SV30,32,33..4FC |
2 | ||
| 35301B - RING, O (FOR FRONT OIL PUMP BODY) | ||||
| 90301-99024 |
CV30,SV3#,VZV3#..4FC |
1 | ||
| 35301F - BOLT (FOR FRONT OIL PUMP SETTING) | ||||
| 90105-08050 |
CV30,SV3#,VZV3#..4FC *8−1.25PX28−28 |
7 | ||
| 35307C - RACE, THRUST BEARING (FOR STATOR SHAFT) | ||||
| 35789-32030 |
CV30,SV3#..4FC 厚さ=1.4 |
1 | ||
| 35789-32020 |
CV30,SV3#..4FC 厚さ=0.8 |
1 | ||
| 35789-32030 |
CV30,SV32,33,35..4FC 厚さ=1.4 |
1 | ||
| 35307F - BOLT (FOR STATOR SHAFT) | ||||
| 90119-06180 |
CV30,SV3#,VZV3#..4FC |
11 | ||
| 90119-06180 |
CV30,SV30,32,33..4FC |
22 | ||
| 35321 - GEAR, FRONT OIL PUMP DRIVE | ||||
| 35321-32050 |
CV30,SV30,32,33,VZV3#..4FC 厚さ=9.456−9.474 |
1 | ||
| 35321-32060 |
CV30,SV30,32,33,VZV3#..4FC 厚さ=9.474−9.490 |
1 | ||
| 35321-32040 |
CV30,SV30,32,33..4FC 厚さ=9.440−9.456 |
1 | ||
| 35321-32040 |
CV30,SV30,32,33,VZV3#..4FC 厚さ=9.440−9.456 |
1 | ||
| 35321-32060 |
CV30,SV30,32,33..4FC 厚さ=9.474−9.490 |
1 | ||
| 35321-12110 |
CV30,SV30,32,33..4FC 厚さ=9.481−9.490 |
1 | ||
| 35321-32050 |
CV30,SV30,32,33..4FC 厚さ=9.456−9.474 |
1 | ||
| 35321-12090 |
CV30,SV30,32,33..4FC 厚さ=9.460−9.470 |
1 | ||
| 35321-12100 |
CV30,SV30,32,33..4FC 厚さ=9.471−9.480 |
1 | ||
| 35321-12070 |
CV30,SV30,32,33..4FC 厚さ=9.440−9.449 |
1 | ||
| 35321-12080 |
CV30,SV30,32,33..4FC 厚さ=9.450−9.459 |
1 | ||
| 35322 - GEAR, FRONT OIL PUMP DRIVEN | ||||
| 35322-32040 |
CV30,SV30,32,33,VZV3#..4FC 厚さ=9.440−9.456 |
1 | ||
| 35322-12080 |
CV30,SV30,32,33..4FC 厚さ=9.460−9.470 |
1 | ||
| 35322-32050 |
CV30,SV30,32,33,VZV3#..4FC 厚さ=9.456−9.474 |
1 | ||
| 35322-32040 |
CV30,SV30,32,33..4FC 厚さ=9.440−9.456 |
1 | ||
| 35322-32060 |
CV30,SV30,32,33,VZV3#..4FC 厚さ=9.474−9.490 |
1 | ||
| 35322-12100 |
CV30,SV30,32,33..4FC 厚さ=9.481−9.490 |
1 | ||
| 35322-32060 |
CV30,SV30,32,33..4FC 厚さ=9.474−9.490 |
1 | ||
| 35322-12060 |
CV30,SV30,32,33..4FC 厚さ=9.440−9.449 |
1 | ||
| 35322-32050 |
CV30,SV30,32,33..4FC 厚さ=9.456−9.474 |
1 | ||
| 35322-12090 |
CV30,SV30,32,33..4FC 厚さ=9.471−9.480 |
1 | ||
| 35322-12070 |
CV30,SV30,32,33..4FC 厚さ=9.450−9.459 |
1 | ||
| 35370 - SHAFT ASSY, STATOR | ||||
| 35370-12040 |
CV30,SV30,32,33..4FC AISIN AW |
1 | ||
| 35370-32050 |
CV30,SV30,32,33..4FC TOYOTA |
1 | ||
| 35370 - SHAFT ASSY, STATOR | ||||
| 35370-12040 |
CV30,SV30,32,33..4FC AISIN AW |
1 | ||
| 35370-32050 |
CV30,SV30,32,33..4FC TOYOTA |
1 | ||
| 35616B - WASHER, CLUTCH DRUM THRUST (FOR STATOR SHAFT) | ||||
| 35616-32010 |
CV30,SV3#,VZV3#..4FC |
1 | ||
| 35617 - RING, CLUTCH DRUM OIL SEAL | ||||
| 35617-32011 |
CV30,SV3#,VZV3#..4FC |
2 | ||
| 35617 - RING, CLUTCH DRUM OIL SEAL | ||||
| 35617-32011 |
CV30,SV3#,VZV3#..4FC |
2 | ||
