SV21-UTPMK (1986)
Toyota Camry/Vista
(8608- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55011 - GARNISH SUB-ASSY, INSTRUMENT PANEL SAFETY PAD | ||||
| 55011-32050 |
CV20,SV20,21,VZV20 |
1 | ||
| 55011-32050 |
CV20,SV2#,VZV20 |
1 | ||
| 55011 - GARNISH SUB-ASSY, INSTRUMENT PANEL SAFETY PAD | ||||
| 55011-32050 |
CV20,SV20,21,VZV20 |
1 | ||
| 55011-32050 |
CV20,SV2#,VZV20 |
1 | ||
| 55331 - REINFORCEMENT, INSTRUMENT PANEL | ||||
| 55330-32060 |
CV20,SV2#,VZV20 |
1 | ||
| 55341 - BRACE, INSTRUMENT PANEL, NO.1 | ||||
| 55306-32070 |
CV20,SV2#,VZV20 |
1 | ||
| 55342 - BRACE, INSTRUMENT PANEL, NO.2 | ||||
| 55307-32040 |
CV20,SV2#,VZV20 |
1 | ||
| 55376 - BRACKET, INSTRUMENT PANEL MOUNTING, NO.1 | ||||
| 55376-32030 |
CV20,SV2#,VZV20 |
1 | ||
| 55377A - BRACKET, INSTRUMENT PANEL MOUNTING, NO.2 | ||||
| 55377-32030 |
CV20,SV2#,VZV20 |
1 | ||
| 55378A - BRACKET, GLOVE COMPARTMENT DOOR LOCK MOUNTING | ||||
| 55378-32040 |
CV20,SV2#,VZV20 |
1 | ||
| 55381A - BRACKET, FINISH PANEL MOUNTING | ||||
| 55381-32040 |
CV20,SV2#,VZV20 右側 |
1 | ||
| 55382-32020 |
CV20,SV2#,VZV20 LH |
1 | ||
| 55382-32020 |
CV20,SV2#,VZV20 左側 |
1 | ||
| 55381-32040 |
CV20,SV2#,VZV20 RH |
1 | ||
| 55381A - BRACKET, FINISH PANEL MOUNTING | ||||
| 55381-32040 |
CV20,SV2#,VZV20 右側 |
1 | ||
| 55382-32020 |
CV20,SV2#,VZV20 LH |
1 | ||
| 55382-32020 |
CV20,SV2#,VZV20 左側 |
1 | ||
| 55381-32040 |
CV20,SV2#,VZV20 RH |
1 | ||
| 55401 - PANEL SUB-ASSY, INSTRUMENT CLUSTER FINISH | ||||
| 55404-3205004 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55404-3205005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55404-3205002 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55404-3205002 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55404-3205005 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55404-3205004 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55404-3205001 |
CV20,SV2#,VZV20 BLACK,TRIM3#,4#,8# |
1 | ||
| 55404 - SAFETY PAD SUB-ASSY, INSTRUMENT PANEL, UPPER | ||||
| 55401-3205002 |
CV20,SV2#..LT,VC,VE,VL,XT,ZT MAROON,MAROON,TRIM3# |
1 | ||
| 55401-3205005 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55401-3205004 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55401-3205005 |
CV20,SV2#..LT,VC,VE,VL,XT,ZT BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55401-3205002 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55401-3205004 |
CV20,SV2#..LT,VC,VE,VL,XT,ZT BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55412C - PANEL, INSTRUMENT CLUSTER FINISH, CENTER NO.1 | ||||
| 55412-32070 |
CV20,SV2# |
1 | ||
| 55414 - BEZEL, CIGAR LIGHTER HOLE | ||||
| 55477-12060 |
CV20,SV2#,VZV20 |
1 | ||
| 55432A - PANEL, INSTRUMENT PANEL FINISH, LOWER RH | ||||
| 55432-3203005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55432-3203002 |
CV20,SV2# MAROON,MAROON,TRIM3# |
1 | ||
| 55432-3203002 |
CV20,SV2# MAROON,TRIM3# |
1 | ||
| 55432-3203004 |
CV20,SV2# BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55432-3203005 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55432-3203004 |
CV20,SV2# DARK BLUE,TRIM8# |
1 | ||
| 55433B - PANEL, INSTRUMENT PANEL FINISH, LOWER NO.2 | ||||
| 55433-3203002 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55433-3203005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55433-3203004 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55433-3203002 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55433-3203005 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55433-3203004 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55434B - PANEL, INSTRUMENT PANEL FINISH, LOWER CENTER | ||||
| 55434-3205004 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55434-3205002 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55434-3205002 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55434-3205004 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55434-3205005 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55434-3205005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55441C - BOX, INSTRUMENT PANEL COIN | ||||
| 55441-3203001 |
CV20,SV2#,VZV20 BLACK |
1 | ||
| 55441-3203001 |
CV20,SV20,21,VZV20 BLACK,TRIM3#,4#,8# |
1 | ||
| 55457B - SPACER, INSTRUMENT PANEL SAFETY PAD | ||||
| 55457-22030 |
CV20,SV2#,VZV20 |
3 | ||
| 55457-22030 |
CV20,SV2#,VZV20 |
5 | ||
| 55510 - DOOR ASSY, GLOVE COMPARTMENT | ||||
| 55550-3206002 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55550-3206004 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55550-3206002 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55550-3206005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55550-3206005 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55550-3206004 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55510A - CUSHION(FOR GLOVE COMPARTMENT DOOR) | ||||
| 90541-03015 |
CV20,SV2#,VZV20 |
3 | ||
| 55521C - COVER, STEREO OPENING | ||||
| 55521-1405001 |
CV20,SV2#,VZV20 BLACK,BLACK |
1 | ||
| 55521-1405001 |
CV20,SV2#..LT,VC,VE,VL,VR,XT,ZE,ZT BLACK,TRIM3#,4#,8# |
1 | ||
| 55531B - COVER, CHOKE KNOB HOLE | ||||
| 55531-32020 |
CV20,SV2#,VZV20 |
1 | ||
| 55538A - COVER, COOLER SWITCH HOLE | ||||
| 55538-16020 |
CV20,SV2#..LT,VC,VE,VL,XT,ZT |
1 | ||
| 55539 - COVER, SPARE SWITCH HOLE | ||||
| 55539-3201001 |
SV2#..HT BLACK,BLACK |
1 | ||
| 55539-3201001 |
CV20,SV2# BLACK,TRIM3#,4#,8# |
1 | ||
| 55539 - COVER, SPARE SWITCH HOLE | ||||
| 55539-3201001 |
SV2#..HT BLACK,BLACK |
1 | ||
| 55539-3201001 |
CV20,SV2# BLACK,TRIM3#,4#,8# |
1 | ||
| 55539 - COVER, SPARE SWITCH HOLE | ||||
| 55539-3201001 |
SV2#..HT BLACK,BLACK |
1 | ||
| 55539-3201001 |
CV20,SV2# BLACK,TRIM3#,4#,8# |
1 | ||
| 55548A - COVER, INSTRUMENT PANEL HOLE | ||||
| 55548-32040 |
CV20,SV2#,VZV20 |
1 | ||
| 55561A - STRIKER, GLOVE COMPARTMENT DOOR LOCK | ||||
| 55561-32020 |
CV20,SV2#,VZV20 |
1 | ||
| 55565 - HANDLE, GLOVE COMPARTMENT DOOR LOCK | ||||
| 55565-2004005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55565-2004012 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55565-2004012 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55565-2004014 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55565-2004005 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55565-2004014 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55606 - COVER SUB-ASSY, INSTRUMENT PANEL UNDER, NO.1 | ||||
| 55606-32010 |
CV20,SV21,25,VZV20 |
1 | ||
| 55606-32010 |
CV20,SV21,VZV20 |
1 | ||
| 55607 - COVER SUB-ASSY, INSTRUMENT PANEL UNDER, NO.2 | ||||
| 55607-32010 |
CV20,SV21,25,VZV20 |
1 | ||
| 55607-32010 |
CV20,SV2#,VZV20 |
1 | ||
| 55650 - REGISTER ASSY, INSTRUMENT PANEL, NO.1 | ||||
| 55650-3205102 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55650-3205004 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55650-3205002 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55650-3205104 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55650-3205105 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55650-3205005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55660 - REGISTER ASSY, INSTRUMENT PANEL, NO.2 | ||||
| 55660-3205005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55660-3205004 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55660-3205105 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55660-3205002 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55660-3205104 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55660-3205102 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55670 - REGISTER ASSY, INSTRUMENT PANEL, NO.3 | ||||
| 55670-3205105 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55670-3205004 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55670-3205102 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55670-3205005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55670-3205002 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55670-3205104 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55680 - REGISTER ASSY, INSTRUMENT PANEL, LOWER NO.1 | ||||
| 55680-1403014 |
SV21,25;SV20..HT..VL;SV20..VE,VR,ZE,ZT DARK BLUE,TRIM8# |
1 | ||
| 55680-1403014 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55680-1403005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55680-1403002 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55680-1403002 |
SV21,25;SV20..HT..VL;SV20..VE,VR,ZE,ZT MAROON,TRIM3# |
1 | ||
| 55680-1403005 |
SV21,25;SV20..HT..VL;SV20..VE,VR,ZE,ZT DARK BEIGE,TRIM4# |
1 | ||
| 55680-1403005 |
SV20..HT..VL;SV20..VE,VR,ZE;SV21,25..GT,VE,VL,VR,VX,XT,ZE,ZX DARK BEIGE,TRIM4# |
1 | ||
| 55680-1403002 |
SV20..HT..VL;SV20..VE,VR,ZE;SV21,25..GT,VE,VL,VR,VX,XT,ZE,ZX MAROON,TRIM3# |
1 | ||
| 55680-1403014 |
SV20..HT..VL;SV20..VE,VR,ZE;SV21,25..GT,VE,VL,VR,VX,XT,ZE,ZX DARK BLUE,TRIM8# |
1 | ||
| 55961 - NOZZLE, SIDE DEFROSTER, NO.1 | ||||
| 55961-3205002 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55961-3205004 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55961-3205005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| 55961-3205004 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55961-3205005 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55961-3205002 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55962 - NOZZLE, SIDE DEFROSTER, NO.2 | ||||
| 55962-3203004 |
CV20,SV2#,VZV20 DARK BLUE,TRIM8# |
1 | ||
| 55962-3203002 |
CV20,SV2#,VZV20 MAROON,TRIM3# |
1 | ||
| 55962-3203002 |
CV20,SV2#,VZV20 MAROON,MAROON,TRIM3# |
1 | ||
| 55962-3203004 |
CV20,SV2#,VZV20 BLUE,DARK BLUE,TRIM8# |
1 | ||
| 55962-3203005 |
CV20,SV2# DARK BEIGE,TRIM4# |
1 | ||
| 55962-3203005 |
CV20,SV2# BEIGE,DARK BEIGE,TRIM4# |
1 | ||
| Common parts | ||||
| 90105-08120 | ||||
| 90119-06106 | ||||
| 90151-40005 | ||||
| 90179-06097 | ||||
| 90179-08025 | ||||
| 90183-05094 | ||||
| 90183-05103 | ||||
| 90467-14002 | ||||
| 90468-04087 | ||||
| 90468-05047 | ||||
| 91665-60820 | ||||
| 93540-23006 | ||||
| 93567-55014 | ||||
| 93567-55016 | ||||
| 93568-55014 | ||||
| Linked diagrams | ||||
| 6712 | ||||
| 8302 | ||||
