SV20-JEPNL (1986)
Toyota Camry/Vista
(8608- )CV20,SV2#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88501 - EVAPORATOR SUB-ASSY, COOLER, NO.1 | ||||
| 88501-32040 |
CV20,SV2#,VZV20 |
1 | ||
| 88502 - CASE SUB-ASSY, COOLING UNIT | ||||
| 88502-32040 |
CV20,SV2#,VZV20 NO.2 |
1 | ||
| 88502-32030 |
CV20,SV2#,VZV20 NO.1 |
1 | ||
| 88502 - CASE SUB-ASSY, COOLING UNIT | ||||
| 88502-32040 |
CV20,SV2#,VZV20 NO.2 |
1 | ||
| 88502-32030 |
CV20,SV2#,VZV20 NO.1 |
1 | ||
| 88510 - UNIT ASSY, COOLER | ||||
| 88510-32230 |
SV2# |
1 | ||
| 88510-32230 |
SV20..SED..(VL,XT) |
1 | ||
| 88515 - VALVE, COOLER EXPANSION | ||||
| 88515-16040 |
CV20,SV2#,VZV20 |
1 | ||
| 88539 - HOSE, COOLER UNIT DRAIN, NO.1 | ||||
| 88539-20130 |
CV20,SV2#,VZV20 |
1 | ||
| 88539-22110 |
SV20..SED..(VL,XT) |
1 | ||
| 88605 - HARNESS SUB-ASSY, COOLER WIRING, NO.1 | ||||
| 88605-32350 |
SV2# |
1 | ||
| 88605-32350 |
SV2#..LT,VC,VE,VL,VR,VX,XT,ZE,ZT,ZX |
1 | ||
| 88605-32350 |
SV20..SED..(VL,XT) |
1 | ||
| 88625 - THERMISTOR, COOLER, NO.1 | ||||
| 88625-32040 |
CV20,SV2#,VZV20 |
1 | ||
| 88650 - AMPLIFIER ASSY, COOLER STABILIZER | ||||
| 88650-32150 |
SV2#..LT,VC,VE,VL,VR,VX,XT,ZE,ZT,ZX NO.2 |
1 | ||
| 88650-32110 |
SV2# NO.1 |
1 | ||
| 88650-32150 |
SV2# NO.2 |
1 | ||
| 88650-32150 |
SV20..SED..(VL,XT) NO.2 |
1 | ||
| 88650-32110 |
SV20..SED..(VL,XT) NO.1 |
1 | ||
| 88650 - AMPLIFIER ASSY, COOLER STABILIZER | ||||
| 88650-32150 |
SV2#..LT,VC,VE,VL,VR,VX,XT,ZE,ZT,ZX NO.2 |
1 | ||
| 88650-32110 |
SV2# NO.1 |
1 | ||
| 88650-32150 |
SV2# NO.2 |
1 | ||
| 88650-32150 |
SV20..SED..(VL,XT) NO.2 |
1 | ||
| 88650-32110 |
SV20..SED..(VL,XT) NO.1 |
1 | ||
| 88688A - BRACKET, COOLER STABILIZER AMPLIFIER | ||||
| 88688-32180 |
SV2#..LT,VC,VE,VL,VR,VX,XT,ZE,ZT,ZX |
1 | ||
| 88688-32180 |
SV2#,VZV20 |
1 | ||
| 88716F - PIPE, COOLER REFRIGERANT LIQUID, F | ||||
| 88716-32270 |
CV20,SV2#,VZV20 |
1 | ||
| 88891 - PACKING (FOR COOLER) | ||||
| 88891-32060 |
SV2# |
1 | ||
| 88891-32060 |
SV2#..LT,VC,VE,VL,VR,VX,XT,ZE,ZT,ZX |
1 | ||
| Common parts | ||||
| 82711-32830 | ||||
| 87116-14010 | ||||
| 88569-32010 | ||||
| 90099-00930 | ||||
| 90099-00968 | ||||
| 90099-32129 | ||||
| 90179-06054 | ||||
| 90480-01378 | ||||
| 93510-15012 | ||||
| 93540-15012 | ||||
