ZZT241W-DWPGK (2002)
Toyota Caldina
(0209- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69030A - LOCK ASSY, FRONT DOOR W/MOTOR, RH | ||||
| 69030-33241 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69040A - LOCK ASSY, FRONT DOOR W/MOTOR, LH | ||||
| 69040-13051 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69201A - FRAME SUB-ASSY, FRONT DOOR OUTSIDE HANDLE, RH | ||||
| 69201-33010 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69202A - FRAME SUB-ASSY, FRONT DOOR OUTSIDE HANDLE, LH | ||||
| 69202-33010 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69205 - HANDLE SUB-ASSY, FRONT DOOR INSIDE, RH | ||||
| 69205-21010C0 |
AZT24#,ST246,ZZT241 BLACK,TRIM2# |
1 | ||
| 69205B - CUSHION(FOR FRONT DOOR INSIDE HANDLE) | ||||
| 90541-04014 |
AZT24#,ST246,ZZT241 |
2 | ||
| 69206B - HANDLE SUB-ASSY, FRONT DOOR INSIDE, LH | ||||
| 69206-21010C0 |
AZT24#,ST246,ZZT241 BLACK,TRIM2# |
1 | ||
| 69210 - HANDLE ASSY, FRONT DOOR, OUTSIDE RH | ||||
| 69210-33080B3 |
AZT24#,ST246,ZZT241 SILVER M.M.,1E7 |
1 | ||
| 69210-33080C1 |
AZT24#,ST246,ZZT241 BLACK MC.,209 |
1 | ||
| 69210-33080A3 |
AZT24#,ST246,ZZT241 WHITE PEARL CS.,070 |
1 | ||
| 69210-33080A0 |
AZT24#,ST246,ZZT241 SUPER WHITE 2,040 |
1 | ||
| 69210-33080E1 |
AZT24#,ST246,ZZT241 ORANGE ME.,4R1 |
1 | ||
| 69210-33080B4 |
AZT24#,ST246,ZZT241 DK.GRAY M.M.,1E9 |
1 | ||
| 69210-33080D4 |
AZT24#,ZZT241 SUPER RED 5,3P0 |
1 | ||
| 69210-33080J4 |
AZT24#,ST246,ZZT241 BLUE M.M.,8Q1 |
1 | ||
| 69217E - COVER, FRONT DOOR OUTSIDE HANDLE, RH | ||||
| 69217-33010A0 |
AZT24#,ST246,ZZT241 SUPER WHITE 2,040 |
1 | ||
| 69217-33010B3 |
AZT24#,ST246,ZZT241 SILVER M.M.,1E7 |
1 | ||
| 69217-33010E1 |
AZT24#,ST246,ZZT241 ORANGE ME.,4R1 |
1 | ||
| 69217-33010A5 |
AZT24#,ST246,ZZT241 WHITE PEARL CS.,070 |
1 | ||
| 69217-33010J4 |
AZT24#,ST246,ZZT241 BLUE M.M.,8Q1 |
1 | ||
| 69217-33010B4 |
AZT24#,ST246,ZZT241 DK.GRAY M.M.,1E9 |
1 | ||
| 69217-33010D5 |
AZT24#,ZZT241 SUPER RED 5,3P0 |
1 | ||
| 69217-33010C1 |
AZT24#,ST246,ZZT241 BLACK MC.,209 |
1 | ||
| 69217F - COVER, FRONT DOOR OUTSIDE HANDLE, LH | ||||
| 69217-33010A0 |
AZT24#,ST246,ZZT241 SUPER WHITE 2,040 |
1 | ||
| 69217-33010J4 |
AZT24#,ST246,ZZT241 BLUE M.M.,8Q1 |
1 | ||
| 69217-33010B3 |
AZT24#,ST246,ZZT241 SILVER M.M.,1E7 |
1 | ||
| 69217-33010A5 |
AZT24#,ST246,ZZT241 WHITE PEARL CS.,070 |
1 | ||
| 69217-33010E1 |
AZT24#,ST246,ZZT241 ORANGE ME.,4R1 |
1 | ||
| 69217-33010C1 |
AZT24#,ST246,ZZT241 BLACK MC.,209 |
1 | ||
| 69217-33010D5 |
AZT24#,ZZT241 SUPER RED 5,3P0 |
1 | ||
| 69217-33010B4 |
AZT24#,ST246,ZZT241 DK.GRAY M.M.,1E9 |
1 | ||
| 69220 - HANDLE ASSY, FRONT DOOR OUTSIDE, LH | ||||
| 69210-33080B3 |
AZT24#,ST246,ZZT241 SILVER M.M.,1E7 |
1 | ||
| 69210-33080C1 |
AZT24#,ST246,ZZT241 BLACK MC.,209 |
1 | ||
| 69210-33080B4 |
AZT24#,ST246,ZZT241 DK.GRAY M.M.,1E9 |
1 | ||
| 69210-33080D4 |
AZT24#,ZZT241 SUPER RED 5,3P0 |
1 | ||
| 69210-33080A0 |
AZT24#,ST246,ZZT241 SUPER WHITE 2,040 |
1 | ||
| 69210-33080E1 |
AZT24#,ST246,ZZT241 ORANGE ME.,4R1 |
1 | ||
| 69210-33080A3 |
AZT24#,ST246,ZZT241 WHITE PEARL CS.,070 |
1 | ||
| 69210-33080J4 |
AZT24#,ST246,ZZT241 BLUE M.M.,8Q1 |
1 | ||
| 69241H - PAD, FRONT DOOR OUTSIDE HANDLE, FRONT | ||||
| 69241-42020 |
AZT24#,ST246,ZZT241 |
2 | ||
| 69242E - PAD, FRONT DOOR OUTSIDE HANDLE, REAR | ||||
| 69242-42010 |
AZT24#,ST246,ZZT241 |
2 | ||
| 69283 - PLUG, FRONT DOOR INSIDE HANDLE BEZEL, RH | ||||
| 69283-33020C0 |
AZT24#,ST246,ZZT241 BLACK,TRIM2# |
1 | ||
| 69284C - PLUG, FRONT DOOR INSIDE HANDLE BEZEL, LH | ||||
| 69284-33020C0 |
AZT24#,ST246,ZZT241 BLACK,TRIM2# |
1 | ||
| 69293G - SNAP, FRONT DOOR OUTSIDE HANDLE, RH | ||||
| 69293-33010 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69293H - SNAP, FRONT DOOR OUTSIDE HANDLE, LH | ||||
| 69293-33020 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69311A - ROD, FRONT DOOR LOCK OPEN, RH | ||||
| 69311-21020 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69312 - ROD, FRONT DOOR LOCK OPEN, LH | ||||
| 69312-21020 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69318C - SEAL, DOOR LOCK WIRING HARNESS | ||||
| 69318-51010 |
AZT24#,ST246,ZZT241 |
2 | ||
| 69410 - PLATE ASSY, FRONT DOOR LOCK STRIKER | ||||
| 69410-33010 |
AZT24#,ST246,ZZT241 |
2 | ||
| 69710B - CABLE ASSY, FRONT DOOR LOCK REMOTE CONTROL, RH | ||||
| 69710-21020 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69720B - CABLE ASSY, FRONT DOOR LOCK REMOTE CONTROL, LH | ||||
| 69710-21020 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69750C - CABLE ASSY, FRONT DOOR INSIDE LOCKING, RH | ||||
| 69750-21010 |
AZT24#,ST246,ZZT241 |
1 | ||
| 69760C - CABLE ASSY, FRONT DOOR INSIDE LOCKING LH | ||||
| 69750-21010 |
AZT24#,ST246,ZZT241 |
1 | ||
| Common parts | ||||
| 90148-50003 | ||||
| 90148-60022 | ||||
| 90148-80027 | ||||
| 90164-50031 | ||||
| 90166-50003 | ||||
| 90189-05003 | ||||
| 90189-05171 | ||||
