CT198V-DXMDS (1992)
Toyota Caldina
(9601- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 48131 - SPRING, FRONT COIL, RH | ||||
| 48131-2S430 |
CT198;CT196..4FC |
1 | ||
| 48131-2S430 |
CT198;CT196,ST195..4FC |
1 | ||
| 48131-2S430 |
CT198;CT196..4FC |
1 | ||
| 48131-2S410 |
CT198,199;CT196,ST198..4FC |
1 | ||
| 48132 - SPRING, FRONT COIL, LH | ||||
| 48131-2S410 |
CT198;CT196..4FC |
1 | ||
| 48131-2S410 |
CT198;CT196,ST195..4FC |
1 | ||
| 48131-2S410 |
CT198,199;CT196,ST198..4FC |
1 | ||
| 48157B - INSULATOR, FRONT COIL SPRING, UPPER RH | ||||
| 48157-12070 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48157-20130 |
CT19#,ET196,ST19# |
1 | ||
| 48157C - INSULATOR, FRONT COIL SPRING, UPPER LH | ||||
| 48157-12070 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48157-20130 |
CT19#,ET196,ST19# |
1 | ||
| 48158B - INSULATOR, FRONT COIL SPRING, LOWER RH | ||||
| 48158-20080 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48158C - INSULATOR, FRONT COIL SPRING, LOWER LH | ||||
| 48158-20080 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48331B - BUMPER, FRONT SPRING, RH | ||||
| 48331-12130 |
CT19#,ST19# |
1 | ||
| 48331-12150 |
CT19#,ST19# |
1 | ||
| 48331-12151 |
CT19#,ST19# |
1 | ||
| 48331C - BUMPER, FRONT SPRING, LH | ||||
| 48331-12130 |
CT19#,ST19# |
1 | ||
| 48331-12150 |
CT19#,ST19# |
1 | ||
| 48331-12151 |
CT19#,ST19# |
1 | ||
| 48471B - SEAT, FRONT COIL SPRING, UPPER RH | ||||
| 48044-20040 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48471C - SEAT, FRONT COIL SPRING, UPPER LH | ||||
| 48044-20040 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48510 - ABSORBER ASSY, SHOCK, FRONT RH | ||||
| 48510-29346 |
CT198,ST195 ﾏｰｸ 48510−21051 |
1 | ||
| 48510-29346 |
CT198 ﾏｰｸ 48510−21051 |
1 | ||
| 48510-29435 |
CT198,ST195..TZG,U,UL ﾏｰｸ 48510−21020 |
1 | ||
| 48510-29645 |
CT198 ﾏｰｸ 48510−21050 |
1 | ||
| 48520 - ABSORBER ASSY, SHOCK, FRONT LH | ||||
| 48520-29166 |
CT198,ST195 ﾏｰｸ 48520−20851 |
1 | ||
| 48520-29166 |
CT198 ﾏｰｸ 48520−20851 |
1 | ||
| 48520-29245 |
CT198,ST195..TZG,U,UL ﾏｰｸ 48520−21020 |
1 | ||
| 48520-29355 |
CT198 ﾏｰｸ 48520−21050 |
1 | ||
| 48603 - SUPPORT SUB-ASSY, FRONT SUSPENSION, RH | ||||
| 48609-20381 |
CT196,198,ET196 |
1 | ||
| 48609-21010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| 48603 - SUPPORT SUB-ASSY, FRONT SUSPENSION, RH | ||||
| 48609-20381 |
CT196,198,ET196 |
1 | ||
| 48609-21010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| 48603C - SEAL, DUST(FOR FRONT SUSPENSION SUPPORT RH) | ||||
| 90303-22049 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48603D - NUT(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER RH) | ||||
| 94182-11400 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48609 - SUPPORT SUB-ASSY, FRONT SUSPENSION, LH | ||||
| 48609-21010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| 48609-20381 |
CT196,198,ET196 |
1 | ||
| 48609 - SUPPORT SUB-ASSY, FRONT SUSPENSION, LH | ||||
| 48609-21010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| 48609-20381 |
CT196,198,ET196 |
1 | ||
| 48609D - SEAL, DUST(FOR FRONT SUSPENSION SUPPORT LH) | ||||
| 90303-22049 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48609E - NUT(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER LH) | ||||
| 94182-11400 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48684A - COVER, FRONT SUSPENSION SUPPORT DUST, RH | ||||
| 48684-32010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| 48684B - COVER, FRONT SUSPENSION SUPPORT DUST, LH | ||||
| 48684-32010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| Common parts | ||||
| 90179-10095 | ||||
| 90950-01453 | ||||
| 91611-60822 | ||||
(9211-9601)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 48131 - SPRING, FRONT COIL, RH | ||||
| 48131-2S430 |
CT198;CT196..4FC |
1 | ||
| 48131-2S430 |
CT198;CT196,ST195..4FC |
1 | ||
| 48131-2S430 |
CT198;CT196..4FC |
1 | ||
| 48131-2S410 |
CT198,199;CT196,ST198..4FC |
1 | ||
| 48132 - SPRING, FRONT COIL, LH | ||||
| 48131-2S410 |
CT198;CT196..4FC |
1 | ||
| 48131-2S410 |
CT198;CT196,ST195..4FC |
1 | ||
| 48131-2S410 |
CT198,199;CT196,ST198..4FC |
1 | ||
| 48157B - INSULATOR, FRONT COIL SPRING, UPPER RH | ||||
| 48157-12070 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48157-20130 |
CT19#,ET196,ST19# |
1 | ||
| 48157C - INSULATOR, FRONT COIL SPRING, UPPER LH | ||||
| 48157-12070 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48157-20130 |
CT19#,ET196,ST19# |
1 | ||
| 48158B - INSULATOR, FRONT COIL SPRING, LOWER RH | ||||
| 48158-20080 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48158C - INSULATOR, FRONT COIL SPRING, LOWER LH | ||||
| 48158-20080 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48331B - BUMPER, FRONT SPRING, RH | ||||
| 48331-12130 |
CT19#,ST19# |
1 | ||
| 48331-12150 |
CT19#,ST19# |
1 | ||
| 48331-12151 |
CT19#,ST19# |
1 | ||
| 48331C - BUMPER, FRONT SPRING, LH | ||||
| 48331-12130 |
CT19#,ST19# |
1 | ||
| 48331-12150 |
CT19#,ST19# |
1 | ||
| 48331-12151 |
CT19#,ST19# |
1 | ||
| 48471B - SEAT, FRONT COIL SPRING, UPPER RH | ||||
| 48044-20040 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48471C - SEAT, FRONT COIL SPRING, UPPER LH | ||||
| 48044-20040 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48510 - ABSORBER ASSY, SHOCK, FRONT RH | ||||
| 48510-29346 |
CT198,ST195 ﾏｰｸ 48510−21051 |
1 | ||
| 48510-29346 |
CT198 ﾏｰｸ 48510−21051 |
1 | ||
| 48510-29435 |
CT198,ST195..TZG,U,UL ﾏｰｸ 48510−21020 |
1 | ||
| 48510-29645 |
CT198 ﾏｰｸ 48510−21050 |
1 | ||
| 48520 - ABSORBER ASSY, SHOCK, FRONT LH | ||||
| 48520-29166 |
CT198,ST195 ﾏｰｸ 48520−20851 |
1 | ||
| 48520-29166 |
CT198 ﾏｰｸ 48520−20851 |
1 | ||
| 48520-29245 |
CT198,ST195..TZG,U,UL ﾏｰｸ 48520−21020 |
1 | ||
| 48520-29355 |
CT198 ﾏｰｸ 48520−21050 |
1 | ||
| 48603 - SUPPORT SUB-ASSY, FRONT SUSPENSION, RH | ||||
| 48609-20381 |
CT196,198,ET196 |
1 | ||
| 48609-21010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| 48603 - SUPPORT SUB-ASSY, FRONT SUSPENSION, RH | ||||
| 48609-20381 |
CT196,198,ET196 |
1 | ||
| 48609-21010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| 48603C - SEAL, DUST(FOR FRONT SUSPENSION SUPPORT RH) | ||||
| 90303-22049 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48603D - NUT(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER RH) | ||||
| 94182-11400 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48609 - SUPPORT SUB-ASSY, FRONT SUSPENSION, LH | ||||
| 48609-21010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| 48609-20381 |
CT196,198,ET196 |
1 | ||
| 48609 - SUPPORT SUB-ASSY, FRONT SUSPENSION, LH | ||||
| 48609-21010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| 48609-20381 |
CT196,198,ET196 |
1 | ||
| 48609D - SEAL, DUST(FOR FRONT SUSPENSION SUPPORT LH) | ||||
| 90303-22049 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48609E - NUT(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER LH) | ||||
| 94182-11400 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 48684A - COVER, FRONT SUSPENSION SUPPORT DUST, RH | ||||
| 48684-32010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| 48684B - COVER, FRONT SUSPENSION SUPPORT DUST, LH | ||||
| 48684-32010 |
CT196,197,198,199,ET196,ST198 |
1 | ||
| Common parts | ||||
| 90179-10095 | ||||
| 90950-01453 | ||||
| 91611-60822 | ||||
