CT196V-DXPDS (1992)
Toyota Caldina
(9211- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 85031C - VALVE SUB-ASSY, WASHER | ||||
| 85031-90A00 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 85375-12520 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 85035R - NOZZLE SUB-ASSY, REAR WASHER | ||||
| 85391-21010 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 85348R - JOINT, REAR WASHER HOSE, NO.1 | ||||
| 85349-89122 |
CT190,198,ET196..3FC,5F;CT196,ST19#..CZ,FZ,U,UL,UX ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85349-89122 |
AT191,CT19#,ET196,ST19# |
2 | ||
| 85349-89122 |
CT196,ST19#;CT190,198,ET196..3FC,5F |
2 | ||
| 85349-89122 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 85349-89122 |
CT196,198,ET196..U ｱﾘ(*RW) |
1 | ||
| 85348R - JOINT, REAR WASHER HOSE, NO.1 | ||||
| 85349-89122 |
CT190,198,ET196..3FC,5F;CT196,ST19#..CZ,FZ,U,UL,UX ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85349-89122 |
AT191,CT19#,ET196,ST19# |
2 | ||
| 85349-89122 |
CT196,ST19#;CT190,198,ET196..3FC,5F |
2 | ||
| 85349-89122 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 85349-89122 |
CT196,198,ET196..U ｱﾘ(*RW) |
1 | ||
| 85348R - JOINT, REAR WASHER HOSE, NO.1 | ||||
| 85349-89122 |
CT190,198,ET196..3FC,5F;CT196,ST19#..CZ,FZ,U,UL,UX ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85349-89122 |
AT191,CT19#,ET196,ST19# |
2 | ||
| 85349-89122 |
CT196,ST19#;CT190,198,ET196..3FC,5F |
2 | ||
| 85349-89122 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 85349-89122 |
CT196,198,ET196..U ｱﾘ(*RW) |
1 | ||
| 85348R - JOINT, REAR WASHER HOSE, NO.1 | ||||
| 85349-89122 |
CT190,198,ET196..3FC,5F;CT196,ST19#..CZ,FZ,U,UL,UX ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85349-89122 |
AT191,CT19#,ET196,ST19# |
2 | ||
| 85349-89122 |
CT196,ST19#;CT190,198,ET196..3FC,5F |
2 | ||
| 85349-89122 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 85349-89122 |
CT196,198,ET196..U ｱﾘ(*RW) |
1 | ||
| 85348R - JOINT, REAR WASHER HOSE, NO.1 | ||||
| 85349-89122 |
CT190,198,ET196..3FC,5F;CT196,ST19#..CZ,FZ,U,UL,UX ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85349-89122 |
AT191,CT19#,ET196,ST19# |
2 | ||
| 85349-89122 |
CT196,ST19#;CT190,198,ET196..3FC,5F |
2 | ||
| 85349-89122 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 85349-89122 |
CT196,198,ET196..U ｱﾘ(*RW) |
1 | ||
| 85348S - JOINT, REAR WASHER ELBOW, NO.1 | ||||
| 85355-14481 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 85349F - JOINT, REAR WASHER HOSE, NO.1 | ||||
| 85349-32150 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 85349J - JOINT, REAR WASHER HOSE, NO.4 | ||||
| 85349-89122 |
AT191,CT19#,ET196,ST190,191,195 ｶﾝｹﾂ ﾘﾔ ﾜｲﾊﾟ |
3 | ||
| 85349J - JOINT, REAR WASHER HOSE, NO.4 | ||||
| 85349-89122 |
AT191,CT19#,ET196,ST190,191,195 ｶﾝｹﾂ ﾘﾔ ﾜｲﾊﾟ |
3 | ||
| 85349J - JOINT, REAR WASHER HOSE, NO.4 | ||||
| 85349-89122 |
AT191,CT19#,ET196,ST190,191,195 ｶﾝｹﾂ ﾘﾔ ﾜｲﾊﾟ |
3 | ||
| 85371R - HOSE, REAR WASHER (FROM MOTOR TO JOINT) | ||||
| 90446-07001 |
AT191,CT19#,ET196,ST19# *H,L=650 |
1 | ||
| 90099-33299 |
AT191,CT19#,ET196,ST19# *H,L=750 |
1 | ||
| 90446-07001 |
AT191,CT19#,ET196,ST19# *H,L=720 |
1 | ||
| 85374B - HOSE,WINDSHIELD WASHER (FROM JOINT TO JOINT NO.1) | ||||
| 85317-28040 |
CT196,ST19#;CT190,198,ET196..3FC,5F 長さ=36 |
1 | ||
| 90446-07001 |
CT196,ST19#;CT190,198,ET196..3FC,5F ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 90446-07001 |
CT196,ST19#;CT190,198,ET196..3FC,5F ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85317-28040 |
CT196,ST19#;CT190,198,ET196..3FC,5F 長さ=36 |
1 | ||
| 90446-07001 |
CT190,198,ET196..3FC,5F;CT196,ST19#..CZ,FZ,U,UL,UX ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85374B - HOSE,WINDSHIELD WASHER (FROM JOINT TO JOINT NO.1) | ||||
| 85317-28040 |
CT196,ST19#;CT190,198,ET196..3FC,5F 長さ=36 |
1 | ||
| 90446-07001 |
CT196,ST19#;CT190,198,ET196..3FC,5F ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 90446-07001 |
CT196,ST19#;CT190,198,ET196..3FC,5F ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85317-28040 |
CT196,ST19#;CT190,198,ET196..3FC,5F 長さ=36 |
1 | ||
| 90446-07001 |
CT190,198,ET196..3FC,5F;CT196,ST19#..CZ,FZ,U,UL,UX ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 85374C - HOSE,WINDSHIELD WASHER (FROM JOINT TO JOINT NO.2) | ||||
| 90099-33080 |
CT196,ST19#;CT190,198,ET196..3FC,5F L=1450,ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 90099-33080 |
CT190,198,ET196..3FC,5F;CT196,ST19#..CZ,FZ,U,UL,UX L=1450,ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 90446-07001 |
CT196,ST19#;CT190,198,ET196..3FC,5F |
1 | ||
| 90099-33080 |
CT196,ST19#;CT190,198,ET196..3FC,5F L=1450,ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 90446-07001 |
CT196,ST19#;CT190,198,ET196..3FC,5F |
1 | ||
| 85374C - HOSE,WINDSHIELD WASHER (FROM JOINT TO JOINT NO.2) | ||||
| 90099-33080 |
CT196,ST19#;CT190,198,ET196..3FC,5F L=1450,ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 90099-33080 |
CT190,198,ET196..3FC,5F;CT196,ST19#..CZ,FZ,U,UL,UX L=1450,ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 90446-07001 |
CT196,ST19#;CT190,198,ET196..3FC,5F |
1 | ||
| 90099-33080 |
CT196,ST19#;CT190,198,ET196..3FC,5F L=1450,ｶﾝﾚｲﾁ ｼﾖｳ OR ｶｺﾞｼﾏ ｼﾖｳ |
1 | ||
| 90446-07001 |
CT196,ST19#;CT190,198,ET196..3FC,5F |
1 | ||
| 85374D - HOSE,WINDSHIELD WASHER (FROM JOINT TO JOINT NO.3) | ||||
| 90099-33080 |
CT196,ST19#;CT190,198,ET196..3FC,5F L=1450 |
1 | ||
| 90099-33080 |
CT196,ST19#;CT190,198,ET196..3FC,5F L=1450 |
1 | ||
| 85374F - HOSE,WINDSHIELD WASHER (FROM JOINT TO JOINT NO.5) | ||||
| 90099-33651 |
AT191,CT19#,ET196,ST19# *H,L=1730 |
1 | ||
| 90446-07001 |
AT191,CT19#,ET196,ST19# *H,L=1760 |
1 | ||
| 85374G - HOSE,WINDSHIELD WASHER (FROM JOINT TO JOINT NO.6) | ||||
| 90446-06006 |
CT19#,ET196,ST19# |
1 | ||
| 90446-06006 |
CT196,197,198,199,ET196,ST198 *H,L=1670 |
1 | ||
| 85374H - HOSE,WINDSHIELD WASHER (FROM JOINT TO JOINT NO.7) | ||||
| 90099-33080 |
AT191,CT19#,ET196,ST19# *H,L=30 |
1 | ||
| 90099-33080 |
CT19#,ET196,ST19# L=1450 |
1 | ||
| 85374J - HOSE,WINDSHIELD WASHER (FROM JOINT TO JOINT NO.8) | ||||
| 90446-07001 |
AT191,CT19#,ET196,ST19# *H,L=1350 |
1 | ||
| 85374K - HOSE,WINDSHIELD WASHER (FROM JOINT TO JOINT NO.9) | ||||
| 90099-33080 |
AT191,CT19#,ET196,ST19# *H,L=240 |
1 | ||
| 90099-33080 |
CT19#,ET196,ST19# L=1450 |
1 | ||
| Common parts | ||||
| 85389-21020 | ||||
| 90480-14013 | ||||
| Linked diagrams | ||||
| 8503 | ||||
