CT196V-DXPDS (1992)
Toyota Caldina
(9211-9601)CT196,198,ET196
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55539K - COVER, SPARE SWITCH HOLE | ||||
| 55539-21010B0 |
CT196,198,ET196..U,UX SHADOW GRAY,TRIM1# |
1 | ||
| 55539-21010C0 |
CT196,198,ET196..U,UX BLACK,TRIM2# |
1 | ||
| 58843 - BEZEL, SHIFTING HOLE | ||||
| 58843-20060 |
CT190,196,ET196,ST19#..ATM |
1 | ||
| 58843-20060 |
CT190,196,ET196,ST19#..ATM |
1 | ||
| 58901A - BOX SUB-ASSY, CONSOLE, REAR | ||||
| 58901-21010B1 |
CT196,198,ET196 SHADOW GRAY,TRIM1# |
1 | ||
| 58901-20140B0 |
AT191,CT19#,ET196,ST19#..CZ,FZ,TZ,TZG,U,UX SHADOW GRAY,TRIM1# |
1 | ||
| 58901-21010C1 |
CT196,198,ET196 BLACK,TRIM2# |
1 | ||
| 58941A - COVER, PARKING BRAKE HOLE | ||||
| 58904-21010B0 |
CT196,198,ET196 SHADOW GRAY,TRIM1# |
1 | ||
| 58904-20050B0 |
AT191,CT19#,ET196,ST19# SHADOW GRAY,TRIM1# |
1 | ||
| 58904-21010C0 |
CT196,198,ET196 BLACK,TRIM2# |
1 | ||
| 58985 - RETAINER, CONSOLE BOX | ||||
| 58985-20050 |
CT19#,ET196,ST19# |
1 | ||
| 58985-20050 |
CT19#,ET196,ST19# |
1 | ||
| Common parts | ||||
| 90468-04157 | ||||
| 91665-40616 | ||||
| 93560-55014 | ||||
| Linked diagrams | ||||
| 7404 | ||||
(9601- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 58815A - CARPET, CONSOLE BOX | ||||
| 58815-21010 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 58815-20060 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 58901A - BOX SUB-ASSY, CONSOLE, REAR | ||||
| 58901-21010B1 |
CT196,198,ET196 SHADOW GRAY,TRIM1# |
1 | ||
| 58901-20140B0 |
AT191,CT19#,ET196,ST19#..CZ,FZ,TZ,TZG,U,UX SHADOW GRAY,TRIM1# |
1 | ||
| 58901-21010C1 |
CT196,198,ET196 BLACK,TRIM2# |
1 | ||
| 58905 - DOOR SUB-ASSY, CONSOLE COMPARTMENT | ||||
| 58905-20250B0 |
AT191,CT19#,ET196,ST19#..CZ,FZ,U,UL,UX SHADOW GRAY,TRIM1# |
1 | ||
| 58905 - DOOR SUB-ASSY, CONSOLE COMPARTMENT | ||||
| 58905-20250B0 |
AT191,CT19#,ET196,ST19#..CZ,FZ,U,UL,UX SHADOW GRAY,TRIM1# |
1 | ||
| 58941A - COVER, PARKING BRAKE HOLE | ||||
| 58904-21010B0 |
CT196,198,ET196 SHADOW GRAY,TRIM1# |
1 | ||
| 58904-20050B0 |
AT191,CT19#,ET196,ST19# SHADOW GRAY,TRIM1# |
1 | ||
| 58904-21010C0 |
CT196,198,ET196 BLACK,TRIM2# |
1 | ||
| 58961A - HINGE, CONSOLE COMPARTMENT DOOR MALE | ||||
| 58961-20030 |
AT191,CT19#,ET196,ST19#..CZ,FZ,U,UL,UX |
1 | ||
| 58964 - STOPPER, CONSOLE COMPARTMENT DOOR, NO.1 | ||||
| 58964-20030C0 |
AT191,CT19#,ET196,ST19#..CZ,FZ,U,UL,UX BLACK,TRIM1# |
1 | ||
| 58964 - STOPPER, CONSOLE COMPARTMENT DOOR, NO.1 | ||||
| 58964-20030C0 |
AT191,CT19#,ET196,ST19#..CZ,FZ,U,UL,UX BLACK,TRIM1# |
1 | ||
| 58964 - STOPPER, CONSOLE COMPARTMENT DOOR, NO.1 | ||||
| 58964-20030C0 |
AT191,CT19#,ET196,ST19#..CZ,FZ,U,UL,UX BLACK,TRIM1# |
1 | ||
| 58965A - STOPPER, CONSOLE COMPARTMENT DOOR, NO.2 | ||||
| 58965-20040C0 |
AT191,CT19#,ET196,ST19#..CZ,FZ,U,UL,UX BLACK,TRIM1# |
1 | ||
| 58965A - STOPPER, CONSOLE COMPARTMENT DOOR, NO.2 | ||||
| 58965-20040C0 |
AT191,CT19#,ET196,ST19#..CZ,FZ,U,UL,UX BLACK,TRIM1# |
1 | ||
| 58965A - STOPPER, CONSOLE COMPARTMENT DOOR, NO.2 | ||||
| 58965-20040C0 |
AT191,CT19#,ET196,ST19#..CZ,FZ,U,UL,UX BLACK,TRIM1# |
1 | ||
| 58976 - STRIKER, CONSOLE COMPARTMENT DOOR LOCK | ||||
| 58976-20020 |
AT191,CT19#,ET196,ST19# |
1 | ||
| 58976 - STRIKER, CONSOLE COMPARTMENT DOOR LOCK | ||||
| 58976-20020 |
AT191,CT19#,ET196,ST19# |
1 | ||
| Common parts | ||||
| 90468-04152 | ||||
| 91665-40616 | ||||
| 93567-54512 | ||||
| 93567-55016 | ||||
| Linked diagrams | ||||
| 7404 | ||||
