NSP151L-AHXGKV (2017)
Toyota Yaris
ILLUST NO. 2 OF 3(1310- )
EXTERIOR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 74515C - LABEL, THEFT WARNING INFORMATION | ||||
| 74515-33020 |
NSP151..C |
2 | ||
| 74515-33020 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 74559B - LABEL, FUEL INFORMATION | ||||
| 74559-20140 |
NSP151..(G,V)..C;NSP151..CVT..R..C;NSP150..5F..GEN..R;NSP150..LHD..CVT..A;NSP151..AGT,GCC,GEN,PH,SA,VN TYPE B:REFER ILLUST. |
1 | ||
| 74596A - LABEL, SIDE AIR BAG CAUTION | ||||
| 74596-53012 |
NSP151..V..H;NSP151..CVT..AGT..G |
2 | ||
| 74596-02070 |
NSP151..V..F |
2 | ||
| 74596-0K040 |
NSP151..C |
2 | ||
| 74596-02070 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
2 | ||
| 74751 - LABEL, TIRE PRESSURE INFORMATION | ||||
| 42661-0DA30 |
NSP150,151..H |
1 | ||
| 42661-0D750 |
NSP151..CVT..G..C BRUNEI SPEC |
1 | ||
| 42661-0D291 |
NSP150,151..GCC..R |
1 | ||
| 42661-0D211 |
NSP150,151..GCC..R E-HI PACKAGE(WHEEL CAP(FOR 15INCH)) |
1 | ||
| 42661-0D750 |
NSP151..CVT..R..C |
1 | ||
| 42661-0D211 |
NSP151..GCC..R E-SPORT PACKAGE(GRADE MARK(S)) |
1 | ||
| 42661-0D211 |
NSP150..GCC..G;NSP150..5F..GEN..R;NSP151..(GEN,VN)..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GCC,GEN,PH,SA)..(D,G)..A |
1 | ||
| 42661-0D760 |
NSP151..(G,V)..C |
1 | ||
ILLUST NO. 3 OF 3(1310- )
INTERIOR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69339C - LABEL, CHILD PROTECTOR INFORMATION | ||||
| 69339-06060 |
NSP151..C |
2 | ||
| 74541E - PLATE, COMPACT SPARE TIRE CAUTION | ||||
| 42668-02140 |
NSP151..F |
1 | ||
| 74598A - LABEL, PASSENGER AIR BAG CAUTION | ||||
| 74598-02030 |
NSP150,151..H |
1 | ||
| 74598-02040 |
NSP151..C |
1 | ||
ILLUST NO. 1 OF 3(1310- )
ENGINE ROOM
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11285A - LABEL, COOLANT SYSTEM NOTICE | ||||
| 11285-47010 |
1NRFE..NSP150..LHD..(GCC,GEN);2NRFE,3NRFKE..NSP151,152..(GCC,GEN,SA,TH,VN)..A |
1 | ||
| 11285-0Y031 |
1NRFBE,2NR#..NSP150,151..H |
1 | ||
| 11298B - LABEL, EMISSION CONTROL INFORMATION | ||||
| 11298-0Y060 |
2NRFE..NSP151..F |
1 | ||
| 11298-0Y062 |
2NRFE..NSP151..F |
1 | ||
| 11298-0Y061 |
2NRFE..NSP151..F |
1 | ||
| 47288 - LABEL, BRAKE FLUID NOTICE | ||||
| 47288-71010 |
NSP150,151..GCC |
1 | ||
| 88723J - LABEL, COOLER SERVICE CAUTION, NO.2 | ||||
| 88723-0D280 |
NSP150,151..H |
1 | ||
| 88723-0D170 |
NSP151..(G,V)..C |
1 | ||
| 88723-0D110 |
NSP150,151..GCC |
1 | ||
| 88723-0D120 |
NSP151..CVT..G..C BRUNEI SPEC&FRONT AIR CONDITIONER-AUTO COOLER(DOP) |
1 | ||
| 88723-0D170 |
NSP151..CVT..G..C BRUNEI SPEC |
1 | ||
(1908- )
| Part # | Description | Qty | Price |
|---|
(1911- )
ENGINE ROOM
| Part # | Description | Qty | Price |
|---|
(1911- )
EXTERIOR
| Part # | Description | Qty | Price |
|---|
(1911- )
INTERIOR
| Part # | Description | Qty | Price |
|---|
