NSP151L-AHXGKM (2017)
Toyota Yaris
ILLUST NO. 1 OF 2(1310-1911)A ; (1310- )B,C,F
LH SEAT,W(VERTICAL ADJUSTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71014S - FRAME SUB-ASSY, FRONT SEAT BACK, LH | ||||
| 71014-0D320 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71014-0D300 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71014-0D280 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71014-0D280 |
NSP151..(G,V)..C |
1 | ||
| 71014-0D110 |
NSP151..(G,R)..F |
1 | ||
| 71014-0D300 |
NSP151..V..F |
1 | ||
| 71014-0D280 |
NSP151..CVT..R..C |
1 | ||
| 71014-0D210 |
NSP151..(G,V)..C |
1 | ||
| 71072S - COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE) | ||||
| 71072-0DL50C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71072-0DW50C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71072-0U040C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71072-0U050C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71072-0UE60C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71072-0UE40C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71072-0DZ40C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71072-0DF20A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71072-0DZ40A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71072-0U050C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71072-0DZ50C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71072-0U030C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71072-0UG00C1 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71072-0UG10C1 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71072-0UE60C7 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71072-0UG20C1 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71072-0U050C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71072-0UK00C3 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71074S - COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71074-0DG80C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71074-0DL80C0 |
NSP151..D..A BLACK,TRIM2# |
1 | ||
| 71074-0DV60C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71074-0DY40C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71074-0DY30C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71074-0UD50C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71074-0DY40C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71074-0DX50C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71074-0UD80C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71074-0DX40C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71074-0DX40A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71074-0DC90C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71074-0DY20C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71074-0UC20C0 |
NSP151..D..A BLACK,TRIM2# |
1 | ||
| 71074-0UD80C5 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71074-0UJ20C2 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71074-0UJ40C2 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71074-0UJ30C2 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71074-0UK80C4 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71074-0DY40C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71122 - BRACKET, FRONT SEAT CUSHION, LH | ||||
| 71122-0D050 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71122-0D180 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71122-0D120 |
NSP151..(G,V)..C |
1 | ||
| 71122-0D010 |
NSP151..(G,V)..C |
1 | ||
| 71122-0D120 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71122-0D120 |
NSP151..CVT..R..C |
1 | ||
| 71122-0D150 |
NSP151..(G,R)..F |
1 | ||
| 71122-0D220 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 71512S - PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE) | ||||
| 71512-0D850 |
NSP151..PH |
1 | ||
| 71512-0D610 |
NSP151..PH |
1 | ||
| 71512-0D750 |
NSP150,151..H |
1 | ||
| 71502-0D090 |
NSP151..G..C |
1 | ||
| 71512-0D690 |
NSP151..V..F |
1 | ||
| 71512-0D680 |
NSP151..(G,R)..F |
1 | ||
| 71502-0D090 |
NSP151..CVT..R..C |
1 | ||
| 71502-0D100 |
NSP151..V..C |
1 | ||
| 71502-0D160 |
NSP151..V..A |
1 | ||
| 71502-0D210 |
NSP151..G..C |
1 | ||
| 71537H - PROTECTOR, FRONT SEAT CUSHION EDGE, RH(FOR LH SEAT) | ||||
| 71537-0D390C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71537-0D120C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71537-0D310C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71537-0D170C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D170C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71537-0D170C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D170C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D310C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71538B - PROTECTOR, FRONT SEAT CUSHION EDGE, LH(FOR LH SEAT) | ||||
| 71538-0D320C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71538-0D110C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71538-0D160C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D160C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71538-0D160C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D210C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71538-0D160C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71538-0D210C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71552S - PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71552-0D720 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71552-0D600 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71552-0D640 |
NSP151..V..C |
1 | ||
| 71552-0D690 |
NSP151..V..F |
1 | ||
| 71552-0D630 |
NSP151..CVT..R..C |
1 | ||
| 71552-0D630 |
NSP151..G..C |
1 | ||
| 71552-0D640 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71552-0D280 |
NSP151..(G,R)..F |
1 | ||
| 71552-0D390 |
NSP151..V..C |
1 | ||
| 71552-0D680 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71552-0DA10 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71552-0D830 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71552-0DA00 |
NSP151..G..C |
1 | ||
| 71812D - SHIELD, FRONT SEAT CUSHION, LH | ||||
| 71812-0D460C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71812-0D310C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71812-0D520C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71812-0D510C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71812-0D480C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71812-0D520C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71812-0D520C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71812-0D590C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71812-0D570C0 |
NSP152;NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71812-0D310C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71812-0D370C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71812-0D510C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71812-0D520C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71812-0D510C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71812-0D590C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71862 - SHIELD, FRONT SEAT CUSHION, INNER LH | ||||
| 71862-0D230C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71862-0D360C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71862-0D450C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71862-0D280C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71862-0D340C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71862-0D360C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71862-0D280C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71862-0D290C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71862-0D450C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71862-0D340C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71862-0D360C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71873B - SHIELD, FRONT SEAT CUSHION, LOWER RH, NO.1 | ||||
| 71873-0D400C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71873-06460 |
NSP151..F |
1 | ||
| 71873-0D370 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 71874 - SHIELD, FRONT SEAT CUSHION, LOWER LH | ||||
| 71874-0D440C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71874-0D350 |
NSP151..F |
1 | ||
| 71874-0D360 |
NSP150,151..LHD..(GCC,GEN,PH,VN)..(G,R)..A |
1 | ||
| 71874A - SHIELD, FRONT SEAT CUSHION, LOWER LH | ||||
| 71874-0D430C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71874-0D390 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 71874-06450 |
NSP151..F |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-0DB00C1 |
NSP151..PH BLACK/RED,TRIM2# |
2 | ||
| 71910-0DL20C0 |
NSP150,151..D..H BLACK,TRIM2# |
2 | ||
| 71910-0DK60C0 |
NSP151..PH BLACK,TRIM2# |
2 | ||
| 71910-0DD30C1 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DD10C2 |
NSP151..(G,R)..C BLACK/BLUE 121,TRIM2# |
2 | ||
| 71910-0DN00C0 |
NSP151..V..A BLACK,TRIM2# |
2 | ||
| 71910-0DJ50C1 |
NSP151..V..F BLACK,TRIM2# |
2 | ||
| 71910-0DB30A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
2 | ||
| 71910-0DB30C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
2 | ||
| 71910-0DD10C5 |
NSP151..5F..G;NSP151..CVT..(G,R)..C BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DB60A2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
2 | ||
| 71910-0DB60C2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
2 | ||
| 71910-0DK50C8 |
NSP151..R..A;NSP150..LHD..CVT;NSP150..5F..GEN..R BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DD30C2 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DN00C3 |
NSP152;NSP151..(PH,SA)..(G,V) BLACK/BLUE,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 72020 - ADJUSTER ASSY, FRONT SEAT, LH | ||||
| 72020-0D501 |
NSP151..F |
1 | ||
| 72020-0D561 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72020-0D740 |
NSP150,151..H |
1 | ||
| 72020-0D521 |
NSP150,151..LHD..(GCC,GEN,PH,VN)..(G,R)..A |
1 | ||
| 72020-0D741 |
NSP150,151..H |
1 | ||
| 72125A - COVER, SEAT TRACK, UPPER REAR | ||||
| 72125-0D040 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 72265-0D070 |
NSP151..F |
2 | ||
| 72125-0D050 |
NSP151..F |
2 | ||
| 72125D - COVER, SEAT TRACK, UPPER REAR NO.2 | ||||
| 72265-0D060 |
NSP151..F |
2 | ||
| 72125-0D090 |
NSP151..F |
2 | ||
| 72125-0D120 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72138 - COVER, SEAT TRACK, OUTER LH | ||||
| 72138-0D180C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72138-0D150C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72138-0D120C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72138-0D120C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72138-0D260C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72138-0D120C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72138-0D150C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72138-0D120C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72138-0D260C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72148 - BRACKET, FRONT INNER SEAT TRACK, LOWER REAR LH | ||||
| 72148-0D120 |
NSP151..F |
1 | ||
| 72148-0D200 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 72148-0D180 |
NSP150,151..H |
1 | ||
| 72148-0D150 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72211C - HANDLE, SEAT TRACK ADJUSTING | ||||
| 72211-0D240 |
NSP150,151..H |
2 | ||
| 72211-0D300 |
NSP151..F |
2 | ||
| 72211-0D260 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 72211-0D290 |
NSP15#..A |
2 | ||
| 72265 - COVER, SEAT TRACK UPPER RAIL, RH | ||||
| 72265-0D100 |
NSP151..F |
2 | ||
| 72265-0D090 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 71848-0D150 |
NSP151..F |
2 | ||
| 72266 - COVER, SEAT TRACK UPPER RAIL, LH | ||||
| 72265-0D100 |
NSP151..F |
2 | ||
| 72265-0D090 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 71848-0D150 |
NSP151..F |
2 | ||
| 72495 - HANDLE, VERTICAL ADJUSTING, LH | ||||
| 72495-0D060C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72495-0D050C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72495-0D100C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72495-0D050C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72495-0D050C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72495-0D090C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72495-0D100C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 72495-0D050C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526A - HANDLE, RECLINING ADJUSTER RELEASE, LH | ||||
| 72526-0D320C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72526-0M010C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72526-06130C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72526-0D300C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72526-0D360C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72526-0M010C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72526-0M010C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526-0D360C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72526-0M010C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526-0D300C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 73920A - AIR BAG ASSY, FRONT SEAT, LH | ||||
| 73920-0D100 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 73920-0D100 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 73920-0D160 |
NSP151..(PH,SA,VN)..(G,V);NSP15#..CVT..(PH,TH,VN)..R |
1 | ||
| Common parts | ||||
| 72702-52030 | ||||
| 90105-T0176 | ||||
| 90107-T0003 | ||||
| 90119-10601 | ||||
| 90167-40044 | ||||
| 90168-50078 | ||||
| 91553-10820 | ||||
| 94170-60600 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 1 OF 2(1310-1911)A ; (1310- )B,C,F
LH SEAT,W/O(VERTICAL ADJUSTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71014S - FRAME SUB-ASSY, FRONT SEAT BACK, LH | ||||
| 71014-0D320 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71014-0D300 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71014-0D280 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71014-0D280 |
NSP151..(G,V)..C |
1 | ||
| 71014-0D110 |
NSP151..(G,R)..F |
1 | ||
| 71014-0D300 |
NSP151..V..F |
1 | ||
| 71014-0D280 |
NSP151..CVT..R..C |
1 | ||
| 71014-0D210 |
NSP151..(G,V)..C |
1 | ||
| 71072S - COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE) | ||||
| 71072-0DL50C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71072-0DW50C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71072-0U040C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71072-0U050C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71072-0UE60C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71072-0UE40C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71072-0DZ40C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71072-0DF20A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71072-0DZ40A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71072-0U050C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71072-0DZ50C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71072-0U030C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71072-0UG00C1 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71072-0UG10C1 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71072-0UE60C7 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71072-0UG20C1 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71072-0U050C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71072-0UK00C3 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71074S - COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71074-0DG80C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71074-0DL80C0 |
NSP151..D..A BLACK,TRIM2# |
1 | ||
| 71074-0DV60C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71074-0DY40C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71074-0DY30C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71074-0UD50C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71074-0DY40C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71074-0DX50C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71074-0UD80C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71074-0DX40C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71074-0DX40A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71074-0DC90C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71074-0DY20C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71074-0UC20C0 |
NSP151..D..A BLACK,TRIM2# |
1 | ||
| 71074-0UD80C5 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71074-0UJ20C2 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71074-0UJ40C2 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71074-0UJ30C2 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71074-0UK80C4 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71074-0DY40C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71122 - BRACKET, FRONT SEAT CUSHION, LH | ||||
| 71122-0D050 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71122-0D180 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71122-0D120 |
NSP151..(G,V)..C |
1 | ||
| 71122-0D010 |
NSP151..(G,V)..C |
1 | ||
| 71122-0D120 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71122-0D120 |
NSP151..CVT..R..C |
1 | ||
| 71122-0D150 |
NSP151..(G,R)..F |
1 | ||
| 71122-0D220 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 71512S - PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE) | ||||
| 71502-0D090 |
NSP151..CVT..R..C |
1 | ||
| 71512-0D850 |
NSP151..PH |
1 | ||
| 71512-0D610 |
NSP151..PH |
1 | ||
| 71512-0D750 |
NSP150,151..H |
1 | ||
| 71502-0D090 |
NSP151..G..C |
1 | ||
| 71512-0D690 |
NSP151..V..F |
1 | ||
| 71512-0D680 |
NSP151..(G,R)..F |
1 | ||
| 71502-0D100 |
NSP151..V..C |
1 | ||
| 71502-0D160 |
NSP151..V..A |
1 | ||
| 71502-0D210 |
NSP151..G..C |
1 | ||
| 71537H - PROTECTOR, FRONT SEAT CUSHION EDGE, RH(FOR LH SEAT) | ||||
| 71537-0D390C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71537-0D120C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71537-0D310C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71537-0D170C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D170C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71537-0D170C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D170C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D310C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71538B - PROTECTOR, FRONT SEAT CUSHION EDGE, LH(FOR LH SEAT) | ||||
| 71538-0D320C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71538-0D110C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71538-0D160C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D160C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71538-0D160C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D210C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71538-0D160C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71538-0D210C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71552S - PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71552-0D720 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71552-0D600 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71552-0D640 |
NSP151..V..C |
1 | ||
| 71552-0D690 |
NSP151..V..F |
1 | ||
| 71552-0D630 |
NSP151..CVT..R..C |
1 | ||
| 71552-0D630 |
NSP151..G..C |
1 | ||
| 71552-0D640 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71552-0D280 |
NSP151..(G,R)..F |
1 | ||
| 71552-0D390 |
NSP151..V..C |
1 | ||
| 71552-0D680 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71552-0DA10 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71552-0D830 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71552-0DA00 |
NSP151..G..C |
1 | ||
| 71812D - SHIELD, FRONT SEAT CUSHION, LH | ||||
| 71812-0D460C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71812-0D310C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71812-0D520C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71812-0D510C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71812-0D480C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71812-0D520C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71812-0D520C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71812-0D590C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71812-0D570C0 |
NSP152;NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71812-0D310C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71812-0D370C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71812-0D510C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71812-0D520C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71812-0D510C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71812-0D590C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71862 - SHIELD, FRONT SEAT CUSHION, INNER LH | ||||
| 71862-0D230C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71862-0D360C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71862-0D450C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71862-0D280C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71862-0D340C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71862-0D360C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71862-0D280C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71862-0D290C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71862-0D450C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71862-0D340C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71862-0D360C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-0DB00C1 |
NSP151..PH BLACK/RED,TRIM2# |
2 | ||
| 71910-0DL20C0 |
NSP150,151..D..H BLACK,TRIM2# |
2 | ||
| 71910-0DK60C0 |
NSP151..PH BLACK,TRIM2# |
2 | ||
| 71910-0DD30C1 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DD10C2 |
NSP151..(G,R)..C BLACK/BLUE 121,TRIM2# |
2 | ||
| 71910-0DN00C0 |
NSP151..V..A BLACK,TRIM2# |
2 | ||
| 71910-0DJ50C1 |
NSP151..V..F BLACK,TRIM2# |
2 | ||
| 71910-0DB30A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
2 | ||
| 71910-0DB30C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
2 | ||
| 71910-0DD10C5 |
NSP151..5F..G;NSP151..CVT..(G,R)..C BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DB60A2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
2 | ||
| 71910-0DB60C2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
2 | ||
| 71910-0DK50C8 |
NSP151..R..A;NSP150..LHD..CVT;NSP150..5F..GEN..R BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DD30C2 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DN00C3 |
NSP152;NSP151..(PH,SA)..(G,V) BLACK/BLUE,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 72020 - ADJUSTER ASSY, FRONT SEAT, LH | ||||
| 72020-0D501 |
NSP151..F |
1 | ||
| 72020-0D561 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72020-0D740 |
NSP150,151..H |
1 | ||
| 72020-0D521 |
NSP150,151..LHD..(GCC,GEN,PH,VN)..(G,R)..A |
1 | ||
| 72020-0D741 |
NSP150,151..H |
1 | ||
| 72125A - COVER, SEAT TRACK, UPPER REAR | ||||
| 72125-0D040 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 72265-0D070 |
NSP151..F |
2 | ||
| 72125-0D050 |
NSP151..F |
2 | ||
| 72125D - COVER, SEAT TRACK, UPPER REAR NO.2 | ||||
| 72265-0D060 |
NSP151..F |
2 | ||
| 72125-0D090 |
NSP151..F |
2 | ||
| 72125-0D120 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72138 - COVER, SEAT TRACK, OUTER LH | ||||
| 72138-0D180C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72138-0D150C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72138-0D120C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72138-0D120C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72138-0D260C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72138-0D120C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72138-0D150C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72138-0D120C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72138-0D260C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72148 - BRACKET, FRONT INNER SEAT TRACK, LOWER REAR LH | ||||
| 72148-0D120 |
NSP151..F |
1 | ||
| 72148-0D200 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 72148-0D180 |
NSP150,151..H |
1 | ||
| 72148-0D150 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72211C - HANDLE, SEAT TRACK ADJUSTING | ||||
| 72211-0D240 |
NSP150,151..H |
2 | ||
| 72211-0D300 |
NSP151..F |
2 | ||
| 72211-0D260 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 72211-0D290 |
NSP15#..A |
2 | ||
| 72265 - COVER, SEAT TRACK UPPER RAIL, RH | ||||
| 72265-0D100 |
NSP151..F |
2 | ||
| 72265-0D090 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 71848-0D150 |
NSP151..F |
2 | ||
| 72266 - COVER, SEAT TRACK UPPER RAIL, LH | ||||
| 72265-0D100 |
NSP151..F |
2 | ||
| 72265-0D090 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 71848-0D150 |
NSP151..F |
2 | ||
| 72526A - HANDLE, RECLINING ADJUSTER RELEASE, LH | ||||
| 72526-0D320C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72526-0M010C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72526-06130C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72526-0D300C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72526-0D360C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72526-0M010C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72526-0M010C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526-0D360C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72526-0M010C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526-0D300C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 73920A - AIR BAG ASSY, FRONT SEAT, LH | ||||
| 73920-0D100 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 73920-0D100 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 73920-0D160 |
NSP151..(PH,SA,VN)..(G,V);NSP15#..CVT..(PH,TH,VN)..R |
1 | ||
| Common parts | ||||
| 72702-52030 | ||||
| 90105-T0176 | ||||
| 90107-T0003 | ||||
| 90119-10601 | ||||
| 91553-10820 | ||||
| 94170-60600 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 2 OF 2(1310-1911)A ; (1310- )B,C,F
RH SEAT,W(VERTICAL ADJUSTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71013S - FRAME SUB-ASSY, FRONT SEAT BACK, RH | ||||
| 71013-0D360 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71013-0D270 |
NSP151..(G,V)..C |
1 | ||
| 71013-0D270 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71013-0D300 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71013-0D300 |
NSP151..V..F |
1 | ||
| 71013-0D200 |
NSP151..(G,V)..C |
1 | ||
| 71013-0D270 |
NSP151..CVT..R..C |
1 | ||
| 71013-0D110 |
NSP151..(G,R)..F |
1 | ||
| 71071S - COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71071-0U590C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71071-0DW80C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71071-0DE10A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71071-0DE10C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71071-0DZ80C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71071-0DZ70C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71071-0DY80A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71071-0UG60C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71071-0DY90C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71071-0DZ80C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71071-0UG30C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71071-0DE10C2 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71071-0DE10A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71071-0DY80C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71071-0DZ60C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71071-0UK10C1 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71071-0UK20C1 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71071-0UG60C7 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71071-0UK00C1 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71071-0UL40C3 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71071-0DZ80C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71073S - COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71073-0DM40C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71073-0DY10C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71073-0DG10C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71073-0U170C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71073-0DG10A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71073-0U190C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71073-0UJ10C1 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71073-0UJ40C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71073-0U090A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71073-0U190C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71073-0U090C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71073-0DG10C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71073-0U100C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71073-0DG10A3 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71073-0U160C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71073-0UJ40C3 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71073-0UL90C2 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71073-0UN10C2 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71073-0UN00C2 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71073-0UP40C4 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71073-0U190C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71511S - PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71051-0D100 |
NSP150,151..H |
1 | ||
| 71501-0D200 |
NSP151..PH |
1 | ||
| 71511-0D660 |
NSP151..G..C |
1 | ||
| 71511-0D740 |
NSP151..V..F |
1 | ||
| 71511-0D260 |
NSP151..(G,R)..F |
1 | ||
| 71511-0D730 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71511-0D670 |
NSP151..V..C |
1 | ||
| 71511-0D660 |
NSP151..CVT..R..C |
1 | ||
| 71511-0DA50 |
NSP151..V..A |
1 | ||
| 71501-0D330 |
NSP151..PH |
1 | ||
| 71501-0D240 |
NSP150,151..LHD..CVT..(GEN,PH)..R |
1 | ||
| 71511-0DB80 |
NSP151..G..C |
1 | ||
| 71537G - PROTECTOR, FRONT SEAT CUSHION EDGE, RH(FOR RH SEAT) | ||||
| 71537-0D110C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71537-0D320C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71537-0D100C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D280C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71537-0D100C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71537-0D320C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71537-0D100C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D100C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538A - PROTECTOR, FRONT SEAT CUSHION EDGE, LH(FOR RH SEAT) | ||||
| 71538-0D220C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71538-0D090C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D310C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71538-0D100C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71538-0D090C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71538-0D090C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D090C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71538-0D220C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71551S - PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71551-0D800 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71551-0D680 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71551-0D720 |
NSP151..V..C |
1 | ||
| 71551-0D710 |
NSP151..G..C |
1 | ||
| 71551-0D360 |
NSP151..(G,R)..F |
1 | ||
| 71551-0D740 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71551-0D750 |
NSP151..V..F |
1 | ||
| 71551-0D710 |
NSP151..CVT..R..C |
1 | ||
| 71551-0D880 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71551-0D490 |
NSP151..V..C |
1 | ||
| 71551-0D720 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71551-0DA60 |
NSP151..G..C |
1 | ||
| 71551-0DA70 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71811D - SHIELD, FRONT SEAT CUSHION, RH | ||||
| 71811-0D440C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71811-0D510C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71811-0D450C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71811-0D260C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71811-0D530C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71811-0D530C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71811-0D530C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71811-0D570C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71811-0D590C0 |
NSP152;NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71811-0D260C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71811-0D400C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71811-0D570C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71811-0D510C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71811-0D530C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71811-0D510C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71861 - SHIELD, FRONT SEAT CUSHION, INNER RH | ||||
| 71861-0D330C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71861-0D330C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71861-0D330C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71861-0D440C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71861-0D360C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71861-0D410C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71861-0D210C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71861-0D210C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71861-0D360C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71861-0D330C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71861-0D330C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71861-0D440C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71861-0D360C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71861-0D290C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71873 - SHIELD, FRONT SEAT CUSHION, LOWER RH | ||||
| 71873-0D380 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 71873B - SHIELD, FRONT SEAT CUSHION, LOWER RH, NO.1 | ||||
| 71873-0D400C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71873-06460 |
NSP151..F |
1 | ||
| 71873-0D370 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 71874A - SHIELD, FRONT SEAT CUSHION, LOWER LH | ||||
| 71874-0D430C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71874-0D390 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 71874-06450 |
NSP151..F |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-0DK60C0 |
NSP151..PH BLACK,TRIM2# |
2 | ||
| 71910-0DB00C1 |
NSP151..PH BLACK/RED,TRIM2# |
2 | ||
| 71910-0DL20C0 |
NSP150,151..D..H BLACK,TRIM2# |
2 | ||
| 71910-0DD30C1 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DD10C2 |
NSP151..(G,R)..C BLACK/BLUE 121,TRIM2# |
2 | ||
| 71910-0DN00C0 |
NSP151..V..A BLACK,TRIM2# |
2 | ||
| 71910-0DJ50C1 |
NSP151..V..F BLACK,TRIM2# |
2 | ||
| 71910-0DB30A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
2 | ||
| 71910-0DB30C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
2 | ||
| 71910-0DD10C5 |
NSP151..5F..G;NSP151..CVT..(G,R)..C BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DB60A2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
2 | ||
| 71910-0DB60C2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
2 | ||
| 71910-0DK50C8 |
NSP151..R..A;NSP150..LHD..CVT;NSP150..5F..GEN..R BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DD30C2 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DN00C3 |
NSP152;NSP151..(PH,SA)..(G,V) BLACK/BLUE,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 72010 - ADJUSTER ASSY, FRONT SEAT, RH | ||||
| 72010-0D531 |
NSP150,151..PH,VN |
1 | ||
| 71011-0D220 |
NSP150,151..H |
1 | ||
| 72010-0D461 |
NSP151..(G,R)..F |
1 | ||
| 72010-0D700 |
NSP151..(G,V)..C |
1 | ||
| 72010-0D750 |
NSP151..V..F |
1 | ||
| 72010-0D700 |
NSP151..CVT..R..C |
1 | ||
| 72010-0D551 |
NSP151..(G,V)..C |
1 | ||
| 72010-0D750 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 72010-0D700 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 72125A - COVER, SEAT TRACK, UPPER REAR | ||||
| 72125-0D040 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 72265-0D070 |
NSP151..F |
2 | ||
| 72125-0D050 |
NSP151..F |
2 | ||
| 72125D - COVER, SEAT TRACK, UPPER REAR NO.2 | ||||
| 72265-0D060 |
NSP151..F |
2 | ||
| 72125-0D090 |
NSP151..F |
2 | ||
| 72125-0D120 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72137 - COVER, SEAT TRACK, OUTER RH | ||||
| 72137-0D140C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72137-0D170C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72137-0D140C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72137-0D200C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72137-0D270C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72137-0D140C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72137-0D140C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72137-0D170C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72137-0D270C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72147 - BRACKET, FRONT INNER SEAT TRACK, LOWER REAR RH | ||||
| 72147-0D170 |
NSP150,151..H |
1 | ||
| 72147-0D110 |
NSP151..F |
1 | ||
| 72147-0D140 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72147-0D190 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 72211C - HANDLE, SEAT TRACK ADJUSTING | ||||
| 72211-0D240 |
NSP150,151..H |
2 | ||
| 72211-0D300 |
NSP151..F |
2 | ||
| 72211-0D260 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 72211-0D290 |
NSP15#..A |
2 | ||
| 72265 - COVER, SEAT TRACK UPPER RAIL, RH | ||||
| 72265-0D100 |
NSP151..F |
2 | ||
| 72265-0D090 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 71848-0D150 |
NSP151..F |
2 | ||
| 72266 - COVER, SEAT TRACK UPPER RAIL, LH | ||||
| 72265-0D100 |
NSP151..F |
2 | ||
| 72265-0D090 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 71848-0D150 |
NSP151..F |
2 | ||
| 72494 - HANDLE, VERTICAL ADJUSTING, RH | ||||
| 72494-0D170C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72494-0D170C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72525A - HANDLE, RECLINING ADJUSTER RELEASE, RH | ||||
| 72525-0D270C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72525-0D330C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72525-02230C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72525-02230C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72525-0D370C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72525-02230C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72525-0D370C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72525-02230C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72525-0D330C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72525-0D300C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 73910A - AIR BAG ASSY, FRONT SEAT, RH | ||||
| 73910-0D100 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 73910-0D100 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 73910-0D160 |
NSP151..(PH,SA,VN)..(G,V);NSP15#..CVT..(PH,TH,VN)..R |
1 | ||
| Common parts | ||||
| 72702-52030 | ||||
| 90105-T0176 | ||||
| 90107-T0003 | ||||
| 90119-10601 | ||||
| 90167-40044 | ||||
| 90168-50078 | ||||
| 91553-10820 | ||||
| 94170-60600 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 2 OF 2(1310-1911)A ; (1310- )B,C,F
RH SEAT,W/O(VERTICAL ADJUSTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71013S - FRAME SUB-ASSY, FRONT SEAT BACK, RH | ||||
| 71013-0D360 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71013-0D270 |
NSP151..(G,V)..C |
1 | ||
| 71013-0D270 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71013-0D300 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71013-0D300 |
NSP151..V..F |
1 | ||
| 71013-0D200 |
NSP151..(G,V)..C |
1 | ||
| 71013-0D270 |
NSP151..CVT..R..C |
1 | ||
| 71013-0D110 |
NSP151..(G,R)..F |
1 | ||
| 71071S - COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71071-0U590C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71071-0DW80C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71071-0DE10A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71071-0DE10C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71071-0DZ80C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71071-0DZ70C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71071-0DY80A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71071-0UG60C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71071-0DY90C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71071-0DZ80C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71071-0UG30C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71071-0DE10C2 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71071-0DE10A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71071-0DY80C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71071-0DZ60C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71071-0UK10C1 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71071-0UK20C1 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71071-0UG60C7 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71071-0UK00C1 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71071-0UL40C3 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71071-0DZ80C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71073S - COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71073-0U190C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71073-0DM40C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71073-0DY10C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71073-0DG10C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71073-0U170C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71073-0DG10A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71073-0U190C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71073-0UJ10C1 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71073-0UJ40C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71073-0U090A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71073-0U090C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71073-0DG10C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71073-0U100C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71073-0DG10A3 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71073-0U160C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71073-0UJ40C3 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71073-0UL90C2 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71073-0UN10C2 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71073-0UN00C2 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71073-0UP40C4 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71073-0U190C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71511S - PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71051-0D100 |
NSP150,151..H |
1 | ||
| 71501-0D200 |
NSP151..PH |
1 | ||
| 71511-0D660 |
NSP151..G..C |
1 | ||
| 71511-0D740 |
NSP151..V..F |
1 | ||
| 71511-0D260 |
NSP151..(G,R)..F |
1 | ||
| 71511-0D730 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71511-0D670 |
NSP151..V..C |
1 | ||
| 71511-0D660 |
NSP151..CVT..R..C |
1 | ||
| 71511-0DA50 |
NSP151..V..A |
1 | ||
| 71501-0D330 |
NSP151..PH |
1 | ||
| 71501-0D240 |
NSP150,151..LHD..CVT..(GEN,PH)..R |
1 | ||
| 71511-0DB80 |
NSP151..G..C |
1 | ||
| 71537G - PROTECTOR, FRONT SEAT CUSHION EDGE, RH(FOR RH SEAT) | ||||
| 71537-0D110C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71537-0D320C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71537-0D100C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D280C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71537-0D100C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71537-0D320C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71537-0D100C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D100C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538A - PROTECTOR, FRONT SEAT CUSHION EDGE, LH(FOR RH SEAT) | ||||
| 71538-0D220C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71538-0D090C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D310C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71538-0D100C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71538-0D090C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71538-0D090C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D090C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71538-0D220C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71551S - PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71551-0D800 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71551-0D680 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71551-0D720 |
NSP151..V..C |
1 | ||
| 71551-0D710 |
NSP151..G..C |
1 | ||
| 71551-0D360 |
NSP151..(G,R)..F |
1 | ||
| 71551-0D740 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71551-0D750 |
NSP151..V..F |
1 | ||
| 71551-0D710 |
NSP151..CVT..R..C |
1 | ||
| 71551-0D880 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71551-0D490 |
NSP151..V..C |
1 | ||
| 71551-0D720 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71551-0DA60 |
NSP151..G..C |
1 | ||
| 71551-0DA70 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71811D - SHIELD, FRONT SEAT CUSHION, RH | ||||
| 71811-0D440C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71811-0D510C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71811-0D450C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71811-0D260C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71811-0D530C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71811-0D530C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71811-0D530C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71811-0D570C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71811-0D590C0 |
NSP152;NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71811-0D260C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71811-0D400C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71811-0D570C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71811-0D510C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71811-0D530C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71811-0D510C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71861 - SHIELD, FRONT SEAT CUSHION, INNER RH | ||||
| 71861-0D330C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71861-0D330C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71861-0D330C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71861-0D440C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71861-0D360C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71861-0D410C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71861-0D210C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71861-0D210C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71861-0D360C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71861-0D330C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71861-0D330C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71861-0D440C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71861-0D360C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71861-0D290C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-0DB00C1 |
NSP151..PH BLACK/RED,TRIM2# |
2 | ||
| 71910-0DL20C0 |
NSP150,151..D..H BLACK,TRIM2# |
2 | ||
| 71910-0DK60C0 |
NSP151..PH BLACK,TRIM2# |
2 | ||
| 71910-0DD30C1 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DD10C2 |
NSP151..(G,R)..C BLACK/BLUE 121,TRIM2# |
2 | ||
| 71910-0DN00C0 |
NSP151..V..A BLACK,TRIM2# |
2 | ||
| 71910-0DJ50C1 |
NSP151..V..F BLACK,TRIM2# |
2 | ||
| 71910-0DB30A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
2 | ||
| 71910-0DB30C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
2 | ||
| 71910-0DD10C5 |
NSP151..5F..G;NSP151..CVT..(G,R)..C BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DB60A2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
2 | ||
| 71910-0DB60C2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
2 | ||
| 71910-0DK50C8 |
NSP151..R..A;NSP150..LHD..CVT;NSP150..5F..GEN..R BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DD30C2 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DN00C3 |
NSP152;NSP151..(PH,SA)..(G,V) BLACK/BLUE,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 72010 - ADJUSTER ASSY, FRONT SEAT, RH | ||||
| 72010-0D531 |
NSP150,151..PH,VN |
1 | ||
| 71011-0D220 |
NSP150,151..H |
1 | ||
| 72010-0D461 |
NSP151..(G,R)..F |
1 | ||
| 72010-0D700 |
NSP151..(G,V)..C |
1 | ||
| 72010-0D750 |
NSP151..V..F |
1 | ||
| 72010-0D700 |
NSP151..CVT..R..C |
1 | ||
| 72010-0D551 |
NSP151..(G,V)..C |
1 | ||
| 72010-0D750 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 72010-0D700 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 72125A - COVER, SEAT TRACK, UPPER REAR | ||||
| 72125-0D040 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 72265-0D070 |
NSP151..F |
2 | ||
| 72125-0D050 |
NSP151..F |
2 | ||
| 72125D - COVER, SEAT TRACK, UPPER REAR NO.2 | ||||
| 72265-0D060 |
NSP151..F |
2 | ||
| 72125-0D090 |
NSP151..F |
2 | ||
| 72125-0D120 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72137 - COVER, SEAT TRACK, OUTER RH | ||||
| 72137-0D140C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72137-0D170C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72137-0D140C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72137-0D200C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72137-0D270C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72137-0D140C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72137-0D140C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72137-0D170C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72137-0D270C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72147 - BRACKET, FRONT INNER SEAT TRACK, LOWER REAR RH | ||||
| 72147-0D170 |
NSP150,151..H |
1 | ||
| 72147-0D110 |
NSP151..F |
1 | ||
| 72147-0D140 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72147-0D190 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 72211C - HANDLE, SEAT TRACK ADJUSTING | ||||
| 72211-0D240 |
NSP150,151..H |
2 | ||
| 72211-0D300 |
NSP151..F |
2 | ||
| 72211-0D260 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 72211-0D290 |
NSP15#..A |
2 | ||
| 72265 - COVER, SEAT TRACK UPPER RAIL, RH | ||||
| 72265-0D100 |
NSP151..F |
2 | ||
| 72265-0D090 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 71848-0D150 |
NSP151..F |
2 | ||
| 72266 - COVER, SEAT TRACK UPPER RAIL, LH | ||||
| 72265-0D100 |
NSP151..F |
2 | ||
| 72265-0D090 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 71848-0D150 |
NSP151..F |
2 | ||
| 72525A - HANDLE, RECLINING ADJUSTER RELEASE, RH | ||||
| 72525-0D270C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72525-0D330C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72525-02230C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72525-02230C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72525-0D370C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72525-02230C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72525-0D370C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72525-02230C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72525-0D330C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72525-0D300C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 73910A - AIR BAG ASSY, FRONT SEAT, RH | ||||
| 73910-0D100 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 73910-0D100 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 73910-0D160 |
NSP151..(PH,SA,VN)..(G,V);NSP15#..CVT..(PH,TH,VN)..R |
1 | ||
| Common parts | ||||
| 72702-52030 | ||||
| 90105-T0176 | ||||
| 90107-T0003 | ||||
| 90119-10601 | ||||
| 91553-10820 | ||||
| 94170-60600 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 1 OF 2(1806- )H
LH SEAT,W(VERTICAL ADJUSTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71014S - FRAME SUB-ASSY, FRONT SEAT BACK, LH | ||||
| 71014-0D320 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71014-0D300 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71014-0D280 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71014-0D280 |
NSP151..(G,V)..C |
1 | ||
| 71014-0D110 |
NSP151..(G,R)..F |
1 | ||
| 71014-0D300 |
NSP151..V..F |
1 | ||
| 71014-0D280 |
NSP151..CVT..R..C |
1 | ||
| 71014-0D210 |
NSP151..(G,V)..C |
1 | ||
| 71072S - COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE) | ||||
| 71072-0DL50C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71072-0DW50C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71072-0U040C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71072-0U050C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71072-0UE60C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71072-0UE40C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71072-0DZ40C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71072-0DF20A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71072-0DZ40A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71072-0U050C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71072-0DZ50C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71072-0U030C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71072-0UG00C1 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71072-0UG10C1 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71072-0UE60C7 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71072-0UG20C1 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71072-0U050C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71072-0UK00C3 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71074S - COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71074-0DG80C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71074-0DL80C0 |
NSP151..D..A BLACK,TRIM2# |
1 | ||
| 71074-0DV60C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71074-0DY40C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71074-0DY30C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71074-0UD50C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71074-0DY40C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71074-0DX50C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71074-0UD80C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71074-0DX40C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71074-0DX40A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71074-0DC90C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71074-0DY20C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71074-0UC20C0 |
NSP151..D..A BLACK,TRIM2# |
1 | ||
| 71074-0UD80C5 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71074-0UJ20C2 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71074-0UJ40C2 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71074-0UJ30C2 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71074-0UK80C4 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71074-0DY40C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71122 - BRACKET, FRONT SEAT CUSHION, LH | ||||
| 71122-0D050 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71122-0D180 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71122-0D120 |
NSP151..(G,V)..C |
1 | ||
| 71122-0D010 |
NSP151..(G,V)..C |
1 | ||
| 71122-0D120 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71122-0D120 |
NSP151..CVT..R..C |
1 | ||
| 71122-0D150 |
NSP151..(G,R)..F |
1 | ||
| 71122-0D220 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 71512S - PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE) | ||||
| 71502-0D090 |
NSP151..CVT..R..C |
1 | ||
| 71512-0D850 |
NSP151..PH |
1 | ||
| 71512-0D610 |
NSP151..PH |
1 | ||
| 71512-0D750 |
NSP150,151..H |
1 | ||
| 71502-0D090 |
NSP151..G..C |
1 | ||
| 71512-0D690 |
NSP151..V..F |
1 | ||
| 71512-0D680 |
NSP151..(G,R)..F |
1 | ||
| 71502-0D100 |
NSP151..V..C |
1 | ||
| 71502-0D160 |
NSP151..V..A |
1 | ||
| 71502-0D210 |
NSP151..G..C |
1 | ||
| 71537H - PROTECTOR, FRONT SEAT CUSHION EDGE, RH(FOR LH SEAT) | ||||
| 71537-0D390C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71537-0D120C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71537-0D310C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71537-0D170C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D170C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71537-0D170C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D170C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D310C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71538B - PROTECTOR, FRONT SEAT CUSHION EDGE, LH(FOR LH SEAT) | ||||
| 71538-0D320C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71538-0D110C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71538-0D160C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D160C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71538-0D160C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D210C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71538-0D160C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71538-0D210C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71552S - PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71552-0D720 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71552-0D600 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71552-0D640 |
NSP151..V..C |
1 | ||
| 71552-0D690 |
NSP151..V..F |
1 | ||
| 71552-0D630 |
NSP151..CVT..R..C |
1 | ||
| 71552-0D630 |
NSP151..G..C |
1 | ||
| 71552-0D640 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71552-0D280 |
NSP151..(G,R)..F |
1 | ||
| 71552-0D390 |
NSP151..V..C |
1 | ||
| 71552-0D680 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71552-0DA10 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71552-0D830 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71552-0DA00 |
NSP151..G..C |
1 | ||
| 71812D - SHIELD, FRONT SEAT CUSHION, LH | ||||
| 71812-0D460C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71812-0D310C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71812-0D520C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71812-0D510C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71812-0D480C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71812-0D520C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71812-0D520C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71812-0D590C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71812-0D570C0 |
NSP152;NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71812-0D310C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71812-0D370C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71812-0D510C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71812-0D520C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71812-0D510C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71812-0D590C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71862 - SHIELD, FRONT SEAT CUSHION, INNER LH | ||||
| 71862-0D230C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71862-0D360C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71862-0D450C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71862-0D280C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71862-0D340C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71862-0D360C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71862-0D280C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71862-0D290C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71862-0D450C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71862-0D340C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71862-0D360C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71873B - SHIELD, FRONT SEAT CUSHION, LOWER RH, NO.1 | ||||
| 71873-0D400C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71873-06460 |
NSP151..F |
1 | ||
| 71873-0D370 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 71874 - SHIELD, FRONT SEAT CUSHION, LOWER LH | ||||
| 71874-0D440C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71874-0D350 |
NSP151..F |
1 | ||
| 71874-0D360 |
NSP150,151..LHD..(GCC,GEN,PH,VN)..(G,R)..A |
1 | ||
| 71874A - SHIELD, FRONT SEAT CUSHION, LOWER LH | ||||
| 71874-0D430C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71874-0D390 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 71874-06450 |
NSP151..F |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-0DB00C1 |
NSP151..PH BLACK/RED,TRIM2# |
2 | ||
| 71910-0DL20C0 |
NSP150,151..D..H BLACK,TRIM2# |
2 | ||
| 71910-0DK60C0 |
NSP151..PH BLACK,TRIM2# |
2 | ||
| 71910-0DD30C1 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DD10C2 |
NSP151..(G,R)..C BLACK/BLUE 121,TRIM2# |
2 | ||
| 71910-0DN00C0 |
NSP151..V..A BLACK,TRIM2# |
2 | ||
| 71910-0DJ50C1 |
NSP151..V..F BLACK,TRIM2# |
2 | ||
| 71910-0DB30A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
2 | ||
| 71910-0DB30C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
2 | ||
| 71910-0DD10C5 |
NSP151..5F..G;NSP151..CVT..(G,R)..C BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DB60A2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
2 | ||
| 71910-0DB60C2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
2 | ||
| 71910-0DK50C8 |
NSP151..R..A;NSP150..LHD..CVT;NSP150..5F..GEN..R BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DD30C2 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DN00C3 |
NSP152;NSP151..(PH,SA)..(G,V) BLACK/BLUE,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 72020 - ADJUSTER ASSY, FRONT SEAT, LH | ||||
| 72020-0D501 |
NSP151..F |
1 | ||
| 72020-0D561 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72020-0D740 |
NSP150,151..H |
1 | ||
| 72020-0D521 |
NSP150,151..LHD..(GCC,GEN,PH,VN)..(G,R)..A |
1 | ||
| 72020-0D741 |
NSP150,151..H |
1 | ||
| 72138 - COVER, SEAT TRACK, OUTER LH | ||||
| 72138-0D180C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72138-0D150C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72138-0D120C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72138-0D120C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72138-0D260C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72138-0D120C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72138-0D150C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72138-0D120C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72138-0D260C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72148 - BRACKET, FRONT INNER SEAT TRACK, LOWER REAR LH | ||||
| 72148-0D120 |
NSP151..F |
1 | ||
| 72148-0D200 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 72148-0D180 |
NSP150,151..H |
1 | ||
| 72148-0D150 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72211C - HANDLE, SEAT TRACK ADJUSTING | ||||
| 72211-0D240 |
NSP150,151..H |
2 | ||
| 72211-0D300 |
NSP151..F |
2 | ||
| 72211-0D260 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 72211-0D290 |
NSP15#..A |
2 | ||
| 72495 - HANDLE, VERTICAL ADJUSTING, LH | ||||
| 72495-0D060C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72495-0D050C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72495-0D100C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72495-0D050C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72495-0D050C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72495-0D090C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72495-0D100C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 72495-0D050C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526A - HANDLE, RECLINING ADJUSTER RELEASE, LH | ||||
| 72526-0D320C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72526-0M010C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72526-06130C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72526-0D300C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72526-0D360C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72526-0M010C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72526-0M010C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526-0D360C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72526-0M010C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526-0D300C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 73920A - AIR BAG ASSY, FRONT SEAT, LH | ||||
| 73920-0D100 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 73920-0D100 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 73920-0D160 |
NSP151..(PH,SA,VN)..(G,V);NSP15#..CVT..(PH,TH,VN)..R |
1 | ||
| Common parts | ||||
| 72702-52030 | ||||
| 90080-11132 | ||||
| 90167-40044 | ||||
| 90168-50078 | ||||
| 91553-10820 | ||||
| 94170-60600 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 2 OF 2(1806- )H
RH SEAT,W/O(VERTICAL ADJUSTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71013S - FRAME SUB-ASSY, FRONT SEAT BACK, RH | ||||
| 71013-0D360 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71013-0D270 |
NSP151..(G,V)..C |
1 | ||
| 71013-0D270 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71013-0D300 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71013-0D300 |
NSP151..V..F |
1 | ||
| 71013-0D200 |
NSP151..(G,V)..C |
1 | ||
| 71013-0D270 |
NSP151..CVT..R..C |
1 | ||
| 71013-0D110 |
NSP151..(G,R)..F |
1 | ||
| 71071S - COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71071-0DY90C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71071-0U590C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71071-0DW80C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71071-0DE10A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71071-0DE10C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71071-0DZ80C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71071-0DZ70C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71071-0DY80A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71071-0UG60C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71071-0DZ80C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71071-0UG30C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71071-0DE10C2 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71071-0DE10A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71071-0DY80C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71071-0DZ60C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71071-0UK10C1 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71071-0UK20C1 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71071-0UG60C7 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71071-0UK00C1 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71071-0UL40C3 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71071-0DZ80C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71073S - COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71073-0DM40C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71073-0DY10C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71073-0DG10C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71073-0U170C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71073-0DG10A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71073-0U190C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71073-0UJ10C1 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71073-0UJ40C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71073-0U090A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71073-0U190C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71073-0U090C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71073-0DG10C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71073-0U100C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71073-0DG10A3 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71073-0U160C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71073-0UJ40C3 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71073-0UL90C2 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71073-0UN10C2 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71073-0UN00C2 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71073-0UP40C4 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71073-0U190C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71121 - BRACKET, FRONT SEAT CUSHION, RH | ||||
| 71121-0D010 |
NSP150,151..H |
1 | ||
| 71511S - PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71051-0D100 |
NSP150,151..H |
1 | ||
| 71501-0D200 |
NSP151..PH |
1 | ||
| 71511-0D660 |
NSP151..G..C |
1 | ||
| 71511-0D740 |
NSP151..V..F |
1 | ||
| 71511-0D260 |
NSP151..(G,R)..F |
1 | ||
| 71511-0D730 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71511-0D670 |
NSP151..V..C |
1 | ||
| 71511-0D660 |
NSP151..CVT..R..C |
1 | ||
| 71511-0DA50 |
NSP151..V..A |
1 | ||
| 71501-0D330 |
NSP151..PH |
1 | ||
| 71501-0D240 |
NSP150,151..LHD..CVT..(GEN,PH)..R |
1 | ||
| 71511-0DB80 |
NSP151..G..C |
1 | ||
| 71537G - PROTECTOR, FRONT SEAT CUSHION EDGE, RH(FOR RH SEAT) | ||||
| 71537-0D110C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71537-0D320C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71537-0D100C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D280C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71537-0D100C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71537-0D320C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71537-0D100C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D100C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538A - PROTECTOR, FRONT SEAT CUSHION EDGE, LH(FOR RH SEAT) | ||||
| 71538-0D220C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71538-0D090C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D310C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71538-0D100C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71538-0D090C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71538-0D090C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D090C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71538-0D220C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71551S - PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71551-0D800 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71551-0D680 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71551-0D720 |
NSP151..V..C |
1 | ||
| 71551-0D710 |
NSP151..G..C |
1 | ||
| 71551-0D360 |
NSP151..(G,R)..F |
1 | ||
| 71551-0D740 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71551-0D750 |
NSP151..V..F |
1 | ||
| 71551-0D710 |
NSP151..CVT..R..C |
1 | ||
| 71551-0D880 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71551-0D490 |
NSP151..V..C |
1 | ||
| 71551-0D720 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71551-0DA60 |
NSP151..G..C |
1 | ||
| 71551-0DA70 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71811D - SHIELD, FRONT SEAT CUSHION, RH | ||||
| 71811-0D440C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71811-0D510C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71811-0D450C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71811-0D260C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71811-0D530C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71811-0D530C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71811-0D530C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71811-0D570C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71811-0D590C0 |
NSP152;NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71811-0D260C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71811-0D400C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71811-0D570C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71811-0D510C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71811-0D530C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71811-0D510C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71861 - SHIELD, FRONT SEAT CUSHION, INNER RH | ||||
| 71861-0D330C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71861-0D330C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71861-0D330C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71861-0D440C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71861-0D360C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71861-0D410C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71861-0D210C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71861-0D210C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71861-0D360C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71861-0D330C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71861-0D330C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71861-0D440C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71861-0D360C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71861-0D290C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-0DB00C1 |
NSP151..PH BLACK/RED,TRIM2# |
2 | ||
| 71910-0DL20C0 |
NSP150,151..D..H BLACK,TRIM2# |
2 | ||
| 71910-0DK60C0 |
NSP151..PH BLACK,TRIM2# |
2 | ||
| 71910-0DD30C1 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DD10C2 |
NSP151..(G,R)..C BLACK/BLUE 121,TRIM2# |
2 | ||
| 71910-0DN00C0 |
NSP151..V..A BLACK,TRIM2# |
2 | ||
| 71910-0DJ50C1 |
NSP151..V..F BLACK,TRIM2# |
2 | ||
| 71910-0DB30A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
2 | ||
| 71910-0DB30C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
2 | ||
| 71910-0DD10C5 |
NSP151..5F..G;NSP151..CVT..(G,R)..C BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DB60A2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
2 | ||
| 71910-0DB60C2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
2 | ||
| 71910-0DK50C8 |
NSP151..R..A;NSP150..LHD..CVT;NSP150..5F..GEN..R BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DD30C2 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DN00C3 |
NSP152;NSP151..(PH,SA)..(G,V) BLACK/BLUE,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 72010 - ADJUSTER ASSY, FRONT SEAT, RH | ||||
| 72010-0D531 |
NSP150,151..PH,VN |
1 | ||
| 71011-0D220 |
NSP150,151..H |
1 | ||
| 72010-0D461 |
NSP151..(G,R)..F |
1 | ||
| 72010-0D700 |
NSP151..(G,V)..C |
1 | ||
| 72010-0D750 |
NSP151..V..F |
1 | ||
| 72010-0D700 |
NSP151..CVT..R..C |
1 | ||
| 72010-0D551 |
NSP151..(G,V)..C |
1 | ||
| 72010-0D750 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 72010-0D700 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 72137 - COVER, SEAT TRACK, OUTER RH | ||||
| 72137-0D140C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72137-0D170C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72137-0D140C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72137-0D200C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72137-0D270C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72137-0D140C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72137-0D140C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72137-0D170C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72137-0D270C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72147 - BRACKET, FRONT INNER SEAT TRACK, LOWER REAR RH | ||||
| 72147-0D170 |
NSP150,151..H |
1 | ||
| 72147-0D110 |
NSP151..F |
1 | ||
| 72147-0D140 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72147-0D190 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 72211C - HANDLE, SEAT TRACK ADJUSTING | ||||
| 72211-0D240 |
NSP150,151..H |
2 | ||
| 72211-0D300 |
NSP151..F |
2 | ||
| 72211-0D260 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
2 | ||
| 72211-0D290 |
NSP15#..A |
2 | ||
| 72525A - HANDLE, RECLINING ADJUSTER RELEASE, RH | ||||
| 72525-0D270C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72525-0D330C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72525-02230C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72525-02230C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72525-0D370C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72525-02230C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72525-0D370C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72525-02230C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72525-0D330C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72525-0D300C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 73910A - AIR BAG ASSY, FRONT SEAT, RH | ||||
| 73910-0D100 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 73910-0D100 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 73910-0D160 |
NSP151..(PH,SA,VN)..(G,V);NSP15#..CVT..(PH,TH,VN)..R |
1 | ||
| Common parts | ||||
| 72702-52030 | ||||
| 90080-11132 | ||||
| 91553-10820 | ||||
| 94170-60600 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 1 OF 2(1911- )A
LH SEAT,W(VERTICAL ADJUSTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71052A - SPRING SUB-ASSY, FRONT SEAT CUSHION, LH | ||||
| 71051-0D160 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 71072S - COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE) | ||||
| 71072-0DL50C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71072-0DW50C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71072-0U040C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71072-0U050C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71072-0UE60C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71072-0UE40C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71072-0DZ40C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71072-0DF20A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71072-0DZ40A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71072-0U050C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71072-0DZ50C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71072-0U030C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71072-0UG00C1 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71072-0UG10C1 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71072-0UE60C7 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71072-0UG20C1 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71072-0U050C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71072-0UK00C3 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71074S - COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71074-0DG80C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71074-0DL80C0 |
NSP151..D..A BLACK,TRIM2# |
1 | ||
| 71074-0DV60C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71074-0DY40C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71074-0DY30C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71074-0UD50C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71074-0DY40C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71074-0DX50C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71074-0UD80C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71074-0DX40C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71074-0DX40A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71074-0DC90C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71074-0DY20C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71074-0UC20C0 |
NSP151..D..A BLACK,TRIM2# |
1 | ||
| 71074-0UD80C5 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71074-0UJ20C2 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71074-0UJ40C2 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71074-0UJ30C2 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71074-0UK80C4 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71074-0DY40C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71102A - SEAT SUB-ASSY, FRONT LH | ||||
| 71102-0D050 |
NSP150..LHD..CVT;NSP150..5F..GEN..R;NSP151..LHD..(G,R)..A |
1 | ||
| 71120B - FRAME ASSY, FRONT SEAT W/ADJUSTER, LH | ||||
| 71120-0D050 |
NSP150..LHD..CVT;NSP150..5F..GEN..R;NSP151..LHD..(G,R)..A |
1 | ||
| 71122 - BRACKET, FRONT SEAT CUSHION, LH | ||||
| 71122-0D050 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71122-0D180 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71122-0D120 |
NSP151..(G,V)..C |
1 | ||
| 71122-0D010 |
NSP151..(G,V)..C |
1 | ||
| 71122-0D120 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71122-0D120 |
NSP151..CVT..R..C |
1 | ||
| 71122-0D150 |
NSP151..(G,R)..F |
1 | ||
| 71122-0D220 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 71512S - PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE) | ||||
| 71502-0D090 |
NSP151..CVT..R..C |
1 | ||
| 71512-0D850 |
NSP151..PH |
1 | ||
| 71512-0D610 |
NSP151..PH |
1 | ||
| 71512-0D750 |
NSP150,151..H |
1 | ||
| 71502-0D090 |
NSP151..G..C |
1 | ||
| 71512-0D690 |
NSP151..V..F |
1 | ||
| 71512-0D680 |
NSP151..(G,R)..F |
1 | ||
| 71502-0D100 |
NSP151..V..C |
1 | ||
| 71502-0D160 |
NSP151..V..A |
1 | ||
| 71502-0D210 |
NSP151..G..C |
1 | ||
| 71537H - PROTECTOR, FRONT SEAT CUSHION EDGE, RH(FOR LH SEAT) | ||||
| 71537-0D390C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71537-0D120C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71537-0D310C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71537-0D170C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D170C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71537-0D170C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D170C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D310C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71538B - PROTECTOR, FRONT SEAT CUSHION EDGE, LH(FOR LH SEAT) | ||||
| 71538-0D320C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71538-0D110C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71538-0D160C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D160C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71538-0D160C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D210C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71538-0D160C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71538-0D210C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71552S - PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71552-0D720 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71552-0D600 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71552-0D640 |
NSP151..V..C |
1 | ||
| 71552-0D690 |
NSP151..V..F |
1 | ||
| 71552-0D630 |
NSP151..CVT..R..C |
1 | ||
| 71552-0D630 |
NSP151..G..C |
1 | ||
| 71552-0D640 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71552-0D280 |
NSP151..(G,R)..F |
1 | ||
| 71552-0D390 |
NSP151..V..C |
1 | ||
| 71552-0D680 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71552-0DA10 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71552-0D830 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71552-0DA00 |
NSP151..G..C |
1 | ||
| 71812D - SHIELD, FRONT SEAT CUSHION, LH | ||||
| 71812-0D460C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71812-0D310C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71812-0D520C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71812-0D510C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71812-0D480C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71812-0D520C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71812-0D520C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71812-0D590C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71812-0D570C0 |
NSP152;NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71812-0D310C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71812-0D370C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71812-0D510C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71812-0D520C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71812-0D510C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71812-0D590C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71862 - SHIELD, FRONT SEAT CUSHION, INNER LH | ||||
| 71862-0D230C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71862-0D360C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71862-0D450C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71862-0D280C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71862-0D340C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71862-0D360C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71862-0D280C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71862-0D290C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71862-0D450C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71862-0D340C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71862-0D360C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71875A - COVER, RECLINING ADJUSTER INSIDE, RH | ||||
| 71875-0D260 |
NSP150..LHD..CVT;NSP150..5F..GEN..R;NSP151..LHD..(G,R)..A |
1 | ||
| 71875-0D260C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71876 - COVER, RECLINING ADJUSTER INSIDE, LH | ||||
| 71876-0D260 |
NSP150..LHD..CVT;NSP150..5F..GEN..R;NSP151..LHD..(G,R)..A |
1 | ||
| 71876-0D260C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-0DB00C1 |
NSP151..PH BLACK/RED,TRIM2# |
2 | ||
| 71910-0DL20C0 |
NSP150,151..D..H BLACK,TRIM2# |
2 | ||
| 71910-0DK60C0 |
NSP151..PH BLACK,TRIM2# |
2 | ||
| 71910-0DD30C1 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DD10C2 |
NSP151..(G,R)..C BLACK/BLUE 121,TRIM2# |
2 | ||
| 71910-0DN00C0 |
NSP151..V..A BLACK,TRIM2# |
2 | ||
| 71910-0DJ50C1 |
NSP151..V..F BLACK,TRIM2# |
2 | ||
| 71910-0DB30A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
2 | ||
| 71910-0DB30C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
2 | ||
| 71910-0DD10C5 |
NSP151..5F..G;NSP151..CVT..(G,R)..C BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DB60A2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
2 | ||
| 71910-0DB60C2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
2 | ||
| 71910-0DK50C8 |
NSP151..R..A;NSP150..LHD..CVT;NSP150..5F..GEN..R BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DD30C2 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DN00C3 |
NSP152;NSP151..(PH,SA)..(G,V) BLACK/BLUE,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 72123B - COVER, SEAT TRACK BRACKET, OUTER FRONT | ||||
| 72123-0D030C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72123-0D030C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72125D - COVER, SEAT TRACK, UPPER REAR NO.2 | ||||
| 72265-0D060 |
NSP151..F |
2 | ||
| 72125-0D090 |
NSP151..F |
2 | ||
| 72125-0D120 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72125R - COVER, SEAT TRACK, UPPER REAR NO.1 | ||||
| 72125-06090 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72128A - COVER, SEAT TRACK BRACKET, INNER FRONT LH | ||||
| 72128-0D030C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72128-0D030C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72138 - COVER, SEAT TRACK, OUTER LH | ||||
| 72138-0D180C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72138-0D150C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72138-0D120C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72138-0D120C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72138-0D260C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72138-0D120C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72138-0D150C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72138-0D120C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72138-0D260C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72148 - BRACKET, FRONT INNER SEAT TRACK, LOWER REAR LH | ||||
| 72148-0D120 |
NSP151..F |
1 | ||
| 72148-0D200 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 72148-0D180 |
NSP150,151..H |
1 | ||
| 72148-0D150 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72157 - COVER, SEAT TRACK BRACKET, INNER | ||||
| 72157-0D070C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72157-0D070C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72211 - HANDLE, SEAT TRACK ADJUSTING | ||||
| 72211-0D320 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72265D - COVER, SEAT TRACK UPPER RAIL | ||||
| 72265-06060 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
4 | ||
| 72265D - COVER, SEAT TRACK UPPER RAIL | ||||
| 72265-06060 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
4 | ||
| 72495 - HANDLE, VERTICAL ADJUSTING, LH | ||||
| 72495-0D060C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72495-0D050C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72495-0D100C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72495-0D050C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72495-0D050C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72495-0D090C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72495-0D100C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 72495-0D050C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526A - HANDLE, RECLINING ADJUSTER RELEASE, LH | ||||
| 72526-0D320C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72526-0M010C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72526-06130C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72526-0D300C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72526-0D360C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72526-0M010C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72526-0M010C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526-0D360C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72526-0M010C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526-0D300C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 73920A - AIR BAG ASSY, FRONT SEAT, LH | ||||
| 73920-0D100 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 73920-0D100 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 73920-0D160 |
NSP151..(PH,SA,VN)..(G,V);NSP15#..CVT..(PH,TH,VN)..R |
1 | ||
| Common parts | ||||
| 90105-T0176 | ||||
| 90148-10007 | ||||
| 90148-T0020 | ||||
| 90168-50078 | ||||
| 91553-10820 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 1 OF 2(1911- )A
LH SEAT,W/O(VERTICAL ADJUSTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71052A - SPRING SUB-ASSY, FRONT SEAT CUSHION, LH | ||||
| 71051-0D160 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 71072S - COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE) | ||||
| 71072-0DL50C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71072-0DW50C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71072-0U040C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71072-0U050C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71072-0UE60C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71072-0UE40C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71072-0DZ40C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71072-0DF20A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71072-0DZ40A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71072-0U050C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71072-0DF20C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71072-0DZ50C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71072-0U030C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71072-0UG00C1 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71072-0UG10C1 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71072-0UE60C7 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71072-0UG20C1 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71072-0U050C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71072-0UK00C3 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71074S - COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71074-0DG80C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71074-0DL80C0 |
NSP151..D..A BLACK,TRIM2# |
1 | ||
| 71074-0DV60C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71074-0DY40C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71074-0DY30C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71074-0UD50C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71074-0DY40C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71074-0DC90A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71074-0DX50C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71074-0UD80C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71074-0DX40C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71074-0DX40A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71074-0DC90C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71074-0DY20C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71074-0UC20C0 |
NSP151..D..A BLACK,TRIM2# |
1 | ||
| 71074-0UD80C5 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71074-0UJ20C2 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71074-0UJ40C2 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71074-0UJ30C2 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71074-0UK80C4 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71074-0DY40C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71102A - SEAT SUB-ASSY, FRONT LH | ||||
| 71102-0D050 |
NSP150..LHD..CVT;NSP150..5F..GEN..R;NSP151..LHD..(G,R)..A |
1 | ||
| 71120B - FRAME ASSY, FRONT SEAT W/ADJUSTER, LH | ||||
| 71120-0D050 |
NSP150..LHD..CVT;NSP150..5F..GEN..R;NSP151..LHD..(G,R)..A |
1 | ||
| 71122 - BRACKET, FRONT SEAT CUSHION, LH | ||||
| 71122-0D050 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71122-0D180 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71122-0D120 |
NSP151..(G,V)..C |
1 | ||
| 71122-0D010 |
NSP151..(G,V)..C |
1 | ||
| 71122-0D120 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71122-0D120 |
NSP151..CVT..R..C |
1 | ||
| 71122-0D150 |
NSP151..(G,R)..F |
1 | ||
| 71122-0D220 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 71512S - PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE) | ||||
| 71502-0D090 |
NSP151..CVT..R..C |
1 | ||
| 71512-0D850 |
NSP151..PH |
1 | ||
| 71512-0D610 |
NSP151..PH |
1 | ||
| 71512-0D750 |
NSP150,151..H |
1 | ||
| 71502-0D090 |
NSP151..G..C |
1 | ||
| 71512-0D690 |
NSP151..V..F |
1 | ||
| 71512-0D680 |
NSP151..(G,R)..F |
1 | ||
| 71502-0D100 |
NSP151..V..C |
1 | ||
| 71502-0D160 |
NSP151..V..A |
1 | ||
| 71502-0D210 |
NSP151..G..C |
1 | ||
| 71537H - PROTECTOR, FRONT SEAT CUSHION EDGE, RH(FOR LH SEAT) | ||||
| 71537-0D390C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71537-0D120C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71537-0D310C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71537-0D170C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D170C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71537-0D170C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D170C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D310C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71538B - PROTECTOR, FRONT SEAT CUSHION EDGE, LH(FOR LH SEAT) | ||||
| 71538-0D320C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71538-0D110C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71538-0D160C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D160C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71538-0D160C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D210C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71538-0D160C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71538-0D210C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71552S - PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71552-0D720 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71552-0D600 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71552-0D640 |
NSP151..V..C |
1 | ||
| 71552-0D690 |
NSP151..V..F |
1 | ||
| 71552-0D630 |
NSP151..CVT..R..C |
1 | ||
| 71552-0D630 |
NSP151..G..C |
1 | ||
| 71552-0D640 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71552-0D280 |
NSP151..(G,R)..F |
1 | ||
| 71552-0D390 |
NSP151..V..C |
1 | ||
| 71552-0D680 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71552-0DA10 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71552-0D830 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71552-0DA00 |
NSP151..G..C |
1 | ||
| 71812D - SHIELD, FRONT SEAT CUSHION, LH | ||||
| 71812-0D460C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71812-0D310C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71812-0D520C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71812-0D510C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71812-0D480C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71812-0D520C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71812-0D520C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71812-0D590C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71812-0D570C0 |
NSP152;NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71812-0D310C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71812-0D370C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71812-0D510C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71812-0D520C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71812-0D510C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71812-0D590C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71862 - SHIELD, FRONT SEAT CUSHION, INNER LH | ||||
| 71862-0D230C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71862-0D360C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71862-0D450C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71862-0D280C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71862-0D340C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71862-0D340C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71862-0D360C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71862-0D280C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71862-0D290C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71862-0D450C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71862-0D340C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71862-0D360C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-0DB00C1 |
NSP151..PH BLACK/RED,TRIM2# |
2 | ||
| 71910-0DL20C0 |
NSP150,151..D..H BLACK,TRIM2# |
2 | ||
| 71910-0DK60C0 |
NSP151..PH BLACK,TRIM2# |
2 | ||
| 71910-0DD30C1 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DD10C2 |
NSP151..(G,R)..C BLACK/BLUE 121,TRIM2# |
2 | ||
| 71910-0DN00C0 |
NSP151..V..A BLACK,TRIM2# |
2 | ||
| 71910-0DJ50C1 |
NSP151..V..F BLACK,TRIM2# |
2 | ||
| 71910-0DB30A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
2 | ||
| 71910-0DB30C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
2 | ||
| 71910-0DD10C5 |
NSP151..5F..G;NSP151..CVT..(G,R)..C BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DB60A2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
2 | ||
| 71910-0DB60C2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
2 | ||
| 71910-0DK50C8 |
NSP151..R..A;NSP150..LHD..CVT;NSP150..5F..GEN..R BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DD30C2 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DN00C3 |
NSP152;NSP151..(PH,SA)..(G,V) BLACK/BLUE,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 72123B - COVER, SEAT TRACK BRACKET, OUTER FRONT | ||||
| 72123-0D030C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72123-0D030C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72125D - COVER, SEAT TRACK, UPPER REAR NO.2 | ||||
| 72265-0D060 |
NSP151..F |
2 | ||
| 72125-0D090 |
NSP151..F |
2 | ||
| 72125-0D120 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72125R - COVER, SEAT TRACK, UPPER REAR NO.1 | ||||
| 72125-06090 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72128A - COVER, SEAT TRACK BRACKET, INNER FRONT LH | ||||
| 72128-0D030C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72128-0D030C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72138 - COVER, SEAT TRACK, OUTER LH | ||||
| 72138-0D180C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72138-0D150C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72138-0D120C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72138-0D120C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72138-0D260C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72138-0D120C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72138-0D150C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72138-0D120C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72138-0D260C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72148 - BRACKET, FRONT INNER SEAT TRACK, LOWER REAR LH | ||||
| 72148-0D120 |
NSP151..F |
1 | ||
| 72148-0D200 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 72148-0D180 |
NSP150,151..H |
1 | ||
| 72148-0D150 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72157 - COVER, SEAT TRACK BRACKET, INNER | ||||
| 72157-0D070C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72157-0D070C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72211 - HANDLE, SEAT TRACK ADJUSTING | ||||
| 72211-0D320 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72265D - COVER, SEAT TRACK UPPER RAIL | ||||
| 72265-06060 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
4 | ||
| 72265D - COVER, SEAT TRACK UPPER RAIL | ||||
| 72265-06060 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
4 | ||
| 72526A - HANDLE, RECLINING ADJUSTER RELEASE, LH | ||||
| 72526-0D320C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72526-0M010C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72526-06130C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72526-0D300C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72526-0D360C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72526-0M010C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72526-0M010C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526-0D360C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72526-0M010C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72526-0D300C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 73920A - AIR BAG ASSY, FRONT SEAT, LH | ||||
| 73920-0D100 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 73920-0D100 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 73920-0D160 |
NSP151..(PH,SA,VN)..(G,V);NSP15#..CVT..(PH,TH,VN)..R |
1 | ||
| Common parts | ||||
| 90105-T0176 | ||||
| 90148-10007 | ||||
| 90148-T0020 | ||||
| 90168-50078 | ||||
| 91553-10820 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 2 OF 2(1911- )A
RH SEAT,W(VERTICAL ADJUSTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71051A - SPRING SUB-ASSY, FRONT SEAT CUSHION, RH | ||||
| 71051-0D160 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 71071S - COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71071-0DY90C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71071-0U590C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71071-0DW80C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71071-0DE10A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71071-0DE10C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71071-0DZ80C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71071-0DZ70C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71071-0DY80A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71071-0UG60C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71071-0DZ80C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71071-0UG30C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71071-0DE10C2 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71071-0DE10A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71071-0DY80C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71071-0DZ60C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71071-0UK10C1 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71071-0UK20C1 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71071-0UG60C7 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71071-0UK00C1 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71071-0UL40C3 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71071-0DZ80C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71073S - COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71073-0DM40C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71073-0DY10C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71073-0DG10C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71073-0U170C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71073-0DG10A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71073-0U190C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71073-0UJ10C1 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71073-0UJ40C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71073-0U090A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71073-0U190C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71073-0U090C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71073-0DG10C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71073-0U100C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71073-0DG10A3 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71073-0U160C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71073-0UJ40C3 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71073-0UL90C2 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71073-0UN10C2 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71073-0UN00C2 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71073-0UP40C4 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71073-0U190C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71101C - SEAT SUB-ASSY, FRONT RH | ||||
| 71101-0D040 |
NSP150,151..CVT..(PH,VN) |
1 | ||
| 71110A - FRAME ASSY, FRONT SEAT W/ADJUSTER, RH | ||||
| 71110-0D040 |
NSP150,151..CVT..(PH,VN) |
1 | ||
| 71511S - PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71051-0D100 |
NSP150,151..H |
1 | ||
| 71501-0D200 |
NSP151..PH |
1 | ||
| 71511-0D660 |
NSP151..G..C |
1 | ||
| 71511-0D740 |
NSP151..V..F |
1 | ||
| 71511-0D260 |
NSP151..(G,R)..F |
1 | ||
| 71511-0D730 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71511-0D670 |
NSP151..V..C |
1 | ||
| 71511-0D660 |
NSP151..CVT..R..C |
1 | ||
| 71511-0DA50 |
NSP151..V..A |
1 | ||
| 71501-0D330 |
NSP151..PH |
1 | ||
| 71501-0D240 |
NSP150,151..LHD..CVT..(GEN,PH)..R |
1 | ||
| 71511-0DB80 |
NSP151..G..C |
1 | ||
| 71537G - PROTECTOR, FRONT SEAT CUSHION EDGE, RH(FOR RH SEAT) | ||||
| 71537-0D110C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71537-0D320C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71537-0D100C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D280C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71537-0D100C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71537-0D320C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71537-0D100C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D100C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538A - PROTECTOR, FRONT SEAT CUSHION EDGE, LH(FOR RH SEAT) | ||||
| 71538-0D220C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71538-0D090C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D310C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71538-0D100C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71538-0D090C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71538-0D090C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D090C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71538-0D220C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71551S - PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71551-0D800 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71551-0D680 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71551-0D720 |
NSP151..V..C |
1 | ||
| 71551-0D710 |
NSP151..G..C |
1 | ||
| 71551-0D360 |
NSP151..(G,R)..F |
1 | ||
| 71551-0D740 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71551-0D750 |
NSP151..V..F |
1 | ||
| 71551-0D710 |
NSP151..CVT..R..C |
1 | ||
| 71551-0D880 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71551-0D490 |
NSP151..V..C |
1 | ||
| 71551-0D720 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71551-0DA60 |
NSP151..G..C |
1 | ||
| 71551-0DA70 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71811D - SHIELD, FRONT SEAT CUSHION, RH | ||||
| 71811-0D440C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71811-0D510C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71811-0D450C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71811-0D260C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71811-0D530C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71811-0D530C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71811-0D530C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71811-0D570C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71811-0D590C0 |
NSP152;NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71811-0D260C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71811-0D400C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71811-0D570C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71811-0D510C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71811-0D530C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71811-0D510C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71861 - SHIELD, FRONT SEAT CUSHION, INNER RH | ||||
| 71861-0D330C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71861-0D330C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71861-0D330C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71861-0D440C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71861-0D360C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71861-0D410C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71861-0D210C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71861-0D210C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71861-0D360C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71861-0D330C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71861-0D330C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71861-0D440C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71861-0D360C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71861-0D290C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71875A - COVER, RECLINING ADJUSTER INSIDE, RH | ||||
| 71875-0D260 |
NSP150..LHD..CVT;NSP150..5F..GEN..R;NSP151..LHD..(G,R)..A |
1 | ||
| 71875-0D260C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71876 - COVER, RECLINING ADJUSTER INSIDE, LH | ||||
| 71876-0D260 |
NSP150..LHD..CVT;NSP150..5F..GEN..R;NSP151..LHD..(G,R)..A |
1 | ||
| 71876-0D260C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-0DB00C1 |
NSP151..PH BLACK/RED,TRIM2# |
2 | ||
| 71910-0DL20C0 |
NSP150,151..D..H BLACK,TRIM2# |
2 | ||
| 71910-0DK60C0 |
NSP151..PH BLACK,TRIM2# |
2 | ||
| 71910-0DD30C1 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DD10C2 |
NSP151..(G,R)..C BLACK/BLUE 121,TRIM2# |
2 | ||
| 71910-0DN00C0 |
NSP151..V..A BLACK,TRIM2# |
2 | ||
| 71910-0DJ50C1 |
NSP151..V..F BLACK,TRIM2# |
2 | ||
| 71910-0DB30A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
2 | ||
| 71910-0DB30C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
2 | ||
| 71910-0DD10C5 |
NSP151..5F..G;NSP151..CVT..(G,R)..C BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DB60A2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
2 | ||
| 71910-0DB60C2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
2 | ||
| 71910-0DK50C8 |
NSP151..R..A;NSP150..LHD..CVT;NSP150..5F..GEN..R BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DD30C2 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DN00C3 |
NSP152;NSP151..(PH,SA)..(G,V) BLACK/BLUE,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 72123B - COVER, SEAT TRACK BRACKET, OUTER FRONT | ||||
| 72123-0D030C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72123-0D030C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72125D - COVER, SEAT TRACK, UPPER REAR NO.2 | ||||
| 72265-0D060 |
NSP151..F |
2 | ||
| 72125-0D090 |
NSP151..F |
2 | ||
| 72125-0D120 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72125R - COVER, SEAT TRACK, UPPER REAR NO.1 | ||||
| 72125-06090 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72127A - COVER, SEAT TRACK BRACKET, INNER FRONT RH | ||||
| 72127-0D030C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72127-0D030C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72137 - COVER, SEAT TRACK, OUTER RH | ||||
| 72137-0D140C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72137-0D170C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72137-0D140C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72137-0D200C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72137-0D270C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72137-0D140C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72137-0D140C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72137-0D170C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72137-0D270C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72147 - BRACKET, FRONT INNER SEAT TRACK, LOWER REAR RH | ||||
| 72147-0D170 |
NSP150,151..H |
1 | ||
| 72147-0D110 |
NSP151..F |
1 | ||
| 72147-0D140 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72147-0D190 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 72157 - COVER, SEAT TRACK BRACKET, INNER | ||||
| 72157-0D070C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72157-0D070C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72211 - HANDLE, SEAT TRACK ADJUSTING | ||||
| 72211-0D320 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72265D - COVER, SEAT TRACK UPPER RAIL | ||||
| 72265-06060 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
4 | ||
| 72265D - COVER, SEAT TRACK UPPER RAIL | ||||
| 72265-06060 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
4 | ||
| 72494 - HANDLE, VERTICAL ADJUSTING, RH | ||||
| 72494-0D170C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72494-0D170C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72525A - HANDLE, RECLINING ADJUSTER RELEASE, RH | ||||
| 72525-0D270C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72525-0D330C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72525-02230C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72525-02230C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72525-0D370C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72525-02230C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72525-0D370C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72525-02230C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72525-0D330C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72525-0D300C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 73910A - AIR BAG ASSY, FRONT SEAT, RH | ||||
| 73910-0D100 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 73910-0D100 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 73910-0D160 |
NSP151..(PH,SA,VN)..(G,V);NSP15#..CVT..(PH,TH,VN)..R |
1 | ||
| Common parts | ||||
| 90105-T0176 | ||||
| 90148-10007 | ||||
| 90148-T0020 | ||||
| 90168-50078 | ||||
| 91553-10820 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 2 OF 2(1911- )A
RH SEAT,W/O(VERTICAL ADJUSTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71051A - SPRING SUB-ASSY, FRONT SEAT CUSHION, RH | ||||
| 71051-0D160 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 71071S - COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71071-0U590C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71071-0DW80C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71071-0DE10A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71071-0DE10C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71071-0DZ80C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71071-0DZ70C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71071-0DY80A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71071-0UG60C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71071-0DY90C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71071-0DZ80C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71071-0UG30C0 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71071-0DE10C2 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71071-0DE10A2 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71071-0DY80C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71071-0DZ60C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71071-0UK10C1 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71071-0UK20C1 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71071-0UG60C7 |
NSP151..V..A BLACK/BLUE,TRIM2# |
1 | ||
| 71071-0UK00C1 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71071-0UL40C3 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71071-0DZ80C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71073S - COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71073-0DM40C0 |
NSP150,151..D..H BLACK,TRIM2# |
1 | ||
| 71073-0DY10C0 |
NSP151..PH BLACK/RED,TRIM2# |
1 | ||
| 71073-0DG10C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71073-0U170C0 |
NSP151..G..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71073-0DG10A1 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71073-0U190C0 |
NSP151..V..C BLACK/RED,TRIM2# |
1 | ||
| 71073-0UJ10C1 |
NSP151..PH BLACK,TRIM2# |
1 | ||
| 71073-0UJ40C0 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71073-0U090A0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
1 | ||
| 71073-0U190C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71073-0U090C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
1 | ||
| 71073-0DG10C1 |
NSP151..(G,R)..F BLACK,TRIM2# |
1 | ||
| 71073-0U100C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71073-0DG10A3 |
NSP151..(G,R)..F IVORY,TRIM0# |
1 | ||
| 71073-0U160C0 |
NSP151..CVT..R..C BLACK/BLUE 121,TRIM2# |
1 | ||
| 71073-0UJ40C3 |
NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71073-0UL90C2 |
NSP151..V..C BLACK,TRIM2# |
1 | ||
| 71073-0UN10C2 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71073-0UN00C2 |
NSP151..G..C BLACK,TRIM2# |
1 | ||
| 71073-0UP40C4 |
NSP151..PH BLACK/BLUE,TRIM2# |
1 | ||
| 71073-0U190C2 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK/RED,TRIM2# |
1 | ||
| 71101C - SEAT SUB-ASSY, FRONT RH | ||||
| 71101-0D040 |
NSP150,151..CVT..(PH,VN) |
1 | ||
| 71110A - FRAME ASSY, FRONT SEAT W/ADJUSTER, RH | ||||
| 71110-0D040 |
NSP150,151..CVT..(PH,VN) |
1 | ||
| 71511S - PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71051-0D100 |
NSP150,151..H |
1 | ||
| 71501-0D200 |
NSP151..PH |
1 | ||
| 71511-0D660 |
NSP151..G..C |
1 | ||
| 71511-0D740 |
NSP151..V..F |
1 | ||
| 71511-0D260 |
NSP151..(G,R)..F |
1 | ||
| 71511-0D730 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71511-0D670 |
NSP151..V..C |
1 | ||
| 71511-0D660 |
NSP151..CVT..R..C |
1 | ||
| 71511-0DA50 |
NSP151..V..A |
1 | ||
| 71501-0D330 |
NSP151..PH |
1 | ||
| 71501-0D240 |
NSP150,151..LHD..CVT..(GEN,PH)..R |
1 | ||
| 71511-0DB80 |
NSP151..G..C |
1 | ||
| 71537G - PROTECTOR, FRONT SEAT CUSHION EDGE, RH(FOR RH SEAT) | ||||
| 71537-0D110C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71537-0D320C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71537-0D100C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D280C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71537-0D100C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71537-0D320C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71537-0D100C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D100C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538A - PROTECTOR, FRONT SEAT CUSHION EDGE, LH(FOR RH SEAT) | ||||
| 71538-0D220C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71538-0D090C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D310C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 71538-0D100C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71538-0D090C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71537-0D400 |
NSP150,151..(PH,SA)..(G,R) |
1 | ||
| 71538-0D090C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71538-0D090C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71538-0D220C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71537-0D400 |
NSP150..5F..GEN..R;NSP150..LHD..CVT..(GEN,PH);NSP151..(GEN,PH,SA)..(G,R) |
1 | ||
| 71551S - PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71551-0D800 |
NSP151..V..H;NSP151..CVT..AGT..G |
1 | ||
| 71551-0D680 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71551-0D720 |
NSP151..V..C |
1 | ||
| 71551-0D710 |
NSP151..G..C |
1 | ||
| 71551-0D360 |
NSP151..(G,R)..F |
1 | ||
| 71551-0D740 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 71551-0D750 |
NSP151..V..F |
1 | ||
| 71551-0D710 |
NSP151..CVT..R..C |
1 | ||
| 71551-0D880 |
NSP151..(PH,SA)..(G,V) |
1 | ||
| 71551-0D490 |
NSP151..V..C |
1 | ||
| 71551-0D720 |
NSP151..V..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71551-0DA60 |
NSP151..G..C |
1 | ||
| 71551-0DA70 |
NSP151..G..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 71811D - SHIELD, FRONT SEAT CUSHION, RH | ||||
| 71811-0D440C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71811-0D510C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71811-0D450C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71811-0D260C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71811-0D530C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71811-0D530C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71811-0D530C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71811-0D570C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71811-0D590C0 |
NSP152;NSP151..V..A BLACK,TRIM2# |
1 | ||
| 71811-0D260C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71811-0D400C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71811-0D570C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71811-0D510C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71811-0D530C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71811-0D510C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71861 - SHIELD, FRONT SEAT CUSHION, INNER RH | ||||
| 71861-0D330C0 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71861-0D330C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71861-0D330C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71861-0D440C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 71861-0D360C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 71861-0D410C0 |
NSP151..V..H;NSP151..CVT..AGT..G BLACK,TRIM2# |
1 | ||
| 71861-0D210C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71861-0D210C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 71861-0D360C1 |
NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 71861-0D330C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 71861-0D330C1 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM0#,2# |
1 | ||
| 71861-0D440C1 |
NSP150,151..CVT..PH BLACK,TRIM2# |
1 | ||
| 71861-0D360C1 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE),BLACK,TRIM2# |
1 | ||
| 71861-0D290C1 |
NSP151..(G,V)..C BLACK,TRIM2# |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-0DB00C1 |
NSP151..PH BLACK/RED,TRIM2# |
2 | ||
| 71910-0DL20C0 |
NSP150,151..D..H BLACK,TRIM2# |
2 | ||
| 71910-0DK60C0 |
NSP151..PH BLACK,TRIM2# |
2 | ||
| 71910-0DD30C1 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DD10C2 |
NSP151..(G,R)..C BLACK/BLUE 121,TRIM2# |
2 | ||
| 71910-0DN00C0 |
NSP151..V..A BLACK,TRIM2# |
2 | ||
| 71910-0DJ50C1 |
NSP151..V..F BLACK,TRIM2# |
2 | ||
| 71910-0DB30A0 |
NSP151..(G,R)..F IVORY,TRIM0# |
2 | ||
| 71910-0DB30C0 |
NSP151..(G,R)..F BLACK,TRIM2# |
2 | ||
| 71910-0DD10C5 |
NSP151..5F..G;NSP151..CVT..(G,R)..C BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DB60A2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),IVORY,TRIM0# |
2 | ||
| 71910-0DB60C2 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA),BLACK,TRIM2# |
2 | ||
| 71910-0DK50C8 |
NSP151..R..A;NSP150..LHD..CVT;NSP150..5F..GEN..R BLACK/BLUE,TRIM2# |
2 | ||
| 71910-0DD30C2 |
NSP151..V..C BLACK/RED,TRIM2# |
2 | ||
| 71910-0DN00C3 |
NSP152;NSP151..(PH,SA)..(G,V) BLACK/BLUE,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931 - SUPPORT, FRONT SEAT HEADREST | ||||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-4402021 |
NSP151..(G,R,V)..H W(LOCK),BLACK,TRIM2# |
4 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-47010C8 |
NSP151..(G,R,V)..H W/O(LOCK),BLACK,TRIM2# |
4 | ||
| 71930-02370A2 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-0D140C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130A4 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71930-02370C1 |
NSP151..B,F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-02130A2 |
NSP151..(G,R)..F W/O(LOCK),IVORY,TRIM0# |
2 | ||
| 71931-02130C2 |
NSP151..F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C1 |
NSP151..B,F W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370C2 |
NSP151..F W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71931-0D150C0 |
NSP15#..PH,SA,TH;NSP150,151..(GCC,GEN)..G W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71930-02370A4 |
NSP151..(G,R)..F W(LOCK)&W(BUTTON),IVORY,TRIM0# |
2 | ||
| 71930-02370C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W(LOCK)&W(BUTTON),BLACK,TRIM2# |
2 | ||
| 71930-0D140C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-0D150C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 71931-02130C2 |
NSP151..(G,V)..C;NSP151..CVT..R..C W/O(LOCK),BLACK,TRIM2# |
2 | ||
| 72123B - COVER, SEAT TRACK BRACKET, OUTER FRONT | ||||
| 72123-0D030C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72123-0D030C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72125D - COVER, SEAT TRACK, UPPER REAR NO.2 | ||||
| 72265-0D060 |
NSP151..F |
2 | ||
| 72125-0D090 |
NSP151..F |
2 | ||
| 72125-0D120 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72125R - COVER, SEAT TRACK, UPPER REAR NO.1 | ||||
| 72125-06090 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72127A - COVER, SEAT TRACK BRACKET, INNER FRONT RH | ||||
| 72127-0D030C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72127-0D030C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72137 - COVER, SEAT TRACK, OUTER RH | ||||
| 72137-0D200C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 72137-0D140C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72137-0D170C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72137-0D140C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72137-0D270C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72137-0D140C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72137-0D140C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72137-0D170C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72137-0D270C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72147 - BRACKET, FRONT INNER SEAT TRACK, LOWER REAR RH | ||||
| 72147-0D170 |
NSP150,151..H |
1 | ||
| 72147-0D110 |
NSP151..F |
1 | ||
| 72147-0D140 |
NSP151..(G,V)..C;NSP151..CVT..R..C |
1 | ||
| 72147-0D190 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
1 | ||
| 72157 - COVER, SEAT TRACK BRACKET, INNER | ||||
| 72157-0D070C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72157-0D070C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
2 | ||
| 72211 - HANDLE, SEAT TRACK ADJUSTING | ||||
| 72211-0D320 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
2 | ||
| 72265D - COVER, SEAT TRACK UPPER RAIL | ||||
| 72265-06060 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
4 | ||
| 72265D - COVER, SEAT TRACK UPPER RAIL | ||||
| 72265-06060 |
NSP151,152..A;NSP150..LHD..CVT;NSP150..5F..GEN..R |
4 | ||
| 72525A - HANDLE, RECLINING ADJUSTER RELEASE, RH | ||||
| 72525-0D270C0 |
NSP150,151..PH BLACK,TRIM2# |
1 | ||
| 72525-0D330C0 |
NSP151..C BLACK,TRIM2# |
1 | ||
| 72525-02230C0 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72525-02230C0 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72525-0D370C0 |
NSP15#..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72525-02230C1 |
NSP151..V..F BLACK,TRIM2# |
1 | ||
| 72525-0D370C1 |
NSP150..CVT..PH;NSP151,152..PH,SA,TH BLACK,TRIM2# |
1 | ||
| 72525-02230C1 |
NSP151..(G,R)..F BLACK,TRIM0#,2# |
1 | ||
| 72525-0D330C1 |
NSP151..(G,V)..C;NSP151..CVT..R..C BLACK,TRIM2# |
1 | ||
| 72525-0D300C0 |
NSP150,151..H BLACK,TRIM2# |
1 | ||
| 73910A - AIR BAG ASSY, FRONT SEAT, RH | ||||
| 73910-0D100 |
NSP151..G..F G-HI PACKAGE, WITH(*CUSA) |
1 | ||
| 73910-0D100 |
NSP151..(G,V)..C SRS AIR BAG-WITH(*DRS & *PAS & SIDE & *CUSA & KNEE) |
1 | ||
| 73910-0D160 |
NSP151..(PH,SA,VN)..(G,V);NSP15#..CVT..(PH,TH,VN)..R |
1 | ||
| Common parts | ||||
| 90105-T0176 | ||||
| 90148-10007 | ||||
| 90148-T0020 | ||||
| 91553-10820 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 3 OF 3(1908- )
SEAT COVER EDGE WIRE & CLIP
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 71149-30050 | ||||
| 90468-16019 | ||||
| 90468-18008 | ||||
ILLUST NO. 2 OF 3(1908- )
RH SEAT,POWER SEAT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90105-T0176 | ||||
| 90119-10601 | ||||
| 90148-10007 | ||||
| 90167-40044 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
| 8202 | ||||
| 8401 | ||||
ILLUST NO. 2 OF 3(1908- )
RH SEAT,MANUAL SEAT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90105-T0176 | ||||
| 90107-T0003 | ||||
| 90119-10601 | ||||
| 90167-40044 | ||||
| 90168-50078 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 1 OF 2(1908- )
LH SEAT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90105-T0176 | ||||
| 90107-T0003 | ||||
| 90119-10601 | ||||
| 93269-15012 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 3 OF 3(1911- )
CLIP
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 71149-30050 | ||||
| 90468-16019 | ||||
| 90468-18008 | ||||
ILLUST NO. 1 OF 3(1911- )5D
LH SEAT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 72702-52030 | ||||
| 90080-11132 | ||||
| 90167-40044 | ||||
| 90168-50078 | ||||
| 91553-10820 | ||||
| 94170-60600 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
ILLUST NO. 2 OF 3(1911- )5D
RH SEAT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 72702-52030 | ||||
| 90080-11132 | ||||
| 91553-10820 | ||||
| 94170-60600 | ||||
| 94185-60600 | ||||
| Linked diagrams | ||||
| 7104 | ||||
Part Price Details
Loading price information...
Part Number:
Price:
