RY30L-JD (1979)
Toyota Toyoace
(7903- )ST
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04906 - CUP KIT, REAR WHEEL CYLINDER | ||||
| 04906-36040 |
JY30,LY20,3#,RY20,3#..ST ID=28.5 |
1 | ||
| 47043 - PLATE SUB-ASSY, BRAKE BACKING, REAR RH | ||||
| 47043-25060 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU |
1 | ||
| 47043C - BOLT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING) | ||||
| 42184-35010 |
LY20,3#,RY20,3#..125,15T |
12 | ||
| 42184-35011 |
LY31,RY20,30..ST..CBU *10-1.25PX23-13 |
12 | ||
| 47043F - NUT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING) | ||||
| 94110-71000 |
JY30,LY20,3#,RY20,3# |
12 | ||
| 94110-71000 |
LY31,RY20,30 |
12 | ||
| 47044 - PLATE SUB-ASSY, BRAKE BACKING, REAR LH | ||||
| 47044-25030 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU |
1 | ||
| 47430C - SPRING(FOR REAR BRAKE SHOE HOLD DOWN) | ||||
| 90501-20756 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU |
4 | ||
| 47430D - SPRING, TENSION(FOR REAR BRAKE SHOE RETURN) | ||||
| 90506-26009 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU |
2 | ||
| 47430E - SPRING, TENSION(FOR REAR BRAKE SHOE RETURN) | ||||
| 90506-26009 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU |
2 | ||
| 47430L - SHOE KIT, REAR BRAKE | ||||
| 04494-25020 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU |
1 | ||
| 47457 - PIN, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47447-20010 |
LY20,3#,RY20,3#..125,15T |
4 | ||
| 47459 - CUP, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47449-30020 |
JY30,LY20,3#,RY20,3# |
8 | ||
| 47459 - CUP, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47449-30020 |
JY30,LY20,3#,RY20,3# |
8 | ||
| 47473 - NUT, REAR WHEEL CYLINDER ADJUSTING, RH(FOR REAR BRAKE) | ||||
| 47551-36071 |
JY30,LY20,3#,RY20,3#..ST..CBU |
2 | ||
| 47473 - NUT, REAR WHEEL CYLINDER ADJUSTING, RH(FOR REAR BRAKE) | ||||
| 47551-36071 |
JY30,LY20,3#,RY20,3#..ST..CBU |
2 | ||
| 47474 - NUT, REAR WHEEL CYLINDER ADJUSTING, LH(FOR REAR BRAKE) | ||||
| 47552-36071 |
JY30,LY20,3#,RY20,3#..ST..CBU |
2 | ||
| 47474 - NUT, REAR WHEEL CYLINDER ADJUSTING, LH(FOR REAR BRAKE) | ||||
| 47552-36071 |
JY30,LY20,3#,RY20,3#..ST..CBU |
2 | ||
| 47475 - BOLT, REAR WHEEL CYLINDER ADJUSTING, RH (FOR REAR BRAKE | ||||
| 47553-36021 |
JY30,LY20,3#,RY20,3#..ST..CBU |
2 | ||
| 47475 - BOLT, REAR WHEEL CYLINDER ADJUSTING, RH (FOR REAR BRAKE | ||||
| 47553-36021 |
JY30,LY20,3#,RY20,3#..ST..CBU |
2 | ||
| 47476 - BOLT, REAR WHEEL CYLINDER ADJUSTING, LH(FOR REAR BRAKE) | ||||
| 47554-36021 |
JY30,LY20,3#,RY20,3#..ST..CBU |
2 | ||
| 47476 - BOLT, REAR WHEEL CYLINDER ADJUSTING, LH(FOR REAR BRAKE) | ||||
| 47554-36021 |
JY30,LY20,3#,RY20,3#..ST..CBU |
2 | ||
| 47496 - PLUG, HOLE(FOR REAR BRAKE) | ||||
| 47491-36010 |
JY30,LY20,3#,RY20,3# |
4 | ||
| 47536 - PISTON, WHEEL BRAKE CYLINDER(FOR REAR BRAKE) | ||||
| 47531-35090 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU |
4 | ||
| 47536 - PISTON, WHEEL BRAKE CYLINDER(FOR REAR BRAKE) | ||||
| 47531-35090 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU |
4 | ||
| 47537 - SEAT, WHEEL CYLINDER PISTON SPRING(FOR REAR BRAKE) | ||||
| 47533-30011 |
JY30,LY20,3#,RY20,3#..ST..CBU |
8 | ||
| 47537 - SEAT, WHEEL CYLINDER PISTON SPRING(FOR REAR BRAKE) | ||||
| 47533-30011 |
JY30,LY20,3#,RY20,3#..ST..CBU |
8 | ||
| 47537 - SEAT, WHEEL CYLINDER PISTON SPRING(FOR REAR BRAKE) | ||||
| 47533-30011 |
JY30,LY20,3#,RY20,3#..ST..CBU |
8 | ||
| 47537 - SEAT, WHEEL CYLINDER PISTON SPRING(FOR REAR BRAKE) | ||||
| 47533-30011 |
JY30,LY20,3#,RY20,3#..ST..CBU |
8 | ||
| 47547R - PLUG, BLEEDER(FOR DRUM BRAKE, REAR) | ||||
| 47547-12010 |
JY30,LY20,3#,RY20,3# |
2 | ||
| 47548R - CAP, BLEEDER PLUG(FOR DRUM BRAKE, REAR) | ||||
| 31478-30010 |
JY30,LY20,3#,RY20,3# |
2 | ||
| 47550 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR RH, FRONT OR UPPER) | ||||
| 47550-29215 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU ID=28.5 |
1 | ||
| 47550C - SPRING, COMPRESSION(FOR REAR WHEEL BRAKE CYLINDER) | ||||
| 90501-08122 |
JY30,LY20,3#,RY20,3#..ST..CBU |
4 | ||
| 47550C - SPRING, COMPRESSION(FOR REAR WHEEL BRAKE CYLINDER) | ||||
| 90501-08122 |
JY30,LY20,3#,RY20,3#..ST..CBU |
4 | ||
| 47556 - SPRING, ADJUSTER LOCK(FOR REAR BRAKE) | ||||
| 47555-36020 |
JY30,LY20,3#,RY20,3#..ST..CBU |
4 | ||
| 47556 - SPRING, ADJUSTER LOCK(FOR REAR BRAKE) | ||||
| 47555-36020 |
JY30,LY20,3#,RY20,3#..ST..CBU |
4 | ||
| 47560 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR RH, REAR OR LOWER) | ||||
| 47560-29075 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU ID=28.5 |
1 | ||
| 47570 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR LH, FRONT OR UPPER) | ||||
| 47570-29075 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU ID=28.5 |
1 | ||
| 47580 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR LH, REAR OR LOWER) | ||||
| 47580-29075 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU ID=28.5 |
1 | ||
| 47653 - LINING, REAR BRAKE SHOE(FOR FRONT OR UPPER) | ||||
| 47651-25011 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU |
2 | ||
| 47654 - LINING, REAR BRAKE SHOE(FOR REAR OR LOWER) | ||||
| 47651-25011 |
LY20,3#,RY20,3#..ST..(125,15T)..CBU |
2 | ||
| Common parts | ||||
| 90101-08081 | ||||
| 90149-50001 | ||||
| 90201-08002 | ||||
| 90201-10287 | ||||
| 91651-60614 | ||||
| 94511-00500 | ||||
