KP62RV-PXKRS (1978)
Toyota Starlet
(7802-8005)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 82711-10050 | ||||
| 82711-12200 | ||||
| 82711-22120 | ||||
| 88888-40040 | ||||
| 90461-06075 | ||||
| 90461-06083 | ||||
| 90461-06423 | ||||
| 90461-07021 | ||||
| 90461-08187 | ||||
| 90461-08251 | ||||
| 90463-08088 | ||||
| 90463-08179 | ||||
| 90463-10010 | ||||
| 90463-10050 | ||||
| 90463-10335 | ||||
| 90463-10336 | ||||
| 90463-10337 | ||||
| 90464-00044 | ||||
| 90464-00052 | ||||
| 90464-00153 | ||||
| 90464-00156 | ||||
| 90467-20003 | ||||
| 90480-01060 | ||||
| 90480-01061 | ||||
| 90480-01339 | ||||
| 90480-06750 | ||||
| 90480-13334 | ||||
| 90480-15029 | ||||
| 90480-25008 | ||||
| 90480-25385 | ||||
| 90480-28002 | ||||
| 90480-29471 | ||||
(7802-8005)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 82001 - CABLE, BOND, NO.1 | ||||
| 90980-07112 |
KP6# L=310 |
1 | ||
| 90980-07201 |
KP6# L=380 |
1 | ||
| 90980-07137 |
KP6# L=220 |
1 | ||
| 90980-07138 |
KP6# L=380 |
1 | ||
| 82001 - CABLE, BOND, NO.1 | ||||
| 90980-07112 |
KP6# L=310 |
1 | ||
| 90980-07201 |
KP6# L=380 |
1 | ||
| 90980-07137 |
KP6# L=220 |
1 | ||
| 90980-07138 |
KP6# L=380 |
1 | ||
| 82001 - CABLE, BOND, NO.1 | ||||
| 90980-07112 |
KP6# L=310 |
1 | ||
| 90980-07201 |
KP6# L=380 |
1 | ||
| 90980-07137 |
KP6# L=220 |
1 | ||
| 90980-07138 |
KP6# L=380 |
1 | ||
| 82028 - WIRING SUB-ASSY, COWL | ||||
| 82028-10030 |
KP6#..RHD |
1 | ||
| 82201 - WIRING SUB-ASSY, INSTRUMENT PANEL | ||||
| 82201-10070 |
KP6#..4D W/*DEF |
1 | ||
| 82201-10071 |
KP6# |
1 | ||
| 82201-10090 |
KP6# W/*RW,W/*RW & *DEF |
1 | ||
| 82201-10070 |
KP60;KP62..RHD;KP62..LHD..5F;KP62..LHD..4F..GEN;KP62..LHD..4F..EUG |
1 | ||
| 82210 - HARNESS ASSY, WIRING COWL TO HEADLAMP, NO.1 | ||||
| 82210-1C110 |
KP62..RHD..GEN W/COOLER |
1 | ||
| 82210-10880 |
KP6#..RHD |
1 | ||
| 82210-1C140 |
KP62..RHD..GEN W/COOLER,*IW,*RW & *DEF |
1 | ||
| 82210-1C040 |
KP6#..RHD W/*IW & *DEF,W/*IW & *RW;W/*RW,W/*RW & *DEF |
1 | ||
| 82210-1C141 |
KP62..RHD..GEN W/COOLER |
1 | ||
| 82210-1C041 |
KP6#..RHD W/*RW OR *IW,W/*RW & *IW |
1 | ||
| 82210-10881 |
KP6#..RHD |
1 | ||
| 82210-10882 |
KP6#..RHD |
1 | ||
| 82210-1C142 |
KP62..RHD..GEN W/COOLER |
1 | ||
| 82210-1C143 |
KP62..RHD W/COOLER |
1 | ||
| 82210-10883 |
KP60,62..RHD..GEN |
1 | ||
| 82210-1C042 |
KP6#..RHD W/*RW OR *IW,W/*RW & *IW |
1 | ||
| 82210-1C043 |
KP60,62..RHD..GEN W/*RW OR *IW,W/*RW & *IW |
1 | ||
| 82210C - FUSIBLE LINK | ||||
| 90982-08072 |
KP6# |
1 | ||
| 82210D - FUSIBLE LINK | ||||
| 90982-08131 |
KP6# L=110,BATTERY |
1 | ||
| 90982-08180 |
KP6# L=110,BATTERY |
1 | ||
| 90982-08091 |
KP6# |
1 | ||
| 82310 - WIRING ASSY, TO BACK UP LAMP SWITCH | ||||
| 82310-10162 |
KP6#..4F |
1 | ||
| 82371 - WIRE, WIPER RELAY | ||||
| 82241-22060 |
KP6# |
1 | ||
| 82817 - PROTECTOR, WIRING HARNESS, NO.1 | ||||
| 82817-10080 |
KP6# L=35 |
2 | ||
| 82817-10090 |
KP6# L=80 |
2 | ||
| 88647 - WIRE SUB-ASSY, COOLER | ||||
| 88648-10040 |
KP62..RHD..GEN |
1 | ||
| Common parts | ||||
| 90119-08063 | ||||
| 91611-40614 | ||||
| 91651-40614 | ||||
| 91651-40816 | ||||
(7810-8005)4D
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 82046 - WIRE SUB-ASSY, REAR WINDOW DEFOGGER EARTH | ||||
| 82046-96440 |
KP6#..4D |
1 | ||
| 82046-10040 |
KP6# |
1 | ||
| 82350 - WIRING ASSY, COURTESY LAMP SWITCH (FOR FR OR RR DOOR) | ||||
| 84203-10020 |
KP6#..3D,4D |
1 | ||
| 84203-10021 |
KP6#..3D,4D |
1 | ||
| 82351-10010 |
KP6#..3D,4D |
1 | ||
| 82410 - HARNESS ASSY, WIRING TO REAR LAMP | ||||
| 82410-96442 |
KP6#..4D |
1 | ||
| 82410-96448 |
KP6#..4D |
1 | ||
| 82410-96449 |
KP6#..4D W/*RW |
1 | ||
| 82410-96443 |
KP6#..4D W/*RW & *DEF |
1 | ||
| 82410-96452 |
KP6#..4D |
1 | ||
| 82420 - WIRING ASSY, CHASSIS | ||||
| 82420-96442 |
KP6#..4D W/*RW |
1 | ||
| 82420-96441 |
KP6#..4D |
1 | ||
| 82420-96446 |
KP6#..4D W/*DEF & *RW |
1 | ||
| 82420-96449 |
KP6#..4D |
1 | ||
| 82420-96445 |
KP6#..4D W/*DEF |
1 | ||
| 82420-96444 |
KP6#..4D |
1 | ||
| 82420-96452 |
KP6#..4D EXCL/*WEG |
1 | ||
| 82420-96451 |
KP6#..4D W/*DEF & *RW |
1 | ||
| 82420-96450 |
KP6#..4D W/*DEF |
1 | ||
| 82470 - WIRE ASSY, LICENSE LAMP FEED | ||||
| 82470-96443 |
KP6#..4D |
1 | ||
| 82470-96442 |
KP6#..4D W/*RW & *DEF |
1 | ||
| 82470-96441 |
KP6#..4D W/*DEF |
1 | ||
| 82470-96440 |
KP6#..4D |
1 | ||
| 82470-96445 |
KP6#..4D W/*RW & *DEF |
1 | ||
| 82510 - WIRING ASSY, ROOF | ||||
| 82510-10010 |
KP6#..RHD |
1 | ||
| Common parts | ||||
| 82817-10080 | ||||
| 90119-06005 | ||||
(8005- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 82711-10050 | ||||
| 82711-12480 | ||||
| 82817-10080 | ||||
| 82817-10090 | ||||
| 90461-06075 | ||||
| 90461-06083 | ||||
| 90461-07021 | ||||
| 90461-08025 | ||||
| 90461-08187 | ||||
| 90463-10024 | ||||
| 90463-10050 | ||||
| 90463-10335 | ||||
| 90463-10336 | ||||
| 90463-10337 | ||||
| 90464-00047 | ||||
| 90464-00052 | ||||
| 90467-20003 | ||||
| 90480-01060 | ||||
| 90480-01061 | ||||
| 90480-01118 | ||||
| 90480-01119 | ||||
| 90480-01339 | ||||
| 90480-13334 | ||||
| 90480-15029 | ||||
| 90480-15083 | ||||
(8005- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 82711-10170 | ||||
| 82711-12200 | ||||
| 82817-22170 | ||||
| 90462-06008 | ||||
| 90463-10012 | ||||
| 90464-00044 | ||||
| 90464-00056 | ||||
| 90480-06750 | ||||
| 90480-19027 | ||||
| 90480-25385 | ||||
| 90480-30004 | ||||
| 90950-01056 | ||||
(8005- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 82001 - CABLE, BOND, NO.1 | ||||
| 90980-07112 |
KP6# L=310 |
1 | ||
| 90980-07201 |
KP6# L=380 |
1 | ||
| 90980-07137 |
KP6# L=220 |
1 | ||
| 90980-07138 |
KP6# L=380 |
1 | ||
| 82001 - CABLE, BOND, NO.1 | ||||
| 90980-07112 |
KP6# L=310 |
1 | ||
| 90980-07201 |
KP6# L=380 |
1 | ||
| 90980-07137 |
KP6# L=220 |
1 | ||
| 90980-07138 |
KP6# L=380 |
1 | ||
| 82201 - WIRING SUB-ASSY, INSTRUMENT PANEL | ||||
| 82201-10070 |
KP6#..4D W/*DEF |
1 | ||
| 82201-10071 |
KP6# |
1 | ||
| 82201-10090 |
KP6# W/*RW,W/*RW & *DEF |
1 | ||
| 82201-10070 |
KP60;KP62..RHD;KP62..LHD..5F;KP62..LHD..4F..GEN;KP62..LHD..4F..EUG |
1 | ||
| 82210 - HARNESS ASSY, WIRING COWL TO HEADLAMP, NO.1 | ||||
| 82210-1C110 |
KP62..RHD..GEN W/COOLER |
1 | ||
| 82210-10880 |
KP6#..RHD |
1 | ||
| 82210-1C140 |
KP62..RHD..GEN W/COOLER,*IW,*RW & *DEF |
1 | ||
| 82210-1C040 |
KP6#..RHD W/*IW & *DEF,W/*IW & *RW;W/*RW,W/*RW & *DEF |
1 | ||
| 82210-1C141 |
KP62..RHD..GEN W/COOLER |
1 | ||
| 82210-1C041 |
KP6#..RHD W/*RW OR *IW,W/*RW & *IW |
1 | ||
| 82210-10881 |
KP6#..RHD |
1 | ||
| 82210-10882 |
KP6#..RHD |
1 | ||
| 82210-1C142 |
KP62..RHD..GEN W/COOLER |
1 | ||
| 82210-1C143 |
KP62..RHD W/COOLER |
1 | ||
| 82210-10883 |
KP60,62..RHD..GEN |
1 | ||
| 82210-1C042 |
KP6#..RHD W/*RW OR *IW,W/*RW & *IW |
1 | ||
| 82210-1C043 |
KP60,62..RHD..GEN W/*RW OR *IW,W/*RW & *IW |
1 | ||
| 82210C - FUSIBLE LINK | ||||
| 90982-08072 |
KP6# |
1 | ||
| 82210D - FUSIBLE LINK | ||||
| 90982-08131 |
KP6# L=110,BATTERY |
1 | ||
| 90982-08180 |
KP6# L=110,BATTERY |
1 | ||
| 90982-08091 |
KP6# |
1 | ||
| 82210D - FUSIBLE LINK | ||||
| 90982-08131 |
KP6# L=110,BATTERY |
1 | ||
| 90982-08180 |
KP6# L=110,BATTERY |
1 | ||
| 90982-08091 |
KP6# |
1 | ||
| 82310 - WIRING ASSY, TO BACK UP LAMP SWITCH | ||||
| 82310-10162 |
KP6#..4F |
1 | ||
| 82371 - WIRE, WIPER RELAY | ||||
| 82241-22060 |
KP6# |
1 | ||
| 88647 - WIRE SUB-ASSY, COOLER | ||||
| 88648-10040 |
KP62..RHD..GEN |
1 | ||
| Common parts | ||||
| 90119-06005 | ||||
| 90119-08157 | ||||
| 90159-50105 | ||||
| 91651-40614 | ||||
(8005- )4D
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 82046 - WIRE SUB-ASSY, REAR WINDOW DEFOGGER EARTH | ||||
| 82046-96440 |
KP6#..4D |
1 | ||
| 82046-10040 |
KP6# |
1 | ||
| 82350 - WIRING ASSY, COURTESY LAMP SWITCH (FOR FR OR RR DOOR) | ||||
| 84203-10020 |
KP6#..3D,4D |
1 | ||
| 84203-10021 |
KP6#..3D,4D |
1 | ||
| 82351-10010 |
KP6#..3D,4D |
1 | ||
| 82410 - HARNESS ASSY, WIRING TO REAR LAMP | ||||
| 82410-96442 |
KP6#..4D |
1 | ||
| 82410-96448 |
KP6#..4D |
1 | ||
| 82410-96449 |
KP6#..4D W/*RW |
1 | ||
| 82410-96443 |
KP6#..4D W/*RW & *DEF |
1 | ||
| 82410-96452 |
KP6#..4D |
1 | ||
| 82420 - WIRING ASSY, CHASSIS | ||||
| 82420-96442 |
KP6#..4D W/*RW |
1 | ||
| 82420-96441 |
KP6#..4D |
1 | ||
| 82420-96446 |
KP6#..4D W/*DEF & *RW |
1 | ||
| 82420-96449 |
KP6#..4D |
1 | ||
| 82420-96445 |
KP6#..4D W/*DEF |
1 | ||
| 82420-96444 |
KP6#..4D |
1 | ||
| 82420-96452 |
KP6#..4D EXCL/*WEG |
1 | ||
| 82420-96451 |
KP6#..4D W/*DEF & *RW |
1 | ||
| 82420-96450 |
KP6#..4D W/*DEF |
1 | ||
| 82470 - WIRE ASSY, LICENSE LAMP FEED | ||||
| 82470-96443 |
KP6#..4D |
1 | ||
| 82470-96442 |
KP6#..4D W/*RW & *DEF |
1 | ||
| 82470-96441 |
KP6#..4D W/*DEF |
1 | ||
| 82470-96440 |
KP6#..4D |
1 | ||
| 82470-96445 |
KP6#..4D W/*RW & *DEF |
1 | ||
| 82510 - WIRING ASSY, ROOF | ||||
| 82510-10010 |
KP6#..RHD |
1 | ||
| Common parts | ||||
| 90119-06005 | ||||
| 90119-06067 | ||||
(8108- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 82981-22010 | ||||
| 82982-10010 | ||||
| 82982-12020 | ||||
| 82984-22010 | ||||
| 82985-16010 | ||||
