ACA21L-AWMNK (2000)
Toyota Rav4
(0005-0511)ACA2#..MTM
E352F,E359F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 31105G - BOLT(FOR TRANSAXLE CASE & ENGINE SETTING) | ||||
| 91512-61065 |
ACA2#..MTM *10-1.25PX65-30 |
1 | ||
| 91512-61060 |
ACA2#..MTM *10-1.25PX60-30 |
2 | ||
| 90119-12252 |
ACA2#..MTM *12-1.25PX60-30 |
2 | ||
| 91512-61065 |
ACA2#..MTM *10-1.25PX65-30 |
1 | ||
| 90105-12147 |
ACA2#..MTM *12-1.25PX74.5-25 |
1 | ||
| 90119-12252 |
ACA2#..MTM *12-1.25PX60-30 |
2 | ||
| 90105-12147 |
ACA2#..MTM *12-1.25PX74.5-25 |
1 | ||
| 91512-61060 |
ACA2#..MTM *10-1.25PX60-30 |
2 | ||
| 33030B - BOLT(FOR TRANSAXLE CASE & TRANSMISSION CASE SETTING) | ||||
| 90105-08126 |
ACA20,21,CLA2#..MTM *8-1.25PX45-27.5 |
17 | ||
| 90105-08126 |
ACA2#,CLA2#..MTM *8-1.25PX45-27.5 |
17 | ||
| 33101A - PLUG(FOR MANUAL TRANSMISSION FILLER) | ||||
| 90341-18033 |
ACA2#,CLA2#..MTM |
1 | ||
| 90341-18033 |
ACA20,21,CLA2#..MTM |
1 | ||
| 33101C - GASKET(FOR MANUAL TRANSMISSION FILLER PLUG) | ||||
| 90430-18008 |
ACA2#,CLA2#,ZCA2#..MTM |
1 | ||
| 90430-18008 |
ACA20,21,CLA2#..MTM |
1 | ||
| 33101U - PLUG, BREATHER(FOR MANUAL TRANSMISSION) | ||||
| 90930-03148 |
ACA20,21,CLA2#..MTM |
1 | ||
| 90930-03148 |
ACA2#,CLA2#..MTM |
1 | ||
| 33101V - GASKET(FOR MANUAL TRANSMISSION BREATHER PLUG) | ||||
| 90430-18008 |
ACA2#,CLA2#..MTM |
1 | ||
| 90430-18008 |
ACA20,21,CLA2#..MTM |
1 | ||
| 33102E - COVER SUB-ASSY, MANUAL TRANSMISSION CASE | ||||
| 33102-12041 |
ACA2#,CLA2#..MTM |
1 | ||
| 33102-12042 |
ACA2#,CLA2#..MTM |
1 | ||
| 33102-12042 |
ACA20,21,CLA2#..MTM |
1 | ||
| 33102-12043 |
ACA20,21,CLA2#..MTM |
1 | ||
| 33104 - PLUG SUB-ASSY, DRAIN(MTM) | ||||
| 90341-18006 |
ACA2#,CLA2#,ZCA2#..MTM |
1 | ||
| 90341-18006 |
ACA20,21,CLA2#..MTM |
1 | ||
| 33104A - GASKET, DRAIN PLUG(MTM) | ||||
| 90430-18008 |
ACA2#,CLA2#,ZCA2#..MTM |
1 | ||
| 90430-18008 |
ACA20,21,CLA2#..MTM |
1 | ||
| 33111 - CASE, MANUAL TRANSMISSION | ||||
| 33101-12174 |
ACA2#..MTM |
1 | ||
| 33101-12173 |
ACA2#..MTM |
1 | ||
| 33101-12172 |
ACA2#..MTM |
1 | ||
| 33101-42020 |
ACA20,21..MTM |
1 | ||
| 33101-42020 |
ACA2#..MTM |
1 | ||
| 33111C - PLUG(FOR TRANSMISSION CASE) | ||||
| 90340-10005 |
ACA2#..MTM |
1 | ||
| 90340-10005 |
ACA2#..MTM |
1 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12005 |
ACA2#,CLA2#..MTM L=24,OD=12 |
2 | ||
| 90250-08054 |
ACA2#,CLA2#,ZCA2#..MTM L=23,OD=8 |
4 | ||
| 90250-08054 |
ACA20,21,CLA2#..MTM L=23,OD=8 |
4 | ||
| 90250-12005 |
ACA20,21,CLA2#..MTM L=24,OD=12 |
4 | ||
| 33117 - PROTECTOR, MANUAL TRANSMISSION CASE | ||||
| 33117-20020 |
ACA2#,CLA2#..MTM |
1 | ||
| 33117-20020 |
ACA2#,CLA2#..MTM |
1 | ||
| 33117A - BOLT(FOR MANUAL TRANSMISSION CASE PROTECTOR) | ||||
| 91641-H0820 |
ACA2#,CLA2#..MTM |
2 | ||
| 90105-08040 |
ACA2#,CLA2#..MTM |
2 | ||
| 33121H - BOLT, W/WASHER(FOR TRANSMISSION CASE COVER) | ||||
| 90119-08630 |
ACA2#,CLA2#..MTM |
10 | ||
| 90119-08630 |
ACA20,21,CLA2#..MTM |
10 | ||
| 33124C - PIPE, OIL RECEIVER, NO.1(MTM) | ||||
| 33124-28050 |
ACA2#,CLA2#..MTM |
1 | ||
| 33124-28050 |
ACA20,21,CLA2#..MTM |
2 | ||
| 33124D - PIPE, OIL RECEIVER, NO.2(MTM) | ||||
| 33124-28060 |
ACA20,21,CLA2#..MTM |
2 | ||
| 33124-28060 |
ACA2#,CLA2#..MTM |
1 | ||
| 33124H - BOLT(FOR OIL RECEIVER PIPE) | ||||
| 90119-08830 |
ACA20,21,CLA2#..MTM |
2 | ||
| 90119-08830 |
ACA2#,CLA2#..MTM |
2 | ||
| Linked diagrams | ||||
| 4301 | ||||
| 4302 | ||||
| 8401 | ||||
