ZVW50L-AHXEBV (2018)

Toyota Prius

Production Dec 2018 - Jun 2020
Engine 2ZRFXE
Transmission
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 1 OF 2(1511- )

Click highlighted areas on diagram

ENGINE ROOM & EXTERIOR

diagram 11285A 11293D 16793B 16793B 42661 47288 47997C 74511F 74559B 74561A 74596A 88723E G9275
Part # Description Qty Price
11285A - LABEL, COOLANT SYSTEM NOTICE
11285-33030

2ZRFXE..ZVW50

 1
11293D - LABEL, ENGINE CAUTION
11293-37060

2ZRFXE..ZVW50..GCC

 1
16793B - LABEL, COOLING FAN INFORMATION
16793-36030

2ZRFXE..ZVW50..GCC

 1
16793B - LABEL, COOLING FAN INFORMATION
16793-36030

2ZRFXE..ZVW50..GCC

 1
42661 - LABEL, TIRE PRESSURE INFORMATION
42661-47610

ZVW50..GCC

 1
42661-47850

ZVW50..GCC

FRONT SEAT-DRIVER(8-WAY)

 1
47288 - LABEL, BRAKE FLUID NOTICE
47288-71010

ZVW50..GCC

 1
47997C - LABEL, ACCUMULATOR CAUTION, NO.1
47997-76010

ZVW50..GCC

 1
74511F - LABEL, NAME (IDENTIFICATION LASER LABEL)
74511-2B300

ZVW50..GCC

*111,JORDAN SPEC

 1
74514-52010

ZVW50..GCC

*111

 1
74559B - LABEL, FUEL INFORMATION
74559-20140

ZVW50

 1
74596A - LABEL, SIDE AIR BAG CAUTION
74596-74020

ZVW50..GCC

 2
88723E - LABEL, COOLER SERVICE CAUTION
88723-47150

ZVW50..GCC

 1
G9275 - LABEL, BATTERY CAUTION, NO.1
G9275-47200

ZVW50..GCC

 1
G9275-47110

ZVW50..GCC

JORDAN SPEC

 1

ILLUST NO. 2 OF 2(1511- )

Click highlighted areas on diagram

INTERIOR

diagram 42668 69339C 74541E 861C8
Part # Description Qty Price
42668 - LABEL, COMPACT SPARE TIRE CAUTION
42668-78020

ZVW50..GCC

FRONT SEAT-DRIVER(8-WAY)

 1
69339C - LABEL, CHILD PROTECTOR INFORMATION
69339-33040

ZVW50..GCC

 2
74541E - PLATE, COMPACT SPARE TIRE CAUTION
42668-42010

ZVW50..GCC

FRONT SEAT-DRIVER(8-WAY)

 1
861C8 - LABEL, MOBILE WIRELESS CHARGER CAUTION
861C8-47030

ZVW50

WIRELESS CHARGER-WITH

 1
