ACR50R-GRXDKQ (2016)

Toyota Previa/Tarago

Production May 2016 - Oct 2019
Engine 2AZFE
Transmission CVT
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 1 OF 5(1605- )RHD

Click highlighted areas on diagram

FRONT HEATER CONTROL

diagram 33554H 5551 5551 5551 5551 5551 55900A 55902C 8202 8401 9046705171
Part # Description Qty Price
33554H - COVER, SHIFT LOCK RELEASE BUTTON
33554-28090

ACR50,GSR50..RHD..(DLX,GL)

 1
55900A - CONTROL & ACCESSORY ASSY, HEATER
55900-28A60

ACR50,GSR50..ARL

COLD SPEC(BATTERY SIZE:80D26L)

 1
55900-28A50

GSR50..ARL;ACR50..RHD..DLX

 1
55900-28F50C0

ACR50..ARL

BLACK,TRIM2#

 1
55900-28F60C0

ACR50..ARL

COLD AREA SPEC,BLACK,TRIM2#

 1
55902C - PANEL SUB-ASSY, AIR CONDITIONER
55902-28460

GSR50..ARL;ACR50..RHD..DLX

 1
55902-28570

ACR50..ARL

 1
55902-28580

ACR50..ARL

COLD AREA SPEC

 1
Common parts
90467-05171
Linked diagrams
5551
8202
8401
