ACR50R-GFPGK (2012)
Toyota Previa/Tarago
(0601- )DLX,GL
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52155A - SUPPORT, REAR BUMPER SIDE, RH | ||||
| 52155-28080 |
ACR50,GSR50 |
1 | ||
| 52155-28080 |
ACR50..CVT;GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..4FC..(GCC,GEN) |
1 | ||
| 52155B - SUPPORT, REAR BUMPER SIDE, NO.2 RH | ||||
| 52155-28090 |
ACR50,GSR50 |
1 | ||
| 52155-28090 |
ACR50..CVT;GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..4FC..(GCC,GEN) |
1 | ||
| 52156A - SUPPORT, REAR BUMPER SIDE, LH | ||||
| 52156-28050 |
ACR50,GSR50 |
1 | ||
| 52156-28050 |
ACR50..CVT;GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..4FC..(GCC,GEN) |
1 | ||
| 52156B - SUPPORT, REAR BUMPER SIDE, NO.2 LH | ||||
| 52156-28060 |
ACR50,GSR50 |
1 | ||
| 52156-28060 |
ACR50..CVT;GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..4FC..(GCC,GEN) |
1 | ||
| 52159 - COVER, REAR BUMPER | ||||
| 52159-28915 |
ACR50,GSR50..RHD;ACR50,GSR50..GCC;ACR50..LHD..DLX..GEN PAINT REQ.,CLEARANCE SONAR-WITH(CLEARANCE & BACK SONAR) |
1 | ||
| 52159-28914 |
ACR50,GSR50..RHD;ACR50,GSR50..GCC;ACR50..LHD..DLX..GEN PAINT REQ. |
1 | ||
| 52159-28952 |
GSR50..GCC;GSR50..RHD..GL;ACR50..4FC..(GCC,GEN);ACR50..RHD..CVT..(DLX,GL) PAINT REQ.,CLEARANCE SONAR-WITH |
1 | ||
| 52159-28914 |
GSR50..RHD;GSR50..GCC;ACR50..4FC..(GCC,GEN);ACR50..RHD..CVT..(DLX,GL) PAINT REQ. |
1 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-16010 |
ACR50,GSR50 |
3 | ||
| 52161-16010 |
ACR50..CVT;GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..4FC..(GCC,GEN) |
3 | ||
| 52162D - PIECE, REAR BUMPER | ||||
| 52161-16010 |
ACR50,GSR50 |
4 | ||
| 52161-16010 |
ACR50..CVT;GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..4FC..(GCC,GEN) |
4 | ||
| 52162D - PIECE, REAR BUMPER | ||||
| 52161-16010 |
ACR50,GSR50 |
4 | ||
| 52161-16010 |
ACR50..CVT;GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..4FC..(GCC,GEN) |
4 | ||
| 52162D - PIECE, REAR BUMPER | ||||
| 52161-16010 |
ACR50,GSR50 |
4 | ||
| 52161-16010 |
ACR50..CVT;GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..4FC..(GCC,GEN) |
4 | ||
| 52162D - PIECE, REAR BUMPER | ||||
| 52161-16010 |
ACR50,GSR50 |
4 | ||
| 52161-16010 |
ACR50..CVT;GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..4FC..(GCC,GEN) |
4 | ||
| 52163A - PLATE, REAR BUMPER, RH | ||||
| 52163-28030B0 |
ACR50,GSR50 SILVER ME.,1F7 |
1 | ||
| 52163-28030A1 |
ACR50,GSR50 WHITE PEARL CS.,070 |
1 | ||
| 52163-28030A0 |
ACR50,GSR50 SUPER WHITE 2,040 |
1 | ||
| 52163-28030C0 |
ACR50,GSR50 BLACK,202 |
1 | ||
| 52163-28030B1 |
ACR50,GSR50 MEDIUM SILVER ME.,1F8 |
1 | ||
| 52163-28030J1 |
ACR50,GSR50 LT.BLUE M.M.,8S7 |
1 | ||
| 52163-28030F0 |
ACR50,GSR50 SILKY GOLD M.M.,5A4 |
1 | ||
| 52163-28030J0 |
ACR50,GSR50 DK.BLUE MC.,8S6 |
1 | ||
| 52163-28030D0 |
ACR50,GSR50 DK. RED M.M.,3Q3 |
1 | ||
| 52163-28030A0 |
GSR50..RHD;GSR50..GCC;ACR50..4FC..(GCC,GEN);ACR50..RHD..CVT..(DLX,GL) SUPER WHITE 2,040 |
1 | ||
| 52163-28030C0 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) BLACK,202 |
1 | ||
| 52163-28030E0 |
ACR50,GSR50..DLX,GL DARK SHERRY M.M.,4W4 |
1 | ||
| 52163-28030F0 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) SILKY GOLD M.M.,5A4 |
1 | ||
| 52163-28030B3 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) ICE TITANIUM M.M.,1H4 |
1 | ||
| 52163-28030A1 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) WHITE PEARL CS.,070 |
1 | ||
| 52163-28030D1 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) DEEP RED M.M.,3R9 |
1 | ||
| 52163-28030B0 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) SILVER ME.,1F7 |
1 | ||
| 52164A - PLATE, REAR BUMPER, LH | ||||
| 52164-28020A0 |
ACR50,GSR50 SUPER WHITE 2,040 |
1 | ||
| 52164-28020F0 |
ACR50,GSR50 SILKY GOLD M.M.,5A4 |
1 | ||
| 52164-28020J0 |
ACR50,GSR50 DK.BLUE MC.,8S6 |
1 | ||
| 52164-28020B1 |
ACR50,GSR50 MEDIUM SILVER ME.,1F8 |
1 | ||
| 52164-28020B0 |
ACR50,GSR50 SILVER ME.,1F7 |
1 | ||
| 52164-28020C0 |
ACR50,GSR50 BLACK,202 |
1 | ||
| 52164-28020J1 |
ACR50,GSR50 LT.BLUE M.M.,8S7 |
1 | ||
| 52164-28020D0 |
ACR50,GSR50 DK. RED M.M.,3Q3 |
1 | ||
| 52164-28020A1 |
ACR50,GSR50 WHITE PEARL CS.,070 |
1 | ||
| 52164-28020F0 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) SILKY GOLD M.M.,5A4 |
1 | ||
| 52164-28020D1 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) DEEP RED M.M.,3R9 |
1 | ||
| 52164-28020B0 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) SILVER ME.,1F7 |
1 | ||
| 52164-28020E0 |
ACR50,GSR50..DLX,GL DARK SHERRY M.M.,4W4 |
1 | ||
| 52164-28020C0 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) BLACK,202 |
1 | ||
| 52164-28020B3 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) ICE TITANIUM M.M.,1H4 |
1 | ||
| 52164-28020A0 |
GSR50..RHD;GSR50..GCC;ACR50..4FC..(GCC,GEN);ACR50..RHD..CVT..(DLX,GL) SUPER WHITE 2,040 |
1 | ||
| 52164-28020A1 |
GSR50;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) WHITE PEARL CS.,070 |
1 | ||
| 52615 - ABSORBER, REAR BUMPER ENERGY | ||||
| 52615-28040 |
GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) |
1 | ||
| 52616 - ABSORBER, REAR BUMPER ENERGY, LH | ||||
| 52616-28010 |
GSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..CVT..(DLX,GL);ACR50..4FC..(GCC,GEN) |
1 | ||
| Common parts | ||||
| 90109-06231 | ||||
| 90159-60217 | ||||
| 90159-60431 | ||||
| 90189-06228 | ||||
| Linked diagrams | ||||
| 6151 | ||||
| 8115 | ||||
| 8116 | ||||
| 8417 | ||||
