ACR50L-GFPGK (2016)

Toyota Previa/Tarago

Production May 2016 - Oct 2019
Engine 2AZFE
Transmission 4FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 1 OF 2(1605- )2AZFE

Click highlighted areas on diagram

diagram 04111 04112
Part # Description Qty Price
04111 - GASKET KIT, ENGINE OVERHAUL
04111-28760

2AZFE..ACR50

*195

 1
04111-28766

2AZFE..ACR50..DLX,GL

 1
04112 - GASKET KIT, ENGINE VALVE GRIND
04112-28630

2AZFE..ACR50

*195

 1
04112-28636

2AZFE..ACR50..DLX,GL

 1

ILLUST NO. 2 OF 2(1605- )2AZFE

Click highlighted areas on diagram

diagram 04111 04112 1104 1104 1104 1104 1105 1105 1105 1105 1105 1106 1302 1302 1302 1501 1603 1603 1701 1701 1702 2211 2211 2211 2211 3414
Part # Description Qty Price
04111 - GASKET KIT, ENGINE OVERHAUL
04111-28760

2AZFE..ACR50

*195

 1
04111-28766

2AZFE..ACR50..DLX,GL

 1
04112 - GASKET KIT, ENGINE VALVE GRIND
04112-28630

2AZFE..ACR50

*195

 1
04112-28636

2AZFE..ACR50..DLX,GL

 1
Linked diagrams
1104
1105
1106
1302
1501
1603
1701
1702
2211
3414
