ACM20R-ARSEK (2001)
Toyota Picnic/Avensis Verso
(0105- )RHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53410 - HINGE ASSY, HOOD, RH | ||||
| 53410-44050 |
ACM20,CLM20 PAD T=1.0 |
1 | ||
| 53410-44060 |
ACM2#,CLM20 PAD T=2.0 |
1 | ||
| 53410-44060 |
ACM20,CLM20 PAD T=2.0 |
1 | ||
| 53410-44050 |
ACM2#,CLM20 PAD T=1.0 |
1 | ||
| 53420 - HINGE ASSY, HOOD, LH | ||||
| 53420-44050 |
ACM20,CLM20 PAD T=1.0 |
1 | ||
| 53420-44060 |
ACM2#,CLM20 PAD T=2.0 |
1 | ||
| 53420-44060 |
ACM20,CLM20 PAD T=2.0 |
1 | ||
| 53420-44050 |
ACM2#,CLM20 PAD T=1.0 |
1 | ||
| 53451 - ROD, HOOD SUPPORT | ||||
| 53440-44020 |
ACM2#,CLM20 |
1 | ||
| 53440-44010 |
ACM20..ARL,GEN |
1 | ||
| 53451A - GROMMET(FOR HOOD SUPPORT ROD) | ||||
| 90480-15034 |
ACM20,CLM20 |
1 | ||
| 90480-15034 |
ACM2#,CLM20 |
1 | ||
| 53455 - CLAMP, HOOD SUPPORT ROD | ||||
| 53455-28020 |
ACM2#,CLM20 |
1 | ||
| 53455-28020 |
ACM20,CLM20 |
1 | ||
| 53497 - PAD, HOOD HINGE, NO.1 | ||||
| 53497-20070 |
ACM20,CLM20 T=2.0 |
4 | ||
| 53497-12050 |
ACM20,CLM20 T=1.0 |
4 | ||
| 53497-20070 |
ACM2#,CLM20 T=2.0 |
4 | ||
| 53497-42010 |
ACM2#,CLM20 T=0.5 |
4 | ||
| 53497 - PAD, HOOD HINGE, NO.1 | ||||
| 53497-20070 |
ACM20,CLM20 T=2.0 |
4 | ||
| 53497-12050 |
ACM20,CLM20 T=1.0 |
4 | ||
| 53497-20070 |
ACM2#,CLM20 T=2.0 |
4 | ||
| 53497-42010 |
ACM2#,CLM20 T=0.5 |
4 | ||
| 53497 - PAD, HOOD HINGE, NO.1 | ||||
| 53497-20070 |
ACM20,CLM20 T=2.0 |
4 | ||
| 53497-12050 |
ACM20,CLM20 T=1.0 |
4 | ||
| 53497-20070 |
ACM2#,CLM20 T=2.0 |
4 | ||
| 53497-42010 |
ACM2#,CLM20 T=0.5 |
4 | ||
| 53497 - PAD, HOOD HINGE, NO.1 | ||||
| 53497-20070 |
ACM20,CLM20 T=2.0 |
4 | ||
| 53497-12050 |
ACM20,CLM20 T=1.0 |
4 | ||
| 53497-20070 |
ACM2#,CLM20 T=2.0 |
4 | ||
| 53497-42010 |
ACM2#,CLM20 T=0.5 |
4 | ||
| 53510 - LOCK ASSY, HOOD | ||||
| 53510-44051 |
ACM20..GEN |
1 | ||
| 53510-44050 |
ACM20..GEN |
1 | ||
| 53510-44110 |
ACM20..GEN |
1 | ||
| 53510 - LOCK ASSY, HOOD | ||||
| 53510-44051 |
ACM20..GEN |
1 | ||
| 53510-44050 |
ACM20..GEN |
1 | ||
| 53510-44110 |
ACM20..GEN |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-16077 |
ACM20,CLM20 WD=1.6,CW=12 |
1 | ||
| 90506-09052 |
ACM20,CLM20..RHD WD=0.9,CW=20.75 |
1 | ||
| 90506-12063 |
ACM20,CLM20 WD=1.2,CW=8.5 |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-16077 |
ACM20,CLM20 WD=1.6,CW=12 |
1 | ||
| 90506-09052 |
ACM20,CLM20..RHD WD=0.9,CW=20.75 |
1 | ||
| 90506-12063 |
ACM20,CLM20 WD=1.2,CW=8.5 |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-16077 |
ACM20,CLM20 WD=1.6,CW=12 |
1 | ||
| 90506-09052 |
ACM20,CLM20..RHD WD=0.9,CW=20.75 |
1 | ||
| 90506-12063 |
ACM20,CLM20 WD=1.2,CW=8.5 |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-16077 |
ACM20,CLM20 WD=1.6,CW=12 |
1 | ||
| 90506-09052 |
ACM20,CLM20..RHD WD=0.9,CW=20.75 |
1 | ||
| 90506-12063 |
ACM20,CLM20 WD=1.2,CW=8.5 |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-16077 |
ACM20,CLM20 WD=1.6,CW=12 |
1 | ||
| 90506-09052 |
ACM20,CLM20..RHD WD=0.9,CW=20.75 |
1 | ||
| 90506-12063 |
ACM20,CLM20 WD=1.2,CW=8.5 |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-16077 |
ACM20,CLM20 WD=1.6,CW=12 |
1 | ||
| 90506-09052 |
ACM20,CLM20..RHD WD=0.9,CW=20.75 |
1 | ||
| 90506-12063 |
ACM20,CLM20 WD=1.2,CW=8.5 |
1 | ||
| 53601 - LEVER SUB-ASSY, HOOD LOCK CONTROL | ||||
| 53601-52010C0 |
ACM20..GEN BLACK,TRIM0# |
1 | ||
| 53601-52010C0 |
ACM20..ARL,GEN BLACK,TRIM0# |
1 | ||
| 53630 - CABLE ASSY, HOOD LOCK CONTROL | ||||
| 53630-44060 |
ACM20,CLM20..RHD |
1 | ||
| 53630-44090 |
ACM2#,CLM20..RHD |
1 | ||
| Common parts | ||||
| 90119-06423 | ||||
| 90959-01460 | ||||
| 91651-A0820 | ||||
