ACM20R-ARSEK (2001)
Toyota Picnic/Avensis Verso
(0105- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52152B - EXTENSION, REAR BUMPER, RH | ||||
| 52152-44050 |
ACM20,CLM20 |
1 | ||
| 52152-44080 |
ACM2#,CLM20 |
1 | ||
| 52153B - EXTENSION, REAR BUMPER, LH | ||||
| 52153-44050 |
ACM20,CLM20 |
1 | ||
| 52153-44080 |
ACM2#,CLM20 |
1 | ||
| 52155A - SUPPORT, REAR BUMPER SIDE, RH | ||||
| 52155-44050 |
ACM2#,CLM20 |
1 | ||
| 52155-44050 |
ACM20,CLM20 |
1 | ||
| 52155-44051 |
ACM2# |
1 | ||
| 52156A - SUPPORT, REAR BUMPER SIDE, LH | ||||
| 52156-44020 |
ACM20,CLM20 |
1 | ||
| 52156-44021 |
ACM2# |
1 | ||
| 52156-44020 |
ACM2#,CLM20 |
1 | ||
| 52157A - SUPPORT, REAR BUMPER SIDE, NO.2 RH | ||||
| 52157-44010 |
ACM20,CLM20 |
1 | ||
| 52157-44010 |
ACM2#,CLM20 |
1 | ||
| 52157-28020 |
ACM2# |
1 | ||
| 52158C - SUPPORT, REAR BUMPER SIDE, NO.2 LH | ||||
| 52158-44010 |
ACM2#,CLM20 |
1 | ||
| 52158-28010 |
ACM2# |
1 | ||
| 52158-44010 |
ACM20,CLM20 |
1 | ||
| 52159 - COVER, REAR BUMPER | ||||
| 52159-44906 |
ACM2#,CLM20 |
1 | ||
| 52159-44903 |
ACM20,CLM20 |
1 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-16010 |
ACM20,CLM20 |
4 | ||
| 52161-16010 |
ACM2#,CLM20 |
4 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-16010 |
ACM20,CLM20 |
4 | ||
| 52161-16010 |
ACM2#,CLM20 |
4 | ||
| 52163A - PLATE, REAR BUMPER, RH | ||||
| 52163-44010B1 |
ACM20,CLM20 DARK GRAY M.M.,1E2 |
1 | ||
| 52163-44010D0 |
ACM20,CLM20 RED MC.,3M8 |
1 | ||
| 52163-44010A0 |
ACM20,CLM20 SUPER WHITE 2,040 |
1 | ||
| 52163-44010F0 |
ACM20,CLM20 CHAMPAGNE M.M.,587 |
1 | ||
| 52163-44010G0 |
ACM20,CLM20 DARK GREEN MC.,6R4 |
1 | ||
| 52163-44010H0 |
ACM20,CLM20 AQUA ME.,771 |
1 | ||
| 52163-44010B0 |
ACM20,CLM20 SILVER ME.,1C0 |
1 | ||
| 52163-44010J0 |
ACM20,CLM20 DK.BLUE M.M.,8P4 |
1 | ||
| 52163-44020C0 |
ACM2#,CLM20 BLACK,202 |
1 | ||
| 52163-44020A0 |
ACM2#,CLM20 SUPER WHITE 2,040 |
1 | ||
| 52163-44020F0 |
ACM2#,CLM20 YELLOW M.M.,580 |
1 | ||
| 52163-44020B0 |
ACM2#,CLM20 SILVER ME.,1D4 |
1 | ||
| 52163-44020G0 |
ACM2#,CLM20 DARK GREEN MC.,6R4 |
1 | ||
| 52163-44020J0 |
ACM2#,CLM20 LT.PURPLISH BLUE M.M.,8K2 |
1 | ||
| 52163-44020D0 |
ACM2#,CLM20 DK. RED M.M.,3Q3 |
1 | ||
| 52163-44020J1 |
ACM2#,CLM20 BLUE MC.,8M6 |
1 | ||
| 52164A - PLATE, REAR BUMPER, LH | ||||
| 52164-44010A0 |
ACM20,CLM20 SUPER WHITE 2,040 |
1 | ||
| 52164-44010G0 |
ACM20,CLM20 DARK GREEN MC.,6R4 |
1 | ||
| 52164-44010B1 |
ACM20,CLM20 DARK GRAY M.M.,1E2 |
1 | ||
| 52164-44020D0 |
ACM2#,CLM20 DK. RED M.M.,3Q3 |
1 | ||
| 52164-44010F0 |
ACM20,CLM20 CHAMPAGNE M.M.,587 |
1 | ||
| 52164-44010H0 |
ACM20,CLM20 AQUA ME.,771 |
1 | ||
| 52164-44010J0 |
ACM20,CLM20 DK.BLUE M.M.,8P4 |
1 | ||
| 52164-44010B0 |
ACM20,CLM20 SILVER ME.,1C0 |
1 | ||
| 52164-44020G0 |
ACM2#,CLM20 DARK GREEN MC.,6R4 |
1 | ||
| 52164-44020A0 |
ACM2#,CLM20 SUPER WHITE 2,040 |
1 | ||
| 52164-44020B0 |
ACM2#,CLM20 SILVER ME.,1D4 |
1 | ||
| 52164-44020F0 |
ACM2#,CLM20 YELLOW M.M.,580 |
1 | ||
| 52164-44010D0 |
ACM20,CLM20 RED MC.,3M8 |
1 | ||
| 52164-44020C0 |
ACM2#,CLM20 BLACK,202 |
1 | ||
| 52164-44020J1 |
ACM2#,CLM20 BLUE MC.,8M6 |
1 | ||
| 52164-44020J0 |
ACM2#,CLM20 LT.PURPLISH BLUE M.M.,8K2 |
1 | ||
| 52461 - PAD, REAR BUMPER, CENTER | ||||
| 52461-44010 |
ACM2#,CLM20 |
1 | ||
| 52461-44010 |
ACM20,CLM20 |
1 | ||
| 52591A - SEAL, REAR BUMPER | ||||
| 52591-44010 |
ACM20,CLM20 |
2 | ||
| 52591-44010 |
ACM2#,CLM20 |
2 | ||
| 52791 - BOLT, BUMPER MOULDING SET, NO.1 | ||||
| 52791-44030 |
ACM2#,CLM20 |
2 | ||
| 52791-44030 |
ACM20,CLM20 |
4 | ||
| 52791-28010 |
ACM2#,CLM20 |
2 | ||
| Common parts | ||||
| 90159-50267 | ||||
| 90159-50311 | ||||
| 90159-60266 | ||||
| 90179-06274 | ||||
| 90189-05096 | ||||
| 90189-06065 | ||||
| 90189-06138 | ||||
| 90189-06222 | ||||
| 90210-05006 | ||||
| 90467-09166 | ||||
| Linked diagrams | ||||
| 8115 | ||||
