KM36RV-JRSQ (1988)

Toyota Liteace

Production Aug 1988 - Jan 1992
Engine 5KC
Transmission 4H MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8808- )

Click highlighted areas on diagram

diagram 51021A 51296A 53071 53073 53074 53075 53701 53702 53707B 53708B 53733B 53734B 57045 57046 57101 57102 57105A 57106A 57115A 57116A 57119A 57129A 57155 57156 57451 58101 58102A 58103A 58191 58191 58213A 58214A 58936A 58939A 6779595701 9010506104 9010512017 9017912020 9033320001 9095001001 9095001006 9095001006 9095001047 9095001047 9095001112 9095001127 9095001133 9095001147 9095001398 9095001486 9095001784 9326056016 9338516014 9338616014 9338616014 9461110601
Part # Description Qty Price
51021A - MEMBER SUB-ASSY, ENGINE FRONT SUPPORT
51021-95706

KM36..RHD

 1
51296A - BOLT, ENGINE FRONT SUPPORT MEMBER
51296-95701

CM36,KM3#,YM3#

 4
53071 - SHUTTER SUB-ASSY, HOT AIR, UPPER
53735-95700

CM36,KM37,YM3#;KM36..06S..ARL;KM36..SRF..(4H,5F)

 1
53073 - SHUTTER SUB-ASSY, HOT AIR SIDE, RH
53727-95707

CM36,KM36,YM30,35..ARL

TYPE A

 1
53727-95707

KM37;KM36..06S..ARL;KM36..SRF..(4H,5F)

 1
53074 - SHUTTER SUB-ASSY, HOT AIR SIDE, LH
53728-95704

CM36..5H;CM36..SRF;KM37,YM30,35;KM36..SRF..(4H,5F);CM36,KM36..MRF..ARL

 1
53075 - SHUTTER SUB-ASSY, HOT AIR, LOWER
53737-95701

CM36,KM37,YM3#;KM36..06S..ARL;KM36..SRF..(4H,5F)

 1
53701 - APRON SUB-ASSY, FRONT FENDER, RH
53701-95721

KM37;KM36..06S..ARL;KM36..SRF..(4H,5F)

ROUGH ROAD PACKAGE

 1
53701-95713

KM37;KM36..SRF;KM36..06S..ARL

 1
53701-95721

KM36,37..4H

ROUGH ROAD PACKAGE

 1
53702 - APRON SUB-ASSY, FRONT FENDER, LH
53702-95722

KM37;KM36..06S..ARL;KM36..SRF..(4H,5F)

ROUGH ROAD PACKAGE

 1
53702-95722

KM36,37..4H

ROUGH ROAD PACKAGE

 1
53702-95713

KM37;KM36..SRF;KM36..06S..ARL

 1
53707B - APRON SUB-ASSY, FENDER SIDE, RH
53707-95701

CM36,KM3#,YM3#

 1
53708B - APRON SUB-ASSY, FENDER SIDE, LH
53708-95704

CM36,YM3#;KM36..ARL

 1
53733B - SHUTTER, HOT AIR SIDE, A RH
53733-95701

CM36,KM37,YM3#;KM36..06S..ARL;KM36..SRF..(4H,5F)

 1
53734B - SHUTTER, HOT AIR SIDE, A LH
53733-95701

CM36,KM37,YM3#;KM36..06S..ARL;KM36..SRF..(4H,5F)

 1
57045 - PLATE SUB-ASSY, FLOOR SIDE RAIL, RH
57045-95705

CM36,KM36,YM3#..RHD..V4D

 1
57046 - PLATE SUB-ASSY, FLOOR SIDE RAIL, LH
57046-95716

CM36,KM36,YM3#..RHD

 1
57101 - MEMBER SUB-ASSY, FRONT SIDE, RH
57101-95722

CM36,KM36,YM3#..RHD..V4D

 1
57101-95731

CM36,KM36,YM30,35..ARL

 1
57102 - MEMBER SUB-ASSY, FRONT SIDE, LH
57102-95716

YM35..GEN;CM36,KM36,YM30..RHD

 1
57102-95725

CM36,KM36,YM30..ARL

 1
57105A - PLATE SUB-ASSY, FRONT SIDE MEMBER, RH
57105-95704

CM36,KM3#,YM3#

 1
57106A - PLATE SUB-ASSY, FRONT SIDE MEMBER, LH
57148-95702

CM36,KM3#,YM3#

 1
57115A - PLATE, FRONT SIDE MEMBER, OUTER RH
57115-95703

CM36,KM3#,YM3#

 1
57116A - PLATE, FRONT SIDE MEMBER, OUTER LH
57116-95703

CM36,KM3#,YM3#

 1
57119A - PLATE, FRONT SIDE MEMBER, FRONT RH
57119-95702

CM36,KM3#,YM3#

 1
57129A - PLATE, FRONT SIDE MEMBER, FRONT LH
57129-95702

CM36,KM3#,YM3#

 1
57155 - REINFORCEMENT, FRONT SIDE MEMBER, NO.3, RH
57155-95701

CM36,KM3#,YM3#

 1
57156 - REINFORCEMENT, FRONT SIDE MEMBER, NO.3, LH
57044-95702

CM36,KM3#,YM3#

 1
57451 - MEMBER, FRONT FLOOR CROSS
57408-95705

CM36,KM3#,YM3#

 1
58101 - PAN SUB-ASSY, FRONT FLOOR
58101-95746

KM36..RHD..4H

 1
58102A - REINFORCEMENT SUB-ASSY, FRONT FLOOR
58102-95700

CM36,KM3#,YM3#

 1
58103A - REINFORCEMENT SUB-ASSY, FRONT FLOOR SIDE, LH
58103-95704

CM36,KM3#,YM3#

 1
58213A - PANEL, SEAT FLOOR, RH
58201-95718

CM36,KM3#,YM3#

 1
58214A - PANEL, SEAT FLOOR, LH
58214-95708

CM36,KM36,YM3#..RHD

 1
58936A - BAND, ENGINE SERVICE HOLE COVER SUPPORT
58402-9571403

KM30,37,YM3#;CM36,KM36..MRF;CM36,KM36..LHD..SRF

GRAY,TRIM1#

 1
58939A - SCREW, ENGINE SERVICE HOLE COVER SUPPORT BAND
58939-95J00

CM36,KM3#,YM3#

 1
Common parts
67795-95701
90105-06104
90105-12017
90179-12020
90333-20001
90950-01001
90950-01006
90950-01047
90950-01112
90950-01127
90950-01133
90950-01147
90950-01398
90950-01486
90950-01784
93260-56016
93385-16014
93386-16014
94611-10601

(8808- )

Click highlighted areas on diagram

diagram 53885C 53886C 58407A 58410 58411 58420B 58424D 58426B 58441E 58444C 58444C 58445A 58450A 58460 58471C 58474A 58474A 58475C 5855 59260 59277 71901A 9011908623 9011908623 9012206008 9020505004 9046707069 9046707069 9054109126 9165140616 9166660820 9324016016 9338516014
Part # Description Qty Price
53885C - SEAL, FENDER APRON MUDGUARD, RH
53885-95704

CM36,KM3#,YM3#

 1
53886C - SEAL, FENDER APRON MUDGUARD, LH
53885-95704

CM36,KM3#,YM3#

 1
58407A - COVER SUB-ASSY, ENGINE SERVICE HOLE SUB
58407-95704

KM36..ARL

 1
58410 - COVER, ENGINE SERVICE HOLE
59208-95704

KM36..ARL

 1
58411 - PAD, ENGINE COVER, LH
58411-95A00

KM36,37..4H

 1
58420B - SILENCER, ENGINE SERVICE HOLE COVER, NO.2
58472-95710

KM36,37..4H

 1
58424D - PACKING, ENGINE COVER
58424-95702

KM36..RHD..4H

 1
58441E - COVER, BATTERY SERVICE HOLE
58441-95713

CM36,KM3#,YM3#

 1
58444C - PACKING, ENGINE SUB COVER, NO.1
58444-95702

KM36..RHD..4H

 1
58444C - PACKING, ENGINE SUB COVER, NO.1
58444-95702

KM36..RHD..4H

 1
58445A - CUSHION, ENGINE SERVICE HOLE COVER
58445-95400

CM36,KM3#,YM3#

 1
58450A - PACKING, BATTERY SERVICE HOLE COVER
58449-95701

CM36,KM3#,YM3#

 1
58471C - SILENCER, ENGINE MAIN COVER
58471-95714

KM36..RHD..4H

 1
58474A - PACKING, ENGINE SUB COVER, NO.2
58474-95705

KM36..RHD..4H

 1
58474A - PACKING, ENGINE SUB COVER, NO.2
58474-95705

KM36..RHD..4H

 1
58475C - PACKING, ENGIN SUB COVER, NO.3
58475-95705

CM36,KM3#,YM3#

 1
59260 - LOCK ASSY, ENGINE COVER
59260-95400

CM36,KM36,YM30,35..ARL

 1
59277 - PROTECTOR, ENGINE MAIN COVER
59277-95702

CM36..RHD..GEN;KM36,37,YM35..03S,05S,06S,09S

 1
59277-95700

KM3#;CM36,YM3#..RHD

 1
59277-95702

KM36,37..4H

 1
59277-95702

KM36..4H;KM37,YM31;KM36..MRF..GEN

 1
71901A - CATCH SUB-ASSY, CENTER SEAT CUSHION, FRONT
71902-95J02

KM36,37..4H

RH

 1
71902-95705

CM36,KM36,YM3#..RHD

LH

 1
Common parts
90119-08623
90122-06008
90205-05004
90467-07069
90541-09126
91651-40616
91666-60820
93240-16016
93385-16014
Linked diagrams
5855
