KM36RV-JRSQ (1988)
Toyota Liteace
(8808- )5K..4H,5F
12V 30A
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-13060 |
5KC..KM36 12V 40A |
1 | ||
| 27020-13060 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF 12V 40A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-18011 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27039-18011 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27039-18011 |
5KC..KM36 |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 27212-39050 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27212-39050 |
5KC..KM36 |
1 | ||
| 27212-39050 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-15060 |
5K..KM3#..4H,5F |
1 | ||
| 27310-13050 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27310-13050 |
5KC..KM36 |
1 | ||
| 27310-13050 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10125 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 90099-10125 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-26050 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27330-26050 |
5KC..KM36 |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10116 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 90099-10116 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27350B - CONDENSER, ALTERNATOR | ||||
| 90099-52065 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 90099-52065 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-38051 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27351-38051 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-13050 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27359-13050 |
5KC..KM36 |
1 | ||
| 27359-13050 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
5K#..KM3# |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
5K#..KM3# |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-38120 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27410-38120 |
5KC..KM36 |
1 | ||
| 27410-38120 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27411-31042 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27412A - COLLAR, SPACE(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27412-31040 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27441-34030 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27700A - REGULATOR ASSY, GENERATOR | ||||
| 27700-13080 |
5K#..KM3# |
1 | ||
| 27751A - BRACKET, GENERATOR REGULATOR | ||||
| 27751-13010 |
5K#..KM3# |
1 | ||
| Common parts | ||||
| 27378-31050 | ||||
| 27387-12030 | ||||
| 27447-24061 | ||||
| 90099-00862 | ||||
| 90099-01423 | ||||
| 90099-04808 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90099-34013 | ||||
| 90101-08164 | ||||
| 90119-08023 | ||||
| 90179-06158 | ||||
| 90179-08068 | ||||
| 90179-08082 | ||||
| 91651-40612 | ||||
| 94511-01400 | ||||
| 94612-10800 | ||||
(8808- )5K#
12V 40A,45A,50A
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-13060 |
5KC..KM36 12V 40A |
1 | ||
| 27020-13060 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF 12V 40A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-18011 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27039-18011 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27039-18011 |
5KC..KM36 |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 27212-39050 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27212-39050 |
5KC..KM36 |
1 | ||
| 27212-39050 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-15060 |
5K..KM3#..4H,5F |
1 | ||
| 27310-13050 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27310-13050 |
5KC..KM36 |
1 | ||
| 27310-13050 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10125 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 90099-10125 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-26050 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27330-26050 |
5KC..KM36 |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10116 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 90099-10116 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27330B - RING, SNAP(FOR ALTERNATOR ROTOR) | ||||
| 90099-07048 |
5K#..KM36,37 |
1 | ||
| 27350B - CONDENSER, ALTERNATOR | ||||
| 90099-52065 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 90099-52065 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-38051 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27351-38051 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-13050 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27359-13050 |
5KC..KM36 |
1 | ||
| 27359-13050 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27362 - RECTIFIER ASSY, W/BRUSH | ||||
| 27362-18011 |
5K#..KM36,37 |
1 | ||
| 27362-18011 |
5K#..KM36,37..4H |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
5K#..KM3# |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
5K#..KM3# |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-38120 |
5KC..KM36;5K..KM36..4F;5K..KM36..MRF |
1 | ||
| 27410-38120 |
5KC..KM36 |
1 | ||
| 27410-38120 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27411-31042 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
5K#..KM3# NO.2 |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
5K#..KM3# NO.2 |
1 | ||
| 27412A - COLLAR, SPACE(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27412-31040 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
5KC..KM36;5K..KM36..4F;5K..KM30,36..MRF |
1 | ||
| 27441-34030 |
5K..KM36,37..4H 12V 45A |
1 | ||
| 27700A - REGULATOR ASSY, GENERATOR | ||||
| 27700-13080 |
5K#..KM3# |
1 | ||
| 27751A - BRACKET, GENERATOR REGULATOR | ||||
| 27751-13010 |
5K#..KM3# |
1 | ||
| Common parts | ||||
| 27378-15030 | ||||
| 27378-45090 | ||||
| 27381-45022 | ||||
| 27387-45110 | ||||
| 27447-24061 | ||||
| 90099-00912 | ||||
| 90099-04300 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90101-10049 | ||||
| 90119-08023 | ||||
| 90179-06158 | ||||
| 90179-08082 | ||||
| 90179-10016 | ||||
| 91611-60832 | ||||
| 91651-40612 | ||||
| 94511-01400 | ||||
| 94612-11001 | ||||
