KM20RV-JRBFE (1979)

Toyota Liteace

Production Oct 1979 - Aug 1985
Engine 4K
Transmission 4H MTM
Displacement 2500cc
Power 168 HP (125 kW)

(7910- )

Click highlighted areas on diagram

diagram 11278 11291 11291 11293 11296 11297 11298 17700C 17700C 17700D 17739 17792 23923
Part # Description Qty Price
11278 - PLATE, ENGINE EMISSION IDENTIFICATION
11278-16020

4K..KM20..RHD..03S

SINGAPORE SPEC

 1
11291 - PLATE, ENGINE NAME
11291-13050

4K..KM20..V4D..02S..EUR;4K..KM20..(03S,05S,06S,08S,09S)..(EUR,GEN)

 1
11291-13050

4K..KM20

 1
11291 - PLATE, ENGINE NAME
11291-13050

4K..KM20..V4D..02S..EUR;4K..KM20..(03S,05S,06S,08S,09S)..(EUR,GEN)

 1
11291-13050

4K..KM20

 1
11297 - PLATE, ENGINE CAUTION, NO.3
11297-13020

4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S

 1
11297-13010

4K..KM20..RHD;4K..KM20..LHD..VSP..EUR;4K..KM20..LHD..(03S,05S,06S,07S)

 1
17700D - PLATE, ENGINE CAUTION
11293-13050

4K..KM20..RHD;4K..KM20..LHD..VSP..EUR;4K..KM20..LHD..(03S,05S,06S,07S)

 1
11293-13051

4K..KM20..RHD;4K..KM20..LHD..VSP..EUR;4K..KM20..LHD..(03S,05S,06S,07S,09S)

 1
11293-13052

4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S

 1
11293-13052

4K..KM20..ARL,GEN

 1
