KM20LV-JRBE (1979)
Toyota Liteace
(7910-8210) ; (8210- )4K..ARL,GEN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16100 - PUMP ASSY, ENGINE WATER | ||||
| 16100-19055 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16100K - PUMP KIT, WATER | ||||
| 04161-13011 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 04161-13020 |
4K..KM20..(HRF,SRF)..GEN W/COOLER |
1 | ||
| 16100L - ROTOR KIT, WATER PUMP | ||||
| 04162-13011 |
4K..KM20..(HRF,SRF)..GEN W/COOLER |
1 | ||
| 04162-13012 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16104 - SEAL SET, WATER PUMP | ||||
| 16104-41111 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16117 - PLATE, WATER PUMP | ||||
| 16117-13010 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16119 - GASKET, WATER PUMP BODY | ||||
| 16124-22010 |
4K..KM20..RHD;4K..KM20..LHD..VSP..EUR;4K..KM20..LHD..(03S,05S,06S,07S,09S) |
1 | ||
| 16131 - ROTOR, WATER PUMP | ||||
| 16131-13010 |
4K..KM20 |
1 | ||
| 16131A - BEARING, WATER PUMP | ||||
| 90369-30063 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S WPB16105BRS |
1 | ||
| 16171 - SEAT, WATER PUMP PULLEY | ||||
| 16171-24031 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16271 - GASKET, WATER PUMP | ||||
| 16271-13020 |
4K..KM20..RHD;4K..KM20..LHD..VSP..EUR;4K..KM20..LHD..(03S,05S,06S,07S,09S) |
1 | ||
| 16371 - PULLEY, FAN | ||||
| 16371-24050 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16371-13020 |
4K..KM20..(HRF,SRF)..GEN W/COOLER |
1 | ||
| Common parts | ||||
| 91611-60835 | ||||
| 91611-60850 | ||||
| 93220-16014 | ||||
(8012- )4K..HRF,SRF..GEN ; (8210- )4K..EUR; (8212- )4K..LHD..GEN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16100 - PUMP ASSY, ENGINE WATER | ||||
| 16100-19055 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16100K - PUMP KIT, WATER | ||||
| 04161-13011 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 04161-13020 |
4K..KM20..(HRF,SRF)..GEN W/COOLER |
1 | ||
| 16100L - ROTOR KIT, WATER PUMP | ||||
| 04162-13011 |
4K..KM20..(HRF,SRF)..GEN W/COOLER |
1 | ||
| 04162-13012 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16104 - SEAL SET, WATER PUMP | ||||
| 16104-41111 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16117 - PLATE, WATER PUMP | ||||
| 16117-13010 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16119 - GASKET, WATER PUMP BODY | ||||
| 16124-22010 |
4K..KM20..RHD;4K..KM20..LHD..VSP..EUR;4K..KM20..LHD..(03S,05S,06S,07S,09S) |
1 | ||
| 16131 - ROTOR, WATER PUMP | ||||
| 16131-13010 |
4K..KM20 |
1 | ||
| 16131A - BEARING, WATER PUMP | ||||
| 90369-30063 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S WPB16105BRS |
1 | ||
| 16171 - SEAT, WATER PUMP PULLEY | ||||
| 16171-24031 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16271 - GASKET, WATER PUMP | ||||
| 16271-13020 |
4K..KM20..RHD;4K..KM20..LHD..VSP..EUR;4K..KM20..LHD..(03S,05S,06S,07S,09S) |
1 | ||
| 16371 - PULLEY, FAN | ||||
| 16371-24050 |
4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S |
1 | ||
| 16371-13020 |
4K..KM20..(HRF,SRF)..GEN W/COOLER |
1 | ||
| Common parts | ||||
| 90179-06070 | ||||
| 91611-60835 | ||||
| 91611-60850 | ||||
| 93220-16014 | ||||
