KM10V- (1971)
Toyota Liteace
Production
May 1971
-
Nov 1975
Engine
3K
Transmission
Displacement
2500cc
Power
168 HP (125 kW)
(7105-7909)
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53905 - BRACKET SUB-ASSY, HEADLAMP, NO.1 | ||||
| 55073-95700 |
KM1# |
2 | ||
| 53905 - BRACKET SUB-ASSY, HEADLAMP, NO.1 | ||||
| 55073-95700 |
KM1# |
2 | ||
| 55324 - BRACKET, HEADLAMP DOOR | ||||
| 55321-95700 |
KM10 UPPER |
2 | ||
| 55322-95700 |
KM10 LOWER |
2 | ||
| 55324 - BRACKET, HEADLAMP DOOR | ||||
| 55321-95700 |
KM10 UPPER |
2 | ||
| 55322-95700 |
KM10 LOWER |
2 | ||
| 55711 - PANEL, COWL TOP, OUTER | ||||
| 55701-95700 |
KM10 |
1 | ||
| 55711A - PANEL, FRONT, LOWER | ||||
| 55702-95700 |
KM10 |
1 | ||
| 56111 - GLASS, WINDSHIELD | ||||
| 56111-95700 |
KM1#..TR,V ZN.TP.T=5.0 |
1 | ||
| 56121 - WEATHERSTRIP, WINDSHIELD | ||||
| 56121-95700 |
KM1#..TR,V |
1 | ||
| Common parts | ||||
| 90179-05095 | ||||
| 91651-40614 | ||||
| 91656-40616 | ||||
