AGZ15L-AWTLT (2014)

Toyota Lexus Nx Series

Production Dec 2014 - Sep 2017
Engine 8ARFTS
Transmission 6FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(1412- )AGZ1#,ZGZ1#

Click highlighted areas on diagram

LEG & BATTERY COVER

diagram 58464D 58466K 58467J 71647 71647 71848K 71848K 71848K 71848K 71880B 72525J 72526E 72693 72704F 72704F 79110 79110 79915 9010510539 9010510539 9010510539 9010510539 9010510539 9010510539 9046708226 9046708226 9046708226 9046710203 9046710203
Part # Description Qty Price
58464D - BOARD, BATTERY SERVICE COVER
58464-78010C0

AGZ1#

BLACK,TRIM0#,1#,2#,3#,4#,5#,9#

 1
58466K - BOARD, BATTERY SERVICE COVER, NO.2
58466-78010C0

AGZ1#

BLACK,TRIM0#,1#,2#,3#,4#,5#,9#

 1
58466-78020C0

AGZ1#..ARL,GCC,GEN

REAR SEAT-6:4 FOLDING(POWER SEAT),BLACK,TRIM0#,1#,2#,3#,4#,5#,9#

 1
58467J - BOARD, BATTERY SERVICE COVER, NO.3
58467-78010C0

AGZ1#

BLACK,TRIM0#,1#,2#,3#,4#,5#,9#

 1
58467-78020C0

AGZ1#..ARL,GCC,GEN

REAR SEAT-6:4 FOLDING(POWER SEAT),BLACK,TRIM0#,1#,2#,3#,4#,5#,9#

 1
71647 - PROTECTOR, REAR SEAT CUSHION EDGE
71647-48010

AGZ1#,AYZ1#,ZGZ1#

 1
71647 - PROTECTOR, REAR SEAT CUSHION EDGE
71647-48010

AGZ1#,AYZ1#,ZGZ1#

 1
71848K - CAP, SEAT ADJUSTER COVER
71848-48030

AGZ1#,AYZ1#,ZGZ1#

NO.1:REFER ILLUST.

 1
71848-48040

AGZ1#,AYZ1#,ZGZ1#

NO.2:REFER ILLUST.

 1
71848K - CAP, SEAT ADJUSTER COVER
71848-48030

AGZ1#,AYZ1#,ZGZ1#

NO.1:REFER ILLUST.

 1
71848-48040

AGZ1#,AYZ1#,ZGZ1#

NO.2:REFER ILLUST.

 1
71848K - CAP, SEAT ADJUSTER COVER
71848-48030

AGZ1#,AYZ1#,ZGZ1#

NO.1:REFER ILLUST.

 1
71848-48040

AGZ1#,AYZ1#,ZGZ1#

NO.2:REFER ILLUST.

 1
71848K - CAP, SEAT ADJUSTER COVER
71848-48030

AGZ1#,AYZ1#,ZGZ1#

NO.1:REFER ILLUST.

 1
71848-48040

AGZ1#,AYZ1#,ZGZ1#

NO.2:REFER ILLUST.

 1
71880B - CLIP(FOR REAR SEAT BACK CARPET)
90467-07049C0

AGZ1#,AYZ1#..ARL,GCC,GEN

BLACK,TRIM0#,1#,2#,3#,4#,5#,9#

 7
90467-0704923

AGZ1#,AYZ1#..ARL,GCC,GEN

BLACK,TRIM0#,1#,2#,3#,4#,5#,9#

 7
72525J - HANDLE, RECLINING ADJUSTER RELEASE, RH
72525-48020C0

AGZ1#,AYZ1#

BLACK,TRIM0#,1#,2#,3#,4#,5#,9#

 1
72526E - HANDLE, RECLINING ADJUSTER RELEASE, LH
72526-48050C0

AGZ1#,AYZ1#

BLACK,TRIM0#,1#,2#,3#,4#,5#,9#

 1
72693 - HOOK, REAR SEAT CUSHION LOCK
72693-12080

AGZ1#,AYZ1#,ZGZ1#

 2
72704F - CABLE, REAR SEAT RECLINING CONTROL, NO.3
72704-78010

AGZ1#,AYZ1#,ZGZ1#

 2
72704F - CABLE, REAR SEAT RECLINING CONTROL, NO.3
72704-78010

AGZ1#,AYZ1#,ZGZ1#

 2
79110 - LEG ASSY, NO.1 SEAT
79110-78010

AGZ1#,ZGZ1#

 1
79110-78020

AGZ1#..ARL,GCC,GEN

REAR SEAT-6:4 FOLDING(POWER SEAT)

 1
79110 - LEG ASSY, NO.1 SEAT
79110-78010

AGZ1#,ZGZ1#

 1
79110-78020

AGZ1#..ARL,GCC,GEN

REAR SEAT-6:4 FOLDING(POWER SEAT)

 1
79915 - BRACKET, SEAT LEG
79915-42010

AGZ1#,ZGZ1#

 1
Common parts
90105-10539
90467-08226
90467-10203
