UCF10L-AEPGKW (1989)
Toyota Lexus Ls400
(8912- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85341-5001012 |
UCF10..LHD GRAYISH ROSE MICA M,3H9 |
2 | ||
| 85341-5001003 |
UCF10..LHD BLUISH GRAY MICA M,172 |
2 | ||
| 85341-5001005 |
UCF10..LHD BEIGE METALLIC,4K9 |
2 | ||
| 85341-5001008 |
UCF10..LHD..EUR WHITE PEARL MICA,051 |
2 | ||
| 85341-5001002 |
UCF10..LHD DEEP RED MICA,3H8 |
2 | ||
| 85341-5001001 |
UCF10..LHD BLACK,202 |
2 | ||
| 85341-5001007 |
UCF10..LHD DARK GREEN M.I.O.,6K4 |
2 | ||
| 85341-5001006 |
UCF10..LHD DARK BROWN MICA,4K8 |
2 | ||
| 85341-5001013 |
UCF10 SUPER SILVER 3 M,176 |
2 | ||
| 85341-5001007 |
UCF10 DARK GREEN M.I.O.,6K4 |
2 | ||
| 85341-5001008 |
UCF10 WHITE PEARL MICA,051 |
2 | ||
| 85341-5001013 |
UCF10..LHD SUPER SILVER 3 M,176 |
2 | ||
| 85341-5001023 |
UCF10..LHD GRAY MICA METALLIC,180 |
2 | ||
| 85341-50010E0 |
UCF10..LHD LI.RE.BROWN ME,4K7 |
2 | ||
| 85381-50010J0 |
UCF10 DK.BLUE MCFP,8J5 |
2 | ||
| 85341-5001005 |
UCF10 BEIGE METALLIC,4K9 |
2 | ||
| 85341-5001023 |
UCF10 GRAY MICA METALLIC,180 |
2 | ||
| 85341-5001001 |
UCF10 BLACK,202 |
2 | ||
| 85341-50010J0 |
UCF10..LHD DK.BLUE MCFP,8J5 |
2 | ||
| 85341-5001008 |
UCF10..LHD WHITE PEARL MICA,051 |
2 | ||
| 85341-50010B0 |
UCF10..LHD SILVER ME.,199 |
2 | ||
| 85381-50010E0 |
UCF10 LI.RE.BROWN ME,4K7 |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85341-5001012 |
UCF10..LHD GRAYISH ROSE MICA M,3H9 |
2 | ||
| 85341-5001003 |
UCF10..LHD BLUISH GRAY MICA M,172 |
2 | ||
| 85341-5001005 |
UCF10..LHD BEIGE METALLIC,4K9 |
2 | ||
| 85341-5001008 |
UCF10..LHD..EUR WHITE PEARL MICA,051 |
2 | ||
| 85341-5001002 |
UCF10..LHD DEEP RED MICA,3H8 |
2 | ||
| 85341-5001001 |
UCF10..LHD BLACK,202 |
2 | ||
| 85341-5001007 |
UCF10..LHD DARK GREEN M.I.O.,6K4 |
2 | ||
| 85341-5001006 |
UCF10..LHD DARK BROWN MICA,4K8 |
2 | ||
| 85341-5001013 |
UCF10 SUPER SILVER 3 M,176 |
2 | ||
| 85341-5001007 |
UCF10 DARK GREEN M.I.O.,6K4 |
2 | ||
| 85341-5001008 |
UCF10 WHITE PEARL MICA,051 |
2 | ||
| 85341-5001013 |
UCF10..LHD SUPER SILVER 3 M,176 |
2 | ||
| 85341-5001023 |
UCF10..LHD GRAY MICA METALLIC,180 |
2 | ||
| 85341-50010E0 |
UCF10..LHD LI.RE.BROWN ME,4K7 |
2 | ||
| 85381-50010J0 |
UCF10 DK.BLUE MCFP,8J5 |
2 | ||
| 85341-5001005 |
UCF10 BEIGE METALLIC,4K9 |
2 | ||
| 85341-5001023 |
UCF10 GRAY MICA METALLIC,180 |
2 | ||
| 85341-5001001 |
UCF10 BLACK,202 |
2 | ||
| 85341-50010J0 |
UCF10..LHD DK.BLUE MCFP,8J5 |
2 | ||
| 85341-5001008 |
UCF10..LHD WHITE PEARL MICA,051 |
2 | ||
| 85341-50010B0 |
UCF10..LHD SILVER ME.,199 |
2 | ||
| 85381-50010E0 |
UCF10 LI.RE.BROWN ME,4K7 |
2 | ||
| 85310 - MOTOR AND PUMP ASSY, WINDSHIELD WASHER | ||||
| 85330-50020 |
UCF10 |
1 | ||
| 85310-20190 |
UCF10 |
1 | ||
| 85330A - BUSH, WINDSHIELD WASHER JAR | ||||
| 90099-32089 |
UCF10 |
1 | ||
| 85331 - JAR SUB-ASSY, WINDSHIELD WASHER | ||||
| 85315-50020 |
UCF10..EUR W(HEADLAMP CLEANER) |
1 | ||
| 85315-50040 |
UCF10..LHD..EUR;UCF10..ARL,GEN,V |
1 | ||
| 85315-50050 |
UCF10..EUR |
1 | ||
| 85315-50050 |
UCF10..ARL;UCF10..LHD..EUR W(HEADLAMP CLEANER) |
1 | ||
| 85315-50020 |
UCF10..ARL,EUR W(HEADLAMP CLEANER) |
1 | ||
| 85331-50010 |
UCF10 |
1 | ||
| 85332 - CAP, WINDSHIELD WASHER JAR | ||||
| 85332-50010 |
UCF10 |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85348-50030 |
UCF10 |
1 | ||
| 85348D - JOINT, WINDSHIELD WASHER ELBOW, NO.1 | ||||
| 85355-32110 |
UCF10 |
1 | ||
| 85348G - JOINT, WINDSHIELD WASHER HOSE, NO.2 | ||||
| 85334-22480 |
UCF10 |
1 | ||
| 85349 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85334-22480 |
UCF10 |
1 | ||
| 85349A - JOINT, WINDSHIELD WASHER HOSE, NO.2 | ||||
| 85349-50030 |
UCF10 |
1 | ||
| 85349B - JOINT, WINDSHIELD WASHER HOSE, NO.3 | ||||
| 85349-89122 |
UCF10 |
1 | ||
| 85371 - HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT) | ||||
| 90099-33075 |
UCF10 L=1100 |
1 | ||
| 90099-33888 |
UCF10 L=1450 |
1 | ||
| 90099-33873 |
UCF10 L=1440 |
1 | ||
| 90099-33334 |
UCF10 L=1160 |
1 | ||
| 85371 - HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT) | ||||
| 90099-33075 |
UCF10 L=1100 |
1 | ||
| 90099-33888 |
UCF10 L=1450 |
1 | ||
| 90099-33873 |
UCF10 L=1440 |
1 | ||
| 90099-33334 |
UCF10 L=1160 |
1 | ||
| 85371H - COVER, WASHER NOZZLE SERVICE HOLE | ||||
| 85371-50010 |
UCF10 |
2 | ||
| 85371H - COVER, WASHER NOZZLE SERVICE HOLE | ||||
| 85371-50010 |
UCF10 |
2 | ||
| 85372 - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.1 | ||||
| 90099-33813 |
UCF10 *H,L=720,NO.1 |
1 | ||
| 90099-33088 |
UCF10 *H,L=490,NO.2 |
1 | ||
| 90099-33080 |
UCF10 L=1450,NO.2 |
1 | ||
| 85372 - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.1 | ||||
| 90099-33813 |
UCF10 *H,L=720,NO.1 |
1 | ||
| 90099-33088 |
UCF10 *H,L=490,NO.2 |
1 | ||
| 90099-33080 |
UCF10 L=1450,NO.2 |
1 | ||
| 85373 - HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE) | ||||
| 90099-33080 |
UCF10 L=1450 |
2 | ||
| 85373 - HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE) | ||||
| 90099-33080 |
UCF10 L=1450 |
2 | ||
| 85374A - PROTECTOR, WASHER HOSE | ||||
| 85374-50010 |
UCF10 |
1 | ||
| Common parts | ||||
| 85365-50030 | ||||
| 85369-50030 | ||||
| 90099-04433 | ||||
| 90179-06026 | ||||
| 90989-01037 | ||||
| Linked diagrams | ||||
| 8401 | ||||
