GGH31L-LFZVB (2020)
Toyota Lexus Lm350/Lm300h
Production
Jan 2020
-
Sep 9999
Engine
2GRFKS
Transmission
8FC ATM
Displacement
2500cc
Power
168 HP (125 kW)
(2001- )
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 57443B - SUPPORT, SIDE STEP, REAR RH | ||||
| 51078-58010 |
AYH36,GGH31 |
1 | ||
| 57444A - SUPPORT, SIDE STEP, REAR LH | ||||
| 51079-58010 |
AYH36,GGH31 |
1 | ||
| 68029 - BASE SUB-ASSY, SLIDE DOOR LOWER ROLLER | ||||
| 68029-58030 |
AYH36,GGH31 |
1 | ||
| 68031 - ARM SUB-ASSY, SLIDE DOOR UPPER ROLLER, RH | ||||
| 68381-58030 |
AYH36,GGH31 |
1 | ||
| 68032 - ARM SUB-ASSY, SLIDE DOOR UPPER ROLLER, LH | ||||
| 68382-58030 |
AYH36,GGH31 |
1 | ||
| 68039 - BASE SUB-ASSY, SLIDE DOOR LOWER ROLLER, LH | ||||
| 68039-58030 |
AYH36,GGH31 |
1 | ||
| 68303B - RAIL SUB-ASSY, SLIDE DOOR, CENTER RH | ||||
| 68303-58040 |
AYH36,GGH31 |
1 | ||
| 68304B - RAIL SUB-ASSY, SLIDE DOOR, CENTER LH | ||||
| 68304-58040 |
AYH36,GGH31 |
1 | ||
| 68308 - RAIL SUB-ASSY, SLIDE DOOR, UPPER RH | ||||
| 68308-58030 |
AYH36,GGH31 |
1 | ||
| 68309 - RAIL SUB-ASSY, SLIDE DOOR, UPPER LH | ||||
| 68309-58030 |
AYH36,GGH31 |
1 | ||
| 68310B - ROLLER ASSY, SLIDE DOOR, UPPER RH | ||||
| 68301-58040 |
AYH36,GGH31 |
1 | ||
| 68320A - ROLLER ASSY, SLIDE DOOR, UPPER, LH | ||||
| 68302-58040 |
AYH36,GGH31 |
1 | ||
| 68325 - CUSHION, SLIDE DOOR UPPER RAIL, RH | ||||
| 68325-58030 |
AYH36,GGH31 |
1 | ||
| 68326A - CUSHION, SLIDE DOOR UPPER RAIL, LH | ||||
| 68326-58030 |
AYH36,GGH31 |
1 | ||
| 68335C - ARM, SLIDE DOOR LOWER ROLLER, RH | ||||
| 68335-58030 |
AYH36,GGH31 |
1 | ||
| 68336 - ARM, SLIDE DOOR LOWER ROLLER, LH | ||||
| 68336-58030 |
AYH36,GGH31 |
1 | ||
| 68355 - GARNISH, SLIDE DOOR CENTER RAIL, RH | ||||
| 60835-58030 |
AYH36,GGH31 |
1 | ||
| 68356 - GARNISH, SLIDE DOOR CENTER RAIL, LH | ||||
| 60836-58030 |
AYH36,GGH31 |
1 | ||
| 68380D - HINGE ASSY, SLIDE DOOR, CENTER RH | ||||
| 68380-58033 |
AYH36,GGH31 |
1 | ||
| 68390A - HINGE ASSY, SLIDE DOOR, CENTER LH | ||||
| 68390-58043 |
AYH36,GGH31 |
1 | ||
| 68391 - CUSHION, SLIDE DOOR UPPER ROLLER, RH | ||||
| 68391-28040 |
AYH36,GGH31 |
1 | ||
| 68391A - CUSHION, SLIDE DOOR UPPER ROLLER, LH | ||||
| 68391-28040 |
AYH36,GGH31 |
1 | ||
| 68394A - PLATE, SLIDE DOOR LOWER RAIL, RH | ||||
| 68394-58010 |
AYH36,GGH31 |
2 | ||
| 68395 - PACKING, SLIDE DOOR CENTER RAIL | ||||
| 68395-28120 |
AYH36,GGH31 |
1 | ||
| 68395A - PACKING, SLIDE DOOR CENTER RAIL | ||||
| 68395-52020 |
AYH36,GGH31 |
2 | ||
| 68395B - PACKING, SLIDE DOOR CENTER RAIL | ||||
| 68395-52050 |
AYH36,GGH31 |
3 | ||
| 69415 - STOPPER, SLIDE DOOR DOWN FEMALE | ||||
| 69415-58020 |
AYH36,GGH31 |
2 | ||
| 69416B - STOPPER, SLIDE DOOR DOWN MALE | ||||
| 69046-28020 |
AYH36,GGH31 |
2 | ||
| 69418 - STOP, SLIDE DOOR OPEN | ||||
| 69418-58011 |
AYH36,GGH31 |
1 | ||
| 69418-V2010 |
AYH36,GGH31 |
1 | ||
| 69419B - STOP, SLIDE DOOR OPEN, LH | ||||
| 69419-58011 |
AYH36,GGH31 |
1 | ||
| 69419-V2010 |
AYH36,GGH31 |
1 | ||
| 85005A - MOTOR UNIT, SLIDE DOOR, RH | ||||
| 85005-58054 |
AYH36,GGH31 |
1 | ||
| 85005-58053 |
AYH36,GGH31 |
1 | ||
| 85006 - MOTOR UNIT, SLIDE DOOR, LH | ||||
| 85006-58043 |
AYH36,GGH31 |
1 | ||
| 85006-58044 |
AYH36,GGH31 |
1 | ||
| 85630 - MOTOR ASSY, SLIDE DOOR | ||||
| 85470-V2010 |
AYH36,GGH31 RH |
1 | ||
| 85470-58010 |
AYH36,GGH31 RH |
1 | ||
| 85480-58010 |
AYH36,GGH31 LH |
1 | ||
| 85480-V2010 |
AYH36,GGH31 LH |
1 | ||
| Common parts | ||||
| 65487-28010 | ||||
| 75396-28090 | ||||
| 90105-08187 | ||||
| 90105-08362 | ||||
| 90119-06779 | ||||
| 90119-06911 | ||||
| 90119-08C59 | ||||
| 90148-80049 | ||||
| 90467-07215 | ||||
| 91551-80812 | ||||
| 91553-80610 | ||||
| 91671-80618 | ||||
| 91673-80620 | ||||
| 93269-15012 | ||||
| Linked diagrams | ||||
| 6755 | ||||
